54B-1
GROUP 54B
SIMPLIFIED WIRING
SYSTEM (SWS)
CONTENTS
GENERAL DESCRIPTION. . . . . . . . .54B-2
COMMUNICATION METHOD . . . . . . . . . . 54B-2
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . 54B-2
SPECIAL TOOL . . . . . . . . . . . . . . . . .54B-8
SWS DIAGNOSIS . . . . . . . . . . . . . . .54B-10
GENERAL DESCRIPTION . . . . . . . . . . . . . 54B-10
BEFORE CARRYING OUT
TROUBLESHOOTING . . . . . . . . . . . . . . . . 54B-10
DIAGNOSTIC FUNCTION . . . . . . . . . . . . . 54B-10
SWS DIAGNOSTIC TROUBLESHOOTING
STRATEGY . . . . . . . . . . . . . . . . . . . . . . . . . 54B-12
HOW TO CONNECT SWS MONITOR . . . . 54B-13
HOW TO CHECK ECUS . . . . . . . . . . . . . . . 54B-15
SERVICE DATA CHECK . . . . . . . . . . . . . . 54B-15
PULSE CHECK . . . . . . . . . . . . . . . . . . . . . . 54B-24
DIAGNOSTIC TROUBLE CODE
CHART . . . . . . . . . . . . . . . . . . . . . . . .54B-25
DIAGNOSTIC TROUBLE CODE
PROCEDURES . . . . . . . . . . . . . . . . .54B-25
SYMPTOM CHART . . . . . . . . . . . . . .54B-57
INPUT SIGNAL CHART . . . . . . . . . . .54B-61
SYMPTOM PROCEDURES . . . . . . . .54B-63
TONE ALARM . . . . . . . . . . . . . . . . . . . . . . . 54B-94
GENERAL DESCRIPTION CONCERNING
THE TONE ALARM. . . . . . . . . . . . . . . . . . . 54B-94
CENTRAL DOOR LOCKING SYSTEM. . . . 54B-118GENERAL DESCRIPTION CONCERNING
CENTRAL DOOR LOCKING SYSTEM . . . . 54B-118
POWER WINDOWS . . . . . . . . . . . . . . . . . . 54B-148
GENERAL DESCRIPTION CONCERNING
THE POWER WINDOWS . . . . . . . . . . . . . . 54B-148
KEYLESS ENTRY SYSTEM . . . . . . . . . . . . 54B-187
GENERAL DESCRIPTION CONCERNING
THE KEYLESS ENTRY SYSTEM . . . . . . . . 54B-187
SUNROOF . . . . . . . . . . . . . . . . . . . . . . . . . . 54B-209
GENERAL DESCRIPTION CONCERNING
THE SUNROOF . . . . . . . . . . . . . . . . . . . . . 54B-209
WINDSHIELD WIPER AND WASHER . . . . 54B-223
GENERAL DESCRIPTION CONCERNING
THE WINDSHIELD WIPER AND WASHER 54B-223
HEADLAMP AND TAILLAMP . . . . . . . . . . . 54B-257
GENERAL DESCRIPTION CONCERNING
THE HEADLAMPS AND TAILLAMPS . . . . . 54B-257
FLASHER TIMER . . . . . . . . . . . . . . . . . . . . 54B-309
GENERAL DESCRIPTION CONCERNING
THE FLASHER TIMER . . . . . . . . . . . . . . . . 54B-309
FOG LAMP . . . . . . . . . . . . . . . . . . . . . . . . . 54B-339
GENERAL DESCRIPTION CONCERNING
THE FOG LAMPS . . . . . . . . . . . . . . . . . . . . 54B-339
INTERIOR LAMP . . . . . . . . . . . . . . . . . . . . . 54B-355
GENERAL DESCRIPTION CONCERNING
THE INTERIOR LAMP . . . . . . . . . . . . . . . . 54B-355
INPUT SIGNAL PROCEDURES . . . . .54B-405
CHECK AT ECU TERMINAL . . . . . . .54B-480
ON-VEHICLE SERVICE . . . . . . . . . . .54B-486
CONFIGURATION FUNCTION . . . . . . . . . . 54B-486
Page 4 of 1500
GENERAL DESCRIPTION
SIMPLIFIED WIRING SYSTEM (SWS)54B-4
.
