Page 381 of 426
379 Technical data
Fuels, coolants, lubricants, etc.
Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which
provides:
Corrosion protection
Freeze protection
Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -22°F (-30°C) and
corrosion protection.
If the antifreeze mixture is effective
to -22°F (-30°C), the boiling point of the
coolant in the pressurized cooling system
is reached at approx. 266°F (130°C).The coolant solution must be used
year-round to provide the necessary corro-
sion protection and increase boil-over
protection. Refer to Maintenance Booklet
for replacement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable
if MB 325.0 anticorrosion/antifreeze
solution or other Mercedes-Benz approved
products of equal specification (see
Factory Approved Service Products
pamphlet) are used to renew the coolant
concentration or bring it back up to the
proper level.
To provide important corrosion protection,
the solution must be at least 45%
anticorrosion/antifreeze [equivalent to
freeze protection to approx. - 22°F
(-30°C)]. If you use a solution that is more than 55%
anticorrosion/antifreeze [freeze
protection to approx. - 49°F (-45°C)], the
engine temperature will increase due to
the lower heat transfer capability of the
solution. Therefore, do not use more than
this amount of anticorrosion/antifreeze.
If the coolant level is low, water and
MB 325.0 anticorrosion/antifreeze should
be used to bring it up to the proper level
(have cooling system checked for signs of
leakage). Please make sure the mixture is
in accordance with label instructions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality,
consult an authorized Mercedes-Benz
Center.
Page 382 of 426
380 Technical dataFuels, coolants, lubricants, etc.Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be specifi-
cally formulated to protect the aluminum
parts.Failure to use such anticorrosion/anti-
freeze coolant will result in a significantly
shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
Mercedes-Benz 325.0
Anticorrosion/Antifreeze Agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantityModel
Approx. freeze protection–35°F (–37°C)
–49°F (–45°C)
C 240 (all models)
3.4 US qt (3.2 l)
3.8 US qt (3.6 l)
Page 383 of 426
381 Technical data
Fuels, coolants, lubricants, etc.
Windshield washer and headlamp cleaning system*
Both the windshield washer and headlamp
cleaning system* are supplied from the
windshield washer fluid reservoir.
The washer fluid reservoir has a capacity of
approx.:
3.2 US qt (3.0 l) in vehicles without
headlamp cleaning system*
6.4 US qt (6.0 l) in vehicles with
headlamp cleaning system*
Refill the reservoir with MB Windshield
Washer Concentrate and water
(or concentrate and commercially
available premixed windshield washer
solvent/antifreeze, depending on
ambient temperatures).Washer fluid mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate “S”
and water:
1 part “S” to 100 parts water
(1.34floz [40ml]“S” to 1gallon [4.0l]
water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate “S”
and commercially available premixed
windshield washer solvent/antifreeze:
1part“S” to 100parts solvent
(1.34floz [40ml]“S” to 1gallon [4.0l]
solvent)
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.
Page 384 of 426
382 Technical dataConsumer informationThe following text is published as required
of all manufacturers of passenger cars
under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the
“National Traffic and Motor Vehicle Safety
Act of 1966”.Uniform tire quality grading
Quality grades can be found, where
applicable, on the tire sidewall between
tread shoulder and maximum section
width. For example:
All passenger car tires must conform to
federal safety requirements in addition to
these grades.Treadwear
The treadwear grade is a comparative
rating based on the wear rate of the tire
when tested under controlled conditions
on a specified government test course. For
example, a tire graded 150 would wear
one and one-half (1
1/2) times as well on
the government course as a tire
graded 100. The relative performance of
tires depends upon the actual conditions
of their use, however, and may depart
significantly from the norm due to varia-
tions in driving habits, service practices
and differences in road characteristics and
climate.Traction
The traction grades, from highest to lowest
are AA, A, B, and C. Those grades
represent the tire’s ability to stop on wet
pavement as measured under controlled
conditions on specified government test
surfaces of asphalt and concrete. A tire
marked C may have poor traction
performance.
Treadwear
Traction
Temperature
200
AA
A
Warning!
G
The traction grade assigned to this tire is
based on straight ahead braking traction
tests, and does not include acceleration,
cornering, hydroplaning, or peak traction
characteristics.
Page 385 of 426
383 Technical data
Consumer information
Temperature
The temperature grades are A (the
highest), B, and C, representing the tire’s
resistance to the generation of heat and its
ability to dissipate heat when tested under
controlled conditions on a specified indoor
laboratory test wheel. Sustained high
temperature can cause the material of the
tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden
tire failure. The grade C corresponds to a
level of performance which all passenger
car tires must meet under the Federal Mo-
tor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning!
