motor connector terminal No. 2 (Black wire). Using a fused jumper
wire, connect battery voltage to fan motor connector terminal No. 1
(White/Black wire). See WIRING DIAGRAMS. Fan motor should operate with
no abnormal noises or interferences. Repair or replace components as
necessary.
2) On all models except 1998 2.0L non-turbo, ground fan motor
4-pin connector terminal No. 4 (Black wire). Using a fused jumper
wire, connect battery voltage to fan motor connector terminal No. 3
(White/Blue wire). See WIRING DIAGRAMS. Fan motor should operate with
no abnormal noises or interferences. Repair or replace components as
necessary.
Radiator Fan Motor (Galant)
1) Disconnect radiator fan motor 4-pin connector. Ground fan
motor connector terminal No. 2 (Black wire). Using a fused jumper
wire, connect battery voltage to fan motor connector terminal No. 1
(Blue wire). See WIRING DIAGRAMS. Fan motor should operate with no
abnormal noises or interferences. Repair or replace components as
necessary. If no problems exist, go to next step.
2) Ground fan motor 4-pin connector terminal No. 4 (Black
wire). Using a fused jumper wire, connect battery voltage to fan motor
connector terminal No. 3 (Blue/Black wire). See WIRING DIAGRAMS. Fan
motor should operate with no abnormal noises or interferences. Repair
or replace components as necessary.
Radiator Fan Motor (Mirage)
Disconnect radiator fan motor 2-pin connector. Ground fan
motor 2-pin connector terminal No. 2 (Black wire). Using a fused
jumper wire, connect battery voltage to 2-pin connector terminal No. 1
(Blue/Black wire). See WIRING DIAGRAMS. Fan motor should operate with
no abnormal noises or interferences. Repair or replace components as
necessary.
Radiator Fan Motor (3000GT)
1) Disconnect radiator fan motor 4-pin connector. Ground fan
motor connector terminal No. 4 (Blue/Green wire). Using a fused jumper\
wire, connect battery voltage to fan motor connector terminal No. 2
(Red/Black wire). See WIRING DIAGRAMS. Fan motor should operate with
no abnormal noises or interferences. Repair or replace components as
necessary. If radiator fan motor operates as specified, go to next
step.
2) Disconnect battery voltage and ground from radiator fan
motor 4-pin connector. Using an ohmmeter, measure resistance between
radiator fan motor 4-pin connector terminals No. 1 (Black wire) and
No. 3 (Yellow/Blue wire). See WIRING DIAGRAMS. Resistance should be 0.
29-0.35 ohms. Replace radiator fan motor if resistance is not as
specified.
Condenser Fan Motor (Diamante)
1) Using a fused jumper wire, connect battery voltage to
condenser fan motor 4-pin connector terminal No. 1 (Blue/White wire).
Connect ground to connector terminal No. 2 (Black wire). Fan motor
should operate with no abnormal noises or interferences. Repair or
replace components as necessary. If no problems exist, go to next
step.
2) Using a fused jumper wire, connect battery voltage to
condenser fan motor 4-pin connector terminal No. 3 (Yellow wire). When\
terminal No. 4 (Black wire) is connected to ground, condenser fan
should operate faster. Replace condenser fan if operation is not as
specified. Ensure there are no abnormal noises or interferences during
fan operation.
Condenser Fan Motor (Eclipse)