FORGOTTEN KEY PREVENTION
FUNCTION
If the driver's door is locked while it is open and
when the key is still in the ignition key cylinder,
approximately 0.3 second later the ETACS-ECU
activates the unlock relay output for 0.25 second
to prevent the door from being locked with the
key inside the vehicle. In addition, if locking the
door was not prevented, a re-try current is sent
(an unlock relay output ON is sent for 0.25 sec-
ond up to 5 times including the first attempt).
If the passenger's door or driver's door are locked
while the passenger's door is open and when the
key is still in the ignition key cylinder, approxi-
mately 0.3 second later the ETACS-ECU acti-
vates the unlock relay output for 0.25 second to
prevent the door from being locked with the key
inside the vehicle. In addition, if locking the door
was not prevented, a re-try current is sent (an
unlock relay output ON is sent for 0.25 second up
to 5 times including the first attempt).
POWER WINDOW RELAY CONTROL
.
POWER WINDOW RELAY OPERATION
If the ignition switch is turned to "ON" or "ACC" posi-
tion, the power window relay is energized to activate
the power windows.
.
POWER WINDOW TIMER FUNCTION
Even after the ignition is switched off, the
ETACS-ECU keeps the power window relay acti-
vated for approximately 30 seconds, enabling raising
and lowering of the power windows by using the
power window switches. After approximately 30 sec-
onds, the power window relay is deactivated. During
this timed operation, if the driver or passenger doors
are opened, the power window relay is deactivated
from that moment.
KEYLESS ENTRY SYSTEM
.
KEYLESS ENTRY HAZARD ANSWER-
BACK FUNCTION
If the keyless entry transmitter is used to send a lock
signal to the ETACS-ECU, all doors, the liftgate, and
the glass hatch are locked and the hazard warning
lamps flash once. If an unlock signal is sent, the
driver's door is unlocked first, and if a second signal
is sent, all doors, the liftgate, and the glass hatch are
unlocked. Each time the unlock signal is sent, the
hazard warning lamps flash twice.
.
KEYLESS ENTRY HORN ANSWERBACK
FUNCTION
If the keyless entry transmitter is used to send 2 lock
signals to the ETACS-ECU, the first signal locks all
doors, while the second signal sounds the horn once.
.
TRUNK UNLOCK FUNCTION
Press the "TRUNK" button twice within 5 seconds
and the trunk lid will be unlocked.
.
TIMED LOCKING MECHANISM
After unlocking the doors with the keyless entry
transmitter, if no doors are opened or if the ignition
key is not inserted, the ETACS-ECU automatically
locks the doors in 30 seconds.
SUNROOF CONTROL
.
SUNROOF TIMER FUNCTION
The ETACS-ECU enables opening and closing of the
sunroof for 30 seconds after the ignition is switched
off. During this timed operation, if the driver's or front
passenger’s door is opened, the sunroof timer func-
tion is deactivated from that moment.
WINDSHIELD WIPERS AND WASHERS
.
LOW SPEED WIPER, HIGH SPEED WIPER
CONTROL
When the ignition switch in at the ACC or ON
position, and the windshield low speed wiper
switch of the column switch is turned ON, the
front-ECU turns ON the windshield wiper drive
signal, turns OFF (LO) the windshield wiper
speed relay, and operates the windshield wiper at
low speed.
When the windshield high speed wiper switch is
turned ON, the windshield wiper drive signal is
turned ON, the windshield wiper speed switching
relay is turned ON (HI), and the windshield wiper
is operated at high speed.
.
Page 6 of 1500
GENERAL DESCRIPTION
SIMPLIFIED WIRING SYSTEM (SWS)54B-6
FOG LAMP
.
FOG LAMP
The fog lamps will illuminate only when the fog lamp
switch is operated while the low-beam headlamps
are on.
The fog lamps will be switched off when any of the
following conditions is met. The fog lamps will also
be switched off automatically by headlamp automatic
shutdown function.
When the high-beam headlamps are switched
on, the fog lamps will be switched off. If the
low-beam headlamps are switched on again, the
fog lamps will illuminate again.
When the headlamp switch is turned off while the
tail lamps are on or the tail lamps and headlamps
are off, the fog lamps will be switched off. If the
low-beam headlamps are switched on again, the
fog lamps will not illuminate again.
.
FOG LAMP INDICATOR
At the same time that the fog lamps are illuminated,
the ETACS-ECU sends a signal to illuminate the fog
lamp indicator via the CAN bus line. The combination
meter receives the transmitted signal and turns the
fog lamp indicator on and off.