G
The temperature grade for this tire is
established for a tire that is properly inflated
and not overloaded. Excessive speed,
underinflation, or excessive loading, either
separately or in combination, can cause
excessive heat build-up and possible tire
failure.
Page 386 of 426
384
Page 387 of 426
385 Technical terms
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.
BabySmart
TM1
air bag deactivation
system
This system detects if a special system
compatible child restraint seat is
installed on the front passenger seat.
The system will automatically deacti-
vate the passenger front air bag when
such a seat is properly installed
(the56indicator lamp located
in the center console comes on). See
an authorized Mercedes-Benz Center
for availability.BabySmart
TM compatible child seats
Special restraint system for children.
The sensor system for the passenger
seat prevents deployment of the
passenger front air bag if a
BabySmartTM compatible child seat is
installed.
BAS
(B
rake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking
situations. The system is activated
when it senses an emergency based on
how fast the brake is applied.
Bi-Xenon headlamps*
Headlamps which use an electric arc as
the light source and produce a more
intense light than filament headlamps.
Bi-Xenon headlamps produce low
beam and high beam.CAC
(C
ustomer A
ssistance C
enter)
Mercedes-Benz customer service
center, which can help you with any
questions about your vehicle and
provide assistance in the event of a
breakdown.
CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control
vehicle functions such as door locking
or windshield wiping depending on
vehicle settings and/or ambient
conditions.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the
passenger compartment needed for
vehicle operation and monitoring.
1BabySmart
TM is a trademark of Siemens
Automotive Corp.
Page 388 of 426
386 Technical termsCOMAND*
(C
ockpit M
anagement and D
ata
System)
Information and operating center for
vehicle sound and communications
systems, including the radio and the
navigation system, as well as other
optional equipment (CD changer*,
telephone*, etc.).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to
adjust settings.
Cruise control
Driving convenience system that
automatically maintains the vehicle
speed set by the driver.Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine
produced.
Engine oil viscosity
Measurement for the inner friction
(viscosity) of the oil at different temper-
atures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can
tolerate without becoming viscous, the
better the viscosity.
ESP
(E
lectronic S
tability P
rogram)
Improves vehicle handling and
directional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the
system's threshold to tighten the
seat belts.
->SRSFSS (Canada vehicles)
(F
lexible S
ervice S
ystem)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. FSS evaluates
engine temperature, oil level, vehicle
speed, engine speed, distance driven
and the time elapsed since your last
maintenance service, and calls for the
next maintenance service accordingly.
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the gear selector
lever.
GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special
receivers. Employs CD digital maps for
navigation.
Page 389 of 426
387 Technical terms
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision,
including the tachometer, speedo-
meter, engine temperature display and
fuel gauge.
Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the
vehicle and should not be used for
normal acceleration needs.
Lock button
Button on the door which indicates
whether the door is locked or
unlocked. Pushing the lock button
down on an individual door from inside
will lock that door.Maintenance System (U.S. vehicles)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. The Maintenance
System in your vehicle tracks distance
driven and the time elapsed since your
last maintenance service, and calls for
the next maintenance service accord-
ingly.
Memory function*
Used to store three individual seat,
steering wheel and mirror positions for
each SmartKey.
MON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized
method. It is an indication of a
gasoline's ability to resist undesired
detonation (knocking). The average of
both the MON (Motor Octane Number)
and ->RON (Research Octane Number)
is posted at the pump, also known as
ANTI-KNOCK INDEX.Multifunction display
Display field in the instrument cluster
used to present information provided
by the control system.
Multifunction steering wheel
Steering wheel with buttons for
operating the control system.
Overspeed range
Engine speeds within the red marking
of the tachometer dial. Avoid this
engine speed range, as it may result in
serious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.
Page 390 of 426
388 Technical termsPower train
Collective term designating all
components used to generate and
transmit motive power to the drive
axles, including
engine
clutch/torque converter
transmission
transfer case
drive shaft
differential
axle shafts/axles
Program mode selector switch
Used to switch the automatic trans-
mission between standard operationS
and comfort operationC.REST
(Residual engine heat utilization)
Feature that uses the engine heat
stored in the coolant to heat the
vehicle interior for a short time after
the engine has been turned off.
Restraint systems
Seat belts, belt tensioners, air bags
and child restraint systems. As inde-
pendent systems, their protective
functions complement one another.
RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired deto-
nation (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.Shift lock
When the vehicle is parked, this lock
prevents the transmission gear
selector lever from being moved out of
positionP without SmartKey turned
and brake pedal depressed.
SRS
(S
upplemental R
estraint S
ystem)
Seat belts, emergency tensioning
device and air bags. Though indepen-
dent systems, they are closely inter-
faced to provide effective occupant
protection.
