GDI -Troubleshooting 13A-197
Inspection procedure 36
Purge control solenoid valve system
Probable cause
The engine-A/T-ECU controls the purge control solenoid valve in order to control
the purge air coming from the canister.DMalfunction of the purge control solenoid valve
DOpen circuit or short-circuited harness wire in the
purge control solenoid valve circuit
DMalfunction of the engine-A/T-ECU
OK
Check the trouble symptoms.NGCheck the harness wire between the
engine-A/T-ECU and the purge control
solenoid valve, and repair if necessary.
OK
Check the trouble symptoms.NGReplace the engine-A/T-ECU.
OK
Check the following connector:
D-120NG
Repair
OK
Measure at the engine-A/T-ECU con-
nector D-120.
DDisconnect the connector, and
measure at the harness side.
DVoltage between 5 and earth
(Ignition switch: ON)
OK:
System voltageNGCheck the following connector:
B-106NG
Repair
OK
Measure at the purge control solenoid
valve connector B-106.
DDisconnect the connector, and
measure at the harness side.
DVoltage between 2 and earth
(Ignition switch: ON)
OK:
System voltageNGCheck the harness wire between the
engine controlrelay and the purge
control solenoid valve, and repair if
necessary.
Check the purge control solenoid valve.
(Refer to GROUP 17 - On-vehicle Ser-
vice.)NG
Replace
