SERVICE DATA AND SPECIFICATIONS (SDS)LU-23
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
LU
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000005928705
ENGINE OIL PRESSURE
Unit: kPa (bar, kg/cm2, psi)
ENGINE OIL CAPACITY
Unit: (US qt, Imp qt)
Engine speed
Approximate discharge oil pressure
Idle speed 60 (0.60, 0.61, 9)
2,000 rpm 200 (2.0, 2.0, 29)
Drain and refillWith oil filter change Approximately 4.1 (4 3/8, 3 5/8)
Without oil filter change
Approximately 3.9 (4 1/8, 3 3/8)
Dry engine (engine overhaul) Approximately 4.9 (5 1/8, 4 3/8)
