GENERAL DESCRIPTION
SIMPLIFIED WIRING SYSTEM (SWS)54B-5
INTERMITTENT CONTROL
ETACS-ECU uses the dial position of the variable
intermittent wiper control switch and the vehicle
speed signal sent by the combination meter to calcu-
late the interval to be sent to the front-ECU. The
front-ECU determines the intermittent time from the
input SWS data signal, and turns ON the windshield
wiper drive signal. When the wiper is at the STOP
position, the windshield wiper auto-stop signal goes
OFF to turn OFF the windshield wiper drive signal.
After the intermittent time from when the windshield
wiper drive signal turned ON, the windshield wiper
drive signal is turned ON again and the above opera-
tion is repeated.
.
MIST WIPER CONTROL
When the ignition switch is in the ACC or ON posi-
tion, and the windshield mist wiper switch of the col-
umn switch is turned ON, the front-ECU turns ON the
windshield wiper drive signal. At the same time, the
wiper speed switching relay is turned ON
(HIGH-SPEED). While the windshield mist wiper
switch is ON, the windshield wiper will operate at
high speed. Then, if the windshield mist wiper switch
is turned off, the wiper operates at low speed until it
stops at the predetermined park position.
When the windshield mist switch is turned on briefly,
the wiper operates once at low speed.
At the point the windshield mist switch is turned ON,
if the windshield wiper has been operating intermit-
tently, the same operations as the above will be per-
formed while the windshield mist wiper switch is ON.
After the windshield mist wiper switch goes OFF, the
intermittent operations will be set again after the
windshield wiper auto-stop signal last is turned ON.
.
WASHER CONTROL
When the ignition switch is in the ACC or ON posi-
tion, and the windshield washer switch of the column
switch is turned ON, the front-ECU turns ON the
windshield washer relay. The windshield wiper drive
signal is turned ON in 0.15 seconds until 2 seconds
after the windshield washer switch goes OFF to
operate the windshield wiper continuously. When the
windshield washer switch is turned ON, if the wind-
shield wiper is operating intermittently, intermittent
operations will be continued after continuous opera-
tions.
HEADLAMP
.
HEADLAMP AUTOMATIC SHUTDOWN
FUNCTION
Even if the lighting switch (tail lamp switch or
headlamp switch) is ON, the headlamps and tail
lamps will automatically go off in the following condi-
tions to prevent the battery from discharging:
When the ignition key is turned from "ON" to "LOCK"
(OFF) or "ACC" position with the lighting switch
turned ON, and this state continues for three min-
utes, the lamp will automatically be turned off. If the
driver's seat door is opened during these three min-
utes, the lamp will go off one second later.
.
HIGH-BEAM INDICATOR
At the same time that the high beams are illumi-
nated, the ETACS-ECU sends a signal to illuminate
the high-beam indicator via the CAN bus line. The
combination meter receives the transmitted signal
and turns the high-beam indicator on and off.
FLASHER TIMER
.
TURN-SIGNAL LAMP
The turn-signal lamp output (flashing signal) is
turned ON when the ignition switch is ON and the
turn-signal lamp switch is ON (LH or RH). If the front
turn-signal lamp or rear turn-signal lamp bulb has
burned out, the flashing speed increases to indicate
that the bulb has burned out.
.
HAZARD WARNING LAMP
Detects the signal where the hazard warning lamp
switch input changes from OFF to ON, and reverse
the flashing state according to this signal. The haz-
ard warning lamps toggle on and off whenever the
hazard warning lamp switch is operated.
.
TURN-SIGNAL INDICATORS
At the same time that the turn-signal lamps are illu-
minated, the ETACS-ECU sends a signal to illumi-
nate the turn-signal lamp indicator via the CAN bus
line. The combination meter receives the transmitted
signal and turns the turn-signal lamp indicator on and
off.
Page 17 of 1500

SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-17
ETACS
NOTE: For item No.43, the diagnostic tool
MB991958 (MUT-III Sub Assembly) also displays
"ON" when the lamp reminder tone alarm or the seat
belt tone alarm function is triggered.
.
CHECK
ITEMITEM NO. DISPLAY ON
DIAGNOSTIC
TOOLCHECK CONDITION NORMAL
CONDITION
Tone alarm 43 BUZZER When requirements for sounding each
warning tone alarm are not satisfiedOFF
Front fog
lamps36 F.FOG LAMP
1. Lighting switch: HEAD
2. Fog lamp switch: ONON
Other than the condition above OFF
Driver’s door
switch32 FRONT DOOR
SWDriver’s door switch and Front passenger’s
door switch is on ON
Driver’s door switch and Front passenger’s
door switch is offOFF
Headlamp
automatic
shutoff
function35 H/L AUTO-CUT
1. Lighting switch: Other than OFF
2. Ignition switch: from ON or START to
LOCK (OFF) or ACC
3. Front door switch: ON (front door open) OFF to ON (after
approximately one
second)
When requirements for the headlamp
automatic shutoff are not satisfiedOFF
Ignition
switch (ACC)31 IG SW (ACC) Ignition switch: ACC or ON ON
Ignition switch: LOCK (OFF) or START OFF
Ignition
switch (IG1)30 IG SW (IG1) Ignition switch: ON or START ON
Ignition switch: LOCK (OFF) or ACC OFF
Windshield
intermittent
wiper interval37 INT WIPE
TIME1. Ignition switch: ACC or ON
2. Operate the intermittent wiper control,
and change the wiper intervalThe diagnostic tool
MB991958
(MUT-III Sub
Assembly)
displays
intermittent wiper
interval in
response to the
intermittent wiper
control positions.
Page 58 of 1500

SYMPTOM CHART
SIMPLIFIED WIRING SYSTEM (SWS)54B-58
Power windows General description concerning the power
windowsP.54B-148
Power windows do not work at all. D-1
P.54B-151
The power window timer function does not work
normally.D-2
P.54B-161
Only the front door window (LH) does not work by
operating power window main switch.D-3
P.54B-164
Power windows do not work normally by operating
the front passenger's or rear passenger's sub
switches.D-4
P.54B-167
Front or rear passenger's power windows do not
work at all by operating the power window main
switch.D-5
P.54B-187
Keyless entry system General description concerning the keyless entry
system
P.54B-187
Keyless entry system does not operate. E-1
P.54B-191
The dome lamp, the turn-signal lamps and the
horn do not operate through the answerback
function.E-2
P.54B-193
Encrypted code cannot be registered. E-3
P.54B-202
The trunk is not opened when the keyless entry
transmitter "TRUNK" button is operated.E-4
P.54B-205
Sunroof General description concerning the sunroof
P.54B-209
Sunroof does not operate. F-1
P.54B-210
Any of the sunroof switch positions is defective. F-2
P.54B-219
Sunroof timer function does not work normally. F-3
P.54B-220
Windshield wiper and
washerGeneral description concerning the windshield
wiper and washer
P.54B-223
The windshield wiper do not work at all. G-1
P.54B-226
The windshield wipers do not work when the
windshield wiper switch is at "INT" or "MIST"
position or the windshield washer switch is at "ON"
position. However, the wipers work at low speed
when the windshield wiper switch is at "LO" or "HI."G-2
P.54B-234
All of the windshield wiper switch positions are
defective.G-3
P.54B-236
Windshield wipers does not stop at the
predetermined park position.G-4
P.54B-240
The windshield intermittent wiper interval cannot
be adjusted by using the variable intermittent wiper
control switch.G-5
P.54B-246
The windshield intermittent wiper interval is not
changed according to the vehicle speed.G-6
P.54B-248
The windshield washer does not work. G-7
P.54B-251 SYSTEM SYMPTOM INSPECTION
PROCEDUREREFERENCE
PA G E
Page 59 of 1500

SYMPTOM CHART
SIMPLIFIED WIRING SYSTEM (SWS)54B-59
Headlamp and
taillampGeneral description concerning the headlamp and
taillampP.54B-257
The taillights do not illuminate normally. H-1
P.54B-260
The headlamps (low-beam) do not illuminate
normally.H-2
P.54B-264
The headlamps (high-beam) do not illuminate
normally.H-3
P.54B-268
When the passing switch is turned "ON," the
headlamps (low-beam or high-beam) do not
illuminate.H-4
P.54B-271
Headlights do not illuminate when the lighting
switch is at "TAIL," and "PASSING" position, but
illuminate at low-beam when the switch is at
"HEAD" position. At this position, the headlamps
cannot be changed to high beam by operating the
dimmer switch.H-5
P.54B-273
The taillamps, the position lamps, front parking
lamps or the license plate lamp do not illuminate.H-6
P.54B-275
One of the headlamps does not illuminate. H-7
P.54B-290
The high-beam indicator lamp does not illuminate. H-8
P.54B-301
Headlamp automatic shutoff function does not
work normally.H-9
P.54B-305
Headlamp dimmer switch automatic resetting
function does not work normally.H-10
P.54B-308
Flasher timer General description concerning the flasher timer
P.54B-309
Turn-signal lamps do not flash when the
turn-signal lamp switch is turned on.I-1
P.54B-310
Hazard warning lamps do not flash when the
hazard warning lamp switch is turned on.I-2
P.54B-314
One of the turn-signal lamps does not illuminate. I-3
P.54B-316
The turn-signal lamp indicator does not illuminate
normally.I-4
P.54B-335
Fog lamp General description concerning the fog lamps
P.54B-339
Fog lamps do not illuminate when the fog lamp
switch is turned on.J-1
P.54B-340
Fog lamps do not go out when the headlamps
(low-beam) are turned off while the fog lamps are
on.J-2
P.54B-345
One of the fog lamps does not illuminate. J-3
P.54B-345
The fog lamp indicator does not illuminate
normally.J-4
P.54B-350 SYSTEM SYMPTOM INSPECTION
PROCEDUREREFERENCE
PA G E
Page 220 of 1500

