SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-18
Front-ECU, P/W, S/R
NOTE: For item No.70, the diagnostic tool
MB991958 (MUT-III Sub Assembly) also displays
"NG" under "ECU COMM Check" when it displays
"NO ACK" under the front-ECU check.NOTE: For item No.72, the diagnostic tool
MB991958 (MUT-III Sub Assembly) also displays
"NG" under "ECU COMM Check" when it displays
"NO ACK" under the sunroof-ECU check.

The table below shows the service data and their
normal condition, which are displayed during the
"Function Diag." The column "Normal condition"
shows values that are shown when each operation is
made.
.
CHECK
ITEMITEM NO. DISPLAY ON
DIAGNOSTIC
TOOLCHECK CONDITION NORMAL
CONDITION
Response by
the
front-ECU70 FRONT ECU
ACKLighting switch: Other than OFF (excluding
when high-beam is on) or the wiper switch
is at position other than OFF (ignition
switch: ACC or ON)NORMAL ACK
Ignition switch: Other than ON
Lighting switch: OFF
Wiper switch: OFFSLEEP ACK
Lighting switch: HEAD
Headlights: at high beamHI-BEAM ACK
Other than the condition above NO ACK
Response by
the
sunroof-ECU72 S/R ECU ACK
1. Door switch: OFF
2. Ignition switch: ON
OFF
3. While sunroof is offNORMAL ACK

SLEEP ACK (after
approximately 30
seconds)
1. Ignition switch: ON or START
2. One of the sunroof switches is onINPUT CHECK to
NORMAL ACK
Other than the above conditions NO ACK

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-19
WIPER
ITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION
F.WIPER HI 05 Windshield
intermittent wiper
switchINT WIPER SW (COLUMN
ECU)OFF
06 Windshield
low-speed wiper
switchLO WIPER SW (COLUMN
ECU)OFF
07 Windshield
high-speed wiper
switchHI WIPER SW (COLUMN
ECU)ON
08 Windshield mist
wiper switchMIST WIPER SW
(COLUMN ECU)OFF
09 Windshield washer
switchFRONT WASH.SW
(COLUMN ECU)OFF
31 Ignition switch
(ACC)IG SW (ACC) (ETACS ECU) ON
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK
F.WIPER INT 05 Windshield
intermittent wiper
switchINT WIPER SW (COLUMN
ECU)ON
06 Windshield
low-speed wiper
switchLO WIPER SW (COLUMN
ECU)OFF
07 Windshield
high-speed wiper
switchHI WIPER SW (COLUMN
ECU)OFF
08 Windshield mist
wiper switchMIST WIPER SW
(COLUMN ECU)OFF
09 Windshield washer
switchFRONT WASH.SW
(COLUMN ECU)OFF
31 Ignition switch
(ACC)IG SW (ACC) (ETACS ECU) ON
37 Windshield
intermittent wiper
intervalINT WIPE TIME (ETACS
ECU)The diagnostic tool
MB991958 (MUT-III Sub
Assembly) displays
intermittent wiper interval in
response to the intermittent
wiper control positions.
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-20
.
F.WIPER LO 05 Windshield
intermittent wiper
switchINT WIPER SW (COLUMN
ECU)OFF
06 Windshield
low-speed wiper
switchLO WIPER SW (COLUMN
ECU)ON
07 Windshield
high-speed wiper
switchHI WIPER SW (COLUMN
ECU)OFF
08 Windshield mist
wiper switchMIST WIPER SW
(COLUMN ECU)OFF
09 Windshield washer
switchFRONT WASH.SW
(COLUMN ECU)OFF
31 Ignition switch
(ACC)IG SW (ACC) (ETACS ECU) ON
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK
F.WIPER MIST 05 Windshield
intermittent wiper
switchINT WIPER SW (COLUMN
ECU)OFF
06 Windshield
low-speed wiper
switchLO WIPER SW (COLUMN
ECU)OFF
07 Windshield
high-speed wiper
switchHI WIPER SW (COLUMN
ECU)OFF
08 Windshield mist
wiper switchMIST WIPER SW
(COLUMN ECU)ON
09 Windshield washer
switchFRONT WASH.SW
(COLUMN ECU)OFF
31 Ignition switch
(ACC)IG SW (ACC) (ETACS ECU) ON
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK
F. W I P E R
WASH08 Windshield mist
wiper switchMIST WIPER SW
(COLUMN ECU)OFF
09 Windshield washer
switchFRONT WASH.SW
(COLUMN ECU)ON
31 Ignition switch
(ACC)IG SW (ACC) (ETACS ECU) ON
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK ITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-21
LAMPING
ITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION
H/L AUTO-CUT 00 Headlight switch
HEADLAMP SW (COLUMN
ECU)Either is ON
01 Taillight switch TAILLAMP SW (COLUMN
ECU)
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) OFF
32 Front door switch FRONT DOOR SW (ETACS
ECU)ON
35 Headlight
automatic shutoff
functionH/L AUTO-CUT (ETACS
ECU)ON
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or SLEEP
ACK
OFF 00 Headlight switch
HEADLAMP SW (COLUMN
ECU)OFF
01 Tail lamp switch TAILLAMP SW (COLUMN
ECU)OFF
03 Passing lamp
switchPASSING SW (COLUMN
ECU)OFF
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON or OFF
35 Headlight
automatic shutoff
functionH/L AUTO-CUT (ETACS
ECU)OFF
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or SLEEP
ACK
HEADLAMP HI00 Headlight switch
HEADLAMP SW (COLUMN
ECU)ON
02 Dimmer switch DIMMER SW (COLUMN
ECU)ON or OFF
03 Passing lamp
switchPASSING SW (COLUMN
ECU)OFF
30 Ignition switch
(IG1)IG SW (IG1) (COLUMN
ECU)ON
35 Headlight
automatic shutoff
functionH/L AUTO-CUT (COLUMN
ECU)OFF
70 Response by the
front-ECUFRONT ECU ACK
(COLUMN ECU)HI-BEAM ACK

