MERCEDES-BENZ SPRINTER 2005 Service Repair Manual

8W-48 REAR WINDOW DEFOGGER
Component Page
D+ Relay No. 1...................... 8W-48-4
Daytime Running Lamps Relay......... 8W-48-5
Fuse 7............................ 8W-48-5
Fuse 9............................ 8W-48-4
Fuse 10............................ 8W-48-2
Fuse Block No. 1.................... 8W-48-5
Fuse Block No. 2.................... 8W-48-4
Fuse/Relay Block.................... 8W-48-2
G202............................ 8W-48-3, 4
G203.............................. 8W-48-5Component Page
G300............................ 8W-48-3, 4
Security System Module............. 8W-48-3, 4
Window Defogger Module- Rear . . . 8W-48-2, 3, 4, 5
Window Defogger Relay- Left Rear..... 8W-48-2, 3
Window Defogger Relay- Right Rear . . . 8W-48-2, 4
Window Defogger Switch- Rear......... 8W-48-5
Window Defogger- Left Rear............ 8W-48-3
Window Defogger- Right Rear.......... 8W-48-4
VA8W-48 REAR WINDOW DEFOGGER 8W - 48 - 1
