evap MITSUBISHI MONTERO 1998 Service Manual
[x] Cancel search | Manufacturer: MITSUBISHI, Model Year: 1998, Model line: MONTERO, Model: MITSUBISHI MONTERO 1998Pages: 1501, PDF Size: 25.81 MB
Page 28 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\b\
\
\
\
\
\
EAC Electric Assist Choke](/img/19/57333/w960_57333-27.png "MITSUBISHI MONTERO 1998 Service Manual \
\b\
\
\
\
\
\
EAC Electric Assist Choke")
\
\b\
\
\
\
\
\
EAC Electric Assist Choke
EACV Electric Air Control Valve
EBCM Electronic Brake Control Module
ECA Electronic Control Assembly
ECAT Electronically Controlled Automatic Transaxle
ECM Electronic Control Module
ECT Engine Coolant Temperature Sensor
ECU Electronic Control Unit or Engine Control Unit
EDF Electric Drive Fan relay assembly
EDIS Electronic Distributorless Ignition System
EEC Electronic Engine Control
EECS Evaporative Emission Control System
EEPROM Electronically Erasable PROM
EFE Early Fuel Evaporation
EFI Electronic Fuel Injection
EGO Exhaust Gas Oxygen sensor (see HEGO)
EGR Exhaust Gas Recirculation system
EGRC EGR Control solenoid or system
EGRV EGR Vent solenoid or system
EMR Emission Maintenance Reminder Module
ESA Electronic Spark Advance
ESC Electronic Spark Control
EST Electronic Spark Timing
ETR Emergency Tensioning Retractor
EVAP Fuel Evaporative System
EVIC Electronic Vehicle Information Center
EVO Electronic Variable Orifice
EVP EGR Valve Position Sensor
EVR EGR Valve Regulator
EVRV Electronic Vacuum Regulator Valve
Elect. Electronic
Eng. Engine
Evap. Evaporative
Exc. Except
\
\
\
\
\
\
\
\f
"F" ABBREVIATION TABLE
"F" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
F Fahrenheit (Degrees)
F/B Fuse Block
FBC Feedback Carburetor
FI Fuel Injector or Fuel Injection
FICD Fast Idle Control Device
FIPL Fuel Injector Pump Lever
FP Fuel Pump
FPM Fuel Pump Monitor
FPR-VSV Fuel Pressure Regulator Vacuum Switching Valve
FWD Front Wheel Drive
Fed. Federal
Ft. Lbs. Foot Pounds
\
\
\
\
\
\
\
\f
"G" ABBREVIATION TABLE
"G" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
Page 38 of 1501
Eclipse 2.0L Non-Turbo ............................. 3.4
Montero ............................................ 4.1
Condenser ............................................ 1.4
Evaporator ........................................... 1.4
Receiver-Drier ....................................... 0.3
Suction Hose ......................................... 0.3
(1) - If replacement compressor is shipped without
refrigerant oil, add same amount of NEW refrigerant
oil to replacement compressor that was drained from
old compressor.
\
\
\
\
\
\
SANDEN SCROLL
Diamante, Eclipse 2.0L Turbo & 2.4L, Galant, Mirage, Montero
Sport and 3000GT
Replacement compressor is shipped with NEW refrigerant oil.
Drain, measure and discard refrigerant oil from old compressor. Drain
NEW refrigerant oil from replacement compressor equal to difference
between amount drained from old compressor and amount shipped in
replacement compressor. If any other components are replaced, add NEW
refrigerant oil as specified. See COMPONENT REFRIGERANT OIL CAPACITIES
(SANDEN SCROLL) table.
COMPONENT REFRIGERANT OIL CAPACITIES TABLE (SANDEN SCROLL)
\
\
\
\
\
\
Component Ounces
Compressor ( 1)
Diamante, Eclipse 2.0L Turbo & 2.4L & Galant ... 5.7-6.4
Mirage ............................................. 4.4
3000GT ............................................. 5.4
Condenser
Diamante, Eclipse 2.0L Turbo & 2.4L,
Galant, Mirage & 3000GT ............................ 0.5
Evaporator
Diamante, Eclipse 2.0L Turbo & 2.4L,
Galant, Mirage & 3000GT ............................ 2.0
Receiver-Drier
Diamante, Eclipse 2.0L Turbo & 2.4L,
Galant, Mirage & 3000GT ............................ 0.3
Refrigerant Lines
Diamante, Eclipse 2.0L Turbo & 2.4L,
Galant, Mirage & 3000GT ............................ 0.3
( 1) - If replacement compressor is shipped without
refrigerant oil, add same amount of NEW refrigerant
oil to replacement compressor that was drained from
old compressor.
