MAZDA CX90 2024 Owners Manual

Temporarily Deactivating the Rear
Seat Alert
When the instrument cluster displays a
message concerning the Rear Seat
Alert, the driver can temporarily
deactivate the system.
Operate according to the message
displayed in the instrument cluster.
When the message "Press and Hold
INFO Switch to Deactivate Rear Seat
Alert" is displayed in the instrument
cluster, press and hold the INFO switch
for 2 seconds or longer.
When the system is temporarily
deactivated, a chime sounds and a
message to notify that the operation
was completed appears in the
instrument cluster. The message
disappears after a short period of time.
NOTE
When the vehicle power is switched
OFF, the temporary deactivation is
canceled.
Turning the Rear Seat Alert Off
The Rear Seat Alert can be set to off
using Mazda Connect.
Refer to Mazda Connect Owner's
Manual or consult an Authorized
Mazda Dealer.
NOTE
Under the following conditions, the
warning light
turns on 2 times to
indicate the system has been stopped
when the vehicle power is switched
ON, and then turns off after a short
period of time.
The Rear Seat Alert is turned off.The Rear Seat Alert is temporarily
deactivated.
Remote engine starting via
Connected Service is used*.The lead-acid battery charge is low.
Opening/closing
Rear Seat Alert
4-44*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

5Driving
Mirrors.................................... 5-8Warnings and Cautions for Using
the Mirrors............................ 5-8
How to Use the Outside
Mirrors..................................5-9
Convenient Ways to Use the
Outside Mirrors................... 5-10
Warnings and Cautions for the
Rearview Mirror................... 5-11
How to Use the Rearview
Mirror................................. 5-11
Convenient Ways to Use the
Rearview Mirror................... 5-12
Power Switch..........................5-13 Power Switch....................... 5-13
Warning and Cautions for Using
the Power Switch................. 5-13
How to Use the Power
Switch.................................5-14
e-SKYACTIV PHEV...................5-16 e-SKYACTIV PHEV............... 5-16
e-SKYACTIV PHEV
Overview............................ 5-17
Warning and Cautions for Using
the e-SKYACTIV PHEV.......... 5-19
How to Use the e-SKYACTIV
PHEV.................................. 5-23
Convenient Ways to Use the e-
SKYACTIV PHEV...................5-25
Instrument Cluster.................. 5-27 Instrument Cluster............... 5-27How to Use the Instrument
Cluster................................ 5-28
Convenient Ways to Use the
Instrument Cluster............... 5-31
Speedometer.......................5-31
Tachometer......................... 5-32
Odometer/Trip Meter.......... 5-32
How to Use the Odometer/Trip
Meter................................. 5-33
High Voltage Battery Temperature
Gauge................................. 5-33
Engine Coolant Temperature
Gauge................................. 5-34
High Voltage Battery Power
Gauge................................. 5-34
Fuel Gauge.......................... 5-35
Dashboard Illumination........5-35
How to Use the Dashboard
Illumination.........................5-36
Outside Temperature
Display................................5-37
Maximum Driving Distance
Display................................5-37
Average Electrical Power
Consumption Rate Display ..........
.......................................... 5-38
How to Use the Average Electrical
Power Consumption Rate
Display................................5-38
Average Fuel Economy
Display................................5-39
How to Use the Average Fuel
Economy Display................. 5-39
Instantaneous Electrical Power
Consumption Rate Display ..........
.......................................... 5-40
5-1
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Instantaneous Fuel Economy
Display................................5-40
i-ACTIVSENSE Status Symbol
(Warning/Risk Avoidance
Support System).................. 5-41
Compass Display................. 5-41
Message Display.................. 5-42
Active Driving Display............. 5-43 Active Driving Display
*......... 5-43
Warnings and Cautions for Using
the Active Driving Display..... 5-44
Convenient Ways to Use the
Active Driving Display.......... 5-45
Selector Lever......................... 5-46 Warning and Cautions for Using
the Selector Lever................ 5-46
How to Use the Selector
Lever................................... 5-47
Steering Shift Switches............. 5-50 Warnings and Cautions for Using
the Steering Shift Switches ...........
.......................................... 5-50
How to Use the Steering Shift
Switches..............................5-51
Convenient Ways to Use the
Steering Shift Switches..........5-55
Foot Brake..............................5-56 Warning and Cautions for Using
the Foot Brake..................... 5-56
Electric Parking Br ake (EPB)...... 5-57
Electric Parking Brake (EPB) ..........
.......................................... 5-57
Warning and Cautions for Using
the Electric Parking Brake
(EPB).................................. 5-57
How to Use the Electric Parking
Brake (EPB)..........................5-58
Convenient Ways to Use the
Electric Parking Brake (EPB) ..........
