towing capacity MITSUBISHI OUTLANDER SPORT 2014 3.G Owners Manual

Break-in recommendations
Features and controls 5-3
5
N00508700330
Advanced automobile manufacturing tech- niques permit you to operate your new vehi-cle without requiring a long break-in period of low-speed driving. However, you can add to the future perfor-mance and economy of your vehicle by observing the following precautions during the first 300 miles (500 km).Drive your vehicle at moderate speeds duringthe break-in period.  Avoid revving the engine.  Avoid rough driving such as sudden starts, sudden acceleration, prolonged high-speed driving and sudden braking. These would have a detrimental effect on the engine and also cause increased fuel andoil consumption, which could result in malfunction of the engine components. Be particularly careful to avoid full accelera-tion while in low shift position (low gears).  Do not overload the vehicle. Stay within the seating capacity. (Refer to “Cargo load precautions” on page 6-11.)  Do not use this vehicle for trailer towing.
N00508800562
Two keys are provided. The keys fit all locks. Keep one in a safe place as a spare key. Two F.A.S.T.-keys and two emergency keys are provided. Keep one F.A.S.T.-key and one emergencykey in a safe place together as a set of spare keys.
Break-in recommendations
Keys Type 1 1- Key for the electronic immobilizer and
keyless entry system
2- Key number plateType 2
1- F.A.S.T.-key
(with electronic immob
ilizer and keyless
entry system function)
2- Emergency key 3- Key number plate
NOTE
 The key is a precision electronic device with a built-in signal transmitter. Please observe the following in order to prevent damage. • Do not leave where it may be exposed to heat caused by direct sunlight, such as ontop of the dashboard. • Do not take the remote control transmitter apart. • Do not excessively bend the key or subject it to strong impacts. • Keep the remote control transmitter dry.• Keep away from magnetic objects such as key rings.
BK0202700US.bo
ok 3 ページ ２０１３年３月２８日　木曜日　午前１１時５４分

Loading information Driving safety 6-9
6
6.If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the availablecargo and luggage load capacity of your vehicle.NOTE
The above steps for determiningcorrect load limit were written in accordance with U.S.A. regula-tions. Your vehicle cannot tow a trailer, so step 6 is irrelevant.
BK0202700US.bo
ok 9 ページ ２０１３年３月２８日　木曜日　午前１１時５４分

Alphabetical index
12-5
12
T
Tail light
Bulb capacity
................
.................
9-29
Replacement
.................
.................
9-36
Tank capacity
....................
.................
11-5
Theft-alarm system
.............................
5-33
Time Setting
..................
.....................
7-55
Tire
...........................
........................
9-13
Inflation pressure
............................
9-17
Maintenance
..................
.................
9-18
Quality grading
...............................
10-2
Replacing tires and wheels
...............
9-18
Rotation
....................
.....................
9-19
Size (tire and wheel)
.......................
11-5
Snow tires
.....................
.................
9-20
To change a tire
................
................
8-6
Tread wear indicator
.......................
9-18
Tire pressure monitoring system
...........
5-75
Tires
Tire and loading information placard 11-2 Tire chains
....................
.................
9-20
Tools
.........................
..........................
8-5
Storage
.........................
...................
8-5
Towing
......................
........................
8-12
Trailer towing
....................
.................
6-13
Transfer oil
................
...............
9-10
, 11-5
Turn signal light
Indicators
..................
...................
5-116
Lever
......................
.....................
5-126
U
USB input terminal
............................
5-155
How to connect an iPod
.................
5-156
USB input terminal device
How to connect a USB memory
......
5-155
V
Vanity mirror
...................
.................
5-158
Vanity mirror lights
Bulb capacity
..................
...............
9-30
Vehicle care precautions
.....................
9-38
Vehicle dimensions
............................
11-3
Vehicle labeling
..................
...............
11-2
Vehicle preparation before driving
.........
6-4
Vehicle weights
...................
...............
11-3
Vents
..........................
........................
7-2
W
Warning lights
.................
.................
5-117
Washer
Fluid
....................
.................
9-11
, 11-5
Rear window washer
.....................
5-131
Switch
.....................
.....................
5-131
Washing
......................
......................
9-40
Waxing
.......................
......................
9-41
Weights
........................
.....................
11-3
Wheel
Covers
......................
.....................
8-11
Specification
.................
.................
11-5
Wiper
Rear window wiper
.......................
5-131
Switch
......................
...................
5-128
Wiper blades
.................
.................
9-21
BK0202700US.bo
ok 5 ページ ２０１３年３月２８日　木曜日　午前１１時５４分
