5-78BRAKES - Front Disc Bra&.iDISASSEMBLY AND REASSEMBLY
NO51
< 1 -piston type>
64-86
46-62
64-86
46-6216
/
w”! 14N0284
Caliper assembly disassembly steps
M 1. Guide pin
l + 2. Lock pin
l + 3. Bushing
4. Caliper support (Pad, clip, shim)
l + 5. Guide pin bootMI 6. Lock pin boot
**7. Boot ring4*8. Piston boot
l *** 9. Piston
+I) l * IO. Piston seal11. Brake hosel + 12. Caliper body
Pad assembly disassembly steps
e+ 1. Guide pin
l + 2. Lock pin*+ 3. Bushing4. Caliper support (Pad, clip, shim)
13. Pad and wear indicator assembly
14. Pad assembly
++ 15. Outer shim16. Clip
e+ 17. Inner shim
NOTE
(1) Reverse the disassembly procedures to reassemble.(2)
~~ : Refer to “Service Points of Disassembly”.(3) l + : Refer to “Service Points of Reassembly”.
(4) m : Non-reusable parts
1
i14AO537Brake caliper kit
Pad repair kitSeal and boots
repair kit
10 6
5’ 8 7
-.I.14AD54(

Boot. ring14KO541460054L
SERVICE POINTS OF DISASSEMBLYNOSLFAJWhen disassembling the front disc brakes, disassemble both
sides (left and right) as a set.
7. REMOVAL OF BOOT RING
Remove boot ring with flat tip (-1 screwdriver.
8. REMOVAL OF PISTON BOOT/g. PISTON
Protect caliper body with cloth. Blow compressed air
through brake hose to remove piston boot and piston.
CautionBlow compressed air gently.
10. REMOVAL OF PISTON SEAL
(1) Remove piston seal with finger tip.
CautionDo not use flat tip
(-) screwdriver or other tool to
prevent damage to inner cylinder.
(2) Clean piston surface and inner cylinder with
trichloro-ethylene, alcohol or specified brake fluid.
Specified brake fluid: MOPAR Brake
Fluid/
Conforming to DOT3 or DOT4
INSPECTIONNOXGAJ
l Check cylinder for wear, damage or rust.
l Check piston surface for wear, damage or rust.
l Check caliper body guide pin or lock pin for wear.
l Check pad for damage or adhesion of grease, check
backing metal for damage.
PAD WEAR CHECK
Measure thickness at the thinnest and worn area of the pad.
Replace pad assembly when pad thickness is less than the limit
value.Limit value: 2.0 mm
(.08 in.)

----aI’-I
5-80BRAKES - Front Disc Brake
I-
Pad and wear
indicator assemblyPad assembly
Grease14FOO97
14KOIQPiston boot
’14KO70
Grease
L
SERVICE POINTS OF REASSEMBLYWC17. INSTALLATION OF INNER
SHIM/15. OUTER SHIMCoat the mounting surfaces of the pad and inner shim
antthe mounting surface of the inner shim and outer
shinwith repair kit grease, and assemble them.
Coat grease with care to prevent swelling.
Specified grease: Repair kit grease (orange)
Caution
Prevent oily materials and other dirt from sticking to
tht
friction surfaces of the pad and brake disc.12. APPLICATION OF BRAKE FLUID TO CALIPER BODY
Apply specified brake fluid to inner cylinder.
Specified brake fluid: MDPAR Brake Fluid/
Conforming to DOT3 or
DOT410. INSTALLATION OF PISTON SEAL
Install piston seal in cylinder groove.
Caution
Do not wipe special grease on piston seal.
9. INSTALLATION OF PISTON
(1) Apply specified brake fluid to piston. Insert into
cylinde’without twisting.
Specified brake fluid: MOPAR Brake Fluid/
Conforming to DOT3 or DOT4(2) Fill piston edge with specified grease. Install piston
boots.Specified grease: Repair kit grease (orange)
6. APPLICATION OF GREASE TO LOCK PIN
BOOT/5GUIDE PIN BOOT/3. BUSHING
Grease parts as illustrated with specified grease.
Specified grease: Repair kit grease
(orange)