1) Using a fused jumper wire, connect battery voltage to
condenser fan motor 4-pin connector terminal No. 1 (Blue wire).
Connect ground to connector to terminal No. 4 (Black wire). Fan motor
should operate with no abnormal noises or interferences. Repair or
replace components as necessary. If no problems exist, go to next
step.
2) Using a fused jumper wire, connect battery voltage to
condenser fan motor 4-pin connector terminal No. 3 (Blue/White wire).
When terminal No. 2 (Black wire) is connected to ground, condenser fan\
should operate faster. Replace condenser fan if operation is not as
specified. Ensure there are no abnormal noises or interferences during
fan operation.
Condenser Fan Motor (Galant)
1) Using a fused jumper wire, connect battery voltage to
condenser fan motor 4-pin connector terminal No. 1 (Blue wire).
Connect ground to connector to terminal No. 2 (Black wire). Fan motor
should operate with no abnormal noises or interferences. Repair or
replace components as necessary. If no problems exist, go to next
step.
2) Using a fused jumper wire, connect battery voltage to
condenser fan motor 4-pin connector terminal No. 3 (Blue/White wire).
When terminal No. 4 (Black wire) is connected to ground, condenser fan\
should operate faster. Replace condenser fan if operation is not as
specified. Ensure there are no abnormal noises or interferences during
fan operation.
Condenser Fan Motor (Mirage)
Disconnect radiator fan motor 2-pin connector. Ground fan
motor 2-pin connector terminal No. 2 (Black/Blue wire). Using a fused
jumper wire, connect battery voltage to 2-pin connector terminal No. 1
(Black/Orange wire). See WIRING DIAGRAMS. Fan motor should operate
with no abnormal noises or interferences. Repair or replace components
as necessary.
Condenser Fan Motor (Montero & Montero Sport)
Disconnect radiator fan motor 2-pin connector. Ground fan
motor 2-pin connector terminal No. 1 (Blue/Black wire). Using a fused
jumper wire, connect battery voltage to 2-pin connector terminal No. 2
(Blue/White wire). See WIRING DIAGRAMS. Fan motor should operate with
no abnormal noises or interferences. Repair or replace components as
necessary.
Condenser Fan Motor (1997 3000GT)
1) Disconnect both condenser fan motor 2-pin connectors
located on driver side of radiator. Ground fan motor 2-pin connector
terminal No. 2 (Black wire). Using a fused jumper wire, connect
battery voltage to 2-pin connector terminal No. 1 (Blue wire). See
WIRING DIAGRAMS . Fan motor should operate with no abnormal noises or
interferences. Repair or replace components as necessary. If no
problems exist, go to next step.
2) Ground fan motor 2-pin connector terminal No. 2
(Blue/Black wire). Using a fused jumper wire, connect battery voltage
to 2-pin connector terminal No. 1 (Blue/White wire). See
WIRING DIAGRAMS . Fan motor should operate with no abnormal noises or
interferences. Repair or replace components as necessary.
Condenser Fan Motor (1998 3000GT)
1) Disconnect condenser fan motor 3-pin connector located on
driver-side of radiator. Ground fan motor 2-pin connector terminal No.
3 (Black wire). Using a fused jumper wire, connect battery voltage to
3-pin connector terminal No. 1 (Blue/White wire). See WIRING DIAGRAMS.
Fan motor should operate with no abnormal noises or interferences.

Repair or replace components as necessary. If no problems exist, go to
next step.
2) Ground fan motor 3-pin connector terminal No. 3 (Black
wire). Using a fused jumper wire, connect battery voltage to 3-pin
connector terminal No. 2 (Blue wire). See WIRING DIAGRAMS. Fan motor
should operate with no abnormal noises or interferences. Repair or
replace components as necessary.
Engine Coolant Temperature (ECT) Sensor
Remove ECT sensor from vehicle. Suspend sensor in water so
that sensor does not touch container. Slowly heat water. Using an
ohmmeter, check sensor continuity as temperature increases. Replace
ECT sensor if resistance is not as specified. See
ENGINE COOLANT TEMPERATURE SENSOR RESISTANCE table.
ENGINE COOLANT TEMPERATURE SENSOR RESISTANCE









\









\









\









\









\









\









\







Temperature F (C) Ohms
Diamante, Eclipse 2.0L Turbo & 2.4L
32 (0) ................................................. 5100-6500\
68 (20) ................................................ 2100-2700\
104 (40) ................................................ 900-1300\
176 (80) ................................................. 260-360\
Eclipse Non-Turbo
77 (25) ................................................. 900-1100\
212 (100) ................................................ 600-800\
Galant & Mirage
68 (20) ................................................ 2100-2700\
176 (80) ................................................. 260-360\
Montero
68 (20) ................................................ 2130-2610\
176 (80) ................................................. 258-322\
Montero Sport
68 (20) ................................................ 2100-2700\
176 (80) ................................................. 260-360\
3000GT
32 (0) ...................................................... 5800\
68 (20) ..................................................... 2400\
104 (40) .................................................... 1100\
176 (80) ..................................................... 300\









