NOTE: Testing information for RKE control unit is not available
from manufacturer at time of publication. See
PIN VOLTAGE TESTS .
NOTE: If after all testing procedures are completed, system is not
functioning properly, replace unit with a known-good keyless
entry control unit and retest.
POWER DOOR LOCK CONTROL UNIT
Montero (W/O Remote Keyless Entry)
1) Remove power door lock control unit. See
COMPONENT LOCATIONS . Apply battery voltage to control unit terminal
No. 8 (Red/Yellow wire). See WIRING DIAGRAMS.
2) Jumper control unit terminals No. 4 (Black wire), No. 5
(Blue/White wire), and No. 7 (Black/Yellow wire) to battery negative\
terminal. Connect an analog voltmeter between ground and terminal No.
3 (Blue/Red wire). Set voltmeter to DC volts.
3) Remove jumper from control unit terminal No. 5 or 7.
Voltmeter needle should deflect.
4) Jumper control unit terminals No. 4 (Black wire) and No. \
5
(Blue/White wire) to ground. Connect voltmeter between ground and
terminal No. 3 (Blue/Red wire). Jumper control unit terminal No. 7
(Black/Yellow wire) to ground. Voltmeter needle should deflect.
5) Jumper control unit terminal No. 4 (Black wire) to ground\
.
Connect voltmeter between ground and control unit terminal No. 3
(Blue/Red wire). Jumper control unit terminal No. 7 (Black/Yellow
wire) to ground. Voltmeter needle should not deflect.
6) Check if voltage is present between battery ground and
control unit terminals No. 2 (Black/Blue wire) and No. 6 (Black/Red
wire). Battery voltage should be present. If circuits do not test as
specified, replace door lock control unit.
BACK DOOR (LIFTGATE) LOCK ACTUATOR
Montero
Access door lock actuator. See DOOR LOCK ACTUATOR R & I under
REMOVAL & INSTALLATION. Disconnect back door actuator harness
connector. Remove actuator if needed. Connect positive lead of 12-volt
power source to actuator connector. Actuator should operate when
negative lead contacts actuator housing. Replace actuator as needed.
PIN VOLTAGE TESTS

DOOR LOCK ACTUATOR R & I
Removal & Installation (Except Back Door)
Remove inner door panel. Remove delta cover (access to mirror
mounting). Remove door light, switch panel and armrest. Remove
mounting screws, and slide panel up to remove. Remove waterproof film.
Remove actuator. To install, reverse removal procedure.
Removal & Installation (Back Door)
Remove door pull handle. Remove window trim. Remove door
release handle trim. Remove tool kit (if equipped). Remove door panel
and waterproof film. Remove actuator. To install, reverse removal
procedure.
WIRING DIAGRAMS

Fig. 8: Keyless Entry Wiring Diagram (Montero)

Fig. 9: Keyless Entry Wiring Diagram (3000GT - 1 Of 2)

Fig. 10: Keyless Entry Wiring Diagram (3000GT - 2 Of 2)

Fig. 11: Power Door Locks Wiring Diagram (Montero)

Fig. 12: Power Door Locks Wiring Diagram (Montero Sport)

Mirage &
Montero Sport ... Behind Right Side Of Instrument Panel (Glove Box)\
Montero ..................................... Right Front Kick Panel
All Others ................................... Behind Center Console









\









\









\









\









\









\









\







NOTE: Components are grouped into 2 categories. The first category
covers INPUT DEVICES, which control or produce voltage
signals monitored by Powertrain Control Module (PCM). The
second category covers OUTPUT SIGNALS, which are components
controlled by PCM.
INPUT DEVICES
Vehicles are equipped with different combinations of input
devices. Not all input devices are used on all models. To determine
input device usage on specific models, see appropriate wiring diagram
in L - WIRING DIAGRAMS article. The following are available input
devices.
Air Conditioning Switch
When A/C is turned on, signal is sent to PCM. With engine at
idle, PCM increases idle speed through Idle Air Control (IAC) motor.
Airflow Sensor Assembly
Assembly is mounted inside air cleaner, and incorporates
barometric pressure sensor, intake air temperature sensor and volume
airflow sensor.
Barometric (BARO) Pressure Sensor
Sensor is incorporated into airflow sensor assembly. Sensor
converts barometric pressure to electrical signal, which is sent to
PCM. PCM adjusts air/fuel ratio and ignition timing according to
altitude.
Camshaft Position (CMP) Sensor
On SOHC engines equipped with a distributor, CMP sensor is
located in distributor. On Eclipse (Turbo) and DOHC V6 engines, sensor\
is located beside camshaft, in front of engine. On all other engines,
CMP sensor is a separate unit mounted in place of distributor. PCM
determines TDC based on pulse signals received from sensor, and then
controls MFI timing.
Closed Throttle Position (CTP) Switch
CTP switch is located in the Throttle Position (TP) sensor.
PCM senses whether accelerator pedal is depressed or not. High voltage
(open) or low voltage (closed) signal is input to PCM, which then
controls Idle Air Control (IAC) motor based on input signal.
Crankshaft Position (CKP) Sensor
CKP sensor is located in distributor on SOHC engines, except
1.5L 4-cylinder with California emissions. On DOHC 4-cylinder, DOHC V6
and 1.5L 4-cylinder engines with California emissions, CKP sensor is
located beside crankshaft, in front of engine. PCM determines
crankshaft position on pulse signals received from sensor, and then
controls MFI timing and ignition timing.
Engine Coolant Temperature (ECT) Sensor
ECT sensor converts coolant temperature to electrical signal
for use by PCM. PCM uses coolant temperature information to control
fuel enrichment when engine is cold.
Heated Oxygen Sensor (HO2S)

