IP
N
O P
17. Remove screws (A) and metal clip (B), and remove combination
meter.
Installation Installation is in the reverse order of removal.
GLOVE BOX ASSEMBLY
Removal 1. Remove glove box screws.
2. Pull backward while disengaging the glove box assembly pawls.
3. Disconnect lamp harness connector, and then remove glove box assembly.
Installation Installation is in the reverse order of removal.
INSTRUMENT LOWER FINISHER
Removal 1. Pull backward while disengage the instrument lower finisher's clip and pawls.
: Metal clip
2. Disconnect in-vehicle sensor and harness connector, and then remove instrument lower finisher.
Installation Installation is in the reverse order of removal.
CENTER CONSOLE ASSEMBLY
Removal PIIB3404E
Page 3392 of 4331
341, " Removal and Installation " (CVT),
AT-212, " Control Device
Removal and Installation " (A/T).
5. Pull up and disengage A/T and CVT console finisher metal clips (A/T and CVT only).
6. Remove A/T and CVT console finisher (A/T and CVT only).
7. Remove shift knob (M/T only). Refer to MT-90 .
8. Pull up and disengage M/T console boot metal clips (M/T only).
9. Remove M/T console boot (M/T only).
10. Disengage console rear finisher metal clips and pawl. : Metal clip
: Pawl
11. Remove console rear finisher.
12. Disengage console mask cover metal clips and pawls, and then remove console mask cover (with armrest).
: Metal clip
: Pawl PIIB2454J
PIIB6387E
Page 3393 of 4331
IP
N
O P
13. Disengage rear cup holder metal clips and pawls (without arm-
rest).
: Metal clip
: Pawl
14. Remover rear cup holder (without armrest).
15. Remove console body assembly screws and nut.
16. Disconnect harness connector, and then remove console body assembly.
17. Remove both of the instrument lower cover LH and RH clips. : Metal clip
18. Disengage instrument lower cover LH and RH metal clips and remove both of the instrument lower cover LH and RH.
19. Remove screws and then remove center console.
Installation Installation is in the reverse order of removal.
Disassembly and Assembly INFOID:0000000004307249
GLOVE BOX ASSEMBLY PIIB2882J
Page 3394 of 4331
Page 3395 of 4331
IP
N
O P
Disassembly
Remove the four screws, and then remove front cup holder from center console.
Assembly Assembly is in the reverse order of disassembly.
COMBINATION METER
Disassembly Disengage the eight tabs to separate front cover (1) from the unified
meter control unit assembly (2).
Assembly Assembly is in the reverse order of disassembly. 1. Center console 2. Front cup holder
LIIA2582E
Page 3396 of 4331
LAN
N
O P
CONTENTS
LAN SYSTEM
CAN FUNDAMENTAL
PRECAUTION ....... ........................................
7
PRECAUTIONS .............................................. .....7
Precautions for Trouble Diagnosis ...................... ......7
Precautions for Harness Repair ................................7
FUNCTION DIAGNOSIS .. .............................8
CAN COMMUNICATION SYSTEM ................ .....8
System Description ............................................. ......8
System Diagram .................................................. ......8
CAN Communication Control Circuit ................... ......9
DIAG ON CAN ................................................ ....10
Description .......................................................... ....10
System Diagram .................................................. ....10
TROUBLE DIAGNOSIS ................................. ....11
Condition of Error Detection ................................ ....11
Symptom When Error Oc curs in CAN Communi-
cation System ...................................................... ....
11
CAN Diagnosis with CONSULT-III ...................... ....14
Self-Diagnosis ..................................................... ....14
CAN Diagnostic Support Monitor ........................ ....14
How to Use CAN Communication Signal Chart .. ....16
BASIC INSPECTION ....... ............................17
DIAGNOSIS AND REPAIR WORKFLOW ..... ....17
Trouble Diagnosis Flow Chart ............................. ....17
Trouble Diagnosis Procedure .............................. ....17
CAN
HOW TO USE THIS MANU AL .....................22
HOW TO USE THIS SECTION ....................... ....22
Caution ................................................................ ....22
Abbreviation List .................................................. ....22
PRECAUTION ....... .......................................23 PRECAUTIONS .................................................
23
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ....
23
Precautions for Trouble Diagnosis ...................... ....23
Precautions for Harness Repair .......................... ....23
BASIC INSPECTION ....... ............................25
DIAGNOSIS AND REPAIR WORKFLOW ........ 25
Interview Sheet .................................................... ....25
FUNCTION DIAGNOSIS .. ............................26
CAN COMMUNICATION SYSTEM ................... 26
CAN System Specification Chart ......................... ....26
CAN Communication Signal Chart ...................... ....26
COMPONENT DIAGNOSIS .........................29
CAN COMMUNICATION SYSTEM ................... 29
Component Parts Location .................................. ....29
Schematic ............................................................ ....30
Wiring Diagram - CAN - ....................................... ....31
MALFUNCTION AREA CHART ........................ 33
Main Line ............................................................. ....33
Branch Line ......................................................... ....33
Short Circuit ......................................................... ....33
MAIN LINE BETWEEN DLC AND ABS CIR-
CUIT .................................................................. 34
Diagnosis Procedure ........................................... ....34
MAIN LINE BETWEEN DLC AND TCM CIR-
CUIT .................................................................. 35
Diagnosis Procedure ........................................... ....35
ECM BRANCH LINE CIRCUIT ......................... 36
Diagnosis Procedure ........................................... ....36
BCM BRANCH LINE CIRCUIT ......................... 37
Diagnosis Procedure ........................................... ....37
Page 3397 of 4331
Page 3398 of 4331
LAN
N
O P
Diagnosis Procedure ...........................................