.......................................... 5-59
Brake Override System............. 5-61 Brake Override System......... 5-61
Warning and Cautions for Using
the Brake Override System ...........
.......................................... 5-61
How to Use the Brake Override
System................................ 5-62
AUTOHOLD........................... 5-63 AUTOHOLD........................ 5-63
Warning and Cautions for Using
the AUTOHOLD.................. 5-63
How to Use the
AUTOHOLD........................ 5-64
Hill Launch Assist (HLA)........... 5-66 Hill Launch Assist (HLA)........5-66
Warning and Cautions for Using
the Hill Launch Assist
(HLA).................................. 5-66
Light Switch............................5-67 Light Switch......................... 5-67
Warnings and Cautions for Using
the Light Switch................... 5-67
How to Use the Light
Switch................................. 5-68
Convenient Ways to Use the Light
Switch................................. 5-70
5-2*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Turn Signal lever..................... 5-72How to Use the Turn Signal
Lever................................... 5-72
Windshield Wiper/Washer
Switch................................... 5-73 Windshield Wiper/Washer
Switch.................................5-73
Warning and Cautions for Using
the Windshield Wiper/Washer
Switch.................................5-73
How to Use the Windshield
Wiper/Washer Switch.......... 5-74
How to Use the Rear Wiper/
Washer Switch..................... 5-77
Rear Window Defogger
Switch................................... 5-78 Rear Window Defogger
Switch.................................5-78
Warnings and Cautions for Using
the Rear Window Defogger
Switch.................................5-78
How to Use the Rear Window
Defogger Switch.................. 5-79
Mirror Defogger
*..................5-79
How to Use the Mirror
Defogger............................. 5-80
Windshield Wiper De-icer
*..........
.......................................... 5-80
How to Use the Windshield
Wiper De-icer......................5-81
Hazard Warning Lights............. 5-82 Hazard Warning Lights......... 5-82
How to Use the Hazard Warning
Lights.................................. 5-82
Horn..................................... 5-83How to Use the Horn........... 5-83
Antilock Brake System (ABS)..... 5-84 Antilock Brake System
(ABS).................................. 5-84
Warning and Cautions for Using
the Antilock Brake System
(ABS).................................. 5-84
Traction Control System (TCS) ..........
............................................ 5-85 Tra c t i o n C o n t r o l Sy s t e m
(TCS).................................. 5-85
Warning and Cautions for Using
the Traction Control System
(TCS).................................. 5-85
How to Use the Traction Control
System (TCS)....................... 5-86
Convenient Ways to Use the
Tra c t i o n C o n t r o l Sy s t e m
(TCS).................................. 5-87
Dynamic Stability Control
(DSC).................................... 5-88 Dynamic Stability Control
(DSC)................................. 5-88
Warning and Cautions for Using
the Dynamic Stability Control
(DSC)................................. 5-88
How to Use the Dynamic Stability
Control (DSC)..................... 5-89
Trailer Stability Control (TSC) ...........
............................................ 5-90 Trailer Stability Control
(TSC).................................. 5-90
*Some models.5-3
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warning and Cautions for Using
the Trailer Stability Control
(TSC).................................. 5-90
How to Use the Trailer Stability
Control (TSC)...................... 5-91
Hill Descent Control................5-92 Hill Descent Control
*........... 5-92
Warnings and Cautions for Using
the Hill Descent Control....... 5-92
How to Use the Hill Descent
Control............................... 5-93
Mazda intelligent Drive Select (Mi-
Drive).................................... 5-95 Mazda intelligent Drive Select
(Mi-Drive)........................... 5-95
Warning and Cautions for Using
the Mazda intelligent Drive Select
(Mi-Drive)........................... 5-96
How to Use the Mazda intelligent
Drive Select (Mi-Drive)........ 5-96
i-ACTIV AWD......................... 5-98 i-ACTIV AWD...................... 5-98
Warnings and Cautions for Using
the i-ACTIV AWD................ 5-98
Power Steering....................... 5-99 Power Steering.....................5-99
Tire Pressure Monitoring System
(TPMS)................................ 5-100 Tire Pressure Monitoring System
(TPMS)..............................5-100
Warning and Cautions for Using
the Tire Pressure Monitoring
System (TPMS).................. 5-100
How to Use the Tire Pressure
Monitoring System (TPMS) ..........
