MAZDA MODEL CX-5 2017 Owners Manual (in English)

6–45
Maintenance and Care
Owner Maintenance
*Some models.
CAUTION
When removing the lens or lamp unit
using a fl athead screwdriver, make
sure that the fl athead screwdriver does
not contact the interior terminal. If
the fl athead screwdriver contacts the
terminal, a short circuit may occur.

NOTE
  To replace the bulb, contact an
Authorized Mazda Dealer.
  Use the protective cover and carton for
the replacement bulb to dispose of the
old bulb promptly and out of the reach
of children.

Replacing Exterior Light Bulbs
Headlights/Daytime running lights,
Daytime running lights/Parking lights
(Type A), Front side-marker lights
(Type A), Fog lights
* , Brake lights (Type
A), Taillights (Type A), Reverse lights,
High-mount brake light, Side turn
signal lights, Rear side-marker lights
(Type A)
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized Mazda
Dealer when the replacement is necessary.
Front turn signal lights/Parking lights
1. Make sure the ignition is switched off, and the headlight switch is off.
2. Lift the hood.
Refer to Hood on page 6-20 .
3. Turn the socket and bulb assembly counterclockwise and remove it.
4. Disconnect the bulb from the socket.


5. Install the new bulb in the reverse order of the removal procedure.

Front side-marker lights (Type B)
1. Make sure the ignition is switched off, and the headlight switch is off.
2. If you are changing the right bulb, start the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right.
3. Pull the center of each plastic retainer using a fl athead screwdriver and
remove the retainers, and then partially
peel back the over fender.

Removal
Installation

CX-5_8FN1-EA-16L_Edition1.indb 452016/12/12 10:07:13

6–46
Maintenance and Care
Owner Maintenance
4. Pull the center of each plastic retainer using a fl athead screwdriver and
remove the retainers, and then partially
peel back the mudguard.

Removal
Installation

5. Turn the socket and bulb assembly counterclockwise and remove it.
6. Disconnect the bulb from the socket.


7. Install the new bulb in the reverse order of the removal procedure.

Rear turn signal lights, Brake lights/
Taillights/Rear side-marker lights (Type
B)
1. Make sure the ignition is switched off, and the turn signal switch is off.
2. Wrap a small fl athead screwdriver with
a soft cloth to prevent damage to the
cover, and then remove the cover with
the fl athead screwdriver.


3. Turn the bolts counterclockwise and remove them.


CX-5_8FN1-EA-16L_Edition1.indb 462016/12/12 10:07:14

6–47
Maintenance and Care
Owner Maintenance
4. Pull the unit rearward to remove it.

5. Turn the socket and bulb assembly counterclockwise and remove it.
6. Disconnect the bulb from the socket.
Rear turn signal lights


Brake lights/Taillights/Rear side- marker lights


7. Install the new bulb in the reverse order of the removal procedure.

License plate lights
1. Make sure the ignition is switched off, and the headlight switch is off.
2. Wrap a fl athead screwdriver with a soft
cloth to prevent damage to the lens,
and then remove the lens by carefully
prying on the edge of the lens with a
fl athead screwdriver.
3. Disconnect the bulb by pulling it out.


4. Install the new bulb in the reverse order of the removal procedure.

CX-5_8FN1-EA-16L_Edition1.indb 472016/12/12 10:07:14

6–48
Maintenance and Care
Owner Maintenance
*Some models.
Replacing Interior Light Bulbs
Overhead light/Front map lights, Rear
map lights, Vanity mirror lights *
1. Wrap a fl athead screwdriver with a soft
cloth to prevent damage to the lens,
and then remove the lens by carefully
prying on the edge of the lens with a
fl athead screwdriver.
2. Disconnect the bulb by pulling it out.
Overhead light/Front map lights



Rear map lights




Vanity mirror lights *


3. Install the new bulb in the reverse order of the removal procedure.

CX-5_8FN1-EA-16L_Edition1.indb 482016/12/12 10:07:14

6–49
Maintenance and Care
Owner Maintenance
Luggage compartment light
1. Wrap a small fl athead screwdriver
with a soft cloth to prevent damage to
the lens and remove the lens unit by
carefully prying on the edge of the lens
unit with the fl athead screwdriver.


2. Disconnect the electrical connector from the bulb by pressing the tab on the
connector with your fi nger and pulling
the connector.


CAUTION
When replacing the bulb always
disconnect the connector fi rst.
Otherwise, electric and electronic
devices could be shorted.

3. Insert the fl athead screwdriver into the
gap between the lens and the lens unit,
and then slide the screwdriver to detach
the lens.


4. Disconnect the bulb by pulling it out.


5. Install the new bulb in the reverse order of the removal procedure.

CX-5_8FN1-EA-16L_Edition1.indb 492016/12/12 10:07:15

6–50
Maintenance and Care
Owner Maintenance
Fuses
Your vehicle's electrical system is
protected by fuses.

If any lights, accessories, or controls do
not work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.

If the same fuse blows again, avoid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
Fuse Replacement
Replacing the fuses on the vehicle's left
side
If the electrical system does not work, fi rst
inspect the fuses on the vehicle's left side.


