MITSUBISHI LANCER IX 2006 Service Manual

HEADLAMP WASHER
EXTERIOR51-39
HEADLAMP WASHER
TROUBLESHOOTINGM1511000700356
The headlamp washer is controlled by the Smart Wir-
ing System (SWS). For troubleshooting, refer to
GROUP 54B, Troubleshooting
P.54B-15 or GROUP
54C, Troubleshooting P.54C-4.
HEADLAMP WASHER
REMOVAL AND INSTALLATION
M1511009700063
AC304608AB
10N
2
4
56
8
7
1
9
11
9
1
10N
4.9 ± 0.7 N·m
4.9 ± 0.7 N·m
3
Removal steps
•Washer fluid draining
1.Headlamp washer hose connection
2.Under cover side panel (RH)
3.Splash shield mounting clip (RH)
4.Headlamp washer motor
connection
5.Headlamp washer joint
6.Headlamp washer hose
7.Headlamp washer motor
Removal steps (Continued)

HEADLAMP WASHER
EXTERIOR51-40
INSPECTION
M1511009800082
HEADLAMP WASHER MOTOR CHECK
AC304136AB
12
1.Remove the he adla m p washer motor connector .
2.Check to se e tha t the wat e r is vigorou sly sp rayed
when con nect i ng th e positive ba ttery terminal to
te rmin al nu mber 1 and terminal n u mb er 2 to the
n egative ba ttery terminal.
8.Headlamp wa s h er gasket
•Fr o n t b u m p er ( R ef er to P.51-3).
9.Head lam p wa sh er a c tu ator
assembly
10.O-rin g
11.Headlamp w a s h er hose assembly
Remo val st ep s ( C o n tinue d)

MARK
EXTERIOR51-41
MARK
REMOVAL AND INSTALLATIONM1511011801435
AC504923
11 22
3
AC


3
Removal
>>A<<1.Front three-diamond mark (Refer to
P.51-4)
>>A<<2.Rear three-diamond mark
>>A<<3.Lancer mark
INST ALLA T ION SER VICE POINT
>>A<< MARK APPLICA T ION
1.In st allation positio n
Atta ch each ma rk to the po sition shown in the
i
llu strati on.

AC304163

2. Three-diamond mark

Centre line
of vehicleCentre line
of vehicle
Trunk lid
press linePress line
112 mm
53 ± 1 mm
AC
AC304164

3. Lancer mark
Rear combination
lamp terminal
Trunk lid terminalTailgate terminal
33 mm 24 mm 45 ± 1 mm
13 ± 1 mm 19 ± 1 mm

AB
MARK
EXTERIOR51-42
2.
In st allation procedure
(1)U se 3 M A T D Pa rt number 890 6 or eq uivalen t
to clean the mark inst allation surface s on the
body .
CAUTION
When attaching the marks, the ambient tempera-
ture should be 20 − 38°C and the air should be
completely free of dust. If the ambient tempera
-
ture is lower than 20°C, the marks and the places
on the vehicle body where the marks are to be
attached should be heated to 20
− 38°C.
(2) Peel off the protection sheet on the back of the marks to paste it on the installation position.

DOOR MIRROR
EXTERIOR51-43
DOOR MIRROR
GENERAL INFORMATIONM1511000100536
DOOR MIRROR OPERATION
Remote Controlled Mirror Operation
•The mirror on the door mirror moves up/down
and left/right by operating the remote controlled
door mirror switch when the ignition switch is in
the "ON" or "ACC" position.
Heated Door Mirror operation
•The defogger relay switch is activated (ON) by
turning on the A/C-ECU built-in defogger switch
when the ignition switch is in the "ON" position.
When the defogger relay is turned ON, power is
supplied to the defogger and door mirror, and the
heater of the door mirror (heated door mirror)
starts operations. The defogger comes with a
timer function and will automatically turn OFF the
switch approximately 11 minutes after the defog
-
ger switch is turned ON. The heated door mirror
operations are also terminated along with the
defogger, at this time.
SERVICE SPECIFICATION
M1511000300347
ItemStandard value
Heated door mirror operation current Ω5.9 − 7.8
SPECIAL TOOL
M1511000601103
ToolNumberNameUse
MB990784
MB990 784Ornament removerRemoval of remote controlled
mirror switch
TROUBLESHOOTING
DIAGNOSIS TROUBLESHOOTING FLOW
M151 1 0146 0016 9
Refe r to GROUP 00 − How to Use T r o ubleshoot-
ing/Inspectio n Service Point s P.00-5.
TR OUBLE SYM PT OM CHARTM151 1 0150 0016 0
SymptomInspection
procedureReference
page
All heated door mirrors do not operate1P.51-44
The right or left heated door mirror does not operate2P.51-45