........................................ 5-102
Refueling............................. 5-104 Warnings and Cautions for When
the Refueling..................... 5-104
Refueling........................... 5-105
Fuel Requirements............. 5-107
Warnings and Cautions for Using
the Fuel Requirements....... 5-108
Emission Control System.... 5-108
Warnings and Cautions for Using
the Emission Control
System.............................. 5-109
Warnings and Cautions for Engine
Exhaust (Carbon
monoxide)........................ 5-109
Charging..............................5-111 Warnings and Cautions For
Charging........................... 5-111
Charging Related Part
Overview.......................... 5-113
How to Perform Charging... 5-116
Convenient Ways to Use of
Charging........................... 5-118
i-ACTIVSENSE....................... 5-122 i-ACTIVSENSE.................... 5-122
Warnings and Cautions for Using
the i-ACTIVSENSE.............. 5-122
Active Safety Technology.... 5-123
Pre-crash Safety
Technology........................ 5-124
i-ACTIVSENSE Status Symbol
(Warning/Risk Avoidance
Support System)
*............... 5-124
How to Use the i-ACTIVSENSE
OFF switch
*....................... 5-126
5-4*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Forward Sensing Camera
(FSC)................................... 5-127Forward Sensing Camera
(FSC)
*............................... 5-127
Radar Sensors.......................5-131 Radar Sensors
*...................5-131
Ultrasonic Sensors.................5-135 Ultrasonic Sensors
*............ 5-135
Cameras.............................. 5-137 Cameras
*.......................... 5-137
Driver Monitoring Camera..... 5-139 Driver Monitoring Camera
*..........
........................................ 5-139
High Beam Control System
(HBC).................................. 5-140 High Beam Control System
(HBC)
*.............................. 5-140
Warnings and Cautions for Using
the High Beam Control System
(HBC)............................... 5-141
How to Use the High Beam
Control System (HBC)........ 5-142
Lane Departure Warning System
(LDWS)................................ 5-144 Lane Departure Warning System
(LDWS)
*............................ 5-144
Warnings and Cautions for Using
the Lane Departure Warning
System (LDWS).................. 5-144
How to Use the Lane Departure
Warning System (LDWS)..... 5-145
Blind Spot Monitoring (BSM).. 5-146
Blind Spot Monitoring (BSM)
*......
........................................ 5-146
Warnings and Cautions for Using
the Blind Spot Monitoring
(BSM)............................... 5-146
How to Use the Blind Spot
Monitoring (BSM).............. 5-147
Traffic Sign Recognition System
(TSR)................................... 5-150 Traffic Sign Recognition System
(TSR)
*................................5-150
Warnings and Cautions for Using
the Traffic Sign Recognition
System (TSR)..................... 5-150
How to Use the Traffic Sign
Recognition System (TSR)... 5-151
Convenient Ways to Use the
Traffic Sign Recognition
System (TSR)..................... 5-152
Distance & Speed Alert (DSA) ..........
.......................................... 5-153 Distance & Speed Alert (DSA)
*.....
........................................ 5-153
Warnings and Cautions for Using
the Distance & Speed Alert
(DSA)............................... 5-153
How to Use the Distance &
Speed Alert (DSA)............. 5-154
Driver Attention Alert (DAA)...5-155 Driver Attention Alert (DAA)
*.......
........................................ 5-155
Warnings and Cautions for Using
the Driver Attention Alert
(DAA)............................... 5-155
*Some models.5-5
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Driver Attention
Alert (DAA)....................... 5-156
Driver Monitoring (DM).........5-157 Driver Monitoring (DM)
*.... 5-157
Warnings and Cautions for Using
the Driver Monitoring
(DM)................................ 5-158
How to Use the Driver
Monitoring (DM)............... 5-158
Front Cross Traffic Alert (FCTA) .........
.......................................... 5-160 Front Cross Traffic Alert
(FCTA)
*............................. 5-160
Warnings and Cautions for Using
the Front Cross Traffic
Alert (FCTA)...................... 5-160
How to Use the Front Cross Traffic
Alert (FCTA)...................... 5-161
Rear Cross Traffic Alert (RCTA) .........
.......................................... 5-163 Rear Cross Traffic Alert (RCTA)
*....
........................................ 5-163
Warnings and Cautions for Using
the Rear Cross Traffic Alert
(RCTA).............................. 5-163
How to Use the Rear Cross Tra ffi c
Alert (RCTA)...................... 5-164
Mazda Radar Cruise Control
(MRCC)............................... 5-165 Mazda Radar Cruise Control
(MRCC)
*........................... 5-165
Warnings and Cautions for Using
the Mazda Radar Cruise Control
(MRCC)............................ 5-165
How to Use the Mazda Radar
Cruise Control (MRCC)...... 5-167
Cruising & Traffic Support
(CTS)................................... 5-175 Cruising & Traffic Support
(CTS)
*............................... 5-175
Warnings and Cautions for Using
Cruising & Traffic Support
(CTS)................................ 5-175
How to Use the Cruising & Traffic
Support (CTS)................... 5-177
Lane-keep Assist System (LAS) ..........