5-82BRAKES - Front Disc BrakeDISASSEMBLY AND REASSEMBLY
<2-piston type>
NOBLE..75 Nm
54 ft.lbs.
\
8Nm/6 ft.lbs.75 Nm
/
54 ft.lbs.Brake caliper kit
Pad repair kit
ISeal and boots
repair kit
6lEl/14N02664
Caliper assembly disassembly steps
l + 1. Guide pin
~~ 2. Lock pin
l 3. Bushing
4. Caliper support (pad, clip, shim)+4 5. Boot
6. Boot ring
4*7. Piston boot+e ++ 8. Piston** l + 9. Piston seall +I 0. Caliper body
Pad assembly disassembly steps
~~ 1. Guide pin
l + 2. Lock pinI)+ 3. Bushing
4. Caliper support (pad, clip, shim)
11. Pad assembly (with wear indicator)
12. Pad assembly
l +13. Outer shim
l 414. Inner shim15. ClipReverse the disassembly procedures to reassemble.
d*: Refer to “Service Points of Disassembly”.
l 4: Refer to “Service Points of Reassembly”.
‘:m: Non-reusable parts

BRAKES 7 Front Disc Brake5-83
14AO55314A0552
\Piston seal\
14AO551
--SERVICE POINTS OF DISASSEMBLYiUO5LFCBWhen disassembling the rear disc brakes, disassemble both
sides (left and right) as a set.7. REMOVAL OF PISTON
BOOT/8. PISTON
Pump in compressed air through the brake hose installa-
tion hole and remove the pistons and piston boot.Caution
When removing the pistons, be sure to use the handle
of a plastic hammer and adjust the height of the two
pistons while pumping in air slowly in so that the pis-
tons protrude evenly.
I Do not remove one piston completely before trying to
,remove the other piston because it will become im-Possible to remove the second piston.
9. REMOVAL OF PISTON SEAL
(1) Remove piston seal with finger tip.Caution
Do not use a screwdriver or other tool to prevent
damage to inner cylinder.
(2) Clean piston surface and inner cylinder with trichloro-
ethylene, alcohol or specified brake fluid.Specified brake fluid:
DOT3 or DOT4INSPECTION
NOSLGCB
lCheck cylinder for wear, damage or rust.
lCheck piston surface for wear, damage or rust.
lCheck caliper body or sleeve for wear.
lCheck pad for damage or adhesion of grease, check back-
ing metal for damage.
lCheck wear indicator for damage.PAD WEAR CHECK
Measure thickness at the thinnest and worn area of the pad.
Replace pad assembly when pad thickness is less than the
limit value.Standard value: 10 mm
(.39 in.)
Limit: 2.0 mm
(.08 in.)

BRAKES -Front Disc Brake
l-Pad and wear
indicator assembly Pad assembly
Inner
shim
Outershim
11Inner shim
Outer shim
GreaseGrease14FOO97
al
14LO127Brake fl
Grease
14LO128GreaseSERVICE
POINTS OF REASSEMBLYNW7. INSTALLATION OF INNER
SHIM/13. OUTER SHIM
Coat the mounting surfaces of the pad and inner shim
a
the mounting surface of the inner shim and outer shim vv
repair kit grease, and assemble them.
Coat grease with care to prevent swelling.Specified grease: Repair kit grease (orange)
Caution
Prevent oily materials and other dirt from sticking,
the friction surfaces of the pad and brake disc.12.APPLlCATlON OF BRAKE FLUID TO CALIPER
BODjApply specified brake fluid to inner cylinder.,.;Specified brake fluid: MOPAR Brake Fluid/;:ti
”Conforming to
DOT3 or DOT4
10. INSTALLATION OF PISTON SEAL..I.‘”Install piston seal in cylinder groove.Caution
Do not wipe special grease on piston seal.
9. INSTALLATION OF PISTON.
(1) Apply specified brake fluid to piston.
Insert into cylindlwithout twisting.
(/ifiL-_. i//Specified brake fluid: MOPAR Brake Fluid/
Conforming to
DOT3
or
DOT4(2) Fill piston edge with specified grease. Install pistc
boots.Specified grease: Repair kit grease (orange)
6. APPLICATION OF GREASE TO BOOT/3. BUSHING-’
Grease parts as illustrated with specified grease.Specified grease: Repair kit grease (orange)

BRAKES - Front Disc Brake/Rear Disc Brake5-852. INSTALLATION~OF LOCK PIN/l. GUIDE PIN
Install the guide pin and lock pin so the identification mark
on the caliper body and head mark on the guide pin and
lock pin are aligned.
.+AR msc BRAKEREMOVAL AND INSTALLATION
Pre-removal Operationl Draining of Brake Fluid

