BODY - Main Body23-3 \
Front end upper bar
Headlamp support panelsidemember
to crossmember braceFront end crossmember
Fender suppoR panelFront end upper bar reinforcement
Front upper frame, outer
Front upper frame, lower
Front upper frame, inner
Front fender shield
Shield plateStrut house panel
Front tie down bracket, outer
Front tie down bracket, inner
Front sidemember
Front sidemember, rear
Dash panel crossmember
Dash panel extension
Front floor side sill, inner, front
Dash panelCowl top panel, inner
Cowl top panel, outer
Steering column support bracket
Front deck crossmember
Front upper frame extension, inner
Front upper frame extension. outer
Upper frame extension silencer
Roof side rail, inner
Front pillar, inner, upper
(A)Front pillar, inner, upper (B)Front pillar, inner, lower
Front pillar, outer, lower
Front pillar, outer, upper
Roof side rail, outer
Roof drip channelFront floor side sill, outer
Side sill silencer
Shelf corner bracketSeat striker reinforcement
Rear wheelhouse, innerRear wheelhouse front extension
Quarter panel, inner, upper
Quarter panel, inner, lower
Beltline reinforcementCenter pillar, outer
Rear pillar, outer
Rear lamp housing
Rear lamp housing extensionQuarter outer lower extension
Quarter panel, outer
Center pillar reinforcement, upper
Roof drip channel extension
Roof panel
Front roof rail
Rear roof railFront floor side sill, innerFront floor crossmember, front
Front floor crossmember, rear
Front floor pan
Front floor sidememberFront floor sidemember extension
Rear seat crossmemberRear seat panRear floor crossmember, upper
Lateral rod bracket
Spare tire bracket
Rear floor crossmember, lower
Jack up reinforcement
Rear floor panTrailing arm bracket
Rear floor side sill
Rear floor sidemember
Rear end panelRear fascia bracket, upper
c
c

BODY- Main Body23-5
Front end upper bar
Headlamp support panel
Sidemember to
crossmember brace
Front end crossmember
Fender support panel
Front end upper bar reinforcement
Front upper frame, outerFront upper frame, lower
Front upper frame, inner
Front fender shield
Shield plate
Strut house panelFront tie down bracket, outer
Front tie down bracket, inner
Front sidemember
Front sidemember. rear
Dash panel crossmember
Dash panel extensionFront floor side sill, inner, front
Dash panel
Cowl top panel, innerCowl top panel, outer
Steering column support bracket
Front deck crossmemberFront upper frame extension, inner
Front upper frame extension, outer
Upper frame extension silencer
Roof side rail, inner
Front pillar, inner, upper (A)Front pillar, inner, upper (BI
Front pillar, inner, lowerFront pillar, outer, lower
Front pillar, outer, upper
Roof side rail, outer
Roof drip channelFront floor side sill, outer
c
Side sill silencer
Shelf corner bracket
Seat striker reinforcement
Rear wheelhouse, inner
Rear wheelhouse front extension
Quarter panel. inner. upper
Quarter panel, inner. lower
Beltline reinforcementCenter pillar. outer
Rear pillar, outer
Rear lamp housing
Rear lamp housing extensionQuarter outer lower extension
Quarter panel, outer
Center pillar reinforcement, upper
Roof drip channel extension
.