INTERIOR LAMP
ETACS-ECU makes it possible to force operation of
all ON and OFF lamp switches in the overhead con-
sole (the dome lamp, reading lamp, cargo area lamp,
rear personal lamps, front door lamps, and front foot
lamps). This function is assigned higher priority than
the controls for the interior lamp switch that are per-
formed when the doors are in certain positions.
When the lamps are forced on, the illumination
level is 100% as all interior lamps are switched on
(the dome lamp, reading lamp, cargo area lamp,
rear personal lamps, front door lamps, and front
foot lamps). Even when all lamps are forced on,
the interior lamp automatic shutoff function is
active.
When the lamps are forced off, all interior lamps
are immediately switched off (the dome lamp,
reading lamp, cargo area lamp, rear personal
lamps, front door lamps, and front foot lamps).When the interior lamp switch is at DOOR position,
the ETACS-ECU controls the interior lamps as fol-
lows:
When a door is opened with the ignition switch
off, the interior lamps up to a luminance of 100
percent. When a door is closed, the interior lamps
dims a luminance of 65 percent, and goes off 30
seconds later. However, if the ignition switch is
turned ON or if a door is locked while the interior
lamps is dimming, the dome lamp will go off at
that point.
When a door is opened with the ignition switch
ON, the interior lamps up at a luminance of 100
percent. When all doors are closed, the interior
lamps go off.
When the ignition key is removed with all doors
closed, the interior lamps up at a luminance of
100 percent, and goes off 30 seconds later. How-
ever, if the ignition key is inserted again or if a
door is locked while the interior lamps is lighting,
the interior lamps will go off at that point.
To check keyless entry operations more easily,
the interior lamps will flash twice when doors are
locked. When doors are unlocked, the interior
lamps up at a luminance of 100 percent, and
goes off 15 seconds later.
INTERIOR LAMP AUTOMATIC
SHUTDOUN FUNCTION
Illuminated interior lamps such as the front dome
lamp, etc. (all lamps using the dome lamp fuse as the
power supply) will automatically go off in the follow-
ing conditions to prevent the battery from discharging
as a result of forgetting to turn off the lamps or
incomplete closing of the door.
When the ignition switch is turned off and more
than 30 minutes pass by with the interior lamp
illuminated, the interior lamps will go off automati-
cally.
When the ignition switch is turned off and one of
the door switches remains open for 30 minutes
continuously, the interior lamps will go off auto-
matically.
Page 7 of 1500
GENERAL DESCRIPTION
SIMPLIFIED WIRING SYSTEM (SWS)54B-7
SEAT BELT INDICATOR
If any of the following conditions is met with the igni-
tion switch at "ON" or "ST", the ETACS-ECU illumi-
nates, flashes or extinguishes the seat belt indicator
by using the driver's seat belt switch signal and the
vehicle speed signal sent from the combination
meter.
Illuminates when the ignition switch is at "ON"
and the seat belt switch is turned on (the driver's
seat belt is unfastened).
Flashes and illuminates the indicator 12 cycles
(after 0.5 seconds) if any of the following condi-
tions is met when sixty seconds or more have
elapsed since the ignition switch is turned "ON".
One cycle consists of five-second "flashing" and
then three-second "illumination".
a. The vehicle speed has reached 8 km/h (5
mph) while the seat belt switch is turned on
(driver's seat belt is not fastened) with the
ignition switch "ON.
b. The seat belt switch has been turned on
(driver's seat belt has not been fastened) for
at least ten seconds while the ignition switch
has been turned "ON" and the vehicle speed
has been 8 km/h (5 mph) or more.
NOTE: Once this timer operation has been acti-
vated, it will not be activated again until the
vehicle speed reduces to 3 km/h (2 mph) or
less even if any of the following conditions is
met.
The indicator stops illuminating if the ignition
switch or the seat belt switch is turned off (the
driver's seat belt is fastened) while the timer
operation is active.
DOOR-AJAR INDICATOR LAMP
The combination meter receives the signal sent from
the ETACS-ECU about whether each door or trunk is
open or closed and turns the door ajar indicator lamp
on and off. While the door ajar indicator is illumi-
nated, the door ajar warning function is activated and
the door ajar indicator lamp flashes 4 times. If the
door remains open even after the 4 warning flashes,
the door ajar indicator lamp will be illuminated again.
CONFIGURATION FUNCTION
The following functions can be adjusted by operating
the middle-grade multi center display (if equipped).
