Finish setup.
If you push the “BACK” button after the setup is
completed, the setup will start over, and the
display will return to the climate control or Audio
mode, and Navigation screen.SETTING UP THE START-UP
SCREENWhen you turn the ignition switch to ACC, the
SYSTEM START-UP warning is displayed on
the screen. Read the warning and select the
“I AGREE” (English) or “ENTER” (Franc¸ ais) key
then push the “ENTER” button.
If you do not push the “ENTER” button, this
system will not proceed to the next step display.
If you do not push the button or select the
screen key for more than 1 minute on the TRIP,
SETTING or START-UP screen, the screen will
change to TRIP screen automatically.
To proceed to the next step, refer to the separate
Navigation System Owner’s Manual.
HOW TO USE THE “TRIP” BUTTONWhen the “TRIP” button is pushed, the following
modes will display on the screen.
Warning message (if there are any)→TRIP 1→
TRIP 2→FUEL ECONOMY→MAINTE-
NANCE.
“TRIP” informationElapsed Time, Driving Distance and Average
Speed will be displayed.
To reset, select the “Reset” key using the joy-
stick and push the “ENTER” button or push the
“TRIP” button for more than approximately 1.5
seconds.
SAA1317
4-12
Display screen, heater, air conditioner and audio systems
06.7.5/Z50-D/V5.0
Page 172 of 345
“FUEL ECONOMY” informationAverage Fuel Economy and Distance to Empty
will be displayed for reference.
To reset, select the “Reset” key using the joy-
stick and push the “ENTER” button or push the
“TRIP” button for more than approximately 1.5
seconds.
“MAINTENANCE” informationYou can set the engine oil and the tire rotation
interval.
And the tire pressure will appear on the screen
(if the tire pressure system is equipped).
To display the setting of the maintenance inter-
val, select the “Engine Oil” or “Tire Rotation” key
using the joystick and push the “ENTER” button.To set the maintenance interval, select the
“Maintenance Schedule” key by using the joy-
stick and move the joystick to the right or left.
To reset the maintenance interval, select the
“Reset” key using the joystick and push the
“ENTER” button.
To display the MAINTENANCE NOTICE, auto-
matically when setting trip distance is reached,
select the “Display Maintenance Notification”
key and push the “ENTER” button.
SAA1318
SAA1319
SAA1320
Display screen, heater, air conditioner and audio systems
4-13
06.7.5/Z50-D/V5.0
Page 173 of 345
MAINTENANCE NOTICEThe “MAINTENANCE NOTICE” screen (“EN-
GINE OIL” or “TIRE ROTATION”) will be auto-
matically displayed as shown when both of the
following conditions are met:
the vehicle is driven the set distance and the
ignition switch is turned OFF.
the ignition key is turned ON the next time the
vehicle will be driven.
To return to the previous display after the
“MAINTENANCE NOTICE” screen is displayed,
push the “BACK” button.The “MAINTENANCE NOTICE” screen displays
each time the key is turned ON until one of the
following conditions are met:
“RESET” is selected.
“Display Maintenance Notification” is set
OFF.
the maintenance interval is set again.
Tire pressure information (if so
equipped)To view “TIRE PRESSURE” information, push
the “TRIP” button repeatedly until the “MAINTE-
NANCE” screen is displayed. Select “TIRE
PRESSURE” using the joystick and push the
“ENTER” button.
Pressure indication in ** psi on the screen
indicates that the pressure is being measured.
After a few driving trips, the pressure for each
tire will be displayed randomly.
The order of tire pressure figures displayed on
the screen does not correspond with the actual
SAA1354
SAA1321
4-14
Display screen, heater, air conditioner and audio systems
06.7.5/Z50-D/V5.0
Page 174 of 345
order of the tire position.
Tire pressure rises and falls depending on the
heat caused by the vehicle’s traveling condition
and the temperature.
In case of low tire pressure, a message is
displayed on the screen:
FLAT TIRE — low tire air pressure.
WARNING
When a spare tire is mounted or a
wheel is replaced, tire pressure will
not be indicated, the TPMS will not
function and the low tire pressure
warning light will flash for approxi-
mately 1 minute and remain on after
the 1 minute. Contact your NISSAN
dealer as soon as possible for tire
replacement and/or system reset-
ting.
Replacing tires with those not origi-
nally specified by NISSAN could af-
fect the proper operation of the
TPMS.* — Refer to the separate Navigation System
Owner’s Manual.
HOW TO USE THE “SETTING”
BUTTONThe SETTINGS screen will appear when the
“SETTING” button is pushed.
“Display” settingsThe DISPLAY SETTINGS screen will appear
when selecting the “Display” key and pushing
the “ENTER” button.
Brightness/Contrast:
To adjust the brightness and contrast of the
screen, select the “Brightness/Contrast” key
and push the “ENTER” button. Then you can
adjust the brightness to Darker or Brighter, the
contrast to Lower or Higher using the joystick.