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-220
INSPECTION PROCEDURE F-3: Sunroof: Sunroof Timer Function does not Work Normally.
NOTE: This troubleshooting requires use of
diagnostic tool MB991958 and SWS monitor kit
MB991813. For details of how to use the SWS moni-
tor, refer to "How to connect SWS monitor
P.54B-13."
.
CIRCUIT OPERATION
The sunroof timer function works according to the
signals from the following switches:
Ignition switch (IG1): OFF
Front door switch: OFF
Vehicle condition
Ignition switch: LOCK position
Front door: Closed
When the driver’s door is opened and closed
while the sunroof timer function is on, the sunroof
operative duration will be changed.
.
TECHNICAL DESCRIPTION (COMMENT)
Is the sunroof timer function does not work normally,
the input circuits from the switches described in
"CIRCUIT OPERATION", the sunroof motor assem-
bly, the ETACS-ECU or the SWS communication line
may be defective.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The front door switch may be defective
The sunroof motor assembly may be defective
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
DIAGNOSIS
Required Special Tools:
MB991223: Test Harness Set
MB991958: diagnostic tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A
MB991813: SWS Monitor Kit
MB991806: SWS Monitor Cartridge
MB991812: SWS Monitor Harness (For Column-ECU)
MB991822: Test Probe Harness
Page 222 of 1500

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-222
STEP 2. Check the input signal by using "FUNCTION
DIAG." menu of the SWS monitor.
Observe how the input signal is changed when the ignition
switch is turned from the ON position to the "LOCK" (OFF)
position.
(1) Operate the MUT-III according to the procedure below to
display "SUNROOF-OPE."
a. Select "Interactive Diagnosis."
b. Select "System select."
c. Select "SWS."
d. Select "SWS MONITOR."
e. Select "Function Diag."
f. Select "SUNROOF."
g. Select "SUNROOF-OPE."
(2) Check that normal conditions are displayed for the items
described in the table below.
Q: Does the MUT-III display the items "IG SW (IG1)" and
"S/R ECU ACK" as normal condition?
Normal conditions displayed for all the items : Replace
the sunroof motor assembly. Check that the sunroof
timer function works normally.
Normal condition is not displayed for the "IG SW (IG1)" :
Refer to Inspection Procedure M-2 "ETACS-ECU
does not receive a signal from the ignition switch
(IG1) P.54B-408."
Normal condition is not displayed for the "S/R ECU
ACK" : Replace the sunroof motor assembly. Check that the
sunroof timer function works normally. ITEM NO. ITEM NAME NORMAL
CONDITION
ITEM 30 IG SW (IG1) OFF
ITEM 72 S/R ECU ACK NORMAL ACK
Page 247 of 1500

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-247
Check the input signal by using "DATA LIST" menu of the
SWS monitor.
Set each switch to the following condition to check input signals
from the variable intermittent wiper control switch:
Ignition switch: ACC
Windshield wiper switch: INT
To prevent damage to Diagnostic Tool MB991958, always
turn the ignition switch to the "LOCK" (OFF) position
before connecting or disconnecting Diagnostic Tool
MB991958. Connect special tool MB991910 before con-
necting special tool MB991812. Be sure to connect special
tool MB991806 after turning on special tool MB991824.
(1) Connect the special tool. Refer to "How to connect SWS
monitor P.54B-13."
(2) Operate Diagnostic Tool MB991958 according to the
procedure below to display "F.WIPER INT."
a. Select "Interactive Diagnosis."
b. Select "System select."
c. Select "SWS."
d. Select "SWS MONITOR."
e. Select "Function Diag."
f. Select "WIPER."
g . S e l e c t " F. W I P E R I N T. "
(3) Check that normal conditions are displayed for the items
described in the table below.
NOTE: Also check that the windshield wiper interval
changes smoothly when the variable intermittent wiper con-
trol switch is rotated from "SLOW" to "FAST" position.
Q: Does the value change within the normal range when
the windshield intermittent wiper interval adjusting
knob is rotated?
YES : Replace the front-ECU. Check that the windshield
intermittent wiper interval changes according to the
vehicle speed or while the windshield intermittent
wiper interval adjusting knob is rotated.
NO : Refer to Inspection Procedure M-7 "ETACS-ECU
does not receive any signal from the variable
intermittent wiper control switch P.54B-426." ITEM NO. ITEM NAME NORMAL
CONDITION
ITEM 37 INT WIPER TIME 1.6
19.0 s
Page 250 of 1500