Roof panelFront roof railRear roof railFront floor side sill, innerFront floor crossmember. frontFront floor crossmember. rear
Front floor pan
Front floor sidemember
Rear seat
crossmember
Rear seat panRear floor crossmember, upper
Rear floor crossmember, lower
Rear end crossmember
Rear floor pan
Spare tire bracketRear floor sidemember front extensionRear floor side sill
Rear floor sidemember
Rear fascia bracket. upper
Rear end
oanel

/E 7_.___-__----_BODY
- Main Body23-7Material
IhPan name
1Front door beltline reinforcement,
outer
2Front door, outer, rear3Front door, inner, rear4 Front fender bracket
5Cowl top panel, outer6Cowl top panel. inner7Front upper extension, inner
8 Roof drip channel
9Rear wheelhouse front extension
10 Roof drip channel extension
11 Rear pillar. outer
12 Fuel filler neck bracket
13 Fuel filler door panel
14 Quarter outer lower extension
15 Rear lamp housing extension
16 Dash panel
17Front floor side sill. inner, front
18 Dash panel extension
19 Dash panel crossmember
20 Front floor sidemember
21Front floor side sill, inner
22 Front floor sidemember extension
23 Rear seat pan
24 Rear end panel,
outer25 Rear fascia upper bracket
26 Front end upper bar reinforcement
27 Turn lamp bracket
Fender support plate
Sidemember to crossmember brace
30 Headlamp support panel
31 Oil cooler bracket
32 Front end upper bar
33 Shield plate
34 Front upper frame, inner
35 Front upper frame, lower
36 Front upper frame, outer
37 Rear floor side sill reinforcement
SGACCIO.Part name
38 Roof panel (for sun roof)
39 Front door inner panel
10 Hood panel, inner
11 Front fender panel
12 Tailgate panel, outer, upper13 Tailgate panel. inner14 Front floor side sill. outer
15 Rear wheelhouse, inner
16 Quaner panel, outer17 Quarter panel, inner, lower18 Rear lamp housing
19 Front floor pan50 Rear end panel, inner
51 Front fender shield
52 Rear floor side sill
63 Center pillar, outer
64 Spring house panel
65 Backbone rear reinforcement
66 Rear floor
crossmember. lower
67 Rear floor pan
68 Strut house panel
69 Rear floor sidemember reinforcement
70 Rear floor sidemember
71 Front sidemember, rear
72 Bumper bracket
73 Front
sidemember. inner
74 Front sidemember rear reinforcement
75 Lateral rod bracket
76
ITrailing arm bracket
53 Rear seat crossmember
54 Rear floor crossmember reinforcement
55Rear floor seat belt reinforcement56 Jack up reinforcement
57 Radiator bracket
58 Front tie down bracket. inner
59Rear floor sidemember front bulkhead
60Rear floor sidemember rear bulkhead61Rear floor sidemember centerreinforcement77 Front door panel, outer
78 Hood panel, outer
79 Tailgate panel, outer, lower
80 Front pillar, inner, upper(B)
81 Front pillar, outer, upper
82 Front pillar, outer lower
83 Front upper frame extension, outer
84 Lateral rod reinforcement
85 Sidemember seat belt reinforcement
86 Rear floor sidemember extension
SGAHC87 Front pillar, inner, upper (A)
88 Front pillar, inner, lower
89 Spare tire bracket
62 Rear tie down reinforcement
i
l SGACC%;k; 3 Gaivannealed steel plate
;E;;E I SPHC, SPCD or SPCE plated with an electrical zinc-nickel alloy
SPRC: Phosphorus added
SENC35R: SPRC35R with electrogalvanized zink-nickel CoatingSGAC35R:
Phosporus added (also galvannealed)‘he numbers in the material codes indicate the tensile strengthMaterial
SGACE
SENCE
SENHC
SENC35R
SENPH38
SGAC35R
SPRC35

BODY - Main Bodv23-9
No.Part name
1Front door beltline reinforcement,
outer
2Front door, outer, rear3Front door, inner, rear4 Front fender bracket
5 Roof drip channel
6Rear wheelhouse front extension7Roof drip channel extension8 Rear pillar, outer
