NISSAN LATIO 2011 Service Repair Manual

AV-44
< SERVICE INFORMATION >[AUDIO WITHOUT NAVIGATION]
TELEPHONE
TROL SWITCH
1.CHECK HARNESS BETWEEN BLUETOOTH CONT
ROL UNIT AND BLUETOOTH MICROPHONE
1. Turn ignition switch OFF.
2. Disconnect Bluetooth control unit connector and Bluetooth microphone connector.
3. Check continuity between Bluetooth control unit connector B121 (A) and Bluetooth microphone connector R15 (B).
4. Check continuity between Bluetooth control unit harness con- nector B121 and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness or connector.
2.CHECK BLUETOOTH MICROPHONE POWER SUPPLY
1. Connect Bluetooth control unit connector and Bluetooth microphone connector.
2. Turn ignition switch ON.
3. Check voltage between Bluetooth microphone connector R15 terminal 4 and ground.
YES or NO
YES >> GO TO 3.
NO >> Replace Bluetooth control unit. Refer to AV-46,
"Removal and Installation".
3.CHECK MIC. SIGNAL
1. Check signal between Bluetooth control unit harness connector B121 terminals 7 and 8.
OK or NG
OK >> Replace Bluetooth control unit. Refer to AV-46, "Removal and Installation".
NG >> Replace Bluetooth microphone. Refer to AV-46, "
Removal and Installation".
Te r m i n a l s
Continuity
Connector Terminal Connector Terminal
A: B121 7
B: R15 1
Ye s
82
29 4
Te r m i n a l s Continuity
Connector Terminal —
A: B121 7
Ground No
8
29
WKIA5795E
4 - Ground : Approx. 5 V
WKIA5796E
7 – 8:When giving a voice
LKIA0780EPKIB5037J
Revision: May 2010
2011 Versa

TELEPHONEAV-45
< SERVICE INFORMATION > [AUDIO WITHOUT NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
BLUETOOTH VOICE GUIDANCE IS NOT HEARD WHEN PRESSING STEERING WHEEL AUDIO
CONTROL SWITCH
1.CHECK STEERING WHEEL A UDIO CONTROL SWITCH CIRCUIT
Refer to AV-22, "
Steering Switch Check (With Bluetooth)".
OK or NG
OK >> GO TO 2.
NG >> Replace applicable parts.
2.CHECK BLUETOOTH VOICE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect Bluetooth control uni t connector and audio unit connector.
3. Check continuity between Bluetooth control unit harness con- nector B121 (A) and audio unit harness connector M44 (B).
4. Check continuity between Bluetooth control unit harness con- nector B121 (A) and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3.CHECK MUTE SIGNAL
1. Connect Bluetooth control unit connector and audio unit connector.
2. Turn ignition switch ON.
3. Check voltage between Bluetooth control unit connector B121 terminal 11 and ground.
OK or NG
OK >> GO TO 4.
NG >> Replace audio unit. Refer to AV-29, "
Removal and Instal-
lation".
4.CHECK BLUETOOTH VOICE SIGNAL
Te r m i n a l s
Continuity
Connector Terminal Connector Terminal
A: B121 9
B: M44 66
Ye s
10 67
11 6 4
Te r m i n a l s Continuity
Connector Terminal —
A: B121 9
Ground No
10
11
AWNIA2076ZZ
11 - Ground : Approx. 5 V
LKIA0782E
Revision: May 2010 2011 Versa

AV-46
< SERVICE INFORMATION >[AUDIO WITHOUT NAVIGATION]
TELEPHONE
1. Check signal between Bluetooth control unit harness connector
B121 terminals 9 and 10.
OK or NG
OK >> Replace audio unit. Refer to AV-29, "Removal and Installation".
NG >> Replace Bluetooth control unit. Refer to AV-46, "
Removal and Installation".
Removal and InstallationINFOID:0000000005931307
BLUETOOTH CONTROL UNIT
Hatchback
9 – 10:When giving a voice
LKIA0783ESKIB3609E
LKIA0762E
1. Bluetooth control unit bracket 2. Bluetooth control unit
A. Blue tooth control unit bolts
B. BLuetooth antenna feeder harness clip (hatchback only) C. Bluetooth antenna feeder harness con-
nector D. Bluetooth control unit connector
E. Bluetooth control unit bracket screws Front
Revision: May 2010
2011 Versa

