LINCOLN MARK VIII 1998 Owner's Manual
Manufacturer: LINCOLN, Model Year: 1998, Model line: MARK VIII, Model: LINCOLN MARK VIII 1998Pages: 170, PDF Size: 1.37 MB
Page 21 of 170
²To stop the elapsed time count
while it is running without
resetting the counter, briefly (less
than two seconds) press the
RESET control.
²To start the elapsed time count
when it is stopped without
resetting the counter, briefly (less
than two seconds) press the
RESET control.
²To reset the elapsed time
counter, hold the RESET control
down for about two seconds until
the count reads 00:00:00.
Compass
The compass reading may be affected when you drive near large
buildings, bridges, power lines and powerful broadcast antenna. Magnetic
or metallic objects placed in or on the vehicle may also affect compass
accuracy. Adjustments may be made to the zone and calibration of the
compass.
Compass zone variation adjustment
The variation adjustment is only needed if you travel outside your
current compass zone.
1. Press and hold the COMPASS
control, then press the RESET
control. Then, release both controls.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
22
Page 22 of 170
2. Determine which compass zone
you are in by referring to the zone
map.
3. Press the ECONOMY control until
the current zone number is shown
in the display.
4. Press the RESET control until the
number shown in the display is the
correct number for the zone you are
in.
5. Press the COMPASS control to
complete the zone setting. (Press
any control other than RESET or
COMPASS to exit without setting a
zone.)
Compass calibration adjustment
1. Locate an open, level area free from steel structures and high voltage
lines. An empty, level parking lot is recommended.
2. Press and hold the COMPASS control, then press the RESET control.
Next, release both controls.
1
2
3
4
5
6
7891011121314 15
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
23
Page 23 of 170
3. Press the RESET control to enter
the calibration mode. The display
will show CIRCLE SLOWLY TO CAL.
4. Slowly drive the vehicle at less
than 5 km/h (3 mph) in a circle,
taking at least 20 seconds to
complete one circle, until the
display shows a direction (north,
south, etc.).
5. The compass is now calibrated.
If the message center display shows CHECK COMPASS SYSTEM during
any of the compass adjustment
procedures, contact your dealer.
System check
Pressing this control causes the
message center to cycle through a
status of each of the systems being
monitored.
The sequence of the system check
report is as follows:
²engine oil life status
²engine oil life left
²engine oil level
²voltage level
²engine coolant temperature
²engine coolant level
²washer fluid level
²doors closed (driver and passenger side)
²trunk closed
²exterior lamps (head, front turn, brake and tail)
²air ride system
²traction control
²fuel level
²kilometers to empty (miles to empty)
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
24
Page 24 of 170
At normal conclusion of the system check sequence, the last displayed
feature will be displayed.
Press the RESET control anytime
during the system check to stop the
cycle immediately. The last
displayed feature before RESET was
pressed will be displayed.
Press any of the other message
center controls to stop the system
check cycle and display the
requested feature.
Vehicle system status displays
These messages are displayed on the message center when the operation
or use of one of the following vehicle systems occurs:
²PHONE SCREEN. The display will automatically appear on the
message center during usage of the cellular phone (if equipped with a
factory-installed phone) unless a warning is displayed or the phone
screen feature is turned off in the DRIVER SETTING menu. To disable
the phone screen and return to an operator selectable feature display
during a phone call, press the corresponding feature control (TRIP
ODO, DATE/TIME, etc.).
²AUTO LAMP DELAY STATUS SCREEN. This display indicates the
amount of time the lights will stay on after the ignition is turned OFF
(if the autolamps are turned on). This display automatically appears
on the message center when the autolamp delay time is adjusted.
²PERSONALITY EVENT SCREEN. This display automatically appears
when a vehicle system is adjusted and saved to the driver's personality
profile, when a new driver personality profile is selected or when the
personality feature is turned off.
System warnings
System warnings alert you to possible problems or malfunctions in your
vehicle's operating systems.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
25
Page 25 of 170
In the event of a multiple warning situation, the message center will
cycle the display to show all warnings by displaying each one for
4 seconds.
The message center will display the
last selected feature if there are no
more warning messages. This allows
you to use the full functionality of
the message center after you
acknowledge the warning by
pressing the RESET control and
clearing the warning message.
