129 Controls in detail
Control system

Press buttonk orj repeatedly
until the desired channel is found.Operate the CD player*

Turn on the radio and select the
CD player (
page 201).
Vehicles with COMAND*:
Refer to separate operating
instructions.

Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the
multifunction display.
1Current CD (for CD changer*)
2Current track

Press buttonk orj repeatedly
until the desired track is selected.
iFeature description is based on
preliminary information available at
time of printing.
For more information on satellite radio
operation, see “Introduction to satellite
radio* (USA only)” (
page 196).
Vehicles with COMAND*:
Refer to separate operating
instructions.
iTo select a CD from the magazine,
press a number on the audio system or
the COMAND* system key pad located
in the center dashboard.

130 Controls in detailControl systemNAV* menu
The
NAV
menu contains the functions
needed to operate your navigation system.

Press buttonè orÿ repeatedly
until the message
NAV
appears in the
multifunction display.


If the navigation system is switched off,
the message
NAV OFF
appears in the
multifunction display.


If the navigation system is on, different
messages, depending on the current
state of the navigation system, appear
in the multifunction display.
Please refer to the COMAND* manual for
instructions on how to activate the route
guidance system*.
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the
system. Such messages appear in the mul-
tifunction display and are based on condi-
tions or system status the vehicle’s system
has recorded.

Press buttonè orÿ repeatedly
until the vehicle status message
memory appears in the multifunction
display.Warning!
G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Center to address the malfunction and
warning messages (
page 309).

131 Controls in detail
Control system
No vehicle status messages
If no conditions are recorded in memory,
the message in the multifunction display
is:
No message
Vehicle status messages have been
recorded
If conditions have occured causing status
messages to be recorded, the number of
messages appears in the multifunction
display:
1Number of messages

Press buttonk orj.
The stored messages will now be
displayed in the order in which they
have occured. For malfunction and
warning messages, see “Vehicle status
messages in the multifunction display”
(page 309).
Should the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display when the SmartKey in the
starter switch is turned to position0 or
removed from the starter switch.
iThe vehicle status message memory
will be cleared when you turn the
SmartKey in the starter switch to
position1 or2. You will then only see
high-priority messages in the multi-
function display (
page 309).

132 Controls in detailControl systemSettings menu
In the
Settings
menu there are two
functions:


The function
Reset to factory
settings
, with which you can reset all
the settings to the original factory
settings.


A collection of submenus with which
you can make individual settings for
your vehicle.

Press buttonè orÿ repeatedly
until the
Settings
menu appears in the
multifunction display.Resetting all settings
You can reset all the functions of all
submenus to the factory settings.

Press the reset button in the
instrument cluster (
page 117) for
approximately three seconds.
The request to press the reset button
once more to confirm appears in the
multifunction display.

Press the reset button once more.
The functions of all the submenus will
reset to factory settings.
iThe settings you have changed will not
be reset unless you confirm the action
by pressing the reset button a second
time. After approximately five seconds,
the
Settings
menu reappears in the
multifunction display.
For safety reasons, the following
functions are not reset while driving:


the
Hdlamp mode
function in the
Lighting
submenu


the
Key dependency
function in the
Convenience
submenu

133 Controls in detail
Control system
Submenus in the Settings menu
Press buttonk orj.
The collection of the submenus
appears in the multifunction display.

Press buttonç.
The selection marker moves to the next
submenu.The submenus are arranged by hierarchy.
Scroll down with buttonç, scroll up
with buttonæ.
Move within the submenus with
buttonk orj to the individual
functions.
The settings themselves are made with
buttonæ orç.Resetting the functions of a submenu
For each submenu you can reset all the
functions to the factory settings.

Move to a function in the submenu.

Press the reset button (
page 117) in
the instrument cluster for approxi-
mately three seconds.
The request to press the reset button
once more to confirm appears in the
multifunction display.

Press the reset button once more.
All functions of the submenu will reset
to factory settings.iThe settings you have changed will not
be reset unless you confirm the action
by pressing the reset button a second
time. After approximately five seconds,
the
Settings
menu reappears in the
multifunction display.