\
\
\
\
\
\
Page 44 of 1501
* A/C-HEATER SYSTEM UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
A/C-Heater System Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Heating, Ventilation and Air Conditioning
ACCUMULATORS
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AIR CONDITIONING FITTINGS
AIR CONDITIONING HOSES
AIR CONDITIONING METAL LINES, HOSES AND FITTING ASSEMBLIES
AIR CONTROL DOORS
AIR DAMS (EXTERNAL)
AIR DISTRIBUTION SYSTEM
BELTS
BLEND DOORS
BLOWER FANS (BLOWER WHEEL OR SQUIRREL CAGE)
BLOWER MOTORS
BLOWER RESISTORS
BLOWER SWITCHES
CABIN AIR FILTERS
CIRCUIT BREAKERS
COMPRESSOR CLUTCH ASSEMBLIES
COMPRESSORS
CONDENSER AIR SEALS
CONDENSER FAN MOTORS
CONDENSERS
CONNECTORS
CONTROL CABLES
CONTROL HEADS (FUNCTION SELECTORS)
CONTROL LINKAGES
CONTROL MODULES
COOLANT
COOLING FAN BLADES
COOLING FAN CLUTCHES
COOLING FAN MOTORS
EVAPORATOR DRAIN TUBES
EVAPORATOR PRESSURE REGULATORS (EPRS)
EVAPORATORS
EXPANSION VALVES
FUNCTION SELECTORS
FUSES, FUSIBLE LINKS AND CIRCUIT BREAKERS
FUSIBLE LINKS
GASKETS
HEATER CASES
HEATER CONTROL VALVES
HEATER CORES
Page 65 of 1501
Connector melted, not
affecting performance .. 2 ........... (1) Suggest repair or
replacement.
Connector missing ....... C ............ Require replacement.
Hydraulic fan motor
leaking ................ A .. Require repair or replacement.
Inoperative ............. A ........ ( 2) Require replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 ............ Suggest replacement.
Rotation incorrect for
application ............ B .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Vibration ............... 1 ............ Suggest replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Check fan motor/controls. Inoperative includes
intermittent operation or out of OEM specification.
\
\
\
\
\
\
\
EVAPORATOR DRAIN TUBES
EVAPORATOR DRAIN TUBE INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Disconnected ............ A ................. Require repair.
Leaking ................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Restricted .............. A .. Require repair or replacement.
Routed incorrectly ...... B ................. Require repair.
\
\
\
\
\
\
\
EVAPORATOR PRESSURE REGULATORS (EPRS)
EVAPORATOR PRESSURE REGULATOR (EPR) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Inoperative ............. A ........... ( 1) Require repair or
replacement.
( 1) - Inoperative includes intermittent operation or out of
OEM specification.
\
\
\
\
\
\
\
Page 66 of 1501
![MITSUBISHI MONTERO 1998 Service Manual EVAPORATORS
EVAPORATOR INSPECTION \
\
\
\
\
\
\
Condition](/img/19/57333/w960_57333-65.png "MITSUBISHI MONTERO 1998 Service Manual EVAPORATORS
EVAPORATOR INSPECTION \
\
\
\
\
\
\
Condition")
EVAPORATORS
EVAPORATOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Abrasion damage, affecting
structural integrity ... A .. Require repair or replacement.
Abrasion damage, not
affecting structural
integrity .............. .. ........ No service suggested or
required.
Air flow obstruction,
affecting performance .. A .. Require repair or replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Bracket bent, affecting
performance ............ A .. Require repair or replacement.
Bracket bent, not
affecting performance .. .. ........ No service suggested or
required.
Bracket broken, affecting
performance ............ A ............ Require replacement.
Bracket broken, not
affecting performance .. .. ........ No service suggested or
required.
Bracket corroded,
affecting performance .. A .. Require repair or replacement.
Bracket corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Bracket cracked, affecting
performance ............ A .. Require repair or replacement.
Bracket cracked, not
affecting performance .. 1 .. Suggest repair or replacement.
Bracket holes elongated,
affecting performance .. A .. Require repair or replacement.
Bracket holes elongated,
not affecting
performance ............ .. ........ No service suggested or
required.
Bracket loose, affecting
performance ............ A .. Require repair or replacement.
Bracket loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Bracket missing ......... C ............ Require replacement.
Corroded, affecting
structural integrity ... A ............ Require replacement.
Corroded, not affecting
structural integrity ... .. ........ No service suggested or
required.
Evaporator foam seal
leaking ................ A ............ Require replacement.
Evaporator foam seal
missing ................ C ............ Require replacement.
Fitting type incorrect
Page 72 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
Condition Code](/img/19/57333/w960_57333-71.png "MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
Condition Code")
\
\
\
\
\
\
\
Condition Code Procedure
Air control door
binding ................ A ... Require repair or replacement
Air control door
broken ................. A .. Require repair or replacement.
Air control door
leaking ................ A .. Require repair or replacement.