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-22
NOTE: When checking the input signals (off, tail,
low-beam or high-beam), turn the ignition switch to
the "ON" position in order to disable the headlamp
automatic shutoff function. However, since the
headlamp operation does not depend on the ignition
switch positions, the diagnostic tool MB991958
(MUT-III Sub Assembly) does not display the title "IGNITION SWITCH". HEADLAMP
LO00 Headlight switch
HEADLAMP SW (COLUMN
ECU)ON
03 Passing lamp
switchPASSING SW (COLUMN
ECU)OFF
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON or OFF
35 Headlight
automatic shutoff
functionH/L AUTO-CUT (ETACS
ECU)OFF
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK
PASSING
LAMP03 Passing lamp
switchPASSING SW (COLUMN
ECU)ON
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK
F.FOG LAMP 00 Headlight switch
HEADLAMP SW (COLUMN
ECU)ON
36 Front fog lamp
switchF.FOG LAMP (COLUMN
ECU)ON
35 Headlight
automatic shutoff
functionH/L AUTO-CUT (ETACS
ECU)OFF
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON or OFF
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK or HI-BEAM
ACK
TAIL LAMP 00 Headlight switch
HEADLAMP SW (COLUMN
ECU)OFF
01 Tail lamp switch TAILLAMP SW (COLUMN
ECU)ON
03 Passing lamp
switchPASSING SW (COLUMN
ECU)OFF
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON or OFF
35 Headlight
automatic shutoff
functionH/L AUTO-CUT (ETACS
ECU)OFF
70 Response by the
front-ECUFRONT ECU ACK (FRONT
ECU)NORMAL ACK ITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-23
For checking item "HEADLAMP HI", the diagnostic
tool MB991958 (MUT-III Sub Assembly) displays
"OFF" on the item No.2 "DIMMER SW" when the
headlamps are at high-beam. Therefore, the
diagnostic tool MB991958 (MUT-III Sub Assembly)
should display "ON" momentarily when the dimmer
switch is operated.
.
TURN SIGNAL
.
BUZZER
NOTE: The headlamp automatic shutoff function
operates approximately one second after the lighting
monitor tone alarm starts sounding, and then the
tone alarm ceases sounding.
.
ITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION
TURN-SIG.LH 10 Turn-signal lamp
switch (RH)T/S RH SW (COLUMN
ECU)OFF
11 Tu r n - s i g n a l l a m p
switch (LH)T/S LH SW (COLUMN
ECU)ON
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON
TURN-SIG.RH 10 Turn-signal lamp
switch (RH)T/S RH SW (COLUMN
ECU)ON
11 Tu r n - s i g n a l l a m p
switch (LH)T/S LH SW (COLUMN
ECU)OFF
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON
ITEM ITEM NO. INPUT SIGNAL DISPLAY ON DIAGNOSTIC
TOOLNORMAL CONDITION
LGT
MONI.ALRM00 Headlamp switch
HEADLAMP SW (COLUMN
ECU)Either is ON
01 Tail lamp switch TAILLAMP SW (COLUMN
ECU)
30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) OFF
32 Front door switch FRONT DOOR SW (ETACS
ECU)ON
35 Headlamp
automatic shutoff
functionH/L AUTO-CUT (ETACS
ECU)OFF
43 Tone alarm BUZZER (ETACS ECU) ON
OTHER
ALARM30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON
43 Tone alarm BUZZER (ETACS ECU) ON

