NISSAN MURANO 2007 1.G Owners Manual
Manufacturer: NISSAN, Model Year: 2007, Model line: MURANO, Model: NISSAN MURANO 2007 1.GPages: 345, PDF Size: 3.57 MB
Page 101 of 345
Do not use the hazard warning flash-
ers while moving on the highway un-
less unusual circumstances force you
to drive so slowly that your vehicle
might become a hazard to other traf-
fic.
Turn signals do not work when the
hazard warning flasher lights are on.
The flasher will operate with the ignition switch in
any position.
To sound the horn, push the center pad upper
area of the steering wheel.
WARNING
Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system. Tam-
pering with the supplemental front air
bag system may result in serious per-
sonal injury.The front seats are warmed by built-in heaters.
The switches located on the center console can
be operated independently (driver side seat
A
and front passenger side seat
B) of each other.
1. Start the engine.
2. Select heat range.
1For high heat, push the
(High) side
of the switch.
2For low heat, push the
(Low) side of
the switch.
3For no heat, the switch has a center OFF
position between low and high.
SIC2627
SIC2056
HORNHEATED SEATS (if so equipped)
2-28
Instruments and controls
06.7.5/Z50-D/V5.0
Page 102 of 345
The indicator light in the switch
C
will
illuminate when low or high is selected.
The heater is controlled by a thermostat,
automatically turning the heater on and off.
The indicator light will remain on as long as
the switch is on.
3. When the vehicle’s interior is warmed, or
before you leave the vehicle, be sure to turn
the switch to the off position (center)
3.
CAUTION
The battery could run down if the
seat heater is operated while the en-
gine is not running.
Do not use the seat heater for ex-
tended periods or when no one is
using the seat.
Do not put anything on the seat
which insulates heat, such as a blan-
ket, cushion, seat cover, etc. Other-
wise, the seat may become over-
heated.
Do not place anything hard or heavy
on the seat or pierce it with a pin orsimilar object. This may result in
damage to the heater.
Any liquid spilled on the heated seat
should be removed immediately with
a dry cloth.
When cleaning the seat, never use
gasoline, benzine, thinner, or any
similar materials.
If any abnormalities are found or the
heated seat does not operate, turn
the switch off and have the system
checked by a NISSAN dealer.
The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system ON for most
driving conditions.
If the vehicle is stuck in mud or snow, the VDC
system reduces the engine output to reduce
wheel spin. The engine speed will be reduced
even if the accelerator is depressed to the floor.
If maximum engine power is needed to free a
stuck vehicle, turn the VDC system off.
To turn off the Vehicle Dynamic Control (VDC)
system, push the VDC OFF switch. The
in-
dicator light will come on.
Push the VDC OFF switch again or restart the
engine to turn ON the system. See “Vehicle
SIC1881
VEHICLE DYNAMIC CONTROL
(VDC) OFF SWITCH (if so
equipped)
Instruments and controls
2-29
06.7.5/Z50-D/V5.0
Page 103 of 345
Dynamic Control (VDC) system” in the “5. Start-
ing and driving” section.The power outlet is for powering electrical ac-
cessories such as cellular telephones.
1Located beside the glove box (if so
equipped):
Pull down the cover to open.
2Located inside the console box:
Pull to remove the cover to open.
3Located the side of the luggage room (if so
equipped):
Pull up the cover to open.
CAUTION
The outlet and plug may be hot dur-
ing or immediately after use.
This power outlet is not designed for
use with a cigarette lighter unit.
Do not use with accessories that ex-
ceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.
Use only one power outlet at a time.
Use power outlet with the engine
running to avoid discharging the ve-
SIC3071
POWER OUTLET
2-30
Instruments and controls
06.7.5/Z50-D/V5.0
Page 104 of 345
hicle battery.
Avoid using power outlets when the
air conditioner, headlights or rear
window defroster is on.
Before inserting or disconnecting a
plug, be sure to turn off the power
switch of electrical accessory being
used or the ACC power of the vehicle.
Push the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tem-
perature fuse may open.
When not in use, be sure to close the
cap/cover. Do not allow water to con-
tact the outlet.
COIN BOXTo open, push the coin box lid
1
as illustrated.
The inner tray can be removed
2
as illustrated.
Do not place valuable items in the box.
Do not use the coin box as an ashtray.
CELLULAR PHONE HOLDER
WARNING
A cellular telephone should not be
used while driving so full attention
may be given to vehicle operation.