134 Controls in detailControl systemThe table below shows what settings can
be changed within the various menus. Detailed instructions on making individual
settings can be found on the following
pages.Instrument cluster
Time/Date
Lighting
Vehicle
Convenience
Selecting temperature
display mode
Time synchronization with head
unit*
Setting daytime running
lamp mode (USA only)
Setting automatic
locking
Activating
easy-entry/exit feature
Selecting speedometer
display mode
Setting the time (hours)
Setting locator lighting
Setting key-dependency
Selecting language
Setting the time (minutes)
Setting night security
illumination
Setting parking position
for exterior rear view
mirror
Selecting display (speed
display or outside
temperature) for status
indicator
Selecting time display mode
Setting interior lighting
delayed shut-off
Selecting automatic time
change (Daylight Saving Time
(DST) summer/Standard time
winter)Setting the date (month)Setting the date (day)Setting the date (year)

135 Controls in detail
Control system
Instrument cluster submenu
Access the
Instr.Cl.
submenu via the
Settings
menu. Use the
Instr.Cl.

submenu to change the instrument cluster
display settings.
The following functions are available:Selecting temperature display mode

Move the selection marker with
buttonæ orç to the
Instr.Cl.

submenu.

Press buttonj ork repeatedly
until the message
Temperature
indicator
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to set tem-
perature unit to
°C (degrees Celsius)
or
°F (degrees Fahrenheit).Selecting speedometer display mode

Move the selection marker with
buttonæ orç to the
Instr.Cl.

submenu.

Press buttonj ork repeatedly
until the message
Disp.Unit
Speed/odo
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to set
speedometer unit to
km or
Miles
.
Function
Page
Selecting temperature display
mode
135
Selecting speedometer display
mode
135
Selecting language
136
Selecting display (speed display
or outside temperature) for
status indicator
136

136 Controls in detailControl systemSelecting language
Move the selection marker with
buttonæ orç to the
Instr.Cl.

submenu.

Press buttonj ork repeatedly
until the message
Language
appears in
the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the language to be used for the
multifunction display messages.
Available languages:

German


English


French


Italian


Spanish
Selecting display (digital speedometer
or outside temperature) for status
indicator

Move the selection marker with
buttonæ orç to the
Instr.Cl.

submenu.

Press buttonj ork repeatedly
until the message
Status line
display
appears in the multifunction
display.The selection marker is on the current
setting.

Press buttonæ orç to select
the desired setting.
The selected display is then shown
continuously in the lower display.
The other display now appears in the
menu of the standard display:

Digital speedometer
or


Outside temperature

137 Controls in detail
Control system
Time/Date submenu
Access the
Time/Date
submenu via the
Settings
menu. Use the
Time/Date

submenu to change the instrument cluster
display settings.
The following functions are available:Time synchronization with head unit*
This function can only be seen on vehicles
with COMAND* and navigation module*.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Time synchro.
w/Head Unit
appears in the multifunc-
tion display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired setting.Setting the time (hours)
This function can only be seen with audio
system.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Time Hours
appears
in the multifunction display.
Function
Page
Time synchronization with
head unit*
137
Setting the time (hours)
137
Setting the time (minutes)
138
Selecting time display mode
139
Selecting automatic time change
(Daylight Saving Time (DST)
summer/Standard time winter)
139
Setting the date (month)
139
Setting the date (day)
140
Setting the date (year)
141
iVehicles with COMAND*:
For information on setting the time,
refer to the separate COMAND
operating instructions.


138 Controls in detailControl system
The selection marker is on the hour
setting.

Press buttonæ orç to set the
hour.

Press the reset button in the instru-
ment cluster (
page 117) to confirm.
The hour is set and stored.Setting the time (minutes)
This function can only be seen with audio
system.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Time Minutes

appears in the multifunction display.The selection marker is on the minute
setting.

Press buttonæ orç to set the
minutes.

Press the reset button in the instru-
ment cluster (
page 117) to confirm.
The minutes are set and stored.
iVehicles with COMAND*:
For information on setting the time,
refer to the separate COMAND
operating instructions.
