Clear snow from underneath and
around your vehicle, particularly the
tail pipe, before starting the engine:
Running the engine when a vehicle is
stopped in deep snow is dangerous.
The exhaust pipe could be blocked by
the snow, allowing exhaust gas to
enter the cabin. Because exhaust gas
contains poisonous carbon monoxide,
it could cause loss of consciousness or
even death to occupants in the cabin.
Driving
Refueling
5-110
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Warnings and CautionsFor Charging
WARNING
For occupants who use any medical
device such as an implanted-type
heart pacer or defibrillator, ask a
doctor or manufacturer of the device
about how the medical device may be
affected by the charging operation.
Otherwise, the operation of the
medical device could be affected
resulting in an accident.
For occupants who use any medical
device such as an implanted-type
heart pacer or defibrillator, do not
enter the cabin including the luggage
compartment while charging.
Otherwise, the operation of the
medical device could be affected
resulting in an accident.
Do not disassemble or modify the
charge port and the charge cable.
Otherwise, it could lead to an
electrical shock resulting in an
accident.
Always heed the following when
charging.
Otherwise, it could lead to an
electrical shock resulting in an
accident.
Never allow children to charge the
battery.
 Do not charge the battery while the
vehicle is covered with a car cover.
Always heed the following when
charging in the rain or snow.
Otherwise, it could lead to an
electrical shock resulting in an
accident.
 Do not charge the battery outside if
there is the possibility of heavy rain,
strong winds, or lightning.
 Remove water with a clean cloth if
the charge connector or charge plug
is wet.
 Do not touch the charge port or
charge cable with wet hands.
 If the outlet is covered with snow
while charging, turn
off the power
such as turning off the breaker,
remove the snow, and then remove
the charge plug.
Refer to the instruction manual
accompanying the charge cable and
use the charge cable correctly.
If you handle the charge cable
mistakenly, it could result in an
unexpected accident.
Do not use the charge cable if it has
any of the following malfunctions.
Otherwise, it could lead to an
electrical shock resulting in an
accident.
 The charge connector is rusted or
corroded.
 The charge connector is damaged or
foreign matter penetrates the charge
connector.
Always heed the following when
using the charge cable.
Otherwise, the charge cable could be
damaged resulting in an accident.
 Do not pull out or bend the charge
cable excessively.
 Do not step on the charge cable or
drag it on the ground.
Driving
Charging
5-111
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

When inserting/pulling out the
charge connector and the charge
plug, do not twist them excessively.
 Do not apply excessive force to the
connected charge connector such as
by applying your weight.
 Keep objects which generates
intense heat (such as a heater or
cigarette) away from the charge
cable.
 Do not apply orga nic solvents, acid
or alkaline agents to the charge
cable.
CAUTION
 Do not connect the booster cable to
the lead-acid battery or remove the
lead-acid battery while charging the
high voltage battery. Otherwise, the
vehicle or charging device could be
damaged.
 If the charge connector is removed
after the charging is
finished, close
the charging port cap immediately. If
the charging port lid is closed with
the charging port cap open, water or
foreign matter may enter the
charging inlet causing a malfunction.
 Always make sure that the charge
cable is not connected to the vehicle
before driving. If the charge
connector is connected correctly, the
vehicle cannot be driven. However, if
it is not connected completely, the
vehicle can be driven, which could
result in an accident.
 If the charging port is frozen shut,
defrost the port using a hair dryer. If
the charge cable is inserted/pulled
out with the charging inlet frozen, it
could cause damage.
Driving
Charging
5-112
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Charging Related Part Overview
Charge cable
The charge cable is connected to the electrical outlet and the vehicle to send
electrical power to the vehicle. For details regarding the charge cable, refer to the
instruction manual accompanying the charge cable.
1. Charge connector
2. Control box
3. Charge plug
charge connector
The charge connector is the part used for connecting to the charging port on the
vehicle side.
When the charge connector is connected to the charging port, a vehicle system locks
the charge connector.
When the charge connector is locked by the vehicle system, it unlocks when the
driver’s door is unlocked.
If the charge connector locked by the vehicle system is not unlocked even though
the driver’s door is unlocked, consult an Authorized Mazda Dealer.
NOTE
The conditions for locking the vehicle system can be changed.
