tailgate MITSUBISHI LANCER 2005 Workshop Manual

42-1
GROUP 42
BODY
CONTENTS
HOOD . . . . . . . . . . . . . . . . . . . . .
42-3
ON-VEHICLE SERVICE. . . . . . . . .
42-3
ADJUSTMENT OF CLEARANCE
AROUND HOOD . . . . . . . . . . . . . . . . . . 42-3
ADJUSTMENT OF ALIGNMENT OF
HOOD STEPPED PORTION AND
HOOD STRIKER . . . . . . . . . . . . . . . . . . 42-3
ADJUSTMENT OF HOOD HEIGHT . . . 42-3
HOOD . . . . . . . . . . . . . . . . . . . . . . .42-4
REMOVAL AND INSTALLATION . . . . . 42-4
FENDER . . . . . . . . . . . . . . . . . . .42-5
SPECIAL TOOL . . . . . . . . . . . . . . .
42-5
FENDER . . . . . . . . . . . . . . . . . . . . .42-6
REMOVAL AND INSTALLATION . . . . . 42-6
FUEL FILLER LID . . . . . . . . . . .42-8
REMOVAL AND INSTALLATION .
42-8
STRUT TOWER BAR . . . . . . . .42-9
REMOVAL AND INSTALLATION .
42-9
WINDOW GLASS . . . . . . . . . . . 42-9
ADHESIVE . . . . . . . . . . . . . . . . . . .
42-9
SPECIAL TOOLS . . . . . . . . . . . . . .42-9
WINDOW REPAIR . . . . . . . . . . . . .42-10
WINDSHIELD . . . . . . . . . . . . . . . . .42-12
REMOVAL AND INSTALLATION . . . . . . 42-12
REAR WINDOW GLASS . . . . . . . .42-16
REMOVAL AND INSTALLATION . . . . . . 42-16
QUARTER WINDOW GLASS . . . .42-19
REMOVAL AND INSTALLATION . . . . . . 42-19
TAILGATE WINDOW GLASS . . . .42-22
REMOVAL AND INSTALLATION . . . . . . 42-22
DOOR . . . . . . . . . . . . . . . . . . . . 42-25
SERVICE SPECIFICATIONS . . . . .
42-25
SEALANT . . . . . . . . . . . . . . . . . . . .42-25
SPECIAL TOOLS . . . . . . . . . . . . . .42-25
Continued on next page