\









\









\









\









\









\









\







Electric Cooling Fan Relay (Diamante, Eclipse, Galant &
Mirage)
1) Remove radiator fan motor relay from relay box located at
right side of engine compartment. Check for continuity between relay
terminals No. 1 and 3. If continuity exists, go to next step. If
continuity does not exist, replace cooling fan relay. See Fig. 8.
2) Using a fused jumper wire, connect battery voltage to
cooling fan relay terminal No. 1. Using another jumper wire, connect
cooling fan relay terminal No. 3 to battery ground. With cooling fan
relay energized, there should be continuity between cooling fan relay
terminals No. 4 and 5. With cooling fan relay not energized, there
should be no continuity between terminals No. 4 and 5. If continuity
does not exist as specified, replace cooling fan relay. See Fig. 8.
Electric Cooling Fan Relay (Montero, Montero Sport & 3000GT)
1)Remove relay from relay box in engine compartment relay
box. Check for continuity between relay terminals No. 2 and 4. If
continuity exists, go to next step. If continuity does not exist,
replace cooling fan relay. See Fig. 9.
2) Using a fused jumper wire, connect battery voltage to

Fig. 9: Testing Electric Cooling Fan Relay (Montero, Montero
Sport & 3000GT)
Courtesy of Mitsubishi Motor Sales of America.
SYSTEM TESTING
NOTE: For appropriate wiring diagram, see WIRING DIAGRAMS.
NOTE: Radiator fan on Montero and Montero Sport is mounted to a
hydraulic fan clutch which is mounted to the water pump.
Replace fan clutch if leaks are detected at case joints and
seals, fan can be rotated with very light resistance or the
bimetallic strip is damaged.
NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle

speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Diamante
1) If only the radiator fan does not operate, check fusible
link No. 6 located in engine compartment relay box. If only the
condenser fan does not operate, check dedicated fuse No. 16 (20-amp)
located in engine compartment relay box. See WIRING DIAGRAMS. Repair
as necessary.
2) If radiator fan and condenser fan operate in all speeds
except low, check appropriate low speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If low speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998
3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998
4) To confirm radiator fan or condenser fan operation, see
FAN OPERATING MODE (DIAMANTE) table. If fan operation is not as
specified, check wiring harness for opens or shorts. Repair as
necessary.
FAN OPERATING MODE (DIAMANTE) ( 1)









\









\









\









\









\









\









\







Power Circuit
Coolant Operating Radiator Condenser
Temp.
F (C) Low/High Fan Speed Fan Speed
13 MPH ( 2)
221 (105) ( 2) ........ On/Off ....... Low ................ Low
221 (105) ( 3) ........ Off/On ....... Mid ................ Mid
239 (115) ( 3) ........ On/On ........ High .............. High
13 MPH ( 3)
221 (105) ( 2) ........ On/Off ....... Low ................ Low
221 (105) ( 2) ........ On/On ........ High .............. High
30 MPH ( 2)
203 (95) ( 2) ........ Off/Off ....... Off ................ Off
203 (95) ( 3) ......... On/Off ....... Low ................ Off
221 (105) ( 3) ........ Off/On ....... Mid ................ Mid
30 MPH ( 3)
194 (90) ( 2) ........ Off/Off ....... Off ................ Off
194 (90) ( 3) ......... On/Off ....... Low ................ Off
221 (105) ( 3) ........ On/On ........ High ............... Mid
50 MPH ( 3)
221 (105) ( 2) ....... Off/Off ....... Off ................ Off
221 (105) ( 3) ........ On/On ........ High ............... Mid
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.









\









\









\









\









\









\









\







NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM

will command low, medium or high speed fan operation.
Eclipse
1) If only the radiator fan does not operate, check fusible
link No. 7 (20-amp) located in engine compartment relay box. If only
the condenser fan does not operate, check dedicated fuse No. 9 (20-
amp) located in engine compartment relay box. See WIRING DIAGRAMS.
Repair as necessary.
2) If radiator fan and condenser fan operate in all speeds
except low, check appropriate low speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If low speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 2.0L NON-TURBO - 1997
* G - TESTS W/CODES - 2.0L TURBO - 1997
* G - TESTS W/CODES - 2.4L - 1997
* G - TESTS W/CODES - 2.0L NON-TURBO - 1998
* G - TESTS W/CODES - 2.0L TURBO & 2.4L - 1998
3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 2.0L NON-TURBO - 1997
* G - TESTS W/CODES - 2.0L TURBO - 1997
* G - TESTS W/CODES - 2.4L - 1997
* G - TESTS W/CODES - 2.0L NON-TURBO - 1998
* G - TESTS W/CODES - 2.0L TURBO & 2.4L - 1998
4) To confirm radiator fan or condenser fan operation, see
FAN OPERATING MODE (ECLIPSE NON-TURBO) or FAN OPERATING MODE (ECLIPSE\
2.0L TURBO & 2.4L) table. If fan operation is not as specified, check
wiring harness for opens or shorts. Repair as necessary.
FAN OPERATING MODE (ECLIPSE NON-TURBO)