Refer to Convenient Ways to Use of Charging on page 5-118.
Control box
The control box indicates the charge status by turning on/flashing the indicator light.
For the indicator light illumination/flash pattern, refer to the instruction manual
accompanying the charge cable.
charge plug
The charge plug is the part for connecting to the electrical outlet.

In general, keep the charge cable at home. If the charge cable is kept in the vehicle,
firmly secure it using the following procedure.
1. Store the charge cable in its special storage bag.
Driving
Charging
5-113
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

2. Attach the 2 hooks of the storage bag to each of the 2 luggage hooks on the right
side of the luggage compartment, and tightly secure the storage bag. At this
time, make sure that the logo on the storage bag is facing toward the center of
the luggage compartment.
CAUTION
Be careful when handling the storage bag because the hooks on the storage bag
have sharp areas. If your hands or fingers touch the sharp areas, your hands or
fingers could be injured.
NOTE
When the storage bag hooks and the luggage hooks hit against each other, they
make noise. If the noise distracts your attention while driving , wrap the included
sheet around the areas the hooks make contact.
Charge port
1. Charging indicator
2. Charge port
3. Charging port cap
4. Charging port lid
Driving
Charging
5-114
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Charging indicator
The charging indicator indicates the charging status by turning
on/flashing the light.
For the charging indicator illumination/flash pattern, refer to [Charging].
Charging port lid
The charging port lid is locked/unlocke d in conjunction with the door locking/
unlocking mechanism.
When unlocking the driver’s door, the charging port lid is unlocked. When locking
the driver’s door, the charging port lid is locked.
However, if the driver’s door is unlocked using the auxiliary key, the charging port lid
is not unlocked.
NOTE
When the driver's door is locked using an y of the following functions, the charging
port lid is also locked at the same time.
Vehicle speed sensing auto door lock functionAuto re-lock function
Charge port
The charge port is the part used for connecting to the charge connector of the
charge cable. It is used for charging.
Driving
Charging
5-115
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Perform Charging
It can be charged with a maximum of
7.2 kW of power.
When charging is started after the high
voltage battery warning indication/
warning light turns on, the time until
fully charged is as follows.
(7.2 kW normal charging)
About 2.5 hours
For charging, the charging timer
function can be used to charge
automatically from start to finish. For
details on use, refer to [Charging
Settings].
NOTE
Installation of charging equipment is
required for 7.2 kW normal charging.
Consult an Authorized Mazda Dealer
for details.
If a power outage occurs while
charging, remove the charge plug
and the charge connector and start
charging from the beginning again.
Make sure that no water has
accumulated in the charge connector
and the charging port before
charging. If any foreign matter enters
the charge connector or the charging
port, do not start charging and
consult an Authorized Mazda Dealer.
1. Switch the vehicle power OFF.
2.
3. Open the charging port cap.
4. Connect the charge plug to the outlet.
5. Connect the charge connector to the charging port.
Charging starts after connection is
completed.
NOTE
When the charging timer is set,
charging does not start even if the
charge connector is connected.
When you prefer to start charging
immediately, use the charging timer
cancellation function.
Make sure to lock all the doors
before leaving the vehicle while
charging.
6. When charging is finished, unlock the door to unlock the charge
connector.
7. Remove the charge connector.
8. Close the charging port cap.
9. Close the charging port lid.
10.Disconnect the charge plug.
Driving
Charging
5-116
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Charge indicator
The illumination/flash pattern of the
charge indicator can be checked using
the labels on the charge lid.
Charge indicator
illumination/flash pattern Content
— OFF Charging is possible.
(White) ON
Turns on when waiting for
starting to charge.
(White) Flashes
slowly The brightness changes
when the charging timer is
set.
(Green)
Flashes
slowly The brightness changes
during charging.
(Green)
ONTu r n s o n w h e n c h a rg i n g i s
completed.
Turns off after a certain pe-
riod of time has passed
since charging was com-
pleted.
(Amber)
FlashesFlashes when the charging
connector is connected and
the selector lever is in a po-
sition other than P.
Shift the selector lever to
the P position.
Charge indicator
illumination/
flash pattern Content
(Amber)
ONTurns on if there is a prob-
lem with the charging sys-
tem when the charging
connector is connected.