SAA1322
SAA1551
Display screen, heater, air conditioner and audio systems
4-15
06.7.5/Z50-D/V5.0
Page 175 of 345
Display Off:
To turn off the screen, push the “SETTING”
button and select the “Display” key and “Display
Off” key. The indicator of the “Display Off” will
turn on. When any mode button is pushed with
the screen off, the screen turns on for further
operation. The screen will turn off automatically 5
seconds after the operation is finished on the
map display in the Audio, HVAC (Heater and air
conditioner).
To turn on the screen, push the “SETTING”
button and select the “Display” key and “Display
Off” key, then set the screen to on by pushing
the “ENTER” button.
Setting Audio or HVAC display:
Choose the “Audio” or “HVAC” (Heater and air
conditioner) key to be displayed at the bottom,
by using the joystick. The audio or HVAC
(heater, air conditioner) setting condition will
normally appear on the screen.
To return to the setting screen, push the
“SETTING” button or “BACK” button.
Vehicle electronic systemsThe VEHICLE ELECTRONIC SYSTEMS screen
will appear when selecting the “Vehicle Elec-
tronic Systems” key with the joystick and push-
ing the “ENTER” button.
You can set the various electronic systems
operating conditions.
To set an operating condition, select the appli-
cable item using the joystick, and push the
“ENTER” button.
The indicator light alternately turns on and off
each time the “ENTER” button is pushed.
Indicator light is illuminated. — ONIndicator light is not illuminated. — OFF
Selective door unlock:
This key can switch the unlock doors of the 1st
unlocking operation as follows:
ON (Only the driver side door)←→OFF (All the
doors)
SAA1324
SAA1552
4-16
Display screen, heater, air conditioner and audio systems
06.7.5/Z50-D/V5.0
Page 176 of 345
Keyless Remote Response — Horn*:
This key changes the horn chirp mode that
occurs when pushing the LOCK button on the
keyfobor the Intelligent Key.
Keyless Remote Response — Lights*:
This key changes the hazard indicator flash
mode that occurs when pushing the LOCK or
UNLOCK button on the keyfob or the Intelligent
Key.
* Even if you change the horn chirp or the
hazard flash with the keyfob or the Intel-
ligent Key, the change may not be re-
flected in the display. Use the keyfob orthe Intelligent Key to return to the previ-
ous mode.
Auto Re-Lock Time:
The length of the auto door re-lock time can be
set. Select the “Auto Re-Lock Time” key, then
move the joystick and push the ENTER button to
adjust the time.
Sensitivity of Automatic Headlights:
Automatic light illumination can be set as de-
sired.
Select the “Sensitivity of Automatic Headlights”
key, then move the joystick to the left (lower) or
right (higher).
Automatic Headlights Off Delay:
You can control how long it takes the automatic
turn off timer to extinguish the headlights in the
AUTO position.
Select the “Automatic Headlights Off Delay” key,
then move the joystick to the left or right to
adjust the timer.
Speed Dependent Wiper:
When this item is turned to on, the wiper interval
is adjusted automatically according to the ve-
hicle speed.Intelligent Key Lock Response — Sound
(if so equipped):
The sound pattern of the Intelligent request
switch operation can be set as desired. Select
the “Intelligent Key lock response — Sound” key,
then push the ENTER button to change the
sound pattern.
Intelligent Key Unlock Response — Beep
Sound (if so equipped):
The beep sounds when unlocking door with the
Intelligent request switch can be turned on or off.
Return All Settings to Default:
When this key is selected and turned on using
the “ENTER” button, all settings made by
VEHICLE ELECTRONICS will return to the initial
conditions.
SAA1553
Display screen, heater, air conditioner and audio systems
4-17
06.7.5/Z50-D/V5.0
Page 177 of 345
System settingsLanguage/Unit:
The LANGUAGE/UNIT screen will appear when
selecting the “Language/Unit” key and pushing
the “ENTER” button.
Language: English or French
Unit: US — Mile, °F, MPG
Metric — km, °C, L/100 km
You can select the language and unit using the
joystick and “ENTER” button.Clock:
Adjusting the time
Select the “Hours” or “Minutes” key and move
the joystick to the right or left to adjust the time.
The time will change step by step.
After completion of the setting, push the “BACK”
button.
Setting daylight saving time
Turn ON or OFF daylight saving time.
Every time the “Daylight Saving Time” key is
selected, the light turns ON and OFF alternately.ON: The displayed time advances by one hour.
OFF: The current time is displayed.
Adjusting the time to the GPS
Select the “Auto Adjust” key.
The time will be reset to the GPS time.
SAA1327
SAA1328
4-18
Display screen, heater, air conditioner and audio systems
06.7.5/Z50-D/V5.0
Page 178 of 345
Selecting the time zone
1. Select the “Select Time Zone” key.
The TIME ZONE screen will appear.
2. Select one of the following zones depending
on the current location.
“Pacific” zone
“Mountain” zone
“Central” zone
“Eastern” zone
“Atlantic” zone“Newfoundland” zone
After selection, the CLOCK SETTINGS screen
will appear.
