Essential Safety Equipment
Seat Belt Systems
*Some models.
Pregnant Women and Persons with Serious Medical Conditions
Pregnant women should always wear seat belts. Ask your doctor for specifi c
recommendations.
The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS.
The shoulder belt should be worn across your shoulder properly, but never across the
stomach area.
Persons with serious medical conditions also should wear seat belts. Che\
ck with your doctor
for any special instructions regarding speci fi c medical conditions.


Emergency Locking Mode
When the seat belt is fastened, it will always be in the emergency locking mode.
In the emergency locking mode, the belt remains comfortable on the occupant and the\

retractor will lock in position during a collision.
If the belt is locked and cannot be pulled out, retract the belt once, a\
nd then try pulling it out
slowly. If this fails, pull the belt strongly one time and loosen, then pull i\
t out again slowly.
(Seat Belt with Automatic Locking Mode)
When the seat belt is fastened, it will always be in the emergency locking mode until it is
switched to automatic locking mode by pulling it all the way out to its \
full length. If the belt
feels tight and hinders comfortable movement while the vehicle is stoppe\
d or in motion, it
may be in the automatic locking mode because the belt has been pulled to\
o far out. To return
the belt to the more comfortable emergency locking mode, wait until the vehicle has stopped
in a safe, level area, retract the belt fully to convert it back to emer\
gency locking mode and
then extend it around you again.
Automatic Locking Mode *
Always use the automatic locking mode to keep the child-restraint system\
from shifting to
an unsafe position in the event of an accident. To enable seat belt automatic locking mode,
pull it all the way out and connect it as instructed on the child-restra\
int system. It will retract
down to the child-restraint system and stay locked on it. See the sectio\
n on child restraint
(page 2-28 ).
CX-5_8FN1-EA-16L_Edition1.indb 222016/12/12 10:05:19

2–26
Essential Safety Equipment
Seat Belt Systems
NOTE
  The pretensioner system may not
operate depending on the type of the
collision. For details, refer to the SRS
Air Bag Deployment Criteria (page
2-58 ).
  Some smoke (non-toxic gas) will
be released when the air bags and
pretensioners deploy. This does not
indicate a fi re. This gas normally has
no effect on occupants, however, those
with sensitive skin may experience
light skin irritation. If residue from the
deployment of the air bags or the front
pretensioner system gets on the skin
or in the eyes, wash it off as soon as
possible.

Seat Belt Extender
If your seat belt is not long enough, even
when fully extended, a seat belt extender
may be available to you at no charge from
your Authorized Mazda Dealer.
This extender will be only for you and for
the particular vehicle and seat. Even if it
plugs into other seat belts, it may not hold
in the critical moment of a crash.
When ordering an extender, only order
one that provides the necessary additional
length to fasten the seat belt properly.
Please contact your Authorized Mazda
Dealer for more information.
CX-5_8FN1-EA-16L_Edition1.indb 262016/12/12 10:05:19

2–27
Essential Safety Equipment
Seat Belt Systems
WARNING
Do not use a seat belt extender unless it
is necessary: Using a seat belt extender when not
necessary is dangerous. The seat belt
will be too long and not fi t properly.
In an accident, the seat belt will not
provide adequate protection and you
could be seriously injured. Only use the
extender when it is required to fasten
the seat belt properly.

Do not use an improper extender: Using a seat belt extender that is for
another person or a diff erent vehicle
or seat is dangerous. The seat belt will
not provide adequate protection and
the user could be seriously injured in
an accident. Only use the extender
provided for you and for the particular
vehicle and seat. NEVER use the
extender in a diff erent vehicle or seat.
If you sell your Mazda, do not leave
your seat belt extender in the vehicle. It
could be used accidentally by the new
owner of the vehicle. After removing
the seat belt extender, discard it. Never
use the seat belt extender in any other
vehicle you may own in the future.

Do not use an extender that is too long: Using an extender that is too long is
dangerous. The seat belt will not fi t
properly. In an accident, the seat belt
will not provide adequate protection
and you could be seriously injured.
Do not use the extender or choose
one shorter in length if the distance
between the extender's buckle and the
center of the user's body is less than
15 cm (6 in).
Do not leave a seat belt extender
connected to the buckle:
Leaving a seat belt extender connected
to the buckle without using the seat
belt is dangerous. When the seat belt
extender is connected to the driver's
seat belt buckle (or front passenger's
seat belt buckle), the SRS driver's (or
front passenger's) air bag system will
determine that the driver (or front
passenger) is wearing the seat belt
even if the driver (or front passenger)
is not wearing it. This condition could
cause the driver's (or front passenger's)
air bag to not activate correctly and
result in death or serious injury in the
event of collision. Always wear the seat
belt with the seat belt extender.