DOOR MIRROR
EXTERIOR51-44
SYMPTOM PROCEDURES
Inspection Procedure 1: All Heated Door Mirrors do not Operate
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White \
Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Gray R : Red P : Pink V :\
Violet REAR WINDOW
DEFOGGER RELAY
REAR WINDOW
DEFOGGER
REMOTE
CONTROLLED
MIRROR (LH)
REMOTE
CONTROLLED
MIRROR (RH)
MIRROR
HEATER MIRROR
HEATER
NOTELH drive vehicles
RH drive vehicles
COMM
ENT S ON TROUBL E SYMPT O M
The heated do or mirrors shou ld works for approxi-
mately 11 minu tes whe n the re ar defo gger switch is
turned o
n . If th e mirror hea ter doe s no t work fo r the
specified period, th
e defo gger relay circuit (heated
door mirror p
o wer sup p ly circuit) may be d e fective .
PROBABLE CAUSE
•Damaged h a rness wire and connector
DIAGNOSIS PROCEDURE
STEP 1 . Check the rear wind ow de fogger .
Check that th e rear window def ogger system shou ld
wo
rk normally .
Q:Is t h e che c k r esu lt n o rmal?
YES : Go to S t ep 2 .
NO : Tr oublesh oot the rear win dow defog ger
(Refer to
GROUP 55 ,
T
r oublesh ootin g
P.55B-54).

DOOR MIRROR
EXTERIOR51-45
STEP 2. Connector check: C-212 junction block
connector
AC304913
21716151718
201912345
623 222425282627981011141213
Connector: C-212
Harness side
AB
Junction block (Front view)
Q: Is t h e che c k r esu lt n o rmal?
YES : Intermittent malfun ctio n (Refer to GROUP
00
− Ho w to Cope wit h Intermitte nt
Ma
lfunction
P.00-5).
NO : Repa ir th e defective connector .
Inspection Procedure 2 : Ri ght or Lef t Hea t ed Door Mirror does not Operate
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White \
Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Gray R : Red P : Pink V :\
Violet REAR WINDOW
DEFOGGER RELAY
REAR WINDOW
DEFOGGER
REMOTE
CONTROLLED
MIRROR (LH)
REMOTE
CONTROLLED
MIRROR (RH)
MIRROR
HEATER MIRROR
HEATER
NOTELH drive vehicles
RH drive vehicles
COMM
ENT S ON TROUBL E SYMPT O M
If eit her of t he hea ted d oor mirrors does n o t work, the
door mirror a
sse mbly may b e defe c tive.
PROBABLE CAUSES
•Malfunctio n of th e door mirro r assemb ly
•Damaged ha rness wires and con necto rs

DOOR MIRROR
EXTERIOR51-46
DIAGNOSIS PROCEDURE
STEP 1. Verify the operation of each heated door
mirror.
Q: Which door mirror does not heat?
Door mirror (RH) : Go to Step 2.
Door mirror (LH) : Go to Step 9.
STEP 2. Connector check: E-11 door mirror
assembly (RH) connector
AC304817
Connector: E-11Harness side
AB
Q : Is the check result normal?
YES : Go to S t ep 3.
NO : Repa ir the defective connector .
STEP 3. Ch eck the door mirror assem bly (RH).
Chec k that th e heat er ele m ent of the door mirror
assembly (RH) is in
good condition (Refer to
P.5 1 -51).
Q: Is the check result normal?
YES : Go to S t ep 4.
NO : Replac e th e door mirro r assemb ly ( R H).
STEP 4. Re sist an ce mea surement at the E-1 1
door mirror
assem bly (RH) connec tor .
AC304817
Connector: E-11
Harness side
AB
(1) D isconn ect t he co nnector , an d me asure at the wiring harn e ss side.
AC304821
Connector E-11
(harness side)
AB
(2) R esist ance bet we en E-1 1 door mirro r assemb ly
connector termina l No.4 a nd bod y ea rth
OK: 2 Ω or less
Q:Is t h e che c k r esu lt n o rmal?
YES : Go to S t ep 6 .
NO : Go to S t ep 5.
STEP 5 . Check the wiring harness b e twee n E-1 1
door mirror assem
bly (RH) conne ctor terminal
No.
4 and bo dy earth.
AC304817
Connector: E-11
Harness side
AB
•Check th e earth wires f o r open circuit.
NOTE:
AC304819
Connector: C-112
AB
Prior to the wiring harness insp ection, check interme-
diate connector C-1 1 2 , C-30 and
rep
a ir if necessary .
Q:Is t h e che c k r esu lt n o rmal?
YES : Intermittent malfun ctio n (Refer to GROUP
00
− Ho w to Cope wit h Intermitte nt
Ma
lfunction
P.00-5).
NO : Repa ir th e wirin g harne ss.