....
79
M&A BRANCH LINE CIRCUIT ...................... ....80
Diagnosis Procedure ........................................... ....80
ABS BRANCH LINE CIRCUIT ....................... ....81
Diagnosis Procedure ........................................... ....81
IPDM-E BRANCH LINE CIRCUIT .................. ....82
Diagnosis Procedure ........................................... ....82
CAN COMMUNICATION CIRCUIT ................ ....83
Diagnosis Procedure ........................................... ....83
CAN SYSTEM (TYPE 5)
COMPONENT DIAGNOSIS .........................85
MAIN LINE BETWEEN DLC AND TCM CIR-
CUIT ................................................................ ....85
Diagnosis Procedure ........................................... ....85
ECM BRANCH LINE CIRCUIT ....................... ....86
Diagnosis Procedure ........................................... ....86
BCM BRANCH LINE CIRCUIT ...................... ....87
Diagnosis Procedure ........................................... ....87
DLC BRANCH LINE CIRCUIT ....................... ....88
Diagnosis Procedure ........................................... ....88
EPS BRANCH LINE CIRCUIT ....................... ....89
Diagnosis Procedure ........................................... ....89
M&A BRANCH LINE CIRCUIT ...................... ....90
Diagnosis Procedure ........................................... ....90
TCM BRANCH LINE CIRCUIT ....................... ....91
Diagnosis Procedure ........................................... ....91
IPDM-E BRANCH LINE CIRCUIT .................. ....92
Diagnosis Procedure ........................................... ....92
CAN COMMUNICATION CIRCUIT ................ ....93
Diagnosis Procedure ........................................... ....93
CAN SYSTEM (TYPE 6)
COMPONENT DIAGNOSIS .........................95
MAIN LINE BETWEEN DLC AND ABS CIR-
CUIT ................................................................ ....95
Diagnosis Procedure ........................................... ....95
ECM BRANCH LINE CIRCUIT ....................... ....96
Diagnosis Procedure ........................................... ....96
BCM BRANCH LINE CIRCUIT ...................... ....97
Diagnosis Procedure ........................................... ....97
DLC BRANCH LINE CIRCUIT ....................... ....98
Diagnosis Procedure ........................................... ....98
EPS BRANCH LINE CIRCUIT ....................... ....99
Diagnosis Procedure ........................................... ....99 M&A BRANCH LINE CIRCUIT .......................
100
Diagnosis Procedure ........................................... ..100
ABS BRANCH LINE CIRCUIT ........................ 101
Diagnosis Procedure ........................................... ..101
TCM BRANCH LINE CIRCUIT ........................ 102
Diagnosis Procedure ........................................... ..102
IPDM-E BRANCH LINE CIRCUIT ................... 103
Diagnosis Procedure ........................................... ..103
CAN COMMUNICATION CIRCUIT ................. 104
Diagnosis Procedure ........................................... ..104
CAN SYSTEM (TYPE 7)
COMPONENT DIAGNOSIS .......................106
MAIN LINE BETWEEN DLC AND TCM CIR-
CUIT ................................................................ 106
Diagnosis Procedure ........................................... ..106
ECM BRANCH LINE CIRCUIT ....................... 107
Diagnosis Procedure ........................................... ..107
BCM BRANCH LINE CIRCUIT ....................... 108
Diagnosis Procedure ........................................... ..108
DLC BRANCH LINE CIRCUIT ........................ 109
Diagnosis Procedure ........................................... ..109
EPS BRANCH LINE CIRCUIT ........................ 110
Diagnosis Procedure ........................................... ..110
M&A BRANCH LINE CIRCUIT ....................... 111
Diagnosis Procedure ........................................... ..111
TCM BRANCH LINE CIRCUIT ........................ 112
Diagnosis Procedure ........................................... ..112
IPDM-E BRANCH LINE CIRCUIT ................... 113
Diagnosis Procedure ........................................... ..113
CAN COMMUNICATION CIRCUIT ................. 114
Diagnosis Procedure ........................................... ..114
CAN SYSTEM (TYPE 8)
COMPONENT DIAGNOSIS .......................116
MAIN LINE BETWEEN DLC AND TCM CIR-
CUIT ................................................................ 116
Diagnosis Procedure ........................................... ..116
ECM BRANCH LINE CIRCUIT ....................... 117
Diagnosis Procedure ........................................... ..117
BCM BRANCH LINE CIRCUIT ....................... 118
Diagnosis Procedure ........................................... ..118
DLC BRANCH LINE CIRCUIT ........................ 119
Diagnosis Procedure ........................................... ..119
EPS BRANCH LINE CIRCUIT ........................ 120
Page 3399 of 4331
Page 3400 of 4331
LAN
N
O P
Diagnosis Procedure ...........................................