TELEPHONEAV-47
< SERVICE INFORMATION > [AUDIO WITHOUT NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
Sedan
Removal
1. For hatchback, remove luggage side lower finish (RH). Refer to EI-56, "Removal and Installation".
• Disconnect Bluetooth antenna harness clip.
2. For sedan, remove the trunk room side finisher (RH). Refer to EI-59, "
Removal and Installation".
• Disconnect the Bluetooth antenna harness connector.
3. Disconnect the Bluetooth control unit harness connector.
4. Remove the Bluetooth control unit upper and lower bracket bolts.
5. Unhook the Bluetooth control unit upper and lowe r brackets and remove Bluetooth control unit.
6. Remove Bluetooth control unit bracket screws and remove the upper and lower brackets from unit.
Installation
Installation is in the reverse order of removal.
BLUETOOTH ANTENNA
LKIA0936E
1. Bluetooth control unit bracket 2. Bluetooth control unit 3. Bluetooth antenna feeder connector
A. Bluetooth control unit bolts B. Bluetooth control unit connector Front
Revision: May 2010 2011 Versa

AV-48
< SERVICE INFORMATION >[AUDIO WITHOUT NAVIGATION]
TELEPHONE
Hatchback
Sedan
Removal
1. Disconnect the battery negative terminal.
2. For hatchback, remove luggage side lower finisher (RH). Refer to EI-56, "
Removal and Installation".
3. For sedan, fold the rear seat back down, re move the seat back finisher (RH). Refer to EI-59, "
Removal
and Installation".
4. Disconnect the Bluetooth antenna feeder harness clips.
5. Disconnect the Bluetooth ant enna feeder harness connector.
6. Remove the Bluetooth antenna bracket bolt(s) and remove antenna.
7. Remove the Bluetooth antenna screws and remove bracket.
Installation
Installation is in the reverse order of removal.
LKIA0763E
1. Bluetooth antenna bracket 2. Bluetooth antenna A. Bluetooth antenna bracket bolts
B. Bluetooth antenna screws C. Bluetooth antenna feeder harness
clips
LKIA0937E
1. Bluetooth antenna bracket 2. Bluetooth antenna A. Bluetooth antenna bracket bolts
B. Bluetooth antenna screws C. Bluetooth antenna feeder harness
clip Front
Revision: May 2010
2011 Versa

TELEPHONEAV-49
< SERVICE INFORMATION > [AUDIO WITHOUT NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
BLUETOOTH MICROPHONE
Removal
1. Remove over-head console assembly, roof finisher. Refer to EI-50.
2. Remove the Bluetooth microphone.
Installation
Installation is in the reverse order of removal.
Revision: May 2010 2011 Versa

AV-50
< SERVICE INFORMATION >[AUDIO WITH NAVIGATION]
PRECAUTIONS
SERVICE INFORMATION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006412034
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including incorrect removal and installation of the SRS can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SRS section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000006412035
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
Revision: May 2010 2011 Versa

PRECAUTIONSAV-51
< SERVICE INFORMATION > [AUDIO WITH NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of al l control units using CONSULT-III.
Revision: May 2010 2011 Versa

AV-52
< SERVICE INFORMATION >[AUDIO WITH NAVIGATION]
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000005931309
Tool name
Description
Power tool Loosening bolts and nuts
PBIC0191E
Revision: May 2010 2011 Versa

AUDIOAV-53
< SERVICE INFORMATION > [AUDIO WITH NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
AUDIO
Component Parts LocationINFOID:0000000006216701
1. Steering wheel audio control switch- es 2. Combination meter M24 3. AV control unit M43, M70, M71, M87,
M88, M89
4. USB interface and AUX jack M72, M76 5. Front door speaker LH D12, RH
D112 6. Rear door speaker LH D207, RH
D307
7. Front tweeter LH M46, RH M47 (view with front pillar garnish removed) 8. Bluetooth antenna (hatchback) [view
with luggage side lower finisher (RH)
removed] 9. Bluetooth control unit B121, B122,
B135 (hatchback)
10. Bluetooth antenna (sedan) (view with trunk side finisher RH removed) 11. Bluetooth control unit B121, B122,
B135 (sedan) 12. GPS antenna (view with cluster lid C
removed)
AWNIA2214ZZ