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-24
SUNROOF
PULSE CHECK
M1549015100562
1. The input signals (signals other than SWS
communication line signals), which are
compatible with the SWS monitor by using the
diagnostic tool MB991958 (MUT-III Sub
Assembly) or voltmeter, can be confirmed by the
Pulse Check.2. Use the diagnostic tool MB991958 (MUT-III Sub
Assembly) or voltmeter to check the following
input signals.
NOTE: If a problem is found in the Pulse Check,
refer to Input Signal Chart P.54B-61.
Switches and their conditions, which are applicable
for Pulse CheckITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION
SUNROOF
OPE.30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON
72 Response by the
sunroof-ECUS/R ECU ACK (SUNROOF
ECU)INPUT CHECK (only
momentarily when switch is
operated)
INPUT SIGNAL REQUIREMENTS FOR SOUNDING TONE
ALARM
Key reminder switch When the ignition key is pulled out
Hazard warning lamp switch When the switch is turned from off to on
Door switches A door is opened when all the doors are
closed
Door lock key cylinder switch When a door is locked or unlocked by a key
cylinder
Door lock actuators Move the door lock knob from lock position
to unlock position or vice versa
Door lock switch (incorporated in the power window main
switch and front power window sub switch)When a door is locked or unlocked by a door
lock switch
Keyless entry transmitter When the switch is turned from off to on
Interior lamp loaded signal Illuminates the interior lamps

DIAGNOSTIC TROUBLE CODE CHART
SIMPLIFIED WIRING SYSTEM (SWS)54B-25
DIAGNOSTIC TROUBLE CODE CHARTM1549000700461
DIAGNOSTIC TROUBLE CODE PROCEDURES
DTC 001: Trouble in SWS communication line or ETACS-ECU
NOTE: This troubleshooting procedure requires the
use of diagnostic tool MB991958 and SWS monitor
kit MB991813. For details on how to use the SWS
monitor, refer to "How to connect SWS monitor
P.54B-13."
If DTC 001 is set in the ETACS-ECU, always diag-
nose the CAN main bus line.
.
TROUBLE JUDGMENT
The ETACS-ECU communicates with the column
switch, the front-ECU and the sunroof-ECU through
the SWS communication line. If there is any trouble
in the SWS communication line and the
ETACS-ECU, DTC 001 will be set.
.
TECHNICAL DESCRIPTION (COMMENT)
Current trouble
The wiring harness wire or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector, or the
ETACS-ECU may be defective.Past trouble
If DTC 001 is set as past trouble, carry out diag-
nosis with particular emphasis on wiring and con-
nector(s) in the SWS communication line. For
diagnosis procedures, refer to "How to cope with
past trouble" (Refer to GROUP 00, How to treat
past trouble P.00-16).
.
TROUBLESHOOTING HINTS
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector.
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80 DIAGNOSTIC TROUBLE
CODE NO.DESCRIPTION REFERENCE
PA G E
001 (U1700) Trouble in SWS communication line or ETACS-ECU
P.54B-25
002 (U1701) Trouble in column switch
P.54B-29
003 (U1702) Trouble in front-ECU
P.54B-32
004 (U1703) Trouble in sunroof-ECU
P.54B-35
010 (U1073) Bus Off
P.54B-38
011 (U1100) Engine ECU time-out (related to engine)
P.54B-39
012 (U1101) A/T ECU time-out (related to A/T)
013 (U1110) A/C-ECU time-out
P.54B-43
014 (U1108) Combination meter time-out
P.54B-46
015 (U1111) Multi center display unit time-out
P.54B-50
021 (U1128) Failure information on combination meter
P.54B-53

