holder.
Properly secure all cargo to help pre-
vent it from sliding or shifting. Do not
place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.
The child restraint top tether strap
may be damaged by contact with the
tonneau cover or items in the cargo
area. Remove the tonneau cover from
the vehicle or secure it in the cargo
area. Also secure any items in the
cargo area. Your child could be seri-
ously injured or killed in a collision if
the top tether strap is damaged.
POWER WINDOWS
WARNING
Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.
Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls
and become trapped in a window.
Unattended children could become
involved in serious accidents.
The power windows operate when the ignition
switch is in the ON position and for about 45
seconds, after the ignition switch is turned to the
ACC or OFF position. If the driver’s door or the
front passenger’s door is opened during this
period of about 45 seconds, power to the
windows is canceled.
Main power window switch (driver’s
side)1. Rear left passenger’s side window
2. Driver’s side window
3. Window lock button
4. Rear right passenger’s side window
5. Front passenger’s side window
To open or close the window, push down
A
or
pull up
B
the switch and hold it. The main
switch (driver side switches) will open or close
all the windows.
SIC3283
WINDOWS
2-38
Instruments and controls
06.7.5/Z50-D/V5.0
Page 112 of 345
Locking passenger’s windowsWhen the lock button
C
is pushed in, only the
driver side window can be opened or closed.
Push it in again to cancel.
Passenger side power window switchThe passenger side switch will open or close
only the corresponding window. To open or
close the window, hold the switch down
A
or
up
B.
Automatic operationTo fully open or close the driver’s or front
passenger’s side window, completely push
down or pull up the switch and release it; it need
not be held. The window will automatically open
or close all the way. To stop the window, just
push or lift the switch on the opposite side.Auto reverse function (if so equipped)If the control unit detects something caught in a
front window as it moves up, the window will be
immediately lowered.
The auto reverse function can be activated when
a front window is closed by automatic operation
SIC3284
SIC3285
Instruments and controls
2-39
06.7.5/Z50-D/V5.0
Page 113 of 345
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the ACC, OFF or LOCK position. The
doors remain closed.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-
side the vehicle before closing the win-
dow.
AUTOMATIC SUNROOFThe sunroof will only operate when the ignition
switch is in the ON position.
The automatic sunroof is operational for about
45 seconds, even if the ignition switch is turned
to the ACC, OFF or LOCK position. If the
driver’s door or the front passenger’s door is
opened during this period of about 45 seconds,
power to the sunroof is canceled.Sliding the sunroofTo open the roof, slide the switch to the
side
1. When the roof is tilted up, it will
automatically tilt down and then open.To close the roof, slide the switch to the
side
2.
Sliding position of lid can be chosen according
to sliding amount of switch.
To fully open or close the roof, completely move
the switch to the
1
or
2
side.
Tilting the sunroofTo tilt up, push the
side
3
of the tilt
switch. When the roof is open, it will automati-
cally close and then tilt up. To tilt down the
sunroof, push the
side
4. When the roof
is open, it will automatically close.
Restarting the sunroof sliding switchThe sliding switch will become inoperable after
the battery terminal is disconnected, the electri-
cal supply interrupted and/or some abnormality
detected. Use the following re-set procedure to
return sunroof operation to normal.
1. Keep pushing the tilting switch toward tilt UP.
2. After the lid has tilted up gradually, it will
automatically close all the way, then return to
normal operation.Auto reverse function (When closing
the sunroof)If the control unit detects something caught in
SIC2062
SUNROOF (if so equipped)
2-40
Instruments and controls
06.7.5/Z50-D/V5.0
Page 114 of 345
the sunroof as it moves to the front or tilts down,
the sunroof will immediately open backward or
tilt up.
The auto reverse function can be activated when
the sunroof is closed by automatic operation
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the ACC, OFF or LOCK position.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the sunroof
occurs.
If the auto reverse function malfunctions and
repeats opening or tilting up the sunroof, keep
pushing toward the close position or keep push-
ing the tilt down switch within 5 seconds after it
happens, then the sunroof will fully close gradu-
ally. In this case, make sure nothing is caught in
the sunroof.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-side the vehicle before closing the
sunroof.
Sun shadeOpen or close the sun shade by sliding it
backward or forward.
The shade will open automatically when the
sunroof is opened. However, it must be closed
manually.Comfortable position (
A)
Depending on the driving speed and air recircu-
lating conditions, wind noise may occur when
the sunroof is fully opened. Closing the sunroof
one step toward the front position
A
from full
open will decrease the wind noise.
WARNING
In an accident you could be thrown
from the vehicle through an open
sunroof. Always use seat belts and
child restraints.
Do not allow anyone to stand up or
extend any portion of their body outof the sunroof opening while the ve-
hicle is in motion or while the sun-
roof is closing.
CAUTION
Remove water drops, snow, ice or
sand from the sunroof before open-
ing.
Do not place any heavy object on the
sunroof or surrounding area.If the sunroof does not closeHave a NISSAN dealer check and repair the
sunroof.
