Page 921 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-20 Code No. 22 Input shaft speed sensor systemProbable cause If no output pulse from the input shaft speed sensor is detected for 1 second or more while

Page 922 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-21 (3)NG From the previouspage OK(1)NG NG Repair Check the following connector:E-113 OK NG Repair Check the following connector:E-113 OK(2)NGNG Repair C

Page 923 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-22 Code No. 23 Output shaft speed sensor systemProbable cause If the output from the output shaft speed sensor is 50% or less continuously for 1 second

Page 924 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-23 NG From the previouspage OK(1)NG NG Repair Check the following connector:E-113 OK NG Repair Check the following connector:E-113 OK Replace the output

Page 925 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-24 Code No.25 Wide open throttle switch systemProbable cause If the wideopen throttleswitch does not turn OFF when the acceleratorpedal is not depressed

Page 926 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-25 Code No. 26 Stop lamp switch systemProbable cause If the stoplampswitch is continuously on for 5 minutes or more while the vehicle isbeing driven, it

Page 927 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-26 Code No. 31 LR solenoid valve systemProbable cause If the drive terminal voltage of the LR solenoid valve is 3.0 V or less, it is judged that there i

Page 928 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-27 Code No. 32 UD solenoid valve systemProbable cause If the drive terminal voltage of the UD solenoid valve is 3.0 V or less, it is judged that there i

Page 929 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-28 Code No. 33 2nd solenoid valve systemProbable cause If the drive terminal voltage of the 2nd solenoid valve is 3.0 V or less, it is judged that there

Page 930 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual AUTOMATIC TRANSMISSION -Troubleshooting <A/T>23-29 Code No. 34 OD solenoid valve systemProbable cause If the drive terminal voltage of the OD solenoid valve is 3.0 V or less, it is judged that there i