42-2
TROUBLESHOOTING . . . . . . . . . .42-26
ON-VEHICLE SERVICE. . . . . . . . .42-27
DOOR FIT ADJUSTMENT. . . . . . . . . . . 42-27
DOOR WINDOW GLASS ADJUSTMENT42-28
GLASS SLIDING MECHANISM CHECK
AND ADJUSTMENT . . . . . . . . . . . . . . . 42-28
POWER WINDOW OPERATING
CURRENT CHECK . . . . . . . . . . . . . . . . 42-28
POWER WINDOW RELAY CHECK . . . 42-29
CIRCUIT BREAKER (INCORPORATED
IN THE POWER WINDOW MOTOR)
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-29
POWER WINDOW CHECK . . . . . . . . . . 42-29
CENTRAL DOOR LOCKING SYSTEM
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-29
DOOR OUTSIDE HANDLE PLAY
CHECK . . . . . . . . . . . . . . . . . . . . . . . . . 42-29
DOOR INSIDE HANDLE PLAY
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . 42-30
DOOR ASSEMBLY . . . . . . . . . . . .42-31
REMOVAL AND INSTALLATION . . . . . 42-31
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-32
DOOR GLASS AND
REGULATOR . . . . . . . . . . . . . . . . .
42-32
REMOVAL AND INSTALLATION . . . . . 42-32
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-34
DOOR HANDLE AND LATCH . . . .42-36
REMOVAL AND INSTALLATION . . . . . 42-36
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-37
WINDOW GLASS RUNCHANNEL AND
DOOR OPENING
WEATHERSTRIP . . . . . . . . . . . . . .
42-39
REMOVAL AND INSTALLATION . . . . . 42-39
TRUNK LID . . . . . . . . . . . . . . . .42-41
SPECIAL TOOL . . . . . . . . . . . . . . .
42-41
ON-VEHICLE SERVICE. . . . . . . . .42-41
TRUNK LID ADJUSTMENT . . . . . . . . . . 42-41
ADJUSTMENT OF CLEARANCE
AROUND TRUNK LID . . . . . . . . . . . . . . 42-42
TRUNK LID STRIKER ADJUSTMENT . 42-42
TRUNK LID HEIGHT ADJUSTMENT . . 42-42
TRUNK LID . . . . . . . . . . . . . . . . . . .42-43
REMOVAL AND INSTALLATION . . . . . . 42-43
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-45
TAILGATE . . . . . . . . . . . . . . . . 42-46
SERVICE SPECIFICATIONS . . . . .
42-46
SEALANTS . . . . . . . . . . . . . . . . . . .42-46
SPECIAL TOOL . . . . . . . . . . . . . . .42-46
TROUBLESHOOTING . . . . . . . . . .42-46
ON-VEHICLE SERVICE . . . . . . . . .42-46
TAILGATE FIT ADJUSTMENT. . . . . . . . 42-46
TAILGATE HANDLE PLAY CHECK . . . . 42-47
TAILGATE . . . . . . . . . . . . . . . . . . .42-48
REMOVAL AND INSTALLATION . . . . . . 42-48
TAILGATE HANDLE AND
LATCH . . . . . . . . . . . . . . . . . . . . . .
42-50
REMOVAL AND INSTALLATION . . . . . . 42-50
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-51
KEYLESS ENTRY SYSTEM . . 42-51
SERVICE SPECIFICATIONS . . . . .
42-51
SPECIAL TOOLS . . . . . . . . . . . . . .42-52
TROUBLESHOOTING . . . . . . . . . .42-53
ON-VEHICLE SERVICE . . . . . . . . .42-53
KEYLESS ENTRY SYSTEM CHECK. . . 42-53
KEYLESS ENTRY SYSTEM TIMER
LOCK FUNCTION INSPECTION . . . . . . 42-53
ENABLING/DISABLING
THE ANSWERBACK FUNCTION . . . . . 42-53
HOW TO REGISTER SECRET CODE . 42-55
TRANSMITTER. . . . . . . . . . . . . . . .42-58
DISASSEMBLY AND REASSEMBLY . . 42-58
INSPECTION . . . . . . . . . . . . . . . . . . . . . 42-59

STRUT TOWER BAR
BODY42-9
STRUT TOWER BAR
REMOVAL AND INSTALLATIONM1421005600091
WINDOW GLASS
ADHESIVEM1422000500081
SPECIAL TOOLSM1422000600293
AC304680AB
Strut tower bar44 ± 5 N·m
Item Specified adhesive
Windshield 3M ATD Part No.8609 Super Fast Urethane Auto Glass
Sealant or equivalent
3M ATD Part No.8608 Super Fast Urethane Primer or
equivalent Rear window glass
Quarter window glass
Tailgate window glass
Tool Number Name Use
MB990480 Glass holder Removal and installation of window glass
MB990784 Ornament remover Removal of rear window lower moulding
MB990480
MB990784