Keyless entry horn answerback function
Keyless entry hazard lamp answerback function
Timed locking mechanism
Turn-signal lamp buzzer
Door ajar warning buzzer
Adjustment of door unlocking operation on key-
less entry system
Vehicle speed-dependent wiper function
Headlamp automatic shutdown function
Delay-off time of the dome lamp
Interior lamp automatic shutoff function
Initialisation of above mentioned functions
Page 24 of 1500
SWS DIAGNOSIS
SIMPLIFIED WIRING SYSTEM (SWS)54B-24
SUNROOF
PULSE CHECK
M1549015100562
1. The input signals (signals other than SWS
communication line signals), which are
compatible with the SWS monitor by using the
diagnostic tool MB991958 (MUT-III Sub
Assembly) or voltmeter, can be confirmed by the
Pulse Check.2. Use the diagnostic tool MB991958 (MUT-III Sub
Assembly) or voltmeter to check the following
input signals.
NOTE: If a problem is found in the Pulse Check,
refer to Input Signal Chart P.54B-61.
Switches and their conditions, which are applicable
for Pulse CheckITEM ITEM NO. INPUT SIGNAL DISPLAY ON
DIAGNOSTIC TOOLNORMAL CONDITION
SUNROOF
OPE.30 Ignition switch
(IG1)IG SW (IG1) (ETACS ECU) ON
72 Response by the
sunroof-ECUS/R ECU ACK (SUNROOF
ECU)INPUT CHECK (only
momentarily when switch is
operated)
INPUT SIGNAL REQUIREMENTS FOR SOUNDING TONE
ALARM
Key reminder switch When the ignition key is pulled out
Hazard warning lamp switch When the switch is turned from off to on
Door switches A door is opened when all the doors are
closed
Door lock key cylinder switch When a door is locked or unlocked by a key
cylinder
Door lock actuators Move the door lock knob from lock position
to unlock position or vice versa
Door lock switch (incorporated in the power window main
switch and front power window sub switch)When a door is locked or unlocked by a door
lock switch
Keyless entry transmitter When the switch is turned from off to on
Interior lamp loaded signal Illuminates the interior lamps
Page 58 of 1500
SYMPTOM CHART
SIMPLIFIED WIRING SYSTEM (SWS)54B-58
Power windows General description concerning the power
windowsP.54B-148
Power windows do not work at all. D-1
P.54B-151
The power window timer function does not work
normally.D-2
P.54B-161
Only the front door window (LH) does not work by
operating power window main switch.D-3
P.54B-164
Power windows do not work normally by operating
the front passenger's or rear passenger's sub
switches.D-4
P.54B-167
Front or rear passenger's power windows do not
work at all by operating the power window main
switch.D-5
P.54B-187
Keyless entry system General description concerning the keyless entry
system
P.54B-187
Keyless entry system does not operate. E-1
P.54B-191
The dome lamp, the turn-signal lamps and the
horn do not operate through the answerback
function.E-2
P.54B-193
Encrypted code cannot be registered. E-3
P.54B-202
The trunk is not opened when the keyless entry
transmitter "TRUNK" button is operated.E-4
P.54B-205
Sunroof General description concerning the sunroof
P.54B-209
Sunroof does not operate. F-1
P.54B-210
Any of the sunroof switch positions is defective. F-2
P.54B-219
Sunroof timer function does not work normally. F-3
P.54B-220
Windshield wiper and
washerGeneral description concerning the windshield
wiper and washer
P.54B-223
The windshield wiper do not work at all. G-1
P.54B-226
The windshield wipers do not work when the
windshield wiper switch is at "INT" or "MIST"
position or the windshield washer switch is at "ON"
position. However, the wipers work at low speed
when the windshield wiper switch is at "LO" or "HI."G-2
P.54B-234
All of the windshield wiper switch positions are
defective.G-3
P.54B-236
Windshield wipers does not stop at the
predetermined park position.G-4
P.54B-240
The windshield intermittent wiper interval cannot
be adjusted by using the variable intermittent wiper
control switch.G-5
P.54B-246
The windshield intermittent wiper interval is not
changed according to the vehicle speed.G-6
P.54B-248
The windshield washer does not work. G-7
P.54B-251 SYSTEM SYMPTOM INSPECTION
PROCEDUREREFERENCE
PA G E
Page 187 of 1500
SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-187
INSPECTION PROCEDURE D-5: Power Window: Front or rear passenger's power windows do not
work at all by operating the power window main switch.
.
CIRCUIT OPERATION
When you operate each power window switch for
front or rear passengers (incorporated in the power
window main switch), the corresponding power win-
dow motor operates, opening or closing each power
window.
