NISSAN NOTE 2016 Service Repair Manual

PCS-28
< DTC/CIRCUIT DIAGNOSIS >[IPDM E/R]
B2099 IGNITION RELAY OFF STUCK
B2099 IGNITION RELAY OFF STUCK
DTC LogicINFOID:0000000012433282
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B2099 displayed?
YES >> Refer to PCS-28, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012433283
1. PERFORM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is display history of DTC B2099 CRNT?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Refer to GI-42, "
Intermittent Incident".
CONSULT Display DTC Detection Condition Possible Cause
IGN RELAY OFF
[B2099] The ignition relay OFF is detected for 1 second at
ignition switch ON
(CPU monitors the status at the contact and exci-
tation coil circuits of the ignition relay inside it)
IPDM E/R
Revision: August 2015
2016 Versa Note

cardiagn.com

PCS
POWER SUPPLY AND GROUND CIRCUITPCS-29
< DTC/CIRCUIT DIAGNOSIS > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000012433284
Regarding Wiring Diagram information, refer to
PCS-21, "Wiring Diagram".
1. CHECK FUSE AND FUSIBLE LINKS
Check that the following IPDM E/R fuse or fusible links are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2. CHECK BATTERY POWER SUPPLY CIRCUIT
1. Disconnect IPDM E/R connector E42.
2. Check voltage between IPDM E/R connector E42 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. CHECK GROUND CIRCUIT
1. Disconnect IPDM E/R connectors E45, E46 and E47.
2. Check continuity between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connectors.
Terminal No. Signal nameFuse and fusible link Nos.
1 Battery power supply A (120A), E (80A)
2 B (60A)
IPDM E/R
GroundVo l ta g e
(Approx.)
Connector Terminal
E42 1
—Battery voltage
2
IPDM E/R
GroundContinuity
Connector Terminal
E45 19
Ye s
E46 60
E47 89
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS-30
< REMOVAL AND INSTALLATION >[IPDM E/R]
IPDM E/R
REMOVAL AND INSTALLATION
IPDM E/R
Exploded ViewINFOID:0000000012433285
Removal and InstallationINFOID:0000000012433286
CAUTION:
IPDM E/R integrated relays are not serviceab
le and must not be removed from unit.
REMOVAL
1. Disconnect the negative battery terminal. Refer to PG-70, "Removal and Installation (Battery)".
2. Release pawls on IPDM E/R cover (1) and remove. :Pawl
1.IPDM E/R Front
AWMIA1423ZZ
ALMIA0654ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS
IPDM E/RPCS-31
< REMOVAL AND INSTALLATION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
3. Release pawls, then lift IPDM E/R (1) as shown and position
aside.
:Pawl
4. Disconnect the harness connectors from the IPDM E/R (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALMIA0655ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS-32
< PRECAUTION >[POWER DISTRIBUTION SYSTEM]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012433287
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS
COMPONENT PARTSPCS-33
< SYSTEM DESCRIPTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012433288
AWMIA1438ZZ
No.
Component Description
1. Accessory relay-2 • Accessory relay-2 is controlled by BCM.
• Accessory relay-2 supplies accessory power supply or ignition switch ACC signal to each ECU
when ignition switch is turned to ACC or ON.
• BCM compares status of accessory relay-2 control signal, and ignition switch position judged
by BCM.
2. BCM • BCM controls power distribution system.
• BCM judges ignition switch position by push-button ignition switch (push switch) and vehicle
condition.
• BCM checks ignition switch position internally.
3. Push-button ignition
switch Push-button ignition switch (push switch) is pressed, and transmits status signal to BCM and
IPDM E/R.
4. IPDM E/R • IPDM E/R detects push-button ignition switch (push switch) status, and transmits push-button
ignition switch status signal (CAN) to BCM.
• IPDM E/R receives ignition relay-1 (IPDM E/R) control signal and ignition switch ON signal
(CAN) from BCM, and controls igniti on relay-1 (built into IPDM E/R)
5. Blower relay (in fuse
block) • Blower relay is controlled by BCM.
• Blower relay supplies ignition switch ON power supply or ignition switch ON signal to air con-
ditioning system when ignition switch is turned ON.
• BCM compares status of blower relay control signal and ignition switch position judged by BCM.
6. Accessory relay-1 (in
fuse block) • Accessory relay-1 is controlled by BCM.
• Accessory relay-1 supplies accessory power supply or ignition switch ACC signal to each ECU
when ignition switch is turned ACC or ON.
• BCM compares status of accessory relay-1 control signal, and ignition switch position judged by BCM.
7. Ignition relay-2 (in fuse
block) • Ignition relay-2 is controlled by BCM.
• Ignition relay-2 supplies ignition switch ON power supply or ignition switch ON signal to each
ECU and system when ignition switch is turned ON.
