Page 941 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-40 Code No.45 5th without completion of shiftingProbable cause If the output shaft speed sensor output multiplied by the 5th gear ratio is not identical

Page 942 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-41 NG Replace the valve body assembly. L Check the trouble symptoms. Replace the engine-A/T-ECU or A/T-ECU. Check the trouble symptoms. Repair OK NGDChe

Page 943 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-42 Code No. 46 Reverse without completion of shiftingProbable cause If the output shaft speed sensor output multiplied by the reverse gear ratio is not

Page 944 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-43 NG Replace the valve body assembly. L Check the trouble symptoms. Replace the engine-A/T-ECU or A/T-ECU. Check the trouble symptoms. Repair OK NGDChe

Page 945 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-44 Code No. 52 Damper clutch control systemProbable cause If the DCC solenoid valve drive duty ratio is100% for a continuous period of 4 seconds or more

Page 946 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-45 Code No. 54 A/T control relay systemProbable cause If the A/T control relay voltage is less than 7 V after the ignition switch is turned to the ON po

Page 947 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-46 Code No. 56 N range lamp systemProbable cause If the N range signal is OFF after the N range lamp illuminates(ON), it is judged that there is ashort-

Page 948 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-47 CHART CLASSIFIED BY TROUBLE SYMPTOMS Trouble SymptomInspection pro- cedure No.Reference page Communication with the MUT-IIis not possible.123-48 Driv

Page 949 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-48 INSPECTION PROCEDURES CLASSIFIED BY TROUBLE SYMPTOM Inspection procedure 1 Communication with the MUT-II is not possible. Probable cause If communica

Page 950 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-49 Inspection procedure 2 Starting not possible Probable cause If the enginewill not start when the selector lever is at the P or N position, the cause
