Page 590 of 1501
FUEL TANKS
GAS CAPS
GASKETS
GROMMETS (VALVE COVER)
HARMONIC DAMPERS
HEATER CONTROL VALVES
HEATER CORES
HOSE AND TUBE COUPLERS, CONNECTORS AND CLAMPS
HOSE CLAMPS
HOSE CONNECTORS
HOSE COUPLERS
HOSES AND TUBES (FUEL LINES, RADIATOR, VACUUM, BY PASS,
HEATER, RECOVERY TANK AND OIL COOLERS)
HOUSINGS
IDLE AIR CONTROLS
IDLE SPEED CONTROL ACTUATORS
IGNITION BOOTS
IGNITION COIL TOWERS
IGNITION COILS
IGNITION CONTROL MODULES (ICM)
IGNITION SWITCHES
IGNITION TERMINALS
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY)
IN-TANK FUEL STRAINERS
INERTIA FUEL SHUT-OFF SWITCHES
INTAKE AIR TEMPERATURE SENSORS
INTAKE MANIFOLDS
INTERCOOLERS
KNOCK SENSORS
LIQUID VAPOR SEPARATORS
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSORS
MASS AIR FLOW (MAF) SENSORS
METAL AIR MANIFOLDS AND PIPES
METAL AIR PIPES
MIX CONTROL SOLENOIDS
MOTOR MOUNTS
O-RINGS, GASKETS, SEALS AND SPRING LOCKS
O2 SENSORS
OIL PRESSURE SENDING UNITS
OIL PUMP PICK-UP SCREENS
OIL PUMPS
PARK NEUTRAL POSITION SWITCHES
PCV BREATHER ELEMENTS
PCV ORIFICES
PCV VALVES
PICK-UP ASSEMBLIES (INCLUDES MAGNETIC, HALL EFFECT AND
OPTICAL)
POWER STEERING PRESSURE SENSORS
POWERTRAIN CONTROL MODULES (PCM) AND PROM
POWERTRAIN CONTROL PROM
PRESSURIZED EXPANSION TANK CAPS
RADIATOR CAPS AND PRESSURIZED EXPANSION TANK CAPS
RADIATOR FAN BLADES
RADIATOR FAN CLUTCHES
RADIATORS
ROLL OVER VALVES
SEALING COMPOUNDS
SEALS
SECONDARY AIR INJECTION SYSTEM MANAGEMENT DEVICES
SENSORS AND ACTUATORS
SHROUDS, BAFFLES AND DEFLECTORS
SPARK PLUGS
SPRING LOCKS
Page 592 of 1501
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method
has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
Page 650 of 1501
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... (1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Determine source of contamination, such as engine coolant,
fuel, metal particles, or water. Require repair or
replacement.
( 3) - Inoperative includes intermittent operation or out of
OEM specification. Some components may be serviceable;
check for accepted cleaning procedure.
\
\
\
\
\
\
\
IGNITION BOOTS
See
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY) .
IGNITION COIL TOWERS
See
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY) .
IGNITION COILS
IGNITION COIL INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Arcing .................. A ............ Require replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
Page 652 of 1501
Connector missing ....... A ................. Require repair.
Contaminated ............ A ........... (3) Require repair or
replacement.
Leaking ................. A .. Require repair or replacement.
Malfunctioning .......... A ........... ( 4) Require repair or
replacement.
Missing ................. C ............ Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 2) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
( 1) - Refer to manufacturer's diagnostic trouble code
procedure and require repair or replacement of affected
component(s).
( 2) - Determine cause and correct prior to repair or
replacement of part.
( 3) - Determine source of contamination, such as engine
coolant, fuel, metal particles, or water. Require
repair or replacement.
( 4) - Includes inoperative, intermittent operation, or failure to
perform all functions.
\
\
\
\
\
\
\
IGNITION SWITCHES
See SWITCHES.
IGNITION TERMINALS
See
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY) .
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY)
NOTE: You are not required to replace ignition wires in sets.
However, you may suggest replacement of the entire
secondary wire set for preventive maintenance.
IGNITION WIRE, BOOT, COIL TOWER AND TERMINAL (SECONDARY) INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Application incorrect ... B ............ Require replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Page 694 of 1501
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method
has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
Page 708 of 1501
Measure between center and right terminals of connector for cylinders
No. 1 and 4, and between center and left terminals of connector for
cylinders No. 2 and 3.
