LINCOLN MARK VIII 1998 User Guide

Supplemental restraint system (SRS) warning chime
For information on the SRS warning chime, refer to theSeating and
safety restraintschapter.
Key-in-ignition warning chime
Sounds when the key is left in the ignition in the OFF/LOCK or ACC
position and the driver's door is opened.
GAUGES
Engine coolant temperature gauge
Indicates the temperature of the
engine coolant. At normal operating
temperature, the needle remains
within the normal area (the area
between the ªHº and ªCº). If it
enters the red section, the engine is
overheating. Stop the vehicle as
soon as safely possible, switch off
the engine immediately and let the
engine cool. Refer toEngine
coolantin theMaintenance and
carechapter.
P
5
0 123
4
6
7
RPMx1000
H
C20406080
100
120
1404080120
200160
MPHkm/hFUEL
FILL DOOR
F
PREMIUM FUEL
RECOMMENDED
E
BRAKE000000.00
R
N
D
2
1
ABSCRUISE
ON
H
C
Instrumentation
12

Never remove the coolant recovery cap while the engine is
running or hot.
This gauge indicates the temperature of the engine coolant, not the
coolant level. If the coolant is not at its proper level the gauge indication
will not be accurate.
Tachometer
Indicates the engine speed in
revolutions per minute.
Driving with your tachometer
pointer in the red zone may damage
the engine.
Speedometer
Indicates the current vehicle speed.
5
6
0 123
4
7
RPMx1000
20406080
100
120
1404080120
200160
MPHkm/h
000000.0
0
Instrumentation
13

Odometer
Indicates the total kilometers
(miles) of the vehicle.
Fuel gauge
Displays approximately how much
fuel is in the fuel tank (when the
key is in the ON position). The fuel
gauge may vary slightly when the
vehicle is in motion. The ignition
should be in the OFF position while
the vehicle is being refueled. When
the gauge first indicates empty,
there is a small amount of reserve
fuel in the tank. When refueling the
vehicle from empty indication, the
amount of fuel that can be added
will be less than the advertised
capacity due to the reserve fuel.
ELECTRONIC MESSAGE CENTER
The electronic message center only
works when the ignition is in the
ON position.
The message center tells you about
the condition of your vehicle by
three methods:
²operator selectable features
²vehicle system status displays
²continuous warning reporting of monitored systems
20406080
100
120
1404080120
200160
MPHkm/h
000000.0
0
FUEL
FILL DOOR
F
E
PREMIUM FUEL
RECOMMENDED
Instrumentation
14

Selectable features
You can select different features for the message center to display by
using the message center controls located below the message center
display. You will hear a tone when you press one of these controls.
However, the message center will display the appropriate warning
message if it detects a warning from any of the monitored systems.
Vehicle setting
Each press of the VEHICLE
SETTING control will select a
different feature as follows:
²TRACTION CONTROL. This
system helps prevent wheel spin
to improve tire traction. The
RESET control will toggle this
feature on or off, but the feature
defaults to ON after each cycle of
the ignition key.
²ENGLISH/METRIC. This feature
allows you to change the message
center and electronic automatic temperature control units from metric
to English units. The modes can be toggled by pressing the RESET
control.
²AUTOLAMP DELAY STATUS. This feature displays the current
autolamp delay setting. To change the delay setting, you must rotate
the headlamp control.
²WIPER/HEADLAMP ON. When enabled, the headlamps will
automatically switch on when the windshield wipers are in the
intermittent, low or high speed settings. Use the RESET control to
toggle the feature on or off.
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
Instrumentation
15

²OIL CHANGE RESET. This
feature allows you to reset the oil
monitoring system to 100 percent
after each oil change. To reset,
the RESET control must be
pressed and held for 5 seconds
while the display counts down.
After a successful reset, the
message center will display ªOIL
LIFE RESET TO 100%.º To
ensure accurate oil life indicators,
perform the reset procedure only
after an oil change.
You can also set a personalized oil reset percentage, which allows you to
establish a smaller oil change interval.
1. Press and hold the RESET control from the VEHICLE SETTINGS
menu OIL CHANGE RESET screen.
2. While holding the RESET control
as the display counts down the
seconds to an oil change reset, press
the VEHICLE SETTINGS control.
The display will read START OIL
LIFE AT XXX%, where XXX is the
currently selected oil life
percentage. Release both controls.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
Instrumentation
16