Air control door
seized ................. A .. Require repair or replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Cracked ................. 2 .. Suggest repair or replacement.
Drain hole restricted ... A ................. Require repair.
Drain plugged ........... A ................. Require repair.
Duct disconnected ....... A .. Require repair or replacement.
Duct leaking ............ A .. Require repair or replacement.
Duct missing ............ C ............ Require replacement.
Duct restricted ......... A .. Require repair or replacement.
Leaking ................. A .. Require repair or replacement.
Noisy ................... 2 ..... Suggest cleaning or repair.
Odor .................... 2 ..... Suggest cleaning or repair.
Restricted .............. A .... Require cleaning, repair, or
replacement.
\
\
\
\
\
\
\
PRESSURE CONTROL VALVES
See:
* EVAPORATOR PRESSURE REGULATORS (EPRS)
* HIGH PRESSURE RELIEF VALVES (HPRV)
* PILOT-OPERATED ABSOLUTES (POAS)
* SUCTION THROTTLING VALVES (STVS)
* VALVES IN RECEIVER (VIRS)
PRESSURE SENSORS
See THERMISTORS AND PRESSURE SENSORS .
PULLEYS
PULLEY INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Alignment incorrect ..... B .. Require repair or replacement.
Application incorrect ... B ............ Require replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
Page 84 of 1501
A/C-HEATER SYSTEM
1998 Mitsubishi Montero
1998 AIR CONDITIONING & HEAT
Mitsubishi - A/C-Heater System
Montero
* PLEASE READ THIS FIRST *
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all SERVICE PRECAUTIONS and DISABLING &
ACTIVATING AIR BAG SYSTEM procedures in AIR BAG RESTRAINT
SYSTEM article.
A/C SYSTEM SPECIFICATIONS
A/C SYSTEM SPECIFICATIONS TABLE \
\
\
\
\
\
Application Specification
Compressor Type ............... Nippondenso 10PA15 10-Cyl.
Compressor Belt Deflection ( 1)
New .......................... 13/64-15/64" (5.1-6.0 mm)
Used ......................... 17/64-19/64" (6.6-7.5 mm)
Compressor Oil Capacity ..................... ( 2) 2.7 ozs.
Refrigerant (R-134a) Capacity ................. 21-23 ozs.
System Operating Pressures ( 4)
High Side ............... 149-213 psi (10.5-15.0 kg/cm
)
Low Side .................... 14-33 psi (1.0-2.3 kg/cm)
( 1) - With 22 lbs. (100 N.m) force applied midway on longest
span of belt.
( 2) - Use ND 8-OIL refrigerant oil.
( 3) - Use SUN PAG 56 refrigerant oil.
( 4) - With ambient temperature at about 80
F (27C). \
\
\
\
\
\
DESCRIPTION
Slight variations exist among manual A/C-heater systems used.
On Montero, a Nippondenso 10-cylinder compressor is used. Cycling of
compressor clutch is controlled by an automatic A/C Control Unit
(ACCU).
Compressors will only operate within normal temperatures and
pressures set for each model. An electric condenser fan operates
whenever A/C system is operating. System components may vary depending
upon model. Systems may include an ACCU, fan switch, evaporator,
temperature sensor, dual-pressure switch, engine coolant temperature
switch, compressor, condenser, receiver-drier and various pipes and
hoses.
OPERATION
A/C CONTROL UNIT (ACCU)
ACCU controls cycling of compressor clutch based on
information received from air thermosensor and air inlet sensor, dual-
pressure switch, A/C switch and A/C engine coolant temperature switch.
ACCU is attached to top of evaporator housing.
Page 86 of 1501
ADJUSTMENTS
NOTE: For adjustment procedures, see HEATER SYSTEM article.
TROUBLE SHOOTING
NO COOLING
1) Ensure compressor clutch is operating. If compressor
clutch is operating, go to next step. If compressor clutch is not
operating, check fuses and A/C switch. Check dual-pressure switch.
Check air inlet sensor and air thermosensor. Check A/C compressor
relay. Check A/C compressor clutch coil. Check A/C control unit.
2) Ensure system is properly charged with correct amount of
refrigerant. Evacuate and charge system as necessary. Ensure receiver-
drier is not clogged. Check compressor belt for proper tension. Check
for clogged expansion valve. Check compressor operation. Repair or
replace components as necessary.
INSUFFICIENT AIRFLOW
Check for air leakage at air duct joint. Check for frost on
evaporator. Ensure blower motor is operating properly. Check for
obstructed air intake.
INSUFFICIENT COOLING
Ensure system is properly charged with correct amount of
refrigerant and free of air and moisture. Evacuate and charge system
as necessary. Ensure receiver-drier is not clogged. Ensure sufficient
airflow through condenser exists. Check compressor belt for proper
tension. Check compressor operation. Repair or replace compressor as
necessary. Check for clogged expansion valve. Replace expansion valve
as necessary. Check A/C compressor clutch coil.