4) On all models, remove ignition wires from coil. Measure
secondary coil resistance between coil towers for cylinders No. 1 and
4 and between coil towers for cylinders No. 2 and 3. Primary and
secondary coil resistance should be within specification. See
IGNITION COIL RESISTANCE (ECLIPSE) table. Connect coil harness
connector. Connect ignition wires to coil.
IGNITION COIL RESISTANCE (ECLIPSE) - Ohms @ 68
F (20C) TABLE \
\
\
\
\
\
Application Primary Secondary
2.0L
Non-Turbo ............ .51-.61 ......... 11,500-13,500
Turbo ................ .70-.86 ......... 11,300-15,300
2.4L ................... .74-.90 ......... 20,100-27,300
\
\
\
\
\
\
Power Transistor (Eclipse 2.0L Turbo & 2.4L)
1) To test the section of the power transistor that controls
cylinders No. 1 and 4, disconnect power transistor connector. Using a
1.5-volt dry cell battery, connect negative end of battery to terminal
No. 3 of power transistor and positive end to terminal No. 7. See
Fig. 4 .
Fig. 4: Identifying Power Transistor Connector Terminals (Eclipse
2.0L Turbo & 2.4L)
Courtesy of Mitsubishi Motor Sales of America
2) Using an analog ohmmeter, check for continuity between
terminals No. 3 and 8 of power transistor. Continuity should exist.
With positive end of 1.5-volt battery disconnected, there should be no
continuity. Replace power transistor if it fails test.
3) To test the section of the power transistor that controls
cylinders No. 2 and 3, connect negative end of 1.5-volt dry cell
battery to terminal No. 3 of power transistor and positive end to
terminal No. 2.
4) Using an analog ohmmeter, check for continuity between
terminals No. 1 and 3 of power transistor. Continuity should exist.
With positive end of 1.5-volt battery disconnected, there should be no
continuity. Replace power transistor if it fails test.
Power Transistor (Mirage)
1) Disconnect power transistor (distributor) connector. Usin\
g
a 1.5-volt dry cell battery, connect negative end of battery to
terminal No. 4 of power transistor and positive end to terminal No. 3.
See Fig. 5 .
Page 709 of 1501
Fig. 5: Power Transistor Connector Terminals (Mirage 1.8L)
Courtesy of Mitsubishi Motor Sales of America
2) Using an analog ohmmeter, check for continuity between
terminals No. 2 and 3 of power transistor. Continuity should exist.
With positive end of 1.5-volt battery disconnected, there should be no
continuity. Replace power transistor if it fails test.
DISTRIBUTORLESS IGNITION SYSTEM (DIS - V6)
Ignition Coil Resistance
1) On 3000GT DOHC, go to next step. On Montero and Montero
Sport, use DVOM to measure primary coil resistance between each
individual coil. To check secondary coil resistance, measure
resistance between towers of each individual coil. Replace coil if
primary and secondary coil resistances are not within specification.
See IGNITION COIL RESISTANCE (V6) table.
2) Using DVOM, measure primary coil resistance between
terminal No. 3 (power terminal) and each individual coil terminal. See\
Fig. 6 . Terminal No. 1 controls coil "B", terminal No. 2 controls coil
"A", and terminal No. 4 controls coil "C". See Fig. 7. To check
secondary coil resistance, measure resistance between towers of each
individual coil. Replace coil if primary and secondary coil
Page 712 of 1501
HALL EFFECT IGNITION
Ignition Coil Resistance
Using a DVOM, measure primary coil resistance between
specified coil terminals. See Figs. 9-12. On Galant, measure between
terminals No. 11 and 12. On Mirage measure between terminals No. 1 and
2. On all other vehicles, measure between positive and negative
terminals. Measure secondary coil resistance between coil positive
terminal and ignition coil tower. Primary and secondary coil
resistance should be within specification. See
IGNITION COIL RESISTANCE TABLE .