DIAGNOSTIC TROUBLE CODE PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-28
STEP 3. Use diagnostic tool MB991958 to select "ECU
COMM Check" on the SWS monitor display.
Check the following ECUs:
ETACS-ECU
Column switch (column-ECU)
Front-ECU
Sunroof-ECU
Connect special tool MB991910 before connecting special
tool MB991812. Be sure to connect special tool MB991806
after turning on special tool MB991824.
(1) Connect the SWS monitor. Refer to "How to connect SWS
monitor P.54B-13."
(2) Turn the ignition switch to the "LOCK" (OFF) position.
(3) Operate diagnostic tool MB991958 according to the
procedure below to display "ECU COMM Check."
a. Select "Interactive Diagnosis."
b. Select "System select."
c. Select "SWS."
d. Select "SWS MONITOR."
e. Select "ECU COMM Check."
(4) DIAGNOSTIC TOOL MB991958 should show "OK" on the
"ECU COMM Check" menus for the "ETACS ECU",
"COLUMN ECU", "FRONT ECU" and "SUNROOF ECU"
menus.
Q: Are "OK" displayed for the "ETACS ECU," "COLUMN
ECU," "FRONT ECU" and "SUNROOF ECU" menus?
"OK" are displayed for all the items : It is determined that
there is an intermittent malfunction such as poor
engaged connector(s) or open circuit (Refer to
GROUP 00, How to Cope with Intermittent
Malfunction P.00-14).
"NG" is displayed for the "ETACS ECU" menu : Refer to
Inspection Procedure A-3 "Communication with the
ETACS-ECU is not possible P.54B-74."
"NG" is displayed for the "COLUMN ECU" menu : Refer
to Inspection Procedure A-2 "Communication with the
column switch (column-ECU) is not possible
P.54B-68."
"NG" is displayed for the "FRONT ECU" menu : Refer to
Inspection Procedure A-4 "Communication with the
front-ECU is not possible P.54B-80."
"NG" is displayed for the "SUNROOF ECU" menu :
Refer to Inspection Procedure A-5 "Communication
with the sunroof-ECU is not possible P.54B-87."

DIAGNOSTIC TROUBLE CODE PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-31
STEP 3. Use diagnostic tool MB991958 to select "ECU
COMM Check" on the SWS monitor display.
Check the following ECUs:
Column-ECU
ETACS-ECU
Connect special tool MB991910 before connecting special
tool MB991812. Be sure to connect special tool MB991806
after turning on special tool MB991824.
(1) Connect the SWS monitor. Refer to "How to connect SWS
monitor P.54B-13."
(2) Turn the ignition switch to the "LOCK" (OFF) position.
(3) Operate diagnostic tool MB991958 according to the
procedure below to display "ECU COMM Check."
a. Select "Interactive Diagnosis."
b. Select "System select."
c. Select "SWS."
d. Select "SWS MONITOR."
e. Select "ECU COMM Check."
(4) DIAGNOSTIC TOOL MB991958 should show "OK" on the
"ECU COMM Check" menus for both the "COLUMN ECU"
and the "ETACS ECU" menus.
Q: Are "OK" displayed for both the "COLUMN ECU" and
"ETACS ECU" menus?
"OK" are displayed for all the items : It is determined that
there is an intermittent malfunction such as poor
engaged connector(s) or open circuit (Refer to
GROUP 00, How to Cope with Intermittent
Malfunction P.00-14).
"NG" is displayed for the "COLUMN ECU" menu : Refer
to Inspection Procedure A-2 "Communication with the
column switch (column-ECU) is not possible
P.54B-68."
"NG" is displayed for the "ETACS ECU" menu : Refer to
Inspection Procedure A-3 "Communication with the
ETACS-ECU is not possible P.54B-74."
