NISSAN LATIO 2011 Service Repair Manual

IP-20
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
7. Remove side ventilator assembly (LH).: Pawl
a. Insert a suitable tool into the bottom gap of side ventilator assembly and push against (A) and (B) as shown to disengage
the pawls.
b. Lift the side ventilator up from the bottom, pull backward while disengaging the side ventilator assembly upper pawls, and then
remove the side ventilator.
: Pawl
8. Remove the steering column cover screws, then disengage pawls and remove the steering column upper cover.
9. Remove cluster lid A.
a. Remove screws from instrument upper panel right side.
b. Lift the instrument upper panel up, disengage metal clips. : Metal clip
: Clip
c. Pull backward and disengage clips.
d. Remove cluster lid A.
WIIA1226E
PIIB3976E
PIIB3969E
PIIB2880E
Revision: May 2010 2011 Versa

INSTRUMENT PANEL ASSEMBLYIP-21
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
10. Remove screw (A) and disengage metal clips (B), and pull com- bination meter out.
11. Disconnect combination meter connectors and remove combi- nation meter.
Installation
Installation is in the reverse order of removal.
GLOVE BOX ASSEMBLY
Removal
1. Remove glove box screws.NOTE:
There are three lower and four upper screws.
2. Pull backward while disengaging the glove box assembly pawls. : Pawl
3. Remove glove box assembly.
Installation
Installation is in the reverse order of removal.
INSTRUMENT LOWER FINISHER
Removal
1. Disengage pawls and remove fuse block lid.
2. Remove instrument lower finisher. : Metal clip
: Pawl
a. Remove the instrument lower finisher screws.
b. Pull backward while disengaging the instrument lower finisher metal clips and pawl.
c. Disconnect harness connector, and then remove instrument lower finisher.
Installation
Installation is in the reverse order of removal.
CENTER CONSOLE ASSEMBLY
Removal
PKIC0703E
PIIB3404E
LIIA2544E
Revision: May 2010 2011 Versa

IP-22
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
1. Insert a suitable tool into front side space of console mask, anddisengage metal clips.
: Metal clip
2. Disconnect harness connector, and then remove console mask.
3. On models with A/T or CVT, remo ve the A/T or CVT console fin-
isher.
a. Place the shift selector in "D" position.
b. Remove shift selector handle. Refer to AT-213, "
A/T Shift Selec-
tor Removal and Installation" (A/T) or CVT-160, "Removal and
Installation" (CVT).
c. Pull up and disengage A/T or CVT console finisher metal clips. : Metal clip
d. Remove A/T or CVT console finisher.
4.5. On models with M/T, remove the M/T console boot.
a. Remove M/T shift selector handle. Refer to MT-94
b. Pull up and disengage M/T console boot metal clips.
c. Remove M/T console boot.
6. Disengage console rear finisher metal clips and pawl.
NOTE:
Console rear finisher with armrest is shown in illustration, with-
out armrest is similar.
: Metal clip
: Pawl
7. Remove console rear finisher.
8. On models with an armrest, disengage console mask cover metal clips and pawls, and then remove console mask cover.
: Metal clip
: Pawl
PIIB6386E
PIIB2454J
PIIB2452J
PIIB6387E
Revision: May 2010 2011 Versa

INSTRUMENT PANEL ASSEMBLYIP-23
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
9. On models without an armrest, disengage rear cup holder metal
clips and pawls and then remove the rear cup holder.
: Metal clip
: Pawl
10. Remove console body assembly screws and nut.
11. Disconnect harness connector, and then remove console body assembly.
12. Remove both of the instrument lower cover LH and RH clips.
13. Disengage instrument lower cover LH and RH metal clips and remove both of the instrument lower covers.
: Metal clip
14. Remove screws and then remove center console.
Installation
Installation is in the reverse order of removal.
Disassembly and AssemblyINFOID:0000000005929594
GLOVE BOX ASSEMBLY
PIIB6388E
PIIB2882J
Revision: May 2010 2011 Versa

IP-24
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
Disassembly
1. Remove screws of damper, and then remove damper.
2. Remove screws of glove box striker, and then remove glove box striker.
3. Remove screws of glove box latch, and then remove glove box latch.
Assembly
Assembly is in the reverse order of disassembly.
CENTER CONSOLE ASSEMBLY
1. Glove box striker2. Glove box 3. Glove box latch
4. Damper
LIIA2555E
Revision: May 2010 2011 Versa

INSTRUMENT PANEL ASSEMBLYIP-25
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
Disassembly
Remove the four screws, and then remove
front cup holder from center console.
Assembly
Assembly is in the reverse order of disassembly.
COMBINATION METER
Disassembly
Disengage the eight tabs to separate front cover (1) from the unified
meter control unit assembly (2).
Assembly
Assembly is in the reverse order of disassembly.
1. Center console 2. Front cup holder
LIIA2556E
LIIA2582E
Revision: May 2010 2011 Versa