WINDOW GLASS
BODY42-10
WINDOW REPAIRM1422005600027
The windshield, rear window glass, quarter window
glass and tailgate window glass are attached by an
urethane-base adhesive to the window frame. This
adhesive provides improved glass holding and
sealing, and also gives body openings a greater
structural strength.
ITEMS
HANDLING OF AUTO WINDOW SEALER
Keep the sealant in a cool place, not exposed to the
direct rays of the sun. Do not place any heavy article
on the sealant nor press it, otherwise it will become
deformed. Avoid storing the sealant for more than 6
months, because it will lose its sealing effect.
BODY PINCH-WELD FLANGE SERVICING
Before servicing the body pinch-weld flange, remove
old adhesive completely. If the flange requires
painting, bake it after painting is completed. Name Remark
Adhesive 3M ATD Part No.8609 Super Fast Urethane Auto Glass Sealant or
equivalent
Primer 3M ATD Part No.8608 Super Fast Urethane Primer or equivalent
Spacers Available as service part
Dam Available as service part
Anti-rust solvent (or Tectyl
506T.Valvoline Oil Company)For rust prevention
Isopropyl alcohol For grease removal from bonded surface
Steel piano wire Dia. × length... 0.6mm × 1m For cutting adhesive
Glass adhesive knife For cutting adhesive
Adhesive gun For pressing-out adhesive

WINDOW GLASS
BODY42-22
TAILGATE WINDOW GLASS
REMOVAL AND INSTALLATIONM1422003700170
Pre-removal and Post-installation Operation
•Tailgate Trim Removal and Installation (Refer to GROUP
52A, Tailgate Trim P.52A-19).
•Tailgate Spoiler Assembly Removal and Installation
(Refer to GROUP 51, Tailgate Spoiler P.51-19).
•Rear Wiper Arm Assembly Removal and Installation
(Refer to GROUP 51, Rear Wiper and Washer P.51-29).
AC304811
1
2
6 55
4 33 7
AB
N
NN
N
N
N
N
Y1522AU
Y1538AU
AC304812
Y1537AUY1537AU
AB
Units: mm
Adhesive: 3M ATD Part No. 8609 Super Fast Urethane Auto Glass Sealant or equivalent and
3M ATD Part No. 8608 Super Fast Urethane Primer or equivalentSection A – A
13
14
14 Section B – B
Section C – C A
A
CC
B
B Ceramic line
Mark Apply the primer and adhesive
along the fictitious lines (seal line)
between each of the marks.
Seal line
centrePrimer
Seal line
centrePrimer
Seal line
centre
Primer
22
2

WINDOW GLASS
BODY42-23
REMOVAL SERVICE POINT
<> TAILGATE WINDOW GLASS
REMOVAL
Remove the tailgate window glass using the same
procedure as for the windshield (Refer to P.42-12).
INSTALLATION SERVICE POINTS
>>A<< WINDOW SPACER/GLASS
STOPPER/DUAL LOCK
FASTENER/WINDOW DAM
INSTALLATION
CAUTION
Leave the degreased parts for 3 or more minutes
to dry well, before starting on the next step. Do
not touch the degreased parts.
1. Use isopropyl alcohol to degrease the inside and
outside edges of the tailgate window glass and
the surface of the tailgate flange.
Removal steps
1. Connecting the harness connector
<> >>B<<2. Tailgate window glass
>>A<<3. Window lower dam
>>A<<4. Window side dam
>>A<<5. Dual lock fastener
>>A<<6. Glass stopper
>>A<<7. Window spacerRemoval steps (Continued)

WINDOW GLASS
BODY42-24
2. Assemble the window spacer, glass stopper and
window dam to the tailgate window glass location
shown.3. Assemble the dual lock fastener according to the
standard location of the tailgate flange.
4. Assemble the dual lock fastener to the quarter
window glass relative to the tailgate flange dual
lock fastener.
>>B<< TAILGATE WINDOW GLASS
INSTALLATION
Install the tailgate window glass in the same way as
for the windshield installation (Refer to P.42-12).
AC107207
AC107207
Y1484AUY1484AU
AC304816
AB
Glass stopper Glass spacer
Seal lineCeramic lineCeramic lineGlass end line
Glass end line Window spacer, glass stopper and window dam installation position
Align the glass spacer and with
the tailgate window glass mark.
Position the window side dam
2 mm inside from the tailgate
window glass end.
Butt the ends of
the window lower
and side dams.
Align the glass stopper and with
the tailgate window glass mark.
Seal line
Seal line 22 mm 14.5 mm
2 mm
Tailgate window glass
Window lower dam Window side dam
AC304849AB
Dual lock fastener Flange convex at the tailgate flange