3. Press the RESET control to
obtain the desired personalized oil
change percentage. Your choices are
100%, 90%, 80%, 70%, 60%, 50%,
40% and 30%.
4. Press the VEHICLE SETTING
control to complete the procedure.
A press of any control other than
RESET or VEHICLE SETTING will
abort the procedure and will not
establish a new personalized oil
reset percentage.
Your personalized oil change
percentage will begin upon
completion of your next OIL
CHANGE RESET procedure. Refer
toCHANGE OIL SOON/OIL
CHANGE REQUIREDfor more information.
Driver setting menu
The DRIVER SETTING menu allows
you to cycle through seven (if
equipped with phone) features,
saved for each driver personality
profile. These features can be
turned on or off by pressing the
RESET control.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
Instrumentation
17

²EXPRESS WINDOWS. Allows one tap down operation of the driver's
window using the window switch.
²AUTO LOCK. Automatically locks all doors when all doors are closed
and the vehicle speed is at least 5 km/h (3 mph).
²HORN CHIRP. Briefly sounds the horn when the remote keyless entry
LOCK control is pressed. Refer toRemote keyless entryin the
Controls and featureschapter for more information.
²EASY ENTRY. Moves the driver's seat back two inches and the
steering column to the up and forward position when the key is
removed from the ignition. The driver's seat and steering column
return to the set position when the driver returns.
²REVERSE MIRRORS. When the vehicle is shifted to R (Reverse), the
outside mirrors tilt down for an improved view of the side of the
vehicle and the curb area when backing up. The mirrors return to
their previous position when you shift out of reverse.
²AUTO GLIDE. Automatically moves the seat forward when the
seatback is tilted forward.
²PHONE SCREEN (if equipped with a factory-installed phone). When a
call is placed, information about the call is displayed in the message
center.
Fuel range
Press the RANGE control to display
approximately how many kilometers
(miles) you can drive before
running out of fuel. To ensure
accuracy, turn the ignition to OFF
when you fill the fuel tank.
RANGE is calculated using a
running average fuel economy set by
the factory. This value is not the
same as the average fuel economy
display. The running average fuel
economy is based on more than 800
km (500 miles) of driving history.
If FUEL SENSOR SHORT or OPEN are displayed, there is a problem
with the fuel indication system. If these messages or DATA ERROR are
displayed, you should contact your dealer as soon as possible.
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
Instrumentation
18

Press RANGE a second time to
display the approximate amount of
fuel left in the tank in whole
numbers (liters or gallons). If the
fuel tank is full or nearly full, the
message center will display FULL
FUEL TANK. If the fuel tank is
nearly empty, the message center
will display EMPTY FUEL TANK.
Fuel economy
Press the ECONOMY control to
display one of two features:
1. Average fuel economy. The
message center display will indicate
the vehicle's average fuel economy
in liters/100 kilometers
(miles/gallon).
²Press the RESET control to reset
the average fuel economy feature.
2. Instantaneous fuel economy. The
display will indicate the
instantaneous fuel economy of your
running vehicle. This figure is affected by such factors as braking,
acceleration and road conditions.
When your vehicle is not moving, instantaneous fuel economy will be
displayed at 99 kilometers/liter (0 miles/gallon). When you are moving,
the message center will display between 1 and 99 kilometers/100 liters
(0 and 99 miles/gallons).
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
Instrumentation
19

Trip ODO
Press this control to display the first
of two trip odometers. Press it again
to display the second trip odometer.
To reset the displayed trip
odometer, press the RESET control.
Reset
Press this control to reset:
²warnings
²average fuel economy
²clock set
²compass adjustment
²vehicle settings
²driver settings
Range and instantaneous fuel
economy are unaffected by pressing
RESET.
Date/Time
Press this control to set/adjust the
following features on the message
center:
²day and date
²time only
²elapsed time
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
20

Day and date display
To set the day:
1. Press the RESET control.
2. Press DATE/TIME repeatedly to
select the correct day of the week.
To set the month:
1. Press RESET to proceed to the
month adjustment display.
2. Press DATE/TIME repeatedly to
select the correct month of the year.
To set the date:
1. Press RESET to proceed to the
date adjustment display.
2. Press DATE/TIME repeatedly to select the correct day of the month.
When finished, press RESET to complete the set/adjustment procedure.
Time only display
To set the hour:
1. Press the RESET control.
2. Press DATE/TIME repeatedly to
select the correct hour.
To set the minute:
1. Press RESET to proceed to the
minute adjustment display.
2. Press DATE/TIME repeatedly to
select the correct minute.
When finished, press RESET to
complete the set/adjustment
procedure.
Elapsed time display
This feature monitors the elapsed time if desired, regardless if the
vehicle ignition is ON or OFF.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