1. Make sure the ignition is switched off, and other switches are off.
2. Open the fuse panel cover.

3. Pull the fuse straight out with the
fuse puller provided on the fuse block
located in the engine compartment.


4. Inspect the fuse and replace it if it is blown.

Normal Blown

5. Insert a new fuse of the same amperage rating, and make sure it fi ts tightly. If
it does not fi t tightly, have an expert
install it. We recommend an Authorized
Mazda Dealer.
If you have no spare fuses, borrow one of the same rating from a circuit not
essential to vehicle operation, such as
the AUDIO or OUTLET circuit.
CAUTION
Always replace a fuse with a genuine
Mazda fuse or equivalent of the same
rating. Otherwise you may damage
the electric system.

CX-5_8FN1-EA-16L_Edition1.indb 502016/12/12 10:07:15

6–51
Maintenance and Care
Owner Maintenance
6. Reinstall the cover and make sure that it is securely installed.

Replacing the fuses under the hood
If the headlights or other electrical
components do not work and the fuses
in the cabin are normal, inspect the fuse
block under the hood. If a fuse is blown, it
must be replaced. Follow these steps:


1. Make sure the ignition is switched off, and other switches are off.
2. Remove the fuse block cover.


3. If any fuse but the MAIN fuse is blown, replace it with a new one of the
same amperage rating .

Normal Blown

WARNING
Do not replace the main fuse by
yourself. Have an Authorized Mazda
Dealer perform the replacement:
Replacing the fuse by yourself is
dangerous because the MAIN fuse
is a high current fuse. Incorrect
replacement could cause an electrical
shock or a short circuit resulting in a
fi r e .

4. Reinstall the cover and make sure that it is securely installed.

CX-5_8FN1-EA-16L_Edition1.indb 512016/12/12 10:07:16

6–52
Maintenance and Care
Owner Maintenance
*Some models.
Fuse Panel Description
Fuse block (Engine compartment)

DESCRIPTION FUSE
RATING PROTECTED COMPONENT
1
50 A For protection of various circuits
2 IG2 30 A For protection of various circuits
3 INJECTOR
ENG.SUB 30 A Engine control system
4 SCR1
EVVT 20 A Engine control system
5 P.WINDOW1 30 A Power windows
6 R.HEATER 20 A —
7 ADD FAN DE 40 A —
8 WIPER.DEI 20 A Windshield wiper de-icer
*
9 DEFOG 40 A Rear window defogger
10 DCDC DE 40 A —
11 EPB R 20 A Electric parking brake (EPB) (RH)
12 EPB L 20 A Electric parking brake (EPB) (LH)
13 AUDIO
DCDC REG 30 A Audio system
*
CX-5_8FN1-EA-16L_Edition1.indb 522016/12/12 10:07:16

6–53
Maintenance and Care
Owner Maintenance
*Some models.
DESCRIPTION FUSE
RATING PROTECTED COMPONENT
14 FAN GE 30 A Cooling fan
15 ENG.MAIN 40 A Engine control system
16 ABS/DSC M 50 A ABS, Dynamic stability control system
17 FAN DE 40 A —
18 WIPER 20 A Front window wiper and washer
19 HEATER 40 A Air conditioner
20 ADD FAN GE 30 A Cooling fan
21 ENGINE.IG1 7.5 A Engine control system
22 C/U IG1 15 A For protection of various circuits
23 AUDIO2 7.5 A Audio system
24 METER2 7.5 A —
25 ENGINE3 15 A Engine control system
26 ENGINE2 15 A Engine control system
27 ENGINE1 15 A Engine control system
28 AT 15 A Transaxle control system
* , Ignition switch
29 H/CLEAN 20 A —
30 A/C 7.5 A Air conditioner
31 AT PUMP 15 A Transaxle control system
*
32 HORN 15 A Horn
33 R.WIPER 15 A Rear window wiper
34 H/L HI 20 A Headlight high beam
35 ST.HEATER 15 A Heated steering wheel
*
36 FOG 15 A Fog lights *
37
7.5 A Engine control system
38 H/L LOW L 15 A Headlight low beam (LH)
39 ENGINE4 15 A —
40 — — —
41 METER1 10 A Instrument cluster
42 SRS1 7.5 A Air bag
43 BOSE 25 A Bose
® Sound System-equipped model *
44 AUDIO1 15 A Audio system
45 ABS/DSC S 30 A ABS, Dynamic stability control system
46 FUEL PUMP 15 A Fuel system
47 FUEL WARM 25 A —
48 TAIL 15 A Taillights, License plate lights
49 SCR2
FUEL PUMP2 25 A
—
50 HAZARD 25 A Hazard warning
fl ashers, Turn signal lights/Front side-marker
lights, Parking lights
CX-5_8FN1-EA-16L_Edition1.indb 532016/12/12 10:07:16

6–54
Maintenance and Care
Owner Maintenance
*Some models.
DESCRIPTION FUSE
RATING PROTECTED COMPONENT
51 H/L LOW R 15 A Headlight low beam (RH)
52 OUTLET 25 A Accessory sockets
53 STOP 10 A Brake lights
54 ROOM 15 A Overhead light

Fuse block (Left side)


DESCRIPTION FUSE
RATING PROTECTED COMPONENT
1 P.SEAT D 30 A Power seat
*
2 P.WINDOW3 30 A —
3 R.OUTLET3 15 A Accessory sockets
4 P.WINDOW2 25 A Power windows
5 ESCL 15 A Electronic steering lock
*
6 D.LOCK 25 A Power door locks
7 SEAT WARM 20 A Seat warmer
*
8 SUNROOF 10 A Moonroof *
9 F.OUTLET 15 A Accessory sockets
10 MIRROR 7.5 A Power control mirror