TA I L G AT E
BODY42-46
TA I L G AT E
SERVICE SPECIFICATIONSM1421000300288
SEALANTSM1424000500098
SPECIAL TOOLM1424000600170
TROUBLESHOOTINGM1424000700207
The tailgate system is controlled by the Smart Wiring
System (SWS). For troubleshooting, refer to GROUP
54B, Troubleshooting P.54B-17 or GROUP 54C,
Troubleshooting P.54C-4.
ON-VEHICLE SERVICE
TAILGATE FIT ADJUSTMENTM1424000900137
1. If the striker and latch mesh badly, replace the
striker and striker installation blots with
replacement parts (striker: MR523105, striker
installation blot: MU000474).2. Move the replaced striker forward and backward
or to the left and right to adjust, after bolt the
striker temporarily.
3. After adjusting, tighten the bolts to the specified
torque [24 ± 4 N⋅m]. Item Standard value
Tailgate handle play 2.3 to 5.9 mm
Item Specified sealant
Tailgate waterproof film 3M ATD Part No.8633 or equivalent
Tailgate hinge 3M ATD Part No.8531 Heavy drip check sealer, 3M
ATD Part No.8646 Automotive joint and seam sealer
or equivalent
Tool Number Name Use
MB991223
A: MB991219
B: MB991220
C: MB991221
D: MB991222Harness set
A: Test harness
B: LED harness
C: LED harness
adapter
D: ProbeTerminal voltage measurement
A: For checking connector pin
contact pressure
B: For checking power supply
circuit
C: For checking power supply
circuit
D: For connecting a locally
sourced tester
MB991223
A
D C
B
AD
AC203659

TA I L G AT E
BODY42-47
NOTE:
When the bolt head interferes with the rear end
trim, rasp the interference area with a round file.4. If uneven clearance is present between tailgate
and body, reposition the hinge to adjust the
clearance.
TAILGATE HANDLE PLAY CHECKM1424002400138
1. Check the tailgate handle play.
Standard value (B): 2.3 − 5.9 mm
2. If it deviates from the standard value, remove the
lower tailgate trim (Refer to GROUP 52A, tailgate
trim P.52A-19) and waterproof film (Refer to
P.42-48).
3. Remove the holder from the tailgate handle and
adjust according to the tailgate latch rod and
tailgate handle connection position.
AC203660AB
Grind here
AC201556
AC103270
A
ASection A – A
RodHolder
B
AC

TA I L G AT E
BODY42-48
TAILGATE
REMOVAL AND INSTALLATIONM1424001100178
CAUTION
•Do not disassemble or throw the tailgate gas spring into fire.
•Punch a hole in the gas spring before disposal to release the gas inside.
•Ensure the tailgate gas spring piston rod does not come into contact with foreign material.
Pre-removal Operation
•Tailgate Spoiler Assembly Removal (Refer to GROUP 51,
Tailgate Spoiler P.51-19).
•Tailgate Trim Assembly Removal (Refer to GROUP 52A,
Tailgate Trim P.52A-19).
•Rear Wiper Motor Removal (Refer to GROUP 51, Rear
Wiper and Washer P.51-29).Post-installation Operation
•Tailgate Fit Adjustment (Refer to P.42-46).
•Rear Wiper Motor Installation (Refer to GROUP 51, Rear
Wiper and Washer P.51-29).
•Tailgate Trim Assembly Installation (Refer to GROUP
52A, Tailgate Trim P.52A-19).
•Tailgate Spoiler Assembly Installation (Refer to GROUP
51, Tailgate Spoiler P.51-19).
AC304836
7
3
4 1
6
8
12 ± 2 N·m
13 ± 2 N·m22 ± 4 N·m
AB
Sealant: 3M ATD Part No. 8633 or equivalent9.0 ± 2.0 N·m
2
712 ± 2 N·m
5
7
9
5.0 ± 1.0 N·m
5.0 ± 1.0 N·m
3
11
10