.......................................... 5-188 Lane-keep Assist System (LAS)
*.....
........................................ 5-188
Warnings and Cautions for Using
the Lane-keep Assist System
(LAS).................................5-188
How to Use the Lane-keep Assist
System (LAS)..................... 5-189
Emergency Lane Keeping
(ELK)................................... 5-191 Emergency Lane Keeping
(ELK)
*................................ 5-191
Warnings and Cautions for Using
the Emergency Lane Keeping
(ELK)................................. 5-192
How to Use the Emergency Lane
Keeping (ELK).................... 5-193
Smart Brake Support (SBS)..... 5-197 Smart Brake Support (SBS)
*..........
........................................ 5-197
Warnings and Cautions for Using
the Smart Brake Support
(SBS).................................5-199
5-6*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Smart Brake
Support (SBS).................... 5-200
360° View Monitor............... 5-206 360° View Monitor
*........... 5-206
Warnings and Cautions for Using
the 360° View Monitor...... 5-210
How to Use the 360° View
Monitor............................ 5-212
Convenient Ways to Use the 360°
View Monitor.................... 5-222
Secondary Collision
Reduction............................ 5-223 Secondary Collision
Reduction
*........................ 5-223
Warnings and Cautions for Using
the Secondary Collision
Reduction......................... 5-223
How to Use the Secondary
Collision Reduction........... 5-224
Cruise Control......................5-225 Cruise Control
*.................. 5-225
Warnings and Cautions for Using
the Cruise Control............. 5-225
How to Use the Cruise
Control............................. 5-226
Rear View Monitor................5-229 Rear View Monitor
*........... 5-229
Warnings and Cautions for Using
the Rear View Monitor....... 5-230
How to Use the Rear View
Monitor............................ 5-231
Parking Sensor......................5-234 Pa r k i n g S e n s o r
*.................. 5-234
Warnings and Cautions for Using
the Parking Sensor............. 5-234
How to Use the Parking
Sensor...............................5-235
Winter Driving......................5-240 Winter Driving................... 5-240
Snow Tires........................ 5-241
Tire Chains........................ 5-241
*Some models.5-7
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautionsfor Using the Mirrors
WARNING
Be sure to look over your shoulder
before changing lanes.
Changing lanes without taking into
account the actual distance of a vehicle
in the convex mirror is dangerous. You
could have a serious accident. What
you see in the convex mirror is closer
than it appears.
Always return the outside mirrors to
the driving position before you start
driving.
Driving with the outside mirrors folded
in is dangerous. Your rear view will be
restricted, which could lead to an
unexpected accident.

(Vehicles with electric retractable
mirrors)
Do not touch the outside mirrors
while they are folding in and out.
Touching an outside mirror while it is
folding in or out is dangerous. Your
hands could get caught which could
cause an injury or the door mirror
could be damaged.
Use the switch to set the outside
mirrors.
Setting the outside mirrors manually is
dangerous. The outside mirrors will not
lock into place, which could obstruct
visibility.
Always operate the electric retractable
mirrors with the vehicle parked in a
safe place.
Operating the electric retractable
mirrors while driving is dangerous.
Wind pressure could damage the
outside mirrors, making it impossible
to return them to the driving position
and to see behind you.
Do not adjust the outside mirrors
while driving the vehicle.
Adjusting the outside mirrors while
driving the vehicle is dangerous as
doing so could distract your attention
from the road ahead and lead to an
accident.
CAUTION
(Vehicles with electric retractable
mirrors)
Operate the folding switch to fold in or
out the outside mirrors. If you unfold
the outside mirrors manually, they will
not be in a secured position and you
will be unable to check the view to the
rear of the vehicle.
Driving
Mirrors
5-8
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the OutsideMirrors
Folding in and out the outside mirrors
Manual type
Fold the outside mirror rearward until
it is flush with the vehicle.
Electric type
1. Switch the vehicle power ACC orON.
2. Press the folding mirror button to
fold the mirror in. Press again to
fold out.
Adjusting the Outside Mirror Angle
1. Switch the vehicle power ACC orON.
2. Press the select button on the side of the outside mirror to be
adjusted.
The indicator light turns on.
3. Press the adjustment switch to
adjust the angle of the outside
mirror.
4. Press the select button on the sideof the outside mirror that has been
adjusted.
The indicator light turns off.
Driving
Mirrors
5-9
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