Wait a few minutes then re-
connect the charging con-
nector.
(Red)
ONTurns on if there is a prob-
lem with the charging sys-
tem and the charging port
lid is opened or the charg-
ing connector is connected.
Have your vehicle inspect-
ed by an Authorized Mazda
Dealer.
Charge status screen
When the driver's door is opened
while the charge connector is
connected, the charging status is
displayed in the instrument cluster.
1. Charge status icon
2. Message
3. Remaining power of the high
voltage battery (Displayed only
when vehicle power is switched
OFF)
4. Time to complete charging
5. EV maximum driving distance (Displayed only when vehicle
power is switched OFF)
Driving
Charging
5-117
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

NOTE
When charging is started, the charging
status screen is displayed. The charging
status screen turns off after a certain
period of time passes or the doors or
liftgate is locked. The screen is
displayed again when the doors or
liftgate is unlocked.Convenient Ways to Useof Charging
Charging Schedule
Timer charging is a function which
charges the battery automatically ac-
cording to a preset time.
You can charge the battery using this
function during time periods when
electricity rates are low. In addition,
the maximum charge limit can be set
and changed.
1. Select Settings from the homescreen on Mazda Connect.
2. Select EV Settings from the setting
screen.
3. Select Charging Schedule from the selection screen.
Function Available setting changes
1 ----
Enable, Disa-ble
*1Edit, Delete*2
2 ----
3 ----
4 ----
5 ----
6 ----
7 ----
*1 If a list selected using the cursor has beenset, the item can be Enable or Disable.
*2 Settings can be Edit/Delete by sliding a listselected using the cursor to the right.
NOTE
The charging timer does not work
immediately after the lead-acid
battery is removed or installed, or
when no GPS signal has been
received. When charging without
receiving GPS, charging begins.
When GPS signals are received, the
charging timer becomes operational.
Driving
Charging
5-118
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Immediately after switching to
daylight savings, charging may occur
at the charging timer time set before
the switch to daylight savings until
the vehicle power is switched ON.
Edit
Function Available setting
changes
Start Time
Select the desired charging
start time. Time
(10-minute inter- vals)
End Time
Select the desired charging
end time. Time
(10-minute inter- vals)
Repeat
Select the day(s) of the
week to repeat. Monday
― Sun-
day
Charge Limit
Select the desired charge
limit method. According to Bat-
tery Charge Level, According to Esti- mated Range
Battery Charge Level
*1
Select the desired maxi-
mum charge level. 100%
― 20%
(9 levels)
Estimated Range
*2
Select the desired estimat-
ed range. In 10 km (10 mi)
increments
*1 Can be changed when According to Battery
Charge Level is selected for Charge Limit.
Use when you want to charge only the
amount of charging you need. This helps you
save power and prevent high voltage battery
deterioration.
*2 Can be changed when According toEstimated Range is selected for Charge
Limit.
Use when you want to charge according to
your planned driving distance.
The distance-to-full discharge changes
depending on the driving conditions and
surrounding environment. Check the actual
remaining distance-to-full discharge.
If you change the distance unit after setting
the Estimated Range, the Estimated Range
will be calculated in the unit after the
change. (If you change the units to miles
after setting the estimated range to 100 km,
the charge distance will be for 60 miles.)
NOTE
A charging day is set using Repeat
If 1 repeat day is set, charging is
repeated every week on the set day
of the week.
Depending on the set days of the
week, the Repeat indication is
displayed as Weekdays, Weekends,
and Daily. Otherwise, it is displayed
as Custom.
Setting example
Function Available setting
changes
Start Time 21 : 00
End Time 6 : 00
Repeat Friday
Charge Limit According to Bat-
tery Charge Level
Battery Charge Level 80%
In this case, charging is done every
week from Friday at 21 : 00 hours to
Saturday at 6:00 hours. However, if
the Battery Charge Level reaches
80%, the charging is stopped even if
it is before the End Time.
No day is set using Repeat
If no Repeat day is designated,
charging is done only 1 time at the
set hours.
Setting example (if settings below are
made at 13 : 00 hours)
Function Available setting
changes
Start Time 12 : 00
End Time 18 : 00
Driving
Charging
5-119
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