Do not use the seat belt extender when
installing a child-restraint system on the
front or rear passenger seat: Using a seat belt extender to fasten
a child-restraint system on any seat
is dangerous. Always follow the
child-restraint system manufacturer's
installation instructions and never use
a seat belt extender.

NOTE
When not in use, remove the seat belt
extender and store it in the vehicle. If the
seat belt extender is left connected, the
seat belt extender might get damaged
as it will not retract with the rest of the
seat belt and can easily fall out of the
door when not in use and be damaged. In
addition, the seat belt warning light will
not illuminate and function properly.

CX-5_8FN1-EA-16L_Edition1.indb 272016/12/12 10:05:20

2–36
Essential Safety Equipment
Child Restraint
3. Secure the child-restraint system with the lap portion of the lap/shoulder belt.
See the manufacturer's instructions
on the child-restraint system for belt
routing instructions.
4. To get the retractor into the automatic locking mode, pull the shoulder belt
portion of the seat belt until the entire
length of the belt is out of the retractor.


5. Push the child-restraint system fi rmly
into the vehicle seat. Be sure the
belt retracts as snugly as possible. A
clicking noise from the retractor will be
heard during retraction if the system is
in the automatic locking mode. If the
belt does not lock the seat down tight,
repeat this step.


NOTE
Inspect this function before each use of
the child-restraint system. You should
not be able to pull the shoulder belt out
of the retractor while the system is in the
automatic locking mode. When you remove
the child-restraint system, be sure the
belt fully retracts to return the system to
emergency locking mode before occupants
use the seat belts.

6. If your child-restraint system requires the use of a tether strap, refer to the
manufacturer's instructions to hook and
tighten the tether strap.

CX-5_8FN1-EA-16L_Edition1.indb 362016/12/12 10:05:21

2–40
Essential Safety Equipment
Child Restraint
5. To get the retractor into the automatic locking mode, pull the shoulder belt
portion of the seat belt until the entire
length of the belt is out of the retractor.
6. Push the child-restraint system fi rmly
into the vehicle seat. Be sure the
belt retracts as snugly as possible. A
clicking noise from the retractor will
be heard during retraction if the system
is in automatic locking mode. If the
belt does not lock the seat down tight,
repeat the previous step and also this
one.
NOTE
   Inspect this function before each use of
the child-restraint system. You should
not be able to pull the shoulder belt
out of the retractor while the system is
in the automatic locking mode. When
you remove the child-restraint system,
be sure the belt fully retracts to return
the system to emergency locking mode
before occupants use the seat belts.
  Follow the child-restraint system
manufacturer's instructions carefully.
 Depending on the type of child-restraint system, it may not employ seat belts
which are in automatic locking mode.

7. Seat your child safely in the child- restraint system and secure the child
according to the instructions from the
child-restraint system manufacturer. 8. Switch the ignition ON and make sure
the front passenger air bag deactivation
indicator light illuminates after
installing a child-restraint system on
the front passenger seat.
If the front passenger air bag deactivation indicator light does not
illuminate, remove the child-restraint
system, switch the ignition to OFF, and
then re-install the child-restraint system
(page 2-61 ).


CX-5_8FN1-EA-16L_Edition1.indb 402016/12/12 10:05:23

3–35
Before Driving
Steering Wheel
*Some models.
Steering Wheel
WARNING
Never adjust the steering wheel while
the vehicle is moving: Adjusting the steering wheel while
the vehicle is moving is dangerous.
Moving it can very easily cause the
driver to abruptly turn to the left or
right. This can lead to loss of control or
an accident.

Steering Wheel Adjustment
To change the angle or length of the
steering wheel:

1. Stop the vehicle, and then pull down the lock release lever under the steering
column.


Lock release lever
2. Tilt the steering wheel and/or adjust the steering column length to the desired
positions, then push the lever up to lock
the column.
3. Attempt to push the steering wheel up and down to make sure it's locked
before driving.

Heated Steering Wheel *
The grips on the left and right of the
steering wheel can be warmed up.

Heated steering
wheel switchHeating area

The ignition must be switched ON.

Press the switch to turn on the heated
steering wheel. The heated steering wheel
operates for about 30 minutes and then
turns off automatically.
The indicator light illuminates when the
heater is operating.