Warning messages that have been
reset are divided into two
categories:
²They will reappear on the display
ten minutes from the reset.
²They will not reappear until an ignition OFF-ON cycle has been
completed.
This acts as a reminder that these warning conditions still exist within
the vehicle. All warning messages will reappear after an entire SYSTEM
CHECK sequence has been completed.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
26
Page 26 of 170
Driver's door ajar Warning cannot be reset
Right door ajar
Check engine temp Warning returns after 10 minutes
Low oil level
Check charging system
Low fuel level
Low engine coolant
Engine temp data err
Check transmission
Transmission overheat
Check brake lamps Warning returns after the ignition
key is turned from OFF to ON or
system check sequence is
completed Check headlamps
Check taillamps
Check front turn lamps
Low washer fluid
Trunk ajar
Check traction control
Air ride switch off
Check air ride system
Oil change required
Change oil soon
Gear display data err
DRIVER'S DOOR AJAR. Displayed when the driver's door is not
completely closed and the ignition switch is either ON or in ACC mode.
RIGHT DOOR AJAR. Displayed when the passenger side door is not
completely closed and the ignition switch either ON or in ACC mode.
CHECK ENGINE TEMP. Displayed when the engine coolant is
overheating. Stop the vehicle as soon as safely possible, turn off the
engine and let it cool. Check the coolant and coolant level. Refer to
Engine coolantin theMaintenance and carechapter. If the warning
stays on or continues to come on, contact your dealer as soon as safely
possible.
Instrumentation
27
Page 27 of 170
LOW OIL LEVEL. Displayed when the engine oil level is low. If this
warning message is displayed, check the level of the engine oil.
If you are parked on a steep incline, the LOW OIL LEVEL message may
come on when you start your vehicle, even though the oil is at the
correct level. The oil level is monitored while the engine is off so that the
oil can drain into the oil pan to be measured. Some aftermarket devices
such as remote starters, if improperly installed, can cause the engine to
start without alerting the oil monitoring system. This may also cause the
warning to appear when the vehicle is started, even though the oil level
is correct. Refer toEngine oilin theMaintenance and carechapter for
information about adding engine oil.
CHECK CHARGING SYSTEM. Displayed when the electrical system is
not maintaining proper voltage. If you are operating electrical accessories
when the engine is idling at a low speed, turn off as many of the
electrical loads as soon as possible. If the warning stays on or comes on
when the engine is operating at normal speeds, have the electrical
system checked as soon as safely possible.
LOW FUEL LEVEL. Displayed when you have approximately 80 km (50
miles) or less left before you run out of fuel.
LOW ENGINE COOLANT. Displayed when the engine coolant level is
low. Stop the vehicle as soon as safely possible, turn off the engine and
let it cool. Check the coolant and level. Refer toEngine coolantin the
Maintenance and carechapter.
ENGINE TEMP DATA ERR. Displayed when the engine coolant
temperature information is missing or invalid. Check the instrument
cluster temperature gauge. If the gauge indicates overheating, stop the
vehicle as soon as safely possible, turn off the engine and let it cool.
Check the coolant and level. Refer toEngine coolantin the
Maintenance and carechapter. Contact your dealer for service as soon
as safely possible to correct the engine temperature data error.
CHECK TRANSMISSION. Indicates the transmission is not operating
properly. If this warning stays on, contact your dealer as soon as safely
possible.
Instrumentation
28
Page 28 of 170
TRANSMISSION OVERHEAT. Indicates the transmission is
overheating. This warning may appear when towing heavy loads or when
driving in a low gear at a high speed for an extended period of time.
Stop the vehicle as soon as safely possible, turn off the engine and let it
cool. Check the transmission fluid and level. Refer toTransmission
fluidin theMaintenance and carechapter. If the warning stays on or
continues to come on, contact your dealer for transmission service as
soon as safely possible.
CHECK BRAKE LAMPS. Displayed when the brake lamps are
activated and at least one is burned out. Check the lamps as soon as
safely possible and have the burned out lamp replaced. The center
high-mount brakelamp is not monitored.
