DTC P1762 DIRECT CLUTCH SOLENOID VALVE
AT-143
D
E
F
G
H
I
J
K
L
MA
B
AT
Diagnostic ProcedureECS00G0J
1.CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Start engine.
4. Read the value of “D/C SOLENOID” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer toAT- 1 6 4 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following.
lA/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace control valve with TCM. Refer toAT- 2 1 8 , "Control Valve With TCM and A/T Fluid Temper-
ature Sensor 2".
NG >> Repair or replace damaged parts.
4.CHECK DTC
PerformAT- 1 4 2 , "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.
Item name ConditionDisplay value
(Approx.)
D/C SOLENOIDDirect clutch disengaged. Refer toAT- 1 7
. 0.6 - 0.8 A
Direct clutch engaged. Refer toAT- 1 7
.0-0.05ASCIA4793E

AT-144
DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION
DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION
PFP:31940
DescriptionECS00G0K
lDirect clutch solenoid valve is controlled by TCM in response to signals sent from PNP switch, vehicle
speed sensor and accelerator pedal position sensor. Gears will then be shifted to the optimum position.
lThis is not only caused by electrical malfunction (circuits open or shorted) but also by mechanical mal-
function such as control valve sticking, improper solenoid valve operation.
CONSULT-II Reference ValueECS00G0L
On Board Diagnosis LogicECS00G0M
Diagnostic trouble code “P1764 D/C SOLENOID FNCTN” with CONSULT-II or 2nd judgement flicker without
CONSULT-II is detected under the following conditions.
lWhen TCM detects that actual gear ratio is irregular, and relation between gear position and condition of
ATF pressure switch 5 is irregular during depressing accelerator pedal. (Other than during shift change)
lWhen TCM detects that relation between gear position and condition of ATF pressure switch 5 is irregular
during releasing accelerator pedal. (Other than during shift change)
Possible CauseECS00G0N
lHarness or connectors
(The solenoid and switch circuits are open or shorted.)
lDirect clutch solenoid valve
lATF pressure switch 5
DTC Confirmation ProcedureECS00G0O
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “1”
“2” (D/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
3. Perform step 2 again.
4. Turn ignition switch OFF, then perform step 1 to 3 again.
5. Check “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II. If DTC (P1764) is detected, go toAT- 1 4 5 , "
Diagnostic Procedure".
If DTC (P1762) is detected, go toAT- 1 4 3 , "
Diagnostic Procedure".
If DTC (P1845) is detected, go toAT- 1 6 1 , "
Diagnostic Procedure".
Item name Condition Display value (Approx.)
D/C SOLENOIDDirect clutch disengaged. Refer toAT- 1 7
. 0.6 - 0.8 A
Direct clutch engaged. Refer toAT- 1 7
.0-0.05A
AT F P R E S S W 5Direct clutch engaged. Refer toAT- 1 7
.ON
Direct clutch disengaged. Refer toAT- 1 7
.OFF
BCIA0031E

DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION
AT-145
D
E
F
G
H
I
J
K
L
MA
B
AT
WITHOUT CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
Accelerator opening: 1.5/8 - 2.0/8
Selector lever position: “D” position
Gear position: “1”
“2” (D/C ON/OFF)
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
3. Perform step 2 again.
4. Turn ignition switch OFF position, then perform step 1 to 3 again.
5. Perform self-diagnosis. Refer toAT-89, "
Diagnostic Procedure Without CONSULT-II".
6. If DTC is detected, go toAT- 1 4 5 , "
Diagnostic Procedure".
Diagnostic ProcedureECS00G0P
1.CHECK INPUT SIGNALS
With CONSULT-II
1. Start engine.
2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode
for “A/T” with CONSULT-II.
3. Drive vehicle in the “D” position (1st
2nd gear), and confirm
the display actuation of “ATF PRES SW 5” and electrical current
value of “D/C SOLENOID”.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer toAT- 1 6 4 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following.
lA/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace control valve with TCM. Refer toAT- 2 1 8 , "Control Valve With TCM and A/T Fluid Temper-
ature Sensor 2".
NG >> Repair or replace damaged parts.
Item name ConditionDisplay value
(Approx.)
D/C SOLENOIDDirect clutch disengaged. Refer toAT- 1 7
. 0.6 - 0.8 A
Direct clutch engaged. Refer toAT- 1 7
.0-0.05A
AT F P R E S S W 5Direct clutch engaged. Refer toAT- 1 7
.ON
Direct clutch disengaged. Refer toAT- 1 7
.OFF
SCIA4797E

AT-146
DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION
4.CHECK DTC
PerformAT- 1 4 4 , "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.

DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
AT-147
D
E
F
G
H
I
J
K
L
MA
B
AT
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVEPFP:31940
DescriptionECS00G0Q
High and low reverse clutch solenoid valve is controlled by TCM in response to signals sent from PNP switch,
vehicle speed sensor and accelerator pedal position sensor. Gears will then be shifted to the optimum posi-
tion.
CONSULT-II Reference ValueECS00G0R
On Board Diagnosis LogicECS00G0S
Diagnostic trouble code “P1767 HLR/C SOL/CIRC” with CONSULT-II or 8th judgement flicker without CON-
SULT-II is detected under the following conditions.
lWhen TCM detects an improper voltage drop when it tries to operate the solenoid valve.
lWhen TCM detects as irregular by comparing target value with monitor value.
Possible CauseECS00G0T
lHarness or connectors
(The solenoid circuit is open or shorted.)
lHigh and low reverse clutch solenoid valve
DTC Confirmation ProcedureECS00G0U
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5
consecutive seconds.
ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “2”
“3” (HLR/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions required for this test.
6. If DTC is detected, go toAT- 1 4 8 , "
Diagnostic Procedure".
WITHOUT CONSULT-II
1. Start engine.
2. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds.
Accelerator opening: 1.5/8 - 2.0/8
Selector lever position: “D” position
Gear position: “2”
“3” (HLR/C ON/OFF)
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
3. Perform self-diagnosis. Refer toAT-89, "
Diagnostic Procedure Without CONSULT-II".
4. If DTC is detected, go toAT- 1 4 8 , "
Diagnostic Procedure".
Item name Condition Display value (Approx.)
HLR/C SOLHigh and low reverse clutch disengaged. Refer toAT- 1 7
.0.6-0.8A
High and low reverse clutch engaged. Refer toAT- 1 7
.0-0.05A
BCIA0031E

AT-148
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
Diagnostic Procedure
ECS00G0V
1.CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Start engine.
4. Read the value of “HLR/C SOLENOID” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer toAT- 1 6 4 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following.
lA/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace control valve with TCM. Refer toAT- 2 1 8 , "Control Valve With TCM and A/T Fluid Temper-
ature Sensor 2".
NG >> Repair or replace damaged parts.
4.CHECK DTC
PerformAT- 1 4 7 , "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.
Item name ConditionDisplay value
(Approx.)
HLR/C SOLHigh and low reverse clutch disengaged.
Refer toAT- 1 7
.0.6 - 0.8 A
High and low reverse clutch engaged.
Refer toAT- 1 7
.0 - 0.05 A
SCIA4793E

DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
AT-149
D
E
F
G
H
I
J
K
L
MA
B
AT
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
PFP:31940
DescriptionECS00G0W
lHigh and low reverse clutch solenoid valve is controlled by TCM in response to signals sent from PNP
switch, vehicle speed sensor and accelerator pedal position sensor. Gears will then be shifted to the opti-
mum position.
lThis is not only caused by electrical malfunction (circuits open or shorted) but also by mechanical mal-
function such as control valve sticking, improper solenoid valve operation.
CONSULT-II Reference ValueECS00G0X
On Board Diagnosis LogicECS00G0Y
Diagnostic trouble code “P1769 HLR/C SOL FNCTN” with CONSULT-II or 8th judgement flicker without CON-
SULT-II is detected under the following conditions.
lWhen TCM detects that actual gear ratio is irregular, and relation between gear position and condition of
ATF pressure switch 6 is irregular during depressing accelerator pedal. (Other than during shift change)
lWhen TCM detects that relation between gear position and condition of ATF pressure switch 6 is irregular
during releasing accelerator pedal. (Other than during shift change)
Possible CauseECS00G0Z
lHarness or connectors
(The solenoid and switch circuits are open or shorted.)
lHigh and low reverse clutch solenoid valve
lATFpressureswitch6
DTC Confirmation ProcedureECS00G10
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “2”
“3” (HLR/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
3. Perform step 2 again.
4. Turn ignition switch OFF, then perform step 1 to 3 again.
5. Check “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II. If DTC (P1769) is detected, go toAT- 1 5 0 , "
Diagnostic Procedure".
If DTC (P1767) is detected, go toAT- 1 4 8 , "
Diagnostic Procedure".
If DTC (P1846) is detected, go toAT- 1 6 3 , "
Diagnostic Procedure".
Item name Condition Display value (Approx.)
HLR/C SOLHigh and low reverse clutch disengaged. Refer toAT- 1 7
.0.6-0.8A
High and low reverse clutch engaged. Refer toAT- 1 7
.0-0.05A
AT F P R E S S W 6High and low reverse clutch engaged. Refer toAT- 1 7
.ON
High and low reverse clutch disengaged. Refer toAT- 1 7
.OFF
BCIA0031E

