LINCOLN CONTINENTAL 1996 Customer Assistance Guide

Lubricant Specifications
ItemFord Part No.Part NameFord SpecificationBrake Master CylinderC6AZ-19542-AAFord High Performance DOT 3
Brake FluidESA-M6C25-AHinges, Door Latch, Hood
Latch Auxiliary Latch,
Trunk and Liftgate LatchesDOAZ-19584-AAMulti-Purpose Grease SprayESB-MIC93-BLock CylindersE8AZ-19A501-BFord Penetrating LubricantN/ATransaxle, AutomaticXT-2-QDX
Motorcraft MERCONÒ Auto.
Trans. FluidMERCONÒConstant Velocity Joints
Outboard and InboardE43Z-19590-ACV Joint Grease - High Temp.ESP-MIC207-AEngine CoolantE2FZ-19549-AAFord Premium Cooling System
FluidESE-M97B44-APower Steering (Pump
Reservoir)XT-2-QDXMotorcraft Auto Trans. & Power
Steering MERCONÒ ATFMERCONÒATFEngine OilXO-5W30-QSPMotorcraft 5W30 Super
PremiumESE-M2C I 53-E and API Certification
MarkDoor WeatherstripsCOAZ-19553-AASilicone LubricantESR-Ml3P4-A289

NOTE: Rear axle lube quantities must be
replaced every 100,000 miles (160,000 km) or if
the axle has been submerged in water. Otherwise,
the lube should not be checked or changed unless a
leak is suspected or repair required.
Vehicle Storage
Maintenance Tips
If you plan on storing your vehicle for an extended
period of time (60 days or more), refer to the
following maintenance recommendations to ensure
your vehicle stays in good operating condition.
General Store all vehicles in a dry, ventilated place. Protect from sunlight, if possible. If vehicles are stored outside, they require
regular maintenance to protect against rust
and damage.
290Body Wash vehicle thoroughly to remove dirt, grease,
oil, tar or mud from exterior surfaces, rear
wheel housing and underside of front fenders. Periodically wash vehicles stored in exposed
locations. Touch-up raw or primed metal to prevent rust. Cover chrome and stainless steel parts with a
thick coat of auto wax to prevent discoloration.
Re-wax as necessary when the vehicle is
washed. Lubricate all hood, door and trunk lid hinges
and latches with a light grade oil. Cover interior soft trim to prevent fading. Keep all rubber parts free from oil and solvents.

Engine Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature. With your foot on the brake, shift through all
the gears while the engine is running.
Fuel system Fill fuel tank with high-quahty, premium
unleaded fuel until the first automatic shutoff of
the fuel pump nozzle.
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may deteriorate
due to oxidation. This can damage rubber and
other polymers in the fuel system and may also
clog small orifices.Ford Gas Stabilizer should be added whenever
actual or expected storage periods exceed 60 days.
Follow the instructions on the label. The vehicle
should then be operated at idle speed to circulate
the additive throughout the fuel system.
A volatile corrosion inhibitor added to the fuel
system will protect the fuel system's inner surfaces
from corrosion. Follow the instructions packaged
with the product.
Cooling system Protect against freezing temperatures.
291

Battery Check and recharge as necessary. Keep connections clean and covered with a light
coat of grease. If storing your vehicle for more than 30 days
without recharging the battery, disconnect the
battery cables to ensure battery charge is
maintained for quick starting. NOTE: If battery
cables are disconnected, it will be necessary to
reset any memory features (eg. radio presets).
Brakes Make sure brakes and parking brake are fully
released.
292Tires Maintain recommended air pressures.
Miscellaneous Make sure all linkages, cables, levers and
clevis pins under vehicle are covered with grease to
prevent rust. Move vehicles at least 25 feet (8 m) every 15
days to lubricate working parts and prevent
corrosion.

labels Air Bag warning Child Seat Label Child seat installation precautions Fuel Pump Shut-Off Safety Compliance Certification Label manufacturer, GVWR*
GAWR** Vehicle Identification Servicing or warranty Information Number Child Proof Lock Gross Vehicle
Weight Rating **Gross Axle Weight Rating
297

Engine compartment/ Servicing Windshield wipers Headlamp bulbs and Daytime Running Lights Hood latch Turn signal bulbs Parking lamp bulbs
Cornering lamp bulbs Moon roof Keyless entry Side view mirrors Tires299

Trunk Taillamp bulbs Backup lamp bulbs Brakelamp bulbs Turn signal bulbs High-mount brakelamp bulbs Fuel door
Doors300

Turn signals Windshield wiper Fuse panel Hood release Parking brake Gearshift- Automatic transmission Seats Speed control Head restraints301

Remote fuel door release Seat controls Remote trunk release Side mirror controls Memory profile buttons power locks window controls302