\









\









\









\









\









\









\







With A/T With M/T
Coolant Radiator Radiator Condenser
Temp.
F (C) Fan Speed Fan Speed Fan Speed
28 MPH ( 1) ( 2)
203 (95) ( 2) .......... Off ......... Off ................ Off
203-210 (95-99) ....... Mid ......... High ............... Off\
210 (99) ( 3) .......... High ........ High ............... Mid
28-50 MPH ( 1)
194 (90) ( 2) .......... Off ......... Off ................ Off
194-210 (90-99) ....... Mid ......... High ............... Off\
210 (99) ( 3) .......... High ........ High ............... Mid
50 MPH ( 1) ( 3)
210 (99) ( 2) .......... Off ......... Off ................ Mid
210 (99) ( 3) .......... High ........ High ............... Off
12 MPH ( 2) ( 4)
210 (99) ( 2) .......... Mid ......... High ............... Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
12-50 MPH ( 4)
210 (99) ( 2) .......... Mid ......... High ............... Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
50 MPH ( 3) ( 4)
210 (99) ( 2) .......... Mid ......... High ............... Mid
210-242 (99-117) ( 3) .. High ........ High .............. High

242 (117) (3) ......... High ........ High .............. High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C request switch is turned on.









\









\









\









\









\









\









\







FAN OPERATING MODE (ECLIPSE 2.0L TURBO & 2.4L)








\









\









\









\









\









\









\







With A/T With M/T
Coolant Radiator Radiator Condenser
Temp.
F (C) Fan Speed Fan Speed Fan Speed
28 MPH ( 1) ( 2)
203 (95) ( 2) .......... Off ......... Off ................ Off
203-210 (95-99) ....... Low ......... Mid ................ Off\
210 (99) ( 3) .......... High ........ High ............... Mid
28-50 MPH ( 1)
194 (90) ( 2) .......... Off ......... Off ................ Off
194-210 (90-99) ....... Low ......... Mid ................ Off\
210 (99) ( 3) .......... High ........ High ............... Mid
50 MPH ( 1) ( 3)
210 (99) ( 2) .......... Off ......... Off ................ Off
210 (99) ( 3) .......... High ........ High ............... Mid
12 MPH ( 2) ( 4)
210 (99) ( 2) .......... Low ......... Mid ................ Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
12-50 MPH ( 4)
210 (99) ( 2) .......... Low ......... Mid ................ Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
50 MPH ( 3) ( 4)
210 (99) ( 2) .......... Low ......... Mid ................ Mid
210-242 (99-117) ( 3) .. High ........ High .............. High
242 (117) ( 3) ......... High ........ High .............. High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C request switch is turned on.









\









\









\









\









\









\









\







NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Galant
1) If only the radiator fan does not operate, check fusible
link No. 5 (30-amp) located in engine compartment relay box. If only
the condenser fan does not operate, check dedicated fuse No. 3 (30-
amp) located in engine compartment relay box. See WIRING DIAGRAMS.
Repair as necessary.
2) If radiator fan and condenser fan operate in all speeds
except low, check appropriate low speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If low speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998

3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998
4) To confirm radiator fan or condenser fan operation, see
appropriate FAN OPERATING MODE (GALANT) table. If fan operation is not\
as specified, check wiring harness for opens or shorts. Repair as
necessary.
FAN OPERATING MODE (GALANT) ( 1)









\









\









\









\









\









\









\







Coolant Radiator Condenser
Temp. F (C) Fan Speed Fan Speed
28 MPH ( 2)
203 (95) ( 2) ................ Off .......................... Off
203-221 (95-105) ............ Low .......................... Low\
221 (105) ( 3) .............. High ......................... High
28-50 MPH
194 (90) ( 2) ................ Off .......................... Off
194-221 (90-105) ............ Low .......................... Low\
221 (105) ( 3) .............. High ......................... High
50 MPH ( 3)
221 (105) ( 2) ............... Off .......................... Off
221 (105) ( 3) .............. High ......................... High
Any Speed ( 4)
221 (105) ( 2) ............... Low .......................... Low
221 (105) ( 3) .............. High ......................... High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C request switch is turned on.