IGNITION COIL RESISTANCE TABLE - Ohms @ 68
F (20C) \
\
\
\
\
\
Application Primary Secondary
1.5L (VIN A) ........... .50-.70 ......... 15,000-22,000
2.4L (VIN G)
Galant .............. .90-1.20 ......... 20,000-29,000
Montero Sport ........ .67-.81 ......... 11,300-15,300
3.0L (VIN H) ........... .72-.88 ......... 12,290-13,920
3.5L (VIN P) ........... .50-.70 ........... 9000-13,000
\
\
\
\
\
\
Fig. 9: Ignition Coil Connectors Terminals (Except DIS - Diamante)
Courtesy of Mitsubishi Motor Sales of America
Page 783 of 1501
See Fig. 1 . Connect negative voltmeter lead to ground.
2) Disconnect generator output wire from terminal "B".
Install a 100-amp ammeter in series with terminal "B" and disconnected
output lead. Connect positive lead of ammeter to terminal "B" and
negative lead to disconnected output wire. Install a tachometer, and
reconnect negative battery cable.
3) Turn ignition switch on and ensure voltmeter indicates
battery voltage. If voltage is not present, check for open in wire
between generator terminal "S" and positive battery terminal. Check
for blown fusible link.
4) Start engine. Ensure all lights and accessories are off.
Operate engine at 2500 RPM and read voltmeter when generator output
current drops to 10 amps or less. Voltage regulator is okay if voltage
output is within specification. See REGULATOR VOLTAGE SPECIFICATIONS
table.
REGULATOR VOLTAGE SPECIFICATIONS TABLE
\
\
\
\
\
\
Ambient Temperature Voltage
-4
F (-20C) ................................... 14.2-15.4
68F (20C) .................................... 13.9-14.9
140F (60C) ................................... 13.4-14.6
176F (80C) ................................... 13.1-14.5 \
\
\
\
\
\
GENERATOR RELAY TEST
NOTE: Information for all other models is not available from
manufacturer at time of publication.
Diamante & Mirage
Remove generator relay. On Diamante, relay is located in
relay box in engine compartment near battery. On Mirage, relay is
located in relay box in engine compartment between battery and strut
tower. On both models, connect positive lead of ohmmeter to relay
terminal No. 4. See WIRING DIAGRAMS. Connect negative lead of ohmmeter
to relay terminal No. 2. Continuity should be present. Switch ohmmeter
lead locations. Continuity should not be present. Replace generator
relay if continuity is not as specified.
BENCH TESTING
RECTIFIER ASSEMBLY
1) Using ohmmeter, check for continuity between diodes and
stator coil lead connection. See Fig. 2. Reverse leads. If continuity
is present in both directions, diode is shorted. Replace rectifier
assembly.
2) To check entire diode assembly, use an ohmmeter to check
for continuity between both ends of each diode. See Fig. 2. Switch
ohmmeter leads. Continuity should be present in one direction only. If
continuity is not as specified, diode is defective. Replace rectifier
assembly.
Page 816 of 1501
Torque Converter Clutch Solenoid/Switch ......... Engine Performance
Traction Control Switch ........................... Anti-Lock Brakes
Trailer Tow Connector .............................. Exterior Lights
Trailer Tow Relay .................................. Exterior Lights
Transmission/Transaxle .......................... Engine Performance
Transmission Control Module (TCM) ............... Engine Performance\
Starters
Transmission Range Sensor ................................. Starters
Back-Up Lights
Engine Performance
Transmission Range Switch ........................... Back-Up Lights
Engine Performance
Anti-Theft System
Turn Signal Flasher ................................ Exterior Lights
Turn Signal Lights ................................. Exterior Lights
Twilight Sentinel Switch ......................... Headlight Systems
Daytime Running Lights
Vapor Canister Leak Detection Pump .............. Engine Performance
Vehicle Control Module (VCM) .................... Engine Performance\
Vehicle Dynamic Module ....................... Electronic Suspension
Vehicle Speed Control Servo ................. Cruise Control Systems
Vehicle Speed Sensor .......................... Data Link Connectors
Analog Instrument Panels
Cruise Control Systems
Electronic Suspension
Voltage Regulator .......................... Generators & Regulators
Water-In-Fuel Sensor ............................ Engine Performance
Analog Instrument Panels
Wheel Speed Sensors ............................... Anti-Lock Brakes
Window Timer Module .......................... Power Convertible Top
Windshield Intermittent Wiper Relay ........... Wiper/Washer Systems
Windshield Washer Motor ....................... Wiper/Washer Systems
Wiper Motor ................................... Wiper/Washer Systems
\
\
\
\
\
\
\
