MAZDA CX90 2024 Owners Manual

Moonroof*
The moonroof can be opened or
closed when operating the overhead
tilt/slide switch at the front seats.
1. Tilt/slide switch
Jam-safe function
If foreign matter caught between the
moonroof and the window frame is
detected while it is closing
automatically, the moonroof stops and
opens partway.
NOTE
Before leaving the vehicle or washing
your Mazda, make sure the
moonroof is completely closed so
that water does not get inside the
cabin area.
After washing your Mazda or after it
rains, wipe the water off the
moonroof before operating it to
avoid water penetration which could
cause rust and water damage to your
headliner.
The jam-safe function may operate
under the following conditions.
A strong impact is detected while
the moonroof is closing
automatically.
The moonroof is closing
automatically during very low
temperatures.
When the jam-safe function is
inoperable, the moonroof initial
setting is not performed.
Refer to Initializing the moonroof on
page Reference 8-33.
Opening/closing
Sunroof
4-34*Some models.
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Warnings and Cautions
for Using the Moonroof
WARNING
Do not let passengers stand up or
extend part of the body through the
open moonroof while the vehicle is
moving.
Extending the head, arms, or other
parts of the body through the
moonroof is dangerous. The head or
arms could hit something while the
vehicle is moving. This could cause
serious injury or death.
Never allow children to play with the
tilt/slide switch.
The tilt/slide switch would allow
children to operate the moonroof
unintentionally, which could result in
serious injury if a child's hands, head
or neck becomes caught by the
moonroof.
Make sure the opening is clear before
closing the moonroof.
A closing moonroof is dangerous. The
hands, head, or even neck of a person,
especially a child, could be caught in it
as it closes, causing serious injury or
even death.
Make sure nothing blocks the
moonroof just before it reaches the
fully closed position.
Blocking the moonroof just before it
reaches the closed position is
dangerous.
In this case, the jam-safe function
cannot prevent the moonroof from
closing. If fingers are caught, serious
injuries could occur.
CAUTION
 Do not sit on or put heavy items on
the area where the moonroof opens
and closes. Otherwise, the
moonroof could be damaged.
 Do not open or close the moonroof
forcefully during freezing
temperatures or snowfall. Otherwise,
the moonroof could be damaged.
 The sunshade does not tilt. To avoid
damaging the sunshade, do not push
it up.
 Do not close the sunshade while the
moonroof is opening. Trying to force
the sunshade closed could damage
it.
Opening/closing
Sunroof
4-35
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use theMoonroof
Operating the Sunshade
The sunshade can be opened and
closed by hand.
The sunshade opens at the same time
as the moonroof slides open, but it
must be closed by hand.
Tilt Operation
The rear of the moonroof can be tilted
open to provide more ventilation.
When the moonroof is already slid
open and you want to tilt it open, first
close the moonroof and then do a tilt
operation.
1. Switch the vehicle power ON.
2. Press the tilt/slide switch. The rear side of the front glass
panel of the moonroof opens
upwards.
3. Press the tilt/slide switch forward.
The moonroof closes.
To stop it partway, operate the switch
in the direction opposite to the
direction it is opening/closing.
Slide Operation
When the moonroof is already tilted
open and you want to slide it open,
first close the moonroof and then do a
slide operation.
1. Switch the vehicle power ON.
2. Press the tilt/slide switch rearward.
The moonroof opens.
3. Press the tilt/slide switch forward.The moonroof closes.
To stop it partway, operate the switch
in the direction opposite to the
direction it is opening/closing.
Opening/closing
Sunroof
4-36
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Security System
Mazda cannot guarantee the
immobilizer and the theft-deterrent
system's operation if the system has
been modified or if any add-on
equipment has been installed.
Warnings and Cautionsfor Using the Security System
CAUTION
To avoid damage to the vehicle, do not
modify the system or install any add-on
equipment to the immobilizer and the
theft-deterrent systems or the vehicle.
Opening/closing
Security System
4-37
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Immobilizer System
The immobilizer system allows the
hybrid system to start only with a key
the system recognizes.
NOTE
The keys carry a unique electronic
code. For this reason, and to assure
your safety, obtaining a replacement
key requires security validation, this
will add some delays in supplying a
replacement key. They are only
available through an Authorized
Mazda Dealer.