AT-150
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
WITHOUT CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
Accelerator opening: 1.5/8 - 2.0/8
Selector lever position: “D” position
Gear position: “2”
“3” (HLR/C ON/OFF)
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
3. Perform step 2 again.
4. Turn ignition switch OFF position, then perform step 1 to 3 again.
5. Perform self-diagnosis. Refer toAT-89, "
Diagnostic Procedure Without CONSULT-II".
6. If DTC is detected, go toAT- 1 5 0 , "
Diagnostic Procedure".
Diagnostic ProcedureECS00G11
1.CHECK INPUT SIGNALS
With CONSULT-II
1. Start engine.
2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode
for “A/T” with CONSULT-II.
3. Drive vehicle in the “D” position (2nd
3rd gear), and confirm
the ON/OFF actuation of “ATF PRES SW 6” and electrical cur-
rent value of “HLR/C SOL”.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer toAT- 1 6 4 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following.
lA/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace control valve with TCM. Refer toAT- 2 1 8 , "Control Valve With TCM and A/T Fluid Temper-
ature Sensor 2".
NG >> Repair or replace damaged parts.
Item name ConditionDisplay value
(Approx.)
HLR/C SOLHigh and low reverse clutch disengaged.
Refer toAT- 1 7
.0.6 - 0.8 A
High and low reverse clutch engaged.
Refer toAT- 1 7
.0 - 0.05 A
AT F P R E S S W 6High and low reverse clutch engaged.
Refer toAT- 1 7
.ON
High and low reverse clutch disengaged.
Refer toAT- 1 7
.OFF
SCIA4798E

DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
AT-151
D
E
F
G
H
I
J
K
L
MA
B
AT
4.CHECK DTC
PerformAT- 1 4 9 , "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.

AT-152
DTC P1772 LOW COAST BRAKE SOLENOID VALVE
DTC P1772 LOW COAST BRAKE SOLENOID VALVE
PFP:31940
DescriptionECS00G12
Low coast brake solenoid valve is turned ON or OFF by TCM in response to signals sent from PNP switch,
vehicle speed sensor and accelerator pedal position sensor. Gears will then be shifted to the optimum posi-
tion.
CONSULT-II Reference ValueECS00G13
On Board Diagnosis LogicECS00G14
Diagnostic trouble code “P1772 LC/B SOLENOID/CIRC” with CONSULT-II or 7th judgement flicker without
CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid
valve.
Possible CauseECS00G15
lHarness or connectors
(The solenoid circuit is open or shorted.)
lLow coast brake solenoid valve
DTC Confirmation ProcedureECS00G16
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5
consecutive seconds.
SLCTLVRPOSI:“1”or“2”position
GEAR: “1” or “2” (LC/B ON/OFF)
6. If DTC is detected, go toAT- 1 5 3 , "
Diagnostic Procedure".
WITHOUT CONSULT-II
1. Start engine.
2. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds.
Selector lever position: “1” or “2” position
Gear position: “1” or “2” (LC/B ON/OFF)
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
3. Perform self-diagnosis. Refer toAT-89, "
Diagnostic Procedure Without CONSULT-II".
4. If DTC is detected, go toAT- 1 5 3 , "
Diagnostic Procedure".
Item name Condition Display value
ON OFF SOLLow coast brake engaged. Refer toAT- 1 7
.ON
Low coast brake disengaged. Refer toAT- 1 7
.OFF
BCIA0031E