• BCM compares status of ignition relay-2 control signal and ignition switch position judged by
BCM.
• BCM monitors ignition relay-2 operating status by ignition relay feedback signal.
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS-34
< SYSTEM DESCRIPTION >[POWER DISTRIBUTION SYSTEM]
SYSTEM
SYSTEM
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM
: System DescriptionINFOID:0000000012433289
SYSTEM DIAGRAM
SYSTEM DESCRIPTION
• PDS (POWER DISTRIBUTION SYSTEM) is the system that BCM contro ls with the operation of the push-
button ignition switch and performs the power distribution to each power circuit. This system is used instead
of the mechanical power supply changing mechanism wi th the operation of the conventional key cylinder.
• The push-button ignition switch can be operated when Intelligent Key is in the following condition:
- Intelligent Key is in the detection area of the inside key antenna.
- Intelligent Key backside is contacted to push-button ignition switch.
• The push-button ignition switch operation is input to BCM as a signal. BCM changes the power supply posi-
tion according to the status and operates the following relays to supply power to each power circuit:
- Ignition relay-1
- Ignition relay-2
- Accessory relay-1
- Accessory relay-2
- Blower motor relay NOTE:
The engine switch operation changes due to the conditions of brake pedal, selector lever and vehicle speed.
• The power supply position can be confirmed with the light ing of the indicators in the push-button ignition
switch.
IGNITION BATTERY SAVER SYSTEM
When all the following conditions are met for a period of time, the battery saver system will turn off the power
supply (ignition switch ON/ACC → OFF) to prevent battery discharge.
• Ignition switch is in the ACC or ON position
• Turn signal lamp is not in operation
• Selector lever is in the P (park) position
Reset Condition of Igniti on Battery Saver System
If any of the following conditions are met, the battery saver system is released.
• Ignition switch is not in the ACC or ON position
• Turn signal lamp is in operation
• Selector lever is not in the P (park) position
NOTE:
The ignition battery saver system can be temporarily di sabled, without using CONSULT, to prevent it from
functioning when performing trouble diagnosis. Refer to PCS-53, "
Work Procedure".
POWER SUPPLY POSITION CHANGE TABLE BY PUSH-BUTTON IGNITION SWITCH OPERA-
AWMIA3150GB
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS
SYSTEMPCS-35
< SYSTEM DESCRIPTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
TION
The power supply position changing operation can be performed with the following operations.
NOTE:
• When an Intelligent Key is within the detection area of inside key antenna and when Intelligent Key backside
is contacted to push-button ignition switch, it is equivalent to the operations below.
• When starting the engine, the BCM monitors under the engine start conditions:
- Brake pedal operating condition
- Selector lever position
- Vehicle speed
Vehicle speed: less than 4 km/h (2.5 MPH)
Vehicle speed: 4 km/h (2.5 MPH) or more
Emergency stop operation
• Press and hold the push-button ignition switch for 2 seconds or more.
• Press the push-button ignition switch 3 times or more within 1.5 seconds.
Fail-safeINFOID:0000000012567363
BCM performs fail-safe control when the following DTCs are detected.
Power supply position Engine start/stop condition
Push-button
ignition switch
operation frequency
With CVT
With M/T
Selector lever position Brake pedal condition Clutch pedal condition
OFF → ACC —Released Released 1
OFF → ACC → ON —Released Released 2
OFF → ACC → ON →
OFF —
Released Released 3
OFF → START
ACC → START
ON → START P (Park) or N (Neutral) Depressed
Depressed1
Engine is running → OFF ——— 1
Power supply position Engine start/stop condition
Push-button
ignition switch
operation frequency
With CVT
With M/T
Selector lever position Brake pedal condition Clutch pedal condition
Engine is running →
ACC ———
Emergency stop
operation
Engine stall return opera-
tion while driving N (Neutral)
ReleasedDepressed 1
CONSULT Display Fail-safe Cancellation
B2192: ID DISCORD BCM-ECM Inhibit engine cranking Erase DTC
B2193: CHAIN OF BCM-ECM Inhibit engine cranking Erase DTC
B2195: ANTI SCANNING Inhibit engine cranking Ignition switch ON → OFF
B2196: DONGLE NG Inhibit engine cranking Erase DTC
B2198: NATS ANTENNA AMP Inhibit engine cranking Erase DTC
B2557: VEHICLE SPEED —When the following CAN signal status (vehicle speed signal) becomes
consistent
• Vehicle spee
d signal (ABS)
• Vehicle speed signal (Meter)
B2601: SHIFT P SIGNAL —500 ms after the following signal reception status becomes consistent
• Park position switch signal
• P range signal (CAN)
Revision: August 2015
2016 Versa Note