..
161
ECM BRANCH LINE CIRCUIT ....................... ..162
Diagnosis Procedure ........................................... ..162
BCM BRANCH LINE CIRCUIT ...................... ..163
Diagnosis Procedure ........................................... ..163
DLC BRANCH LINE CIRCUIT ....................... ..164
Diagnosis Procedure ........................................... ..164
EPS BRANCH LINE CIRCUIT ....................... ..165
Diagnosis Procedure ........................................... ..165
I-KEY BRANCH LINE CIRCUIT ..................... ..166
Diagnosis Procedure ........................................... ..166
M&A BRANCH LINE CIRCUIT ...................... ..167
Diagnosis Procedure ........................................... ..167
ABS BRANCH LINE CIRCUIT ....................... ..168
Diagnosis Procedure ........................................... ..168
TCM BRANCH LINE CIRCUIT ....................... ..169
Diagnosis Procedure ........................................... ..169
IPDM-E BRANCH LINE CIRCUIT .................. ..170
Diagnosis Procedure ........................................... ..170
CAN COMMUNICATION CIRCUIT ................ ..171
Diagnosis Procedure ........................................... ..171
CAN SYSTEM (TYPE 13)
COMPONENT DIAGNOSIS .......................173
ECM BRANCH LINE CIRCUIT ....................... ..173
Diagnosis Procedure ........................................... ..173
BCM BRANCH LINE CIRCUIT ...................... ..174
Diagnosis Procedure ........................................... ..174
DLC BRANCH LINE CIRCUIT ....................... ..175
Diagnosis Procedure ........................................... ..175
EPS BRANCH LINE CIRCUIT ....................... ..176
Diagnosis Procedure ........................................... ..176
M&A BRANCH LINE CIRCUIT ...................... ..177
Diagnosis Procedure ........................................... ..177
IPDM-E BRANCH LINE CIRCUIT .................. ..178
Diagnosis Procedure ........................................... ..178
CAN COMMUNICATION CIRCUIT ................ ..179
Diagnosis Procedure ........................................... ..179
CAN SYSTEM (TYPE 14)
COMPONENT DIAGNOSIS .......................181
MAIN LINE BETWEEN DLC AND ABS CIR-
CUIT ................................................................ ..
181
Diagnosis Procedure ........................................... ..181 ECM BRANCH LINE CIRCUIT .......................
182
Diagnosis Procedure ........................................... ..182
BCM BRANCH LINE CIRCUIT ....................... 183
Diagnosis Procedure ........................................... ..183
DLC BRANCH LINE CIRCUIT ........................ 184
Diagnosis Procedure ........................................... ..184
EPS BRANCH LINE CIRCUIT ........................ 185
Diagnosis Procedure ........................................... ..185
M&A BRANCH LINE CIRCUIT ....................... 186
Diagnosis Procedure ........................................... ..186
ABS BRANCH LINE CIRCUIT ........................ 187
Diagnosis Procedure ........................................... ..187
IPDM-E BRANCH LINE CIRCUIT ................... 188
Diagnosis Procedure ........................................... ..188
CAN COMMUNICATION CIRCUIT ................. 189
Diagnosis Procedure ........................................... ..189
CAN SYSTEM (TYPE 15)
COMPONENT DIAGNOSIS .......................191
MAIN LINE BETWEEN DLC AND TCM CIR-
CUIT ................................................................ 191
Diagnosis Procedure ........................................... ..191
ECM BRANCH LINE CIRCUIT ....................... 192
Diagnosis Procedure ........................................... ..192
BCM BRANCH LINE CIRCUIT ....................... 193
Diagnosis Procedure ........................................... ..193
DLC BRANCH LINE CIRCUIT ........................ 194
Diagnosis Procedure ........................................... ..194
EPS BRANCH LINE CIRCUIT ........................ 195
Diagnosis Procedure ........................................... ..195
M&A BRANCH LINE CIRCUIT ....................... 196
Diagnosis Procedure ........................................... ..196
TCM BRANCH LINE CIRCUIT ........................ 197
Diagnosis Procedure ........................................... ..197
IPDM-E BRANCH LINE CIRCUIT ................... 198
Diagnosis Procedure ........................................... ..198
CAN COMMUNICATION CIRCUIT ................. 199
Diagnosis Procedure ........................................... ..199
CAN SYSTEM (TYPE 16)
COMPONENT DIAGNOSIS .......................
201
MAIN LINE BETWEEN DLC AND ABS CIR-
CUIT ................................................................ 201
Diagnosis Procedure ........................................... ..201
ECM BRANCH LINE CIRCUIT ....................... 202
