00-1
GENERAL
CONTENTS
HOW TO USE THIS MANUAL 2..............
Scope of Maintenance, Repair and Servicing
Explanations 2.................................
Definition of Terms 2...........................
Indication of Tightening Torque 2................
Model Indications 3............................
Explanation of Manual Contents 4...............
HOW TO USE
TROUBLESHOOTING/INSPECTION SERVICE
POINTS 6....................................
Troubleshooting Contents 6.....................
Diagnosis Function 7...........................
How to Use the Inspection Procedures 10.......
Connector Measurement Service Points 11.......
Connector Inspection 12........................
Inspection Service Points for a Blown Fuse 13...
Points to Note for Intermittent Malfunctions 13....
TREATMENT BEFORE/AFTER THE FORDING
A STREAM 14..............................
Inspection and Service before Fording a Stream
14 ............................................
Inspection and Service after Fording a Stream
15 ............................................
VEHICLE IDENTIFICATION 16...............
Vehicle Information Code Plate 16...............
Models 16.....................................
Model Code 18................................
Chassis Number 19............................
Engine Model Number 20.......................
Theft Protection
MAJOR SPECIFICATIONS 23................
PRECAUTIONS BEFORE SERVICE 29.......
SUPPLEMENTAL RESTRAINT SYSTEM
(SRS) 33....................................
SUPPORT LOCATIONS FOR LIFTING AND
JACKING 37................................
Support Positions for a Garage Jack 37.........
Support Positions for axle stands and a
Single-Post Lift or Double-Post Lift 38...........
STANDARD PARTS-TIGHTENING-TORQUE
TABLE 39..................................
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 3 of 1839
GENERAL -How to Use This Manual00-2
HOW TO USE THIS MANUAL
SCOPE OF MAINTENANCE, REPAIR
AND SERVICING EXPLANATIONS
This manual provides explanations, etc. concerning
procedures for the inspection, maintenance, repair
and servicing of the subject model. Note, however,
that for engine and transmission-related component
parts, this manual covers only on-vehicle
inspections, adjustments, and the removal and
installation procedures for major components.
For detailed information concerning the inspection,
checking, adjustment, disassembly and reassembly
of the engine, transmission and major components
after they have been removed from the vehicle,
please refer to separate manuals covering the
engine and the transmission.
ON-VEHICLE SERVICE
“On-vehicle Service” is procedures for performing
inspections and adjustments of particularly
important locations with regard to the construction
and for maintenance and servicing, but other
inspection (for looseness, play, cracking, damage,
etc.) must also be performed.
INSPECTION
Under this title are presented inspection and
checking procedures to be performed by using
special tools and measuring instruments and by
feeling, but, for actual maintenance and servicing
procedures, visual inspections should always be
performed as well.
DEFINITION OF TERMS
STANDARD VALUE
Indicates the value used as the standard for judging
the quality of a part or assembly on inspection
or the value to which the part or assembly is
corrected and adjusted. It is given by tolerance.
LIMIT
Shows the standard for judging the quality of a
part or assembly on inspection and means the
maximum or minimum value within which the part
or assembly must be kept functionally or in strength.
It is a value established outside the range of
standard value.
REFERENCE VALUE
Indicates the adjustment value prior to starting the
work (presented in order to facilitate assembly and
adjustment procedures, and so they can be
completed in a shorter time).
CAUTION
Indicates the presentation of information particularly
vital to the worker during the performance of
maintenance and servicing procedures in order to
avoid the possibility of injury to the worker, or
damage to component parts, or a reduction of
component or vehicle function or performance, etc.
INDICATION OF TIGHTENING TORQUE
Tightening torques (units: N×m) are set to take into
account the central value and the allowable
tolerance. The central value is the target value,
and the allowable tolerance provides the checking
range for tightening torques. If bolts and nuts are
not provided with tightening torques, refer to
P.00-39.
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 4 of 1839
GENERAL -How to Use This Manual00-3
MODEL INDICATIONS
The following abbreviations are used in this manual for classification of model types.