The GPS time (manual time) corresponding to
the selected zone will be displayed.
“Pacific” zone has been set as the initial (default)
setting.
Beep setting:
When Beep setting is on (indicator light on), a
beep will sound if any audio button is pushed.
“DAY/NIGHT” BUTTONPushing the “DAY/NIGHT” button will change
the display to the DAY or NIGHT display. Then,
adjust the brightness moving the joystick right or
left.
If no operation is done within 10 seconds, or if
the “BACK” button is pushed, the display will
return to the previous display.
Pushing the “DAY/NIGHT” button for more than
approximately 2 seconds will turn the display off
and on.When the selector lever is shifted into the R
(Reverse) position, the monitor display shows
view to the rear of the vehicle.
The system is designed as an aid to the driver in
detecting large stationary objects to help avoid
damaging the vehicle. The system will not detect
small objects below the bumper and may not
detect objects close to the bumper or on the
ground.
WARNING
The rear view camera is a conve-
nience but it is not a substitute for
proper backing. Always turn and
check that it is safe to do so before
backing up. Always back up slowly.
Objects viewed in the RearView
Monitor differ from actual distance
because a wide-angle lens is used.
Objects in the RearView Monitor will
appear visually opposite like ones
viewed in the inside and outside mir-
rors.
Make sure that the lift gate is se-
curely closed when backing up.
SAA1329
REARVIEW MONITOR (if so
equipped)
Display screen, heater, air conditioner and audio systems
4-19
06.7.5/Z50-D/V5.0
Page 179 of 345
Underneath the bumper and the cor-
ner areas of the bumper cannot be
viewed on the RearView Monitor be-
cause of its monitoring range limita-
tion.
Do not put anything on the rear view
camera. The rear view camera is in-
stalled above the license plate.
When washing the vehicle with high-
pressure water, be sure not to spray
it around the camera. Otherwise, wa-
ter may enter the camera unit caus-
ing water condensation on the lens, a
malfunction, fire or an electric shock.
Do not strike the camera. It is a pre-
cision instrument. Otherwise, it may
malfunction or cause damage result-
ing in a fire or an electric shock.
CAUTION
There is a plastic cover over the camera.
Do not scratch the cover when cleaning
dirt or snow from it.
HOW TO READ THE DISPLAYED
LINESLines which indicate the vehicle clearance and
distances to objects with reference to the
bumper line
A
are displayed on the monitor.
They are indicated as reference distances to
objects. Displayed lines indicate distances 1.5
feet (red)
1, 3 feet (yellow)
2, 7 feet (green)
3and 10 feet (green)
4from the lower part of
the bumper line
A.
The vehicle clearance lines are wider than
the actual clearance.
REARVIEW MONITOR SETTING
WARNING
Do not adjust the Brightness, Contrast,
Tint and Color of the RearView Monitor
while the vehicle is moving. Make sure
the parking brake is firmly applied and
the engine is not running.
To adjust the Brightness, Contrast, Tint and
Color of the RearView Monitor, push the “SET-
TING” button with the RearView Monitor on,
select the item key and adjust the level using the
joystick.OPERATING TIPSWhen the selector lever is shifted to R, the
monitor screen automatically changes to the
RearView Monitor mode. However, the radio
can be heard.
It may take some time until the RearView
Monitor is displayed after the selector lever
has been shifted to R. Objects may be dis-
torted momentarily until the RearView Moni-
tor screen is displayed completely. When the
selector lever is returned to a position other
than R, it may take some time until the screen
SAA0889
4-20
Display screen, heater, air conditioner and audio systems
06.7.5/Z50-D/V5.0
Page 180 of 345
changes. Objects on the screen may be
distorted until they are completely displayed.
When the temperature is extremely high or
low, the screen may not clearly display ob-
jects. This is not a malfunction.
When strong light directly enters the camera,
objects may not be displayed clearly.
Vertical lines may be seen in objects on the
screen. This is due to strong reflected light
from the bumper. This is not a malfunction.
The screen may flicker under fluorescent
light. This is not a malfunction.
The colors of objects on the RearView Moni-
tor may differ somewhat from those of the
actual object.
When the contrast of objects is low at night,
pushing the “ENTER” button may not change
the brightness.
Objects on the monitor may not be clear in a
dark place or at night.
If dirt, rain or snow attaches to the camera,
the RearView Monitor may not clearly display
objects. Clean the camera.
Do not use alcohol, benzine or thinner to
clean the camera. This will cause discolora-
tion. To clean the camera, wipe with a clothdampened with diluted mild cleaning agent
and then wipe with a dry cloth.
Do not damage the camera as the monitor
screen may be adversely affected.
Do not use body wax on the camera window.
Wipe off any wax with a clean cloth damp-
ened with mild detergent diluted with water.
SAA1064
Center ventilators
SAA1065A
Side ventilators
VENTILATORS
Display screen, heater, air conditioner and audio systems
4-21
06.7.5/Z50-D/V5.0