Some jurisdictions prohibit the use
of cellular telephones while driving.
If a conversation in a moving vehicle
requires you to take notes, pull off
the road to a safe location and stop
SIC2057
SIC2058
STORAGE
Instruments and controls
2-31
06.7.5/Z50-D/V5.0
Page 105 of 345
your vehicle before doing so.
To open, push the cellular phone holder lid
1
as illustrated.
The inner tray can be removed
2
as illustrated.
Do not place valuable items in the holder.
Do not use the cellular phone holder as an
ashtray.
CUP HOLDERS
CAUTION
Avoid abrupt starting and braking
when the cup holder is being used to
prevent spilling the drink. If the liquid
is hot, it can scald you or your pas-
senger.
Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.
FrontPush the cup holder opener button
A
to open.
The flap
Bwill be folded down when inserting a
bigger container.
Pull up the inner tray
Cto remove for cleaning.
SIC3039
2-32
Instruments and controls
06.7.5/Z50-D/V5.0
Page 106 of 345
RearType A:
Pull the armrest forward until it is horizontal.Type B:
Push
A
to open the cup holder.
GLOVE BOX
WARNING
Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.
To open the glove box, pull the handle
A.
To close, push the lid in until the lock latches.
To lock
2
or unlock
1
the glove box, use the
master key, mechanical key (Intelligent Key sys-
tem) or wallet key.
SIC3042
Type A
SIC2315A
Type B
SIC2669
Instruments and controls
2-33
06.7.5/Z50-D/V5.0
Page 107 of 345
CONSOLE BOX
Type APush the button
A
to open the upper console
box lid.The partition
C
can be removed.
Pull up the buttonBto open the lower console
box lid.
Push the button
Dand adjust the armrest to the
desired position.
SIC3043
Type A
2-34
Instruments and controls
06.7.5/Z50-D/V5.0
Page 108 of 345
Type BPush the button
A
to open the console box lid.
The inside of the console box lid is designed to
be used as a holderB
such as pen, etc. There
is a power outlet
C
inside the console box.Remove the inside tray
D
to store a large
object.
To lock the console box, turn the key to the
1
position.To unlock the console box, turn the key to the
2
position.
Push the button
3and adjust the armrest to the
desired position.
SIC2208A
Type B
Instruments and controls
2-35
06.7.5/Z50-D/V5.0
Page 109 of 345
DOOR POCKETSThe door pockets are located on the driver’s and
front passenger’s doors. The door pocket open-
ing can be expanded to make it easier to store
and retrieve items. Items stored in the door
pocket should not be larger than the door pocket
opening in its closed position. Make sure that the
item does not hold the door pocket in the open
position.
CAUTION
Do not store items in the door pocketthat are larger than the opening in the
closed position. Do not force the door
pocket closed if an item holds the door
pocket in the open position. Doing so
may damage the door pocket.
CARGO NET (if so equipped)The cargo net helps keep packages in the cargo
area from moving around while your vehicle is
driven.
To install the cargo net, attach the hooks to the
retainers
A
on both sides.
To remove the cargo net, detach the hooks from
the cargo net retainers.
For more retainers, refer to “Vehicle loading
information” in the “9. Technical and consumer
information” section.
SIC3171
SIC2061
2-36
Instruments and controls
06.7.5/Z50-D/V5.0
Page 110 of 345
WARNING
Properly secure all cargo to help pre-
vent it from sliding or shifting.
Be sure to secure all four hooks into
the retainers. The cargo restrained in
the net must not exceed 30 lbs (13.6
kg) or the net may not stay secured.
TONNEAU COVER (if so equipped)The tonneau cover keeps the luggage compart-
ment contents hidden from the outside.
To use the tonneau cover, pull it out
1, hang
both sides on the hooks
2
and open the flap
3.
To use the subcover, pull out
4and hang both
sides on the hooks behind the rear seat head
restraint
5.
To stow the tonneau cover and the subcover,
remove them from the hooks and hold until they
are retracted.
To remove the tonneau cover, stow the cover
and pull the holder to the opposite side
6.
WARNING
Never put anything on the tonneau
cover, no matter how small. Any ob-
ject on it could cause an injury in an
accident or sudden stop.
Close the tonneau and sub covers
when folding the rear seat.
Do not leave the tonneau cover in the
vehicle with it disengaged from the
SIC3058
Instruments and controls
2-37
06.7.5/Z50-D/V5.0