INTERMITTENT COOL AIR
Check for air or moisture in system. Evacuate and charge
system as necessary. Check for expansion valve malfunction. Replace
expansion valve if necessary. Check compressor belt for proper
tension.
TESTING
* PLEASE READ THIS FIRST *
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all SERVICE PRECAUTIONS and DISABLING &
ACTIVATING AIR BAG SYSTEM procedures in AIR BAG RESTRAINT
SYSTEM article.
NOTE: For testing procedures not covered in this article, see
HEATER SYSTEM article.
A/C SYSTEM PERFORMANCE
1) Park vehicle out of direct sunlight. Install A/C gauge
set. Start engine and allow it to idle at 1000 RPM. Turn A/C on. Set
A/C controls to recirculated air, panel (vent) mode and full cold
Page 87 of 1501
settings.
2) Set blower/fan on high speed. Close doors and windows.
Insert thermometer in center vent. Operate system for 20 minutes to
allow system to stabilize. Measure temperature.
3) Discharge air temperature must be 37-44
F (3-7C) at
center vent, with high side and low side pressures within
specification. See A/C SYSTEM SPECIFICATIONS table at beginning of
article.
A/C CONTROL UNIT (ACCU)
1) Locate A/C Control Unit (ACCU) on top of evaporator case
and disconnect 10-pin connector. Inspect connector and wiring for
damage. Turn ignition and A/C on. Set temperature control to maximum
cooling and blower switch to high. Using a DVOM set to appropriate
test function, inspect harness side of connector. See Fig. 3. Go to
next step. If all test readings are as specified, replace ACCU.
2) Terminal No. 1 (Green/Yellow wire) is ACCU output. With
A/C and blower motor on, battery voltage should be present when ACCU
has received signals from pressure and temperature sensors confirming
A/C operation is okay.
3) Terminal No. 3 (Green/Blue wire) is ACCU power supply whe\
n
A/C switch is in A/C mode. With ignition and blower on, and A/C switch
at second level setting, battery voltage should be present.
4) Terminal No. 5 (Green/Red wire) is ACCU power supply when\
A/C switch is in ECONO mode. With ignition and blower on, and A/C
switch at first level setting, battery voltage should be present.
Terminals No. 2 and 7 (Black wire) are ACCU grounds. There should be
zero volts at all times.
5) Turn ignition off. Reconnect 10-pin connector. Turn
ignition on. Turn A/C on. Set temperature control to maximum cooling
and blower switch to high. Backprobe 10-pin connector. Go to next
step. If all test readings are as specified, replace ACCU.
6) Terminal No. 10 (Blue/White wire) is air thermosensor
power supply. With ignition, blower and A/C on, approximately 5.5
volts should be present.
7) Terminal No. 8 (Blue/Yellow wire) is air thermosensor
signal. When temperature of evaporator outlet portion is 77
F (25C),
there should be approximately 3.6 volts present.
8) Terminal No. 4 (White/Blue wire) is air inlet sensor powe\
r
supply. With ignition, blower and A/C on, approximately 5.5 volts
should be present.
9) Terminal No. 9 (Yellow/Green wire) is air inlet sensor
signal. When temperature of evaporator outlet portion is 77
F (25C),
there should be approximately 1.5 volts present.
Fig. 1: Testing ACCU
Courtesy of Mitsubishi Motor Sales of America.
A/C SWITCH
Page 89 of 1501
Fig. 3: Testing A/C Engine Coolant Temperature Switch
Courtesy of Mitsubishi Motor Sales of America.
AIR THERMOSENSOR & AIR INLET SENSOR
1) Disconnect sensor connector at evaporator case. See
Fig. 12 . Using ohmmeter, measure resistance between sensor terminals.
See AIR THERMOSENSOR & AIR INLET SENSOR SPECIFICATIONS table.
2) If resistance is not within specifications, faulty sensor
must be replaced. If resistance is within specifications and all other
components are okay, replace A/C Compressor Control Unit (ACCU).
AIR THERMOSENSOR & AIR INLET SENSOR SPECIFICATIONS TABLE
\
\
\
\
\
\
Sensor Temperature F (C) Ohms
-20 (-4) .......................................... 12,000
32 (0) .............................................. 4800
50 (10) ............................................. 2800
68 (20) ............................................. 1800
86 (30) ............................................. 1000
104 (40) ............................................. 800
\
\
\
\
\
\
BLOWER RESISTOR
Disconnect blower resistor connector. Using an ohmmeter,
measure resistance between indicated terminals. See BLOWER RESISTOR
RESISTANCE table. See Fig. 4
BLOWER RESISTOR RESISTANCE TABLE
