MINI COOPER 2003 User Guide

9
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX

ba.book Seite 9 Montag, 5. August 2002 8:09 20
ProCarManuals.com

10
ba.book Seite 10 Montag, 5. August 2002 8:09 20
ProCarManuals.com

OVERVIEW

CONTROLS
OPERATION, CARE, MAINTENANCE
OWNER SERVICE PROCEDURES
INDEX TECHNICAL DATA

11
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX

Overview

ba.book Seite 11 Montag, 5. August 2002 8:09 20
ProCarManuals.com

12
COCKPIT

1
>
Parking lamps/Low beams52
>
Turn signal indicators52
>
Standing lamps52
>
High beams52
>
Headlamp flasher52
>
Computer602Washer/wiper system54
3Instrument lighting53
4Outside mirror adjustment39
5Hazard warning flashers6Bonnet release91
7Horn19
8Adjusting steering wheel38
9OBD interface socket102

ba.book Seite 12 Montag, 5. August 2002 8:09 20
ProCarManuals.com

13
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX

DISPLAY ELEMENTS

1Tachometer58
with indicator and warning lamps, see
from page 15
2Display for the computer, refer to
page 60 – if there is no computer, display
of the outside temperature
3Speedometer with indicator and warning
lamps, see from page 154Indicator for
>
Odometer58
>
Trip odometer58
>
Service interval60
>
Program display for Continuously
Variable automatic Transmission
(CVT)515Trip odometer, reset to zero58
6Fuel gauge58
7Engine coolant temperature gauge59

ba.book Seite 13 Montag, 5. August 2002 8:09 20
ProCarManuals.com

14
DISPLAY ELEMENTS WITH NAVIGATION SYSTEM

*
1Tachometer58
with indicator and warning lamps, see
from page 15
2Additional indicator and warning lamps,
refer to page 16 – Display for computer
in navigation system, see separate
Owner's Manual 3Speedometer with indicator and warning
lamps, see from page 15
4Trip odometer, reset to zero585Indicator for
>
Odometer58
>
Trip odometer58
>
Service interval60
>
Program display for Continuously
Variable automatic Transmission
(CVT)51

ba.book Seite 14 Montag, 5. August 2002 8:09 20
ProCarManuals.com

15
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX

INDICATOR AND WARNING LAMPS

Technology
that monitors itself
The system runs a check on the warning
and indicator lamps marked by
●
each time
you switch on the ignition. They each light
up once for different periods of time.
If a malfunction should occur in one of
these systems, the corresponding lamp
does not go out after the engine is started
or it lights up while the vehicle is moving.
You will see below the correct way to react
to this.
Red: stop immediately
Battery charge current
●
The battery is no longer being
charged. Indicates a defective alter-
nator drive belt or a problem with the
charge circuit. Please contact the nearest
MINI Dealer.
If this lamp lights up, the power-assist for
steering can be deactivated.
If the drive belt is defective, do not
continue driving. The engine could be
damaged due to overheating. When the
power-assist is deactivated, increased
steering effort is required.
<
Engine oil pressure


●
Stop immediately. Switch off
engine. Check the engine oil and fill
as needed. Please contact the nearest MINI
Dealer.
Do not continue driving, otherwise,
the engine could be damaged
because of inadequate lubrication.
<

Brake warning lamp
●
If the lamp comes on when the
parking brake is not engaged:
Check the brake fluid level. Before driving
further, be sure to comply with the infor-
mation on pages 84 and 97.
Brake warning lamp for Canadian
models.
With navigation system option:
Coolant temperature warning
lamp in the speedometer
●
Lights up while driving:
Engine is too hot. Switch off the engine
immediately and allow to cool down, see
also page 59.

ba.book Seite 15 Montag, 5. August 2002 8:09 20
ProCarManuals.com

16
INDICATOR AND WARNING LAMPS

Yellow: stop immediately
Flat Tire Monitor
●
Flashes: tire failure.
Reduce speed immediately and
stop the vehicle.
With Run Flat tires:
Carefully reduce the driving speed to below
50 mph / 80 km/h and continue to a safe
location.
In both cases, avoid hard brake applications
and steering maneuvers. Check the tire
inflation pressures.
Conduct in the event of a flat tire, refer to
pages 112, 116.
General information on the system, refer to
page 64
Red and yellow: continue driving
cautiously
Brake warning lamp together with
the gold indicator lamp for ABS,
EBD and ASC+T/DSC:
The control system ABS, EBD and
ASC+T/DSC has failed. Drive cau-
tiously and defensively. Avoid full
brake applications. Please have the
system checked by your MINI
Dealer as soon as possible.
More information on pages 62, 63
Brake warning lamp together with
the yellow indicator warning lamps
ABS, EBD and ASC+T/DSC for
Canadian models.
Red: an important reminder
Brake warning lamp
with parking brake applied.
More information on the parking
brake on page 47

Brake warning lamp for Canadian
models.
Fasten safety belts
●
Lights up for several seconds or,
depending on the version, until
after the safety belts are fastened. A sig-
nal

*
also sounds depending on the version.
More information on page 38
Depending on the level of equipment,
the indicator lamp is in the vicinity of
the navigation system.
<
Airbags
●
Please have the system inspected
at your MINI Dealer.
More information on pages 33, 40
Depending on the level of equipment,
the indicator lamp is in the vicinity of
the navigation system.
<
Bonnet/Tailgate
Lights up when the bonnet and/or
tailgate are open.
More information on pages 27, 91

ba.book Seite 16 Montag, 5. August 2002 8:09 20
ProCarManuals.com

17
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX

INDICATOR AND WARNING LAMPS

Yellow: check as soon as possible
Flat Tire Monitor
●
Stays lit: the system is defective.
Please have the system inspected
at your MINI Dealer.
More information on page 64
Antilock Brake System (ABS)
●
ABS has been deactivated in
response to system malfunction.
Conventional braking efficiency is avail-
able. Please have the system inspected at
your MINI Dealer.
More information on pages 83
ABS indicator lamp for Canadian
models.

Automatic Stability Control plus
Traction (ASC+T)/Dynamic Stabil-
ity Control (DSC)
●

Indicator lamp flashes:
System active: drive and braking forces are
regulated.
The indicator lamp stays lit: ASC+T/DSC
switched off with button or defective. In
the event of a defect: please have the sys-
tem inspected at your MINI Dealer.
More information on pages 62, 63
Service Engine Soon
●
If the warning lamp comes on
either continuously or intermit-
tently, this indicates a malfunction in the
emissions-related electronic systems.
Although the vehicle remains operational,
you should have the systems checked by
your MINI Dealer at the earliest possible
opportunity.
Service Engine Soon warning lamp
for Canadian models.
Engine electronics
*

●
Malfunction in the engine electron-
ics. You can continue to drive with
reduced engine output or engine speed.
Please have the system inspected at your
MINI Dealer.
Check Filler Cap
*
●
This indicator lamp comes on when
the fuel filler cap is loose or miss-
ing. Close the filler cap tightly:
Refer to page 82
Depending on the level of equipment,
the indicator lamp is in the vicinity of
the navigation system.
<

ba.book Seite 17 Montag, 5. August 2002 8:09 20
ProCarManuals.com

18
INDICATOR AND WARNING LAMPS

Green: for your information
Turn signal indicators
Flashes when turn signal indicator
is on.
Rapid flashing: the system is defective.
More information on page 52
Cruise control
*
Lights up when the cruise control is
activated: operation via the multi-
function steering wheel.
More information on page 56
Blue: for your information
High beams
Comes on when the high beams
are on or the headlamp flasher is
actuated. More information on page 52