CHECK HEADLAMPS. Displayed when the headlamps are activated
and at least one is burned out. Check the lamps as soon as safely
possible and have the burned out lamp replaced. Refer toReplacing
headlamp bulbsin theMaintenance and carechapter. The high beam
lamps are not monitored.
CHECK TAIL LAMPS. Displayed when the tail lamps are activated and
at least one is burned out. Check the lamps as soon as safely possible
and have the burned out lamp replaced.
CHECK FRT TURN LAMPS. Displayed when the turn signals are
activated and at least one is burned out. Check the lamps as soon as
safely possible and have the burned out lamp replaced.
LOW WASHER FLUID. Indicates there is less than one quarter of
washer fluid left in the reservoir. Check the washer fluid level. Refer to
Windshield washer fluidin theMaintenance and carechapter.
TRUNK AJAR. Displayed when the trunk is not completely closed and
the ignition switch is in ON or ACC.
CHECK TRACTION CONTROL. Displayed when the Traction
Controlysystem is not operating properly. If this message is displayed
on the message centerandthe green T/C OFF light isnotilluminated,
the Traction Controlysystem will be partially operable. If this warning
stays on, contact your dealer for service as soon as possible. For further
information, refer toTraction controlyin theDrivingchapter.
AIR RIDE SWITCH OFF. Displayed when the air suspension switch is
in the OFF position.
Instrumentation
29
Page 29 of 170
CHECK AIR RIDE SYSTEM. Displayed when the air suspension
system is not operating properly. If this message is displayed while
driving, pull off the road as soon as safely possible. The message may
also be displayed if the vehicle is loaded beyond the recommended
maximum payload. This is a normal condition if the vehicle is overloaded.
To correct this condition:
1. Remove or redistribute the payload per the recommended maximum
requirements.
2. Turn the ignition switch from ON to OFF to ON again.
If the message reappears:
1. Turn the air suspension switch (located in the trunk) OFF.
2. Contact your dealer for service as soon as safely possible.
For more information, refer toAir suspensionin theDrivingchapter.
CHANGE OIL SOON/OIL CHANGE REQUIRED. Displayed when the
engine oil life remaining is 5 percent or less. When oil life left is between
5% and 0%, the CHANGE OIL SOON message will be displayed. When oil
life left reaches 0%, the OIL CHANGE REQUIRED message will be
displayed.
An oil change is required whenever indicated by the message center.
USE ONLY RECOMMENDED ENGINE OILS.
To reset the oil monitoring system to 100% (or your personalized oil
reset percentage) after each oil change:
1. Press the VEHICLE SETTINGS
control until the OIL CHANGE
RESET display appears.
VEHICLE
SETTINGDRIVER
SETTINGTRIP
ODO RANGE
FUELECONOMY
Instrumentation
30
Page 30 of 170
2. Press the RESET switch and hold
it down for five seconds while the
display counts down to trigger an oil
change reset.
3. After a successful reset, the
message center will display OIL
LIFE RESET TO 100% (if you have
established a personalized oil reset
percentage, the display will instead
show that percentage).
To ensure accurate oil life
indicators, perform this reset
procedure only after an oil change.
GEAR DISPLAY DATA ERR. Displayed when the data used to provide
the redundant gear selection display on the instrument cluster is missing
or invalid. In this case, the instrument cluster redundant gear selection
display is turned off. The driver should use the mechanical position
indication on the center console gear selector as temporary indication. If
this warning stays on, contact your dealer as soon as safely possible.
Function/status error messages
A function/status error message may be displayed by the message center
instead of a warning or requested function if the information is not
currently available because of:
²improper operation of sensor systems
²the vehicle network communication between electronic modules
Error messages have two formats:
²DATA ERROR or DATA ERR. These messages indicate improper
operation of the vehicle network communication between electronics
modules. Contact your dealer as soon as safely possible if these
messages occur on a regular basis.
²SENSOR OPEN or SENSOR SHORT. These messages indicate
improper operation of vehicle sensor systems or vehicle
wiring/connectors between the sensors and the message center.
Contact your dealer as soon as safely possible if these messages occur
on a regular basis.
RESET
N
S W
E DATE
TIMESYSTEM
CHECK
Instrumentation
31