To turn off the heated steering wheel
before the 30 minutes has elapsed, press
the switch again.
CAUTION
The following types of persons should
be careful not to touch the steering
wheel. Otherwise, it could cause a low-
temperature burn.
 Infants, small children, elderly people, and physically challenged
people
 People with delicate skin People who are excessively fatigued People who are intoxicated People who have taken sleep-inducing medicine such as sleeping
pills or cold medicine

CX-5_8FN1-EA-16L_Edition1.indb 352016/12/12 10:05:34

3–61
Before Driving
Towing
Trailer Towing Tips
  Verify that your Mazda maintains a near-normal attitude when a loaded or unloaded trailer
is connected. Do not drive if it has an abnormal front-up or front-down \
position. Inspect
for incorrect tongue load, worn suspension parts, and trailer overloadin\
g.
   Make sure the trailer is properly loaded and the cargo is secure to prevent it from shifting.  Make sure the mirrors conform to all government regulations. If they do \
not, install
required rear view mirrors appropriate for towing purposes.

The three main causes of vehicle-trailer accidents are driver error, excessive speed, and
improper trailer loading.
Before driving
   Have your cooling and braking system checked by an Authorized Mazda Dealer.  Before starting out, inspect the operation of all vehicle and trailer li\
ghts and all vehicle-
to-trailer connections. Stop and re-inspect all lights and connections a\
fter driving a short
distance.

Driving
   Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and
stopping in a traf fi c-free area.
   Take time to get accustomed to the extra weight and length.  Allow more room between your vehicle and the one in front because brakin\
g distance
increases with a trailer. For each 16 km/h (10 mph) of speed, allow at least one vehicle
and trailer length between your Mazda and the vehicle ahead.
   Avoid jerky starts or sudden acceleration.  Avoid sudden braking. It may cause loss of control and result in jackkni fi ng, especially so
on wet or slippery roads.
   Shift the shift lever to the D position when towing a trailer in hilly t\
errain or when heavily
loaded.

The D position will allow operating the vehicle without frequent shiftin\
g.
Lane changes and turning
Avoid quick lane changes, sudden turns, and tight turns. Slow down before\
turning to avoid
the need of sudden braking.
A turning trailer will make a tighter arc than the tow vehicle. Compensat\
e with turns that are
larger than normal.
CX-5_8FN1-EA-16L_Edition1.indb 612016/12/12 10:05:39

4–132
When Driving
i-ACTIVSENSE
Stop Hold Control
While in headway control using the Mazda Radar Cruise Control with Stop \
& Go function
(MRCC with Stop & Go function) system, your vehicle will stop when a v\
ehicle ahead
stops. When the vehicle is stopped and the stop hold control operates, the Mazd\
a Radar
Cruise Control with Stop & Go function (MRCC with Stop & Go function) \
indicator light
turns on.


NOTE
  If the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) system is canceled during stop hold control, the vehicle is held in its stopped
position. The stop hold control can be canceled by performing one the following actions.
  Press the accelerator pedal and resume driving the vehicle.  While forcefully depressing the brake, switch the Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop & Go function) system off.
  The electric parking brake (EPB) is automatically applied and the vehi\
cle is held in its
stopped position when 10 minutes have elapsed since the stop hold control operated. At
this time, the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop &
Go function) system is canceled.
  The brake lights turn on during stop hold control.
To resume driving
After the vehicle ahead starts moving while your vehicle is stopped unde\
r stop hold control,
press the RES switch or depress the accelerator pedal to cancel the stop hold control\
and
resume driving.
NOTE
  When you resume driving by pressing the RES switch, your vehicle does not start moving
until the distance between your vehicle and the vehicle ahead lengthens \
to the speci fi ed
distance or farther.
   If the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) is temporarily canceled during stop hold control, you cannot resume driving by
pressing the RES switch when there are no vehicles in front of your vehicle. Depress the
accelerator pedal and resume driving the vehicle.

CX-5_8FN1-EA-16L_Edition1.indb 1322016/12/12 10:06:13

9–6
Specifi cations
Specifi cations
Dimensions
Item Vehicle specifi cation
Overall length 4,550 mm (179.1 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,675 mm (65.9 in)
Front tread 17 inch styled steel wheel vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel vehicle 1,596 mm (62.8 in)
Rear tread 17 inch styled steel wheel vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel vehicle 1,596 mm (62.8 in)
Wheelbase 2,698 mm (106.2 in)

Weights
U.S.A. and Canada
SKYACTIV-G 2.0
Item Indication on display
GVWR (Gross Vehicle Weight Rating) 1,944 kg (4,286 lbs)
GAWR (Gross Axle Weight Rating) Front
981 kg (2,163 lbs)
Rear 966 kg (2,130 lbs)

SKYACTIV-G 2.5
Item Indication on display
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,048 kg (4,515 lbs) 2,106 kg (4,643 lbs)
GAWR (Gross Axle Weight Rating) Front
1,057 kg (2,330 lbs) 1,075 kg (2,370 lbs)
Rear 994 kg (2,191 lbs) 1,034 kg (2,280 lbs)

CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:07:39