Always keep a spare key in case one
is lost. If a key is lost, consult an
Authorized Mazda Dealeras soon as
possible.
If you lose a key, an Authorized
Mazda Dealer will reset the
electronic codes of your remaining
keys and immobilizer system. Bring
all the remaining keys to an
Authorized Mazda Dealerto reset.
Warnings and Cautions
for Using the Immobilizer System
CAUTION
Radio equipment like this is
governed by laws in the United
States.
Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user's authority to operate
the equipment.
 To avoid damage to the key, do not:
 Drop the key.
 Get the key wet.
 Expose the key to any kind of
magnetic field.
 Expose the key to high
temperatures on places such as the
dashboard, under direct sunlight.
 If the hybrid system does not start
with the correct key, and the security
indicator light keeps illuminating or
flashing , the system may have a
malfunction. Consult an Authorized
Mazda Dealer.
Opening/closing
Security System
4-38
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the
Immobilizer System
NOTE
The hybrid system may not start and
security indicator light may illuminate
or flash if the key is placed in an area
where it is difficult for the system to
detect the signal, such as on the
dashboard or in the glove
compartment. Move the key to a
location within the signal range,
switch the vehicle power off, and
then restart the hybrid system.
Signals from a TV or radio station, or
from a transceiver or mobile
telephone could interfere with your
immobilizer system. If you are using
the proper key and the hybrid system
fails to start, check the security
indicator light.
Arming
The system is armed when the vehicle
power is switched from ON to off.
The security indicator light
in the
instrument cluster flashes every 2
seconds until the system is disarmed.
Disarming
The system is disarmed when the
vehicle power is switched ON with the
correct programmed key. The security
indicator light
illuminates for
about 3 seconds and then turns off.
If the hybrid system does not start with
the correct key, and the security
indicator light remains illuminated or
flashing , try the following:
Make sure the key is within the
operat ional range for signal
transmission. Switch the vehicle power
off, and then restart the hybrid system.
If the hybrid system does not start after
3 or more tries, contact an Authorized
Mazda Dealer.
Opening/closing
Security System
4-39
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Theft-Deterrent System
If the theft-deterrent system detects an
inappropriate entry into the vehicle,
which could result in the vehicle or its
contents being stolen, the alarm alerts
the surrounding area of an abnormality
by sounding the horn and flashing the
hazard warning lights.

The system will not function unless it's
properly armed. So when you leave the
vehicle, follow the arming procedure
correctly.
How to Use the
Theft-Deterrent System
How to Arm the System
1. Close the windows and the
panorama sunroof/moonroof*
securely.
2. Switch the vehicle power OFF.
3. Make sure the hood, the doors, and the liftgate are closed.
4. Press the lock button on the transmitter. The hazard warning
lights will flash once.
The following method will also arm
the theft-deterrent system:
Press the door-lock switch
while
any door is open and then close all
of the doors.
( With the advanced keyless
function)
Touch the sensing area of the door
lock touch sensor.
The security indicator light
in
the instrument cluster flashes twice
per second for 20 seconds.
5. After 20 seconds, the system is fully armed.
NOTE
The theft-deterrent system can also
be armed by activating the auto
relock function with all the doors,
the liftgate and the hood closed.
Refer to Transmitter on page 4-5.
The system will disarm if one of the
following operations takes place
within 20 seconds after pressing the
lock button:
Unlocking any door.Opening any door.Opening the hood.Switching the vehicle power ON.
To rearm the system, do the arming
procedure again.
Opening/closing
Security System
4-40*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

When the doors are locked by
pressing the lock button on the
transmitter while the theft-deterrent
system is armed, the hazard warning
lights will flash once to indicate that
the system is armed.
Operation
Horn triggering conditions
The horn sounds intermittently and the
hazard warning lights flash for about
30 seconds when the system is
triggered by any one of the following:
Unlocking a door with the auxiliary
key, door lock switch, or an inside
door-lock knob.
Forcing open a door, the hood or the
liftgate.
Opening the hood by operating the
hood release handle.
Switching the vehicle power ON
without using the power switch.