DOOR MIRROR
EXTERIOR51-47
STEP 6. Voltage measurement at the E-11 door
mirror assembly (RH) connector.
(1) Turn the ignition switch to the ON position.
(2) Rear window defogger switch: ON
AC304817
Connector: E-11Harness side
AB
(3) D isconn ect t he co nnector , an d me asure at the
wiring harn e ss side.
AC304826
Connector E-11(harness side)
AB
(4) V olt a g e between E-1 1 door mirror assembly
co nnector termina l No.1 a nd bod y ea rth
OK: System vo lt age
Q: Is the check result normal?
YES : Intermittent ma lfun ctio n (Refer to GROUP
00
− Ho w t o Cope wit h Intermitte nt
Malfunction
P.00-5).
NO : Go to S t ep 7.
STEP 7. Co nnector ch eck: C-212 junction block
connecto
r
AC304913
21716151718
201912345
623 222425282627981011141213
Connector: C-212
Harness side
AB
Junction block (Front view)
Q : Is the check result normal?
YES : Go to S t ep 8.
NO : Repa ir the defective connector .
STEP 8 . Check the wiring harness b e twee n E-1 1
door mirror assem
bly (RH) conne ctor terminal
No.
1 and C-21 2 junctio n block connec tor
terminal No.3
.
AC304817
Connector: E-11
Harness side
AB
AC304913
21716151718
201912345
623 222425282627981011141213
Connector: C-212
Harness side
AB
Junction block (Front view)
•Check th e power supply line fo r open circuit.
NOTE:
AC304819
Connector: C-112
AB
Prior to the wiring harness insp ection, check interme-
diate connector C-1 1 2 , C-30 and
rep
a ir if necessary .
Q:Is t h e che c k r esu lt n o rmal?
YES : Intermittent malfun ctio n (Refer to GROUP
00
− Ho w to Cope wit h Intermitte nt
Ma
lfunction
P.00-5).
NO : Repa ir th e wirin g harne ss.

DOOR MIRROR
EXTERIOR51-48
STEP 9. Connector check: E-02 door mirror
assembly (LH) connector
AC304818
Connector: E-02Harness side
AB
Q : Is the check result normal?
YES : Go to S t ep 10 .
NO : Repa ir the defective connector .
STEP 10 . Check th e door mirror asse mbly (L H).
Chec k that th e heat er ele m ent of the door mirror
assembly (L
H) is in goo d con d ition (Refer to
P.5 1 -51).
Q: Is the check result normal?
YES : Go to S t ep 1 1 .
NO : Replac e th e door mirro r assemb ly ( L H) .
STEP 11 . Resist ance m easureme n t at the E-0 2
door mirror
assem bly (LH) con nector .
AC304818
Connector: E-02
Harness side
AB
(1) D isconn ect t he co nnector , an d me asure at the
wiring harn e ss side.
AC304827
Connector E-02(harness side)
AB
(2) R esist ance betwee n E-02 do or mirror assembly connector termina l No.4 a nd bod y ea rth
OK
: 2 Ω or less
Q:Is t h e che c k r esu lt n o rmal?
YES : Go to S t ep 1 4 .
NO : Go to S t ep 12 .
STEP 1 2 . Chec k the wiring ha rnes s betwe en E-02
door mirror assem
bly (LH) con nector termina l
No.
4 and bo dy earth.
AC304818
Connector: E-02
Harness side
AB
•Check th e earth wires f o r open circuit.
NOTE:
AC304820
Connector: C-29
AB
Prior to the wiring harness insp ection, check interme-
diate connector C-29 , C-1 13 and
rep
a ir if necessary .
Q:Is t h e che c k r esu lt n o rmal?
YES : Intermittent malfun ctio n (Refer to GROUP
00
− Ho w to Cope wit h Intermitte nt
Ma
lfunction
P.00-5).
NO : Repa ir th e wirin g harne ss.