Instruments and controls
2-41
06.7.5/Z50-D/V5.0
Page 115 of 345
CEILING LIGHTThe ceiling light has a three-position switch.
When the switch is in the ON position
1, the
light will illuminate.
When the switch is in the OFF position
2, the
light will turn off.
When the switch is in the DOOR position3,
the light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:
The doors are unlocked by the remote key-
less entry system, a key, power door lock
switch or using the Intelligent Key systemwhile all doors are closed.
The driver’s door is opened and then closed
while the key is removed from the ignition
switch or the ignition switch is turned to the
LOCK position (Intelligent Key system).
The key is removed from the ignition switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system) while all
doors are closed.
The ceiling light will turn off while the 30 second
timer is activated, when:
The driver’s door is locked by the remote
keyless entry system, a key or the power door
lock switch.
The ignition switch is turned ON.
When the ceiling light switch or map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear and
vanity mirror lights will automatically turn
off 30 minutes after the ignition switch has
been turned to the ACC or OFF position. To
turn on the light again, turn the ignition
switch to the ONposition.
After the above procedure, the ceiling, map, rear
personal and vanity mirror lights will automati-
cally turn off 30 minutes after the latest operationof the following with the ignition switch in the
ACC or OFF position:
Opening or closing any door
Locking or unlocking with the remote keyless
entry system, a key, the lock-unlock switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system).
Inserting or removing a key from the ignition
switch
These lights will turn on again when any of the
above operations is performed after the lights
have turned off automatically. (The lights will turn
off 30 minutes after the latest operation of the
above as well.)
CAUTION
Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.
Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
SIC2063
INTERIOR LIGHTS2-42
Instruments and controls
06.7.5/Z50-D/V5.0
Page 116 of 345
MAP LIGHTTo turn on the light, push the plastic surface
A
of the light. Push it again to turn off the light.
REAR PERSONAL LIGHTThe rear personal light has a three-position
switch. (
A: DOOR,
B: OFF,
C: ON)
When the switch is in the DOOR position
A,
the light will illuminate when a door is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition
C, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position
B. To turn on the light again, turn
the ignition switch to the ONposition.
CAUTION
Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.
Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
SIC2068
Front
SIC2069
Rear
Instruments and controls
2-43
06.7.5/Z50-D/V5.0
Page 117 of 345
LUGGAGE LIGHTWhen the switch is in the ON position
A, the
light illuminates while the lift gate is opened.
When the lift gate is closed, the light will turn off.
When the switch is in the OFF position
B, the
light will turn off.The light on the vanity mirror will turn on when
the cover on the vanity mirror is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position. To turn on the light again, turn the
ignition switch to the ONposition.The HomeLink
Universal Transceiver provides a
convenient way to consolidate the functions of
up to three individual hand-held transmitters into
one built-in device.
HomeLink
Universal Transceiver:
Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and se-
curity systems.
Is powered by your vehicle’s battery. No
separate batteries are required. If the vehi-
cle’s battery is discharged or is discon-
nected, HomeLink
will retain all program-
ming.
Once the HomeLinkUniversal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink
Universal Transceiver buttons
should be erased for security purposes.
For additional information, refer to “Pro-
gramming HomeLink
” later in this sec-
tion.
SIC2131
SIC2064
VANITY MIRROR LIGHT (if so
equipped)HomeLink
UNIVERSAL
TRANSCEIVER (if so equipped)
2-44
Instruments and controls
06.7.5/Z50-D/V5.0
Page 118 of 345
WARNING
Do not use the HomeLink
Universal
Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-
dards became effective for opener
models manufactured after April 1,
1982). A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.
During programming procedure, your
garage door or security gate may
open or close. Make sure that people
and objects are clear of the garage
door, gate, etc. that you are program-
ming.
Your vehicle’s engine should be
turned off while programming theHomeLink
Universal Transceiver.
PROGRAMMING HomeLinkTo program your HomeLink
Transceiver to op-
erate a garage door, gate, or entry door opener,
home or office lighting, you need to be at the
same location as the device. Note: Garage door
openers (manufactured after 1996) have “rolling
code protection”. To program a garage door
opener equipped with “rolling code protection”;
you will need to use a ladder to get up to the
garage door opener motor to be able to access
the “smart or learn” program button.
1. To begin, push and hold the 2 outer
HomeLink
buttons (to clear the memory)
until the indicator light
A
blinks (after 20
seconds). Release both buttons.
2. Position the end of the hand-held transmitter
1-3 inches away from the HomeLink
sur-
face.
SIC3040
Instruments and controls
2-45
06.7.5/Z50-D/V5.0
Page 119 of 345
3. Using both hands, simultaneously push and
hold both the HomeLink
button you want to
program and the hand-held transmitter but-
ton.
DO NOT release the buttons until step 4 has
been completed.