If the system is triggered again, the
lights and horn will activate until the
driver's door or the liftgate is unlocked
with the transmitter.
(With the advanced keyless function)
The lights and horn can also be
deactivated by touching the sensing
area of the door release touch sensor.
NOTE
The liftgate does not open while the
theft-deterrent system is operating.
If the lead-acid battery goes dead
while the theft-deterrent system is
armed, the horn will activate and the
hazard warning lights will flash when
the lead-acid battery is charged or
replaced.
To S t o p t h e A l a r m
A triggered alarm can be turned off
using any one of the following
methods:
Pressing the unlock button on the
transmitter.
Starting the hybrid system with the
power switch.
(With the advanced keyless
function)
Touching the sensing area of the
door release touch sensor.
Pressing the electric liftgate opener
while the key is being carried.
The hazard warning lights will flash
twice.
To Turn Off an Armed System
An armed system can be turned off
using any one of the following
methods:
Pressing the unlock button on the
transmitter.
Starting the hybrid system with the
power switch.
(With the advanced keyless
function)
Touching the sensing area of the
door release touch sensor.
The hazard warning lights will flash
twice.
NOTE
When the doors are unlocked by
pressing the unlock button on the
transmitter while the theft-deterrent
system is turned off, the hazard
warning lights will flash twice to
indicate that the system is turned off.
Opening/closing
Security System
4-41
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Rear Seat Alert*
The Rear Seat Alert is a system that
reminds the driver to check if any
occupants or luggage have been left
behind on the second/third-row seats.
The Rear Seat Alert determines if there
is the possibility that occupants or
luggage are on a second/third-row
seat based on the opening and closing
history of the rear doors. For this
reason, the system may operate
differently from the actual conditions,
such as it is not activated even if
occupants or luggage are occupying a
second/third-row seat.
Warnings and Cautions
for Using the Rear Seat Alert
WARNING
Do not rely completely on the system.
The Rear Seat Alert is not a system that
detects occupants and luggage using
sensors. Over reliance on the system
could lead to an accident.
When leaving the vehicle, always
visually check the conditions of the
second/third-row seats.
Opening/closing
Rear Seat Alert
4-42*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Rear SeatAlert
If any of the following operations is
performed, a message appears in the
instrument cluster to notify that the
system is active. Make sure that a
message appears. The message
disappears after a short period of time.
When the Rear Seat Alert is not
needed, temporarily deactivate the
system according to the message.
A rear door is opened and the hybrid
system is started.
The hybrid system is started within
about 10 minutes after a rear door is
opened and closed.
A rear door is opened after the
hybrid system is started.
The vehicle power is switched ON
while the system is active.
If the vehicle power is switched OFF
while the system is active, a message in
the instrument clus ter and a warning
sound indicate the possibility of
occupants or luggage on a second/
third-row seat. The message
disappears after a short period of time.
If the driver's door is opened/closed
after the message in the instrument
cluster disappears, notification is made
again.

When deactivating the system, perform
any of the following operations.
Switch the vehicle power to ACC or
OFF and open a rear door.
Switch the vehicle power ON again
and open a rear door before starting
the hybrid system.
Open a rear door and switch the
vehicle power to ACC or OFF.
Temporarily deactivate the system
according to the message in the
instrument cluster.
NOTE
The Rear Seat Alert determines if there
is the possibility that occupants or
luggage are on a second/third-row
seat based on the opening and closing
history of the rear doors. For this
reason, depending on the usage, it
may not be activated even if occupants
or luggage are on the second/
third-row seats, or it may activate even
if no occupants or luggage are on the
second/third-row seats. The system
will continue to be active until it is
canceled.
Examples of when the system does
not activate even if occupants or
luggage are on the second/third-row
seats.
A rear door is opened and closed in
a very short period of time.
Remote engine starting via
Connected Service is used*.The lead-acid battery charge is low.The lead-acid battery connection
was disconnected/connected.
Examples of when the system
activates even if no occupants or
luggage are on the second/third-row
seats.
A rear door is opened and closed,
but no occupant or luggage is in the
vehicle.
Occupants and luggage are
unloaded while the engine is
running.
A rear door is opened and closed in
a very short period of time.
Opening/closing
Rear Seat Alert
*Some models.4-43
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