.
TECHNICAL DESCRIPTION (COMMENT)
If the corresponding power window opens and closes
normally when each power window sub-switch is
operated, the power window main switch may be
defective.
.
TROUBLESHOOTING HINT
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The power window main switch may be defective
DIAGNOSIS
Check that power window sub switches operate normally.
Q: A power window cannot work by using the power
window main switch. Can you operate the power
window by using the corresponding power window sub
switch?
YES : Replace the power window main switch. Check that
the front or rear passenger's power window can work
normally by means of power window main switch.
NO : Refer to Symptom Chart P.54B-57 before resolving
this trouble.
KEYLESS ENTRY SYSTEM
GENERAL DESCRIPTION CONCERNING THE KEYLESS ENTRY SYSTEMM1549022000255
The following ECUs affect the functions and control
of the keyless entry system.
FUNCTIONCONTROL
ECU
All door lock function Pressing the transmitter lock button ETACS-ECU
Driver’s door unlock function Pressing the transmitter unlock button once ETACS-ECU
All door unlock function Pressing the transmitter unlock button twice ETACS-ECU
Trunk unlock function Pressing the transmitter trunk button twice ETACS-ECU
Keyless entry hazard answerback and horn answerback function ETACS-ECU
Timed locking mechanism ETACS-ECU
Page 190 of 1500
SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-190
KEYLESS ENTRY HAZARD ANSWERBACK AND
HORN ANSWERBACK FUNCTION
.
KEYLESS ENTRY HAZARD ANSWERBACK
FUNCTION*
1
If the keyless entry transmitter is used to send a lock signal to
the ETACS-ECU, all doors are locked and the hazard warning
lamps flash once. If an unlock signal is sent, the driver's door is
unlocked first,*
2 and if a second signal is sent, all doors are
unlocked. Each time the unlock signal is sent, the hazard warn-
ing lamps flash twice.
NOTE: *
1: The hazard answerback function can be customized
using the keyless entry transmitter (Refer to Group 42 P.42-72,
Keyless Entry System) or by using the multi center display
(middle grade type). Refer to P.54B-486.
NOTE: *
2: Vehicles with a multi center display (middle grade
type) can be customized so that a single unlock operation will
unlock all doors. Refer to P.54B-486.
.
KEYLESS ENTRY HORN ANSWERBACK
FUNCTION
If the keyless entry transmitter is used to send a lock signal to
the ETACS-ECU, the first signal locks all doors while the sec-
ond signal sounds the horn once.
NOTE: : The horn answerback function can be customized by
using the keyless entry transmitter (Refer to Group 42 P.42-72,
Keyless Entry System) or by using the multi center display
(middle grade type). Refer to P.54B-486.
TIMED LOCKING MECHANISM
.After unlocking the doors with the keyless entry transmitter, if
no doors are opened, if the ignition key is not inserted or if the
locking function is not operated, the ETACS-ECU automatically
locks the doors in 30 seconds.
NOTE: The timed locking function can be customized on vehi-
cles equipped with a multi center display (middle grade type).
Refer to P.54B-486.
Page 191 of 1500
SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-191
INSPECTION PROCEDURE E-1: Keyless Entry System: Keyless entry system does not operate.
.
CIRCUIT OPERATION
A receiver is incorporated in the ETACS-ECU. This
receiver receives a lock or unlock signal from the
transmitter.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The RKE transmitter may be defective
The ETACS-ECU may be defective
DIAGNOSIS
Required Special Tools:
MB991223: Harness Set
MB991958: diagnostic tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A
STEP 1. Verify the central door locking system.
Q: Does the central door locking system work normally?
YES : Go to Step 2.
NO : Refer to Inspection Procedure C-1 "The central door
locking system does not work at all P.54B-122."
Page 193 of 1500
SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-193
INSPECTION PROCEDURE E-2: Keyless Entry System: The dome lamp, the turn-signal lamps and the
horn do not operate through the answerback function.
.
CIRCUIT OPERATION
The ETACS-ECU operates the following functions
when it receives lock or unlock signal from the trans-
mitter:
Dome lamp answerback function
Turn-signal lamp answerback function
Horn answerback function
.
TECHNICAL DESCRIPTION (COMMENT)
The turn-signal lamps and horn answerback func-
tions can be disabled or enabled. However, the dome
lamp answerback function cannot be disabled.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The turn-signal lamp may be defective
The dome lamp may be defective
The horn may be defective
The ETACS-ECU may be defective
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