GDI: Indicates the gasoline direct injection.
DOHC: Indicates an engine with the double overhead camshaft, or models equipped with such an
engine.
M/T: Indicates the manual transmission, or models equipped with the manual transmission.
A/T: Indicates the automatic transmission, or models equipped with the automatic transmission.
A/C: Indicates the air conditioner.
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 5 of 1839
I
n dic a te s (b y sym bols ) where lu bric a -
t io n is nece ssa ry .
Page 6 of 1839
i
n dic a te s th atth ere is
a co ntin uit y betw een th e te rm i-
n als .
in dic a te s te rm in als to
w hic h batte ry vo lt a ge is applie d. I
n dic a te s th e
s e ctio n tit le . I
n dic a te s th e
g ro up num -
b er. I
n dic a te s th e
p age num ber. I
n dic a te s th e
g ro up tit le . d
enote s non-re -
u sa ble part. R
epair kit or se t parts
a re sh ow n.(O nly ve ry
f r e quently use d parts
a re sh ow n.) O
pera tin g pro ce dure s, ca u-
t io ns, etc . on re m ova l, in sta lla -
t io n, dis a sse m bly and re as-
s e m bly are describ ed. T
he tit le of th e page (fo llo w in g
t h e page on whic h th e dia gra m
o f co m ponent parts is pre s-
e nte d)in dic a tin g th e lo ca tio ns of
l u bric a tio n and se alin g pro ce -
d ure s.
Page 7 of 1839
GENERAL -How to Use Troubleshooting/Inspection Service Points00-6
HOW TO USE TROUBLESHOOTING/INSPECTION SERVICE
POINTS
Troubleshooting of electronic control systems for which the MUT-IIcan be used follows the basic outline
described below. Furthermore, even in systems for which the MUT-IIcannot be used, part of these systems
still follow this outline.
TROUBLESHOOTING CONTENTS
1. STANDARD FLOW OF DIAGNOSIS TROUBLESHOOTING
The troubleshooting sections follow the basic diagnosis flow which is given below. If the diagnosis
flow is different from that given below, or if additional explanation is required, the details of such
differences or additions will also be listed.
Diagnosis method
Gathering information
from the customer.
Check trouble symptom.
Reoccurs Does not reoccur.
Read the diagnosis code
No diagnosis code
or communication
with MUT-
IInot
possible
Refer to the INSPECTION
CHART FOR TROUBLE
SYMPTOMS (Refer to
applicable group.)Diagnosis code
displayed.
Read the diagnosis code
Diagnosis code
displayed.No diagnosis
code
After taking note of the
malfunction code, erase
the diagnosis code
memory
Recheck trouble symptom.
Diagnosis code
displayed.
Read the diagnosis codes.
No diagnosis
code
Refer to the INSPECTION CHART FOR DIAGNOSIS
CODES (Refer to applicable group.)INTERMITTENT MALFUNCTIONS (Refer to P.00-13.)
2. SYSTEM OPERATION AND SYMPTOM VERIFICATION TESTS
If verification of the trouble symptoms is difficult, procedures for checking operation and verifying
trouble symptoms are shown.
3. DIAGNOSIS FUNCTION
Details which are different from those in the “Diagnosis Function” section on the next page are listed.
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 8 of 1839
Page 9 of 1839
W
arn in g la m p nam e A
/T N
eutr a lp osit io n in dic a to r la m p A
BS A
BS warn in g la m p S
S4 II 4
W D warn in g la m p H
yd ra ulic Bra ke Booste r(H BB) B
ra ke warn in g la m p W
hen no dia gnosis co de is outp ut* 1
.5 se cs. 0
.5 se c. 0
.5 se c. P
ause
t im e 3
s e cs. T
e ns
s ig nal P
la ce
d iv is io n
2 se cs. U
nit s
s ig nal O
n
O ff 0
.5 se c. < S S4 II, A /T >
0 .2 5 se c. < A BS,H BB>