usage on specific models, see appropriate wiring diagram in
L - WIRING DIAGRAMS article. For theory and operation on each
output component, refer to system indicated after component.
Data Link Connector (DLC)
See SELF-DIAGNOSTIC SYSTEM .
EGR Control Solenoid Valve
See EXHAUST GAS RECIRCULATION (EGR) CONTROL under EMISSION
SYSTEMS.
Fuel Injectors
See FUEL CONTROL under FUEL SYSTEM.
Fuel Pressure Control Solenoid Valve (Turbo)
See FUEL DELIVERY under FUEL SYSTEM.
Fuel Pressure Regulator
See FUEL DELIVERY under FUEL SYSTEM.
Idle Air Control (IAC) Motor
See IDLE SPEED under FUEL SYSTEM.
Malfunction Indicator Light
See SELF-DIAGNOSTIC SYSTEM .
Power Transistor(s) & Ignition Coils
See IGNITION SYSTEMS .
Purge Control Solenoid Valve
See EVAPORATIVE CONTROL under EMISSION SYSTEMS.
Wastegate Control Solenoid Valve
See TURBOCHARGED ENGINES under AIR INDUCTION SYSTEM.
FUEL SYSTEM
FUEL DELIVERY
Electric fuel pump, located in gas tank, feeds fuel through
in-tank fuel filter, external fuel filter (located in engine
compartment) and fuel injector rail.
Fuel Pump
Fuel pump consists of a motor-driven impeller. Pump has an
internal check valve to maintain system pressure, and a relief valve
to protect fuel pressure circuit. Pump receives voltage supply from
MFI control relay.
Fuel Pressure Control Solenoid Valve (Turbo)
Valve prevents rough idle due to fuel percolation. On engine
restart, if engine coolant or intake air temperature reaches a preset
value, PCM applies voltage to fuel pressure control solenoid valve for
2 minutes after enginerestart. Valve will open, allowing atmospheric
pressure to be applied to fuel pressure regulator diaphragm. This
allows maximum available fuel pressure at injectors, enriching fuel
mixture and maintaining stable idle at high engine temperatures.
Fuel Pressure Regulator
Located on fuel injector rail, this diaphragm-operated relief
valve adjusts fuel pressure according to engine manifold vacuum.
As engine manifold vacuum increases (closed throttle), fuel

F - BASIC TESTING
1998 Mitsubishi Montero
1998 ENGINE PERFORMANCE
Mitsubishi - Basic Diagnostic Procedures
Diamante, Eclipse, Galant, Mirage, Montero, Montero Sport,
3000GT
INTRODUCTION
The following diagnostic steps will help prevent overlooking
a simple problem. This is also where to begin diagnosis for a no-start
condition. The first step in diagnosing any driveability problem is
verifying the customer's complaint with a test drive under the
conditions the problem reportedly occurred.
Before entering self-diagnostics, perform a careful and
complete visual inspection. Most engine control problems result from
mechanical breakdowns, poor electrical connections or
damaged/misrouted vacuum hoses. Before condemning the computerized
system, perform each test listed in this article.
NOTE: Perform all voltage tests with a Digital Volt-Ohmmeter
(DVOM) with a minimum 10-megohm input impedance, unless
stated otherwise in test procedure.
PRELIMINARY INSPECTION & ADJUSTMENTS
VISUAL INSPECTION
Visually inspect all electrical wiring, looking for chafed,
stretched, cut or pinched wiring. Ensure electrical connectors fit
tightly and are not corroded. Ensure vacuum hoses are properly routed
and are not pinched or cut. See M - VACUUM DIAGRAMS article to verify
routing and connections (if necessary). Inspect air induction system
for possible vacuum leaks.
MECHANICAL INSPECTION
Compression
Check engine mechanical condition with a compression gauge,
vacuum gauge, or an engine analyzer. See engine analyzer manual for
specific instructions.
WARNING: DO NOT use ignition switch during compression tests on fuel
injected vehicles. Use a remote starter to crank engine.
Fuel injectors on many models are triggered by ignition
switch during cranking mode, which can create a fire hazard
or contaminate the engine's oiling system.
Check engine compression with engine at normal operating
temperature, all spark plugs removed and throttle wide open. See
COMPRESSION SPECIFICATIONS table.
COMPRESSION SPECIFICATIONS TABLE









\









\









\









\









\









\






Application (1) Specification
Compression Ratio
1.5L (VIN A) ..................................... 9.0:1
1.8L (VIN C) ..................................... 9.5:1