9Fuel filler neck bracket10 Rear lamp housing extension
11Quarter outer lower extension
12 Fuel filler door panel
13 Front upper frame extension, inner
14 Dash panel crossmember
15 Dash panel extension
16 Front floor side sill, inner, front
17 Dash panel
18 Front floor sidemember
19 Front floor side sill, inner
20 Rear seat crossmember
21 Rear seat pan
22 Rear end crossmember
23 Child restraint reinforcement
24 Rear fascia upper bracket
25 Rear end panel, outer
26 Oil cooler bracket
27 Headlamp support panel
28 Sidemember to crossmember brace
29 Fender support plate
30 Turn lamp bracket
31Front end upper bar32Front end upper bar reinforcement33 Front upper frame, outer
34 Front upper frame, lower
35 Front upper frame, inner
36 Shield plate
37 Rear floor side sill reinforcementMaterial
No.Part name
44 Front door panel, inner
45 Roof panel (for sun roof)
46 Hood panel, inner
47 Front fender panel
48 Tailgate panel, outer. upper
49 Tailgate panel, inner
50 Front floor side sill. outer
51 Quarter panel, inner, lower
52 Rear wheelhouse, inner
53 Quarter panel, outer
54 Rear lamp housing
55 Cowl top panel, outer
56 Cowl top panel, inner
57 Front floor pan
58 Rear end panel, inner
59 Front fender shield
60 Rear floor side sill
SGACC61 Spring house panel
62 Center pillar, outer
63 Backbone rear reinforcement
64 Propeller shaft rear bracket
65 Rear floor crossmember. lower
66 Rear floor pan
67 Strut house panel
68 Rear floor sidemember front
extension
69 Rear floor sidemember
70 Differential mount bulkhead
7 1 Front sidemember. rear
72 Rear floor sidemember reinforcement
38 Radiator bracket
39 Front tie down bracket, inner
40 Rear tie down reinforcement
41
’ Rear floor seat belt reinforcement42Rear floor sidemember front bulkhead43Rear floor sidemember rear bulkhead
F
SGAHC73 Front door panel, outer
74 Hood panel, outer
75 Tailgate panel, outer, lower
76 Front pillar, inner, upper(B)
77 Front pillar, outer, upper
78 Front pillar, outer, lower
79 Front upper frame extension, outer
80 Sidemember seat belt reinforcement81Rear floor sidemember extension82 Bumper bracket
83 Front sidemember. inner
84 Front sidemember rear reinforcement
85 (Front pillar. inner, upper (A)86 Front pillar, inner, lower
87 Spare tire bracket
x::-SGAHC-I-Galvannealed steel plate
E% x--
SPHC. SPCD or SPCE plated with an electrical zinc-nickel alloy
SPRC: Phosphorus added
SENC35R: SPRC35R with electrogalvanized zink-nickel coating
SGAC35R: Phosporus added (also galvanneafed)The numbers in the material codes indicate the tensile strengthMaterial
SGACE
SENCE
SENHC
SENHE
AGSC35R
SENC35R
SPRC35

_.-
23-16BODY - Main Bodv
Access Holes
Access holes are provided in inner panels including doors and quarter panels to facilitate correction of outer
panel sheet metals.
= : Access holes32AO119Headlamp Support
The following component supply formats have been adopted in order to cope with various damage
conditions.l Supply as assembly
‘+j
3,Headlamp support
1+2+3+4+5+6l Supply as individual parts
1. 2, 3, 4. 5
1. Front end upper bar
2. Front end upper bar reinforcement
3. Fender support plate
4. Headlamp support side panel
5. Sidemember to crossmember brace
c?jpaiig3L
6. Front end crossmemberl r;‘4
I31AO244Fender Shield
The following component supply formats have been adopted in order to cope with various damage
conditions.
l Supply as assembly
Fender shield
1+2+3+4+5+6+7Wheelhouse inner
1+2+3+4l Supply as individual parts
1. 2, 3. 6, 7. 8
1.Frontupperframe,outer5.Frontsidemember6
2. Front upper frame, inner
3. Shield elate
6. Front end gusset, outer
7. Front end ausset. inner
I4. Front wheelhouse8. Front sidemember. rear