9-14 Nm7-10 ft.lbs.
50-60 Nm
36-43 ft.lbs.
/Post-installation Operation
*Supplying Brake Fluid
l Bleeding(Refer to P.5-50.)*Adjustment of Parking Brake Lever
Stroke
(Refer to P.5-48.)
200-260 Nm144-188 ft.lbs.13-17 Nm
9-12 ft.lbs.
/ -29-14
Nh7- 10 ftlbs.
Removal steps
1. Parking brake cable connection
2. Brake hose connection
3. Rear brake assembly
4. Rear brake disc
5. Hubcap
l 6. Wheel bearing nut
14AO5747. Washer
8. Rear speed sensor bracket

9. Rear hub assembly14. Dust shieldI ‘: I
FyEeverse the removal procedures to reinstall.
(2) +* : Refer to “Service Points of Removal”.,,
(3) l + : Refer to “Service Points pt(4) m : Non-reusable parts:lpstallation
../ ‘E-w,,,

5-86
BRAKES - Rear Disc Btike55-65 Nm
50-60 Nm
36-43 ft.lbs.9-14 Nm
2Pre-removal Operation
*Draining of Brake Fluid
Removal steps
1. Parking brake cable connection
4*2. Brake hose connection
3. Rear brake assembly
4. Rear brake disc
+e l * 10. Self locking nutl * 11. Companion flange
12. Rear speed sensor
ABS>
*e ++ 13. Rear axle shaft
14. Dust shieldPost-installation Operation
@Supplying Brake Fluid@Bleeding(Refer to P.5-50.)l Adjustment of Parking Brake LeverStroke
(Refer to P.5-48.)
NOTE(1) Reverse the removal procedures to reinstall.
(2) +* : Refer to “Service Points of Removal”.
(3) I)+ : Refer to “Service Points of Installation”.
(4) q : Non-reusable parts

Brake tubeSERVICE POINTS OF -REMOVALNO5MBAD2. DISCONNECTION OF BRAKE HOSE
Holding the lock nut on the brake hose side, loosen the
flared brake line nut.
BRAKES - Rear Disc Brake5-8710. REMOVAL OF SELF LOCKING NUT
Using end yoke holder, secure and hold the rear axle shaft,
and remove the self locking nut.13. REMOVAL OF REAR AXLE SHAFT
Using the special tool, remove the rear axle shaft.
INSPECTIONNOSMDABal Check disc for wear. (Refer to
P.5-56, Rear Brake Disc
Thickness Check.)l Check disc for
runout. (Refer to P.5-57, Rear Brake Disc
Run-out Check.)l Check disc for damage.
SERVICE POINTS OF INSTALLATION
NOBMCAF13. INSTALLATION OF
REARAXLESHAFTill.COMPANION
FLANGE/lo. SELF LOCKING NUT(1)
Provisionally install the rear axle shaft to the trailing
arm.(2) Install the companion flange to the rear axle shaft, and
install the self locking nut.
(3) Then, using end yoke holder, secure and hold the rear
axle shaft, and tighten the self locking nut.6. INSTALLATION OF WHEEL BEARING NUT
After tightening the wheel bearing nut, align with the
indentation in the spindle, and then crimp.
:. ‘.:,,

~~~HEEL AND TIREN22GA..
{EMOVAL AND INSTALLATION
Aluminium type
120-140 Nm87-101 ft.lbs.
6
140 Nm01 ft.lbs.
llA0405
Removal steps
I. Wheel cover
2. Center cover
l + 3. Wheel nuts4. Center cap
5. Spring6. Ornament
NOTE7. Balance weight
8. Tire
9. Wheel
(1) Reverse the removal procedures to reinstall.
(2) l 4
: Refer to “Service Points of Installation”.llA0366
llA0407,’ J’
7VA0364
llA0406
SERVICE POINT OF INSTALLATIONN22GDABs3. INSTALLATION OF WHEEL NUTS
On the high speed tire (205/55Rl6 88V) vehicle, the left andright tires are respectively specified. Attach the tires as
follows:
Observe the wheel in the
P direction as illustrated, and the
direction characters will be found.
Attach the
(44 ROTATION LEFT SIDE) tire on the leftwheel, and the (ROTATION RIGHT SIDE DD) tire on the
right wheel.,