4. Hold down both buttons until the indicator
light on the HomeLinkflashes, changing
from a “slow blink” to a “rapid blink”. This
could take up to 90 seconds. When the
indicator light blinks rapidly, both buttons
may be released. The rapidly flashing light
indicates successful programming. To acti-
vate the garage door or other programmed
device, push and hold the programmedHomeLink
button - releasing when the de-
vice begins to activate.
5. If the indicator light on the HomeLink
blinks
rapidly for two seconds and then turns solid,
HomeLink
has picked up a “rolling code”
garage door opener signal. You will need to
proceed with the next steps to train the
HomeLinkto complete the programming
which may require a ladder and another
person for convenience.
6. Push and release the training button located
on the garage door opener’s motor to acti-
vate the “training mode”. This button is usu-
ally located near the antenna wire that hangs
down from the motor. If the wire originates
from under a light lens, you will need to
remove the lens to access the training button.
NOTE:
Once you have pushed and released the
training button on the garage door open-
er’s motor and the “training light” is lit, you
have 30 seconds in which to perform step
7. Use the help of a second person for
convenience to assist when performing
this step.
7. Quickly within 30 seconds of pushing and
releasing the garage door opener training
button, firmly push and release theHomeLink
button you have just pro-
grammed. Push and release the HomeLink
button up to three times to complete the
training.
8. Your HomeLink
button should now be pro-
grammed. (To program the remaining
HomeLink
buttons for additional door or
gate openers, follow steps 2 through 8 only.)
NOTE:
Do not repeat step one unless you want to
“clear” all previously programmed
HomeLinkbuttons).
If you have any questions or are having difficulty
programming your HomeLink
buttons, please
refer to the HomeLinkwebsite at:
www.homelink.com or call 1-800-355-3515.
PROGRAMMING HomeLink
FOR
CANADIAN CUSTOMERS
Prior to 1992, D.O.C. regulations required hand-
held transmitters to stop transmitting after 2
seconds. To program your hand-held transmitter
to HomeLink
, continue to push and hold the
HomeLinkbutton (note steps 2 through 4
under “Programming HomeLink
”) while you
push and re-push (“cycle”) your hand-held
transmitter every 2 seconds until the indicator
SIC3041
2-46
Instruments and controls
06.7.5/Z50-D/V5.0
Page 120 of 345
light flashes rapidly (indicating successful pro-
gramming).
NOTE:
If programming a garage door opener, etc.,
it is advised to unplug the device during
the “cycling” process to prevent possible
damage to the garage door opener compo-
nents.OPERATING THE HomeLinkUNIVERSAL TRANSCEIVERThe HomeLink
Universal Transceiver (once
programmed) may now be used to activate the
garage door, etc. To operate, simply push the
appropriate programmed HomeLink
Universal
Transceiver button. The red indicator light will
illuminate while the signal is being transmitted.
PROGRAMMING TROUBLE
DIAGNOSISIf the HomeLink
does not quickly learn the
hand-held transmitter information:
replace the hand-held transmitter batteries
with new batteries.
position the hand-held transmitter with its
battery area facing away from the HomeLink
surface.push and hold both the HomeLink
and
hand-held transmitter buttons without inter-
ruption.
position the hand-held transmitter 2 to 5
inches (50 to 127 mm) away from the
HomeLink
surface. Hold the transmitter in
that position for up to 15 seconds. If
HomeLinkis not programmed within that
time, try holding the transmitter in another
position - keeping the indicator light in view at
all times.
If you continue to have programming difficulties,
please contact the NISSAN Consumer Affairs
Department. The phone numbers are located in
the Foreword of this Owner’s Manual.
CLEARING THE PROGRAMMED
INFORMATIONIndividual buttons cannot be cleared, however to
clear all programming, push and hold the two
outside buttons and release when the indicator
light begins to flash (approximately 20 seconds).REPROGRAMMING A SINGLE
HomeLink
BUTTON
To reprogram a HomeLink
Universal Trans-
ceiver button, complete the following.
1. Push and hold the desired HomeLink
but-ton.Do notrelease the button until step 4
has been completed.
2. When the indicator light begins to flash
slowly (after 20 seconds), position the hand-
held transmitter 2 to 5 inches (50 to 127 mm)
away from the HomeLink
surface.
3. Push and hold the hand-held transmitter but-
ton.
4. The HomeLink
indicator light will flash, first
slowly and then rapidly. When the indicator
light begins to flash rapidly, release both
buttons.
The HomeLinkUniversal Transceiver button
has now been reprogrammed. The new device
can be activated by pushing the HomeLink
button that was just programmed. This proce-
dure will not affect any other programmed
HomeLink
buttons.
IF YOUR VEHICLE IS STOLENIf your vehicle is stolen, you should change the
codes of any non-rolling code device that has
been programmed into HomeLink
. Consult the
Owner’s Manual of each device or call the
manufacturer or dealer of those devices for
additional information.
When your vehicle is recovered, you will
need to reprogram the HomeLink
Univer-
Instruments and controls
2-47
06.7.5/Z50-D/V5.0