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-250
STEP 3. Check the input signal by using "DATA LIST"
menu of the SWS monitor.
Check the input signals from the following switches:
Ignition switch: ACC
Windshield wiper switch: INT
Intermittent wiper control: slow side
Connect special tool MB991910 before connecting special
tool MB991812. Be sure to connect special tool MB991806
after turning on special tool MB991824.
(1) Operate the Diagnostic Tool MB991958 according to the
procedure below to display "F.WIPER INT."
a. Select "System select."
b. Select "SWS."
c. Select "SWS MONITOR."
d. Select "Function Diag."
e. Select "WIPER."
f. Select "F.WIPER INT."
(2) Check that normal conditions are displayed for the items
described in the table below.
NOTE: Also check that the wiper interval changes smoothly
when the vehicle is accelerated from 0 km/h (0 mph) to 60
km/h (37.5 mph).
Q: Does the value change within the normal range when
the variable intermittent wiper control switch is rotated?
YES : Replace the front-ECU. The windshield intermittent
wiper interval should change according to the vehicle
speed.
NO : Replace the ETACS-ECU. The windshield intermittent
wiper interval should change according to the vehicle
speed. ITEM NO. ITEM NAME NORMAL
CONDITION
ITEM 37 INT WIPER TIME 14.0
19.0 s
Page 309 of 1500

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-309
FLASHER TIMER
GENERAL DESCRIPTION CONCERNING THE FLASHER TIMERM1549023600238
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80The following ECUs affect the functions and control
of the flasher timer.
FLASHER TIMER FUNCTION
.
TURN-SIGNAL LAMP
The turn-signal lamp output (flashing signal) is turned ON when
the ignition switch is ON and the turn-signal lamp switch is ON
(LH or RH). If the front turn-signal lamp or rear turn-signal lamp
bulb has burned out, the flashing speed increases to indicate
that the bulb has burned out.
NOTE: If LH or RH side turn signal lamp bulbs have burned
out, the flashing speed will remain the same.
.
TURN-SIGNAL INDICATORS
At the same time that the turn-signal lamps are illuminated, the
ETACS-ECU sends a signal to illuminate the turn-signal lamp
indicator via the CAN bus line. The combination meter receives
the transmitted signal and turns the turn-signal lamp indicator
on and off.
.
HAZARD WARNING LAMP
Detects the signal where the hazard warning lamp switch input
changes from OFF to ON, and reverse the flashing state
according to this signal. The hazard warning lamps toggle on
and off whenever the hazard warning lamp switch is operated.
NOTE: The hazard warning lamp switch is a push-return type
toggle switch. FUNCTION CONTROL ECU
Turn-signal lamp ETACS-ECU, column switch
Turn-signal indicators ETACS-ECU, column switch
Hazard warning lamp ETACS-ECU
Page 402 of 1500

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-402
INSPECTION PROCEDURE L-1: Can not customise the functions by operating the multi center
display .
NOTE: This troubleshooting procedure requires the
use of diagnostic tool MB991958 and SWS monitor
kit MB991813. For details on how to use the SWS
monitor, refer to "How to connect SWS monitor
P.54B-13."
.
CIRCUIT OPERATION
The ETACS-ECU enables/disables the functions and
changes their operation time, based on the informa-
tion sent from the multi center display
.
TECHNICAL DESCRIPTION (COMMENT)
If it is impossible to customise the functions by oper-
ating the multi center display , connector(s) or wiring
harness in the CAN bus lines, the ETACS-ECU or
the multi center display unit may be defective.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
Trouble in input signal system
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
Malfunction of the multi center display
The ETACS-ECU may be defective
.
DIAGNOSIS
Required Special Tools:
MB991223: Harness Set
MB991958: Diagnostic Tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A
MB991813: SWS Monitor Kit
MB991806: SWS Monitor Cartridge
MB991812: SWS Monitor Harness (For Column-ECU)
MB991822: Test Probe Harness