\









\









\









\









\









\









\







NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Mirage
1) If only the radiator fan does not operate, check fusible
link No. 5 (30-amp) located in engine compartment relay box. If only
the condenser fan does not operate, check fusible link No. 2 (100-amp)\
and dedicated fuse No. 1 (25-amp) located in engine compartment relay
box. See WIRING DIAGRAMS . Repair as necessary.
2) If fusible links and dedicated fuse are okay, check
appropriate fan relay and/or fan motor for proper operation. See
COMPONENT TESTS. See WIRING DIAGRAMS. If fan relay and motor are okay,
check PCM. See appropriate G - TESTS W/CODES article in ENGINE
PERFORMANCE.
* G - TESTS W/CODES - 1.5L - 1997
* G - TESTS W/CODES - 1.8L - 1997
* G - TESTS W/CODES - 1998
3) To confirm radiator fan or condenser fan operation, see
appropriate FAN OPERATING MODE (MIRAGE) table. If fan operation is not\
as specified, check wiring harness for opens or shorts. Repair as

necessary.
FAN OPERATING MODE (MIRAGE)









\









\









\









\









\









\









\







Power Circuit
Coolant Operating Radiator Condenser
Temp.
F (C) RAD/COND Fan Speed Fan Speed
203 (95) ( 1) ( 2) ...... Off/Off ....... Off ................ Off
203-221 (95-105) ( 1) ... On/Off ........ On ................ Off
221 (105) ( 1) ( 3) ...... On/On ......... On ................. On
All Temp. ( 4) .......... On/On ......... On ................. On
( 1) - A/C request switch is turned off.
( 2) - Approximate coolant temperature or less.
( 3) - Approximate coolant temperature or more.
( 4) - A/C request switch is turned on.









\









\









\









\









\









\









\







NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
3000GT
1) If neither the radiator fan nor the condenser fan operate,
check fusible link No. 5 (40-amp). See WIRING DIAGRAMS. If only the
condenser fan does not operate, check dedicated fuse No. 8 (20-amp).
2) If the condenser fan operates in all speeds except low and
A/C compressor clutch does not enter the ON state, check for A/C
compressor lock controller unit output signal. If the A/C compressor
clutch does enter the ON state, check condenser fan low speed relay
operation.
3) If the radiator fan and the condenser fan operate in all
speeds except high, check PCM. See appropriate G - TESTS W/CODES
article in ENGINE PERFORMANCE. If fan operation is not as specified,
check wiring harness for opens or shorts. Repair as necessary.
* G - TESTS W/CODES - NON-TURBO - 1997
* G - TESTS W/CODES - TURBO - 1997
* G - TESTS W/CODES - 1998
4) To confirm radiator fan or condenser fan operation, see
appropriate FAN OPERATING MODE (3000GT) table. If fan operation is not\
as specified, check wiring harness for opens or shorts. Repair as
necessary.
FAN OPERATING MODE (3000GT)









\









\









\









\









\









\









\







Power Circuit
Coolant Operating Radiator Condenser
Temp.
F (C) Low/High Fan Speed Fan Speed
50 MPH ( 1) ( 2)
203 (95) ( 2) ........ Off/Off ....... Off ................ Off
203-221 (95-105) ..... On/Off ....... Low ................ Off\
221 (105) ( 3) ........ On/On ........ High .............. High
50 MPH ( 1) ( 3)
221 (105) ( 2) ....... Off/Off ....... Off ................ Off
221 (105) ( 3) ........ On/On ........ High .............. High
All Speeds
221 (105) ( 2) ........ On/Off ....... Low ................ Low
221 (105) ( 3) ........ On/On ........ High .............. High

(1) - A/C compressor lock controller output is low (zero volts).
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C compressor lock controller output is high (12 volts).









\









\









\









\









\









\









\







WIRING DIAGRAMS
Fig. 10: Wiring Diagram (1997-98 Diamante)