cardiagn.com

PCS-36
< SYSTEM DESCRIPTION >[POWER DISTRIBUTION SYSTEM]
SYSTEM
B2602: SHIFT P DIAG
—5 seconds after the following BCM recognition conditions are fulfilled
• Ignition switch is in the ON position
• Park position switch signal: P position (push selector button) or ex-
cept P position (9 – 16 V)
• Vehicle speed: 4 km/h (2.5 MPH) or more
B2603: SHIFT POSITION —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- Park position switch signal: P position (push selector button) or ex-
cept P position (9 – 16 V)
- P/N position signal: Except P and N positions (0 – 1.5 V)
•Status 2
- Ignition switch is in the ON position
- Park position switch signal: P position (release selector button) (0 – 1.5 V)
- P/N position signal: P or N positions (9 – 16 V)
B2604: SHIFT PN DIAG CAN —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- P/N position signal: P or N position (9 – 16 V)
- Shift position signal (CAN): P or N position
•Status 2
- Ignition switch is in the ON position
- P/N position signal: Except P and N positions (0 – 1.5 V)
- Shift position signal (CAN): Except P and N position
B2605: SHIFT PN DIAG IPDM —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- P/N position signal: Except P and N positions (0 – 1.5 V)
•Status 2
- Ignition switch is in the ON position
- P/N position signal: P or N position (9 – 16 V)
B2608: STARTER RELAY Inhibit engine cranking 500 ms after the following signal communication status becomes con-
sistent
• Starter motor relay control signal
• Starter relay status signal (CAN)
B260F: ECM CAN COMM Inhibit engine cranking When any of the following conditions are fulfilled
• Ignition switch changes to ACC
• Receives engine status signal (CAN)
B26F1: IGN RELAY OFF Inhibit engine cranking When the following conditions are fulfilled
• Ignition switch ON signal (CAN: Transmitted from BCM): ON
• Ignition switch ON signal (CAN: Transmitted from IPDM E/R): ON
B26F2: IGN RELAY ON Inhibit engine crankingWhen the following conditions are fulfilled
• Ignition switch ON signal (CAN: Transmitted from BCM): OFF
• Ignition switch ON signal (CAN: Transmitted from IPDM E/R): OFF
B26F3: START CONT RLY ON Inhibit engine cranking When the following conditions are fulfilled
• Starter control relay signal (CAN: Transmitted from BCM): OFF
• Starter control relay signal (CAN: Transmitted from IPDM E/R): OFF
B26F4: START CONT RLY OFF Inhibit engine cranking When the following conditions are fulfilled
• Starter control relay signal (CAN: Transmitted from BCM): ON
• Starter control relay signal (CAN: Transmitted from IPDM E/R): ON
B26F7: BCM Inhibit engine cranking
by Intelligent Key sys-
temWhen room antenna and luggage room antenna functions normally
U0415: VDC CAN CIR2 —When vehicle speed signal (Meter) (CAN) is received normally
CONSULT Display
Fail-safe Cancellation
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS
DIAGNOSIS SYSTEM (BCM)PCS-37
< SYSTEM DESCRIPTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)INFOID:0000000012542491
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode
Description
ECU Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
ECU Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN DIAG SUPPORT MNTR
Door lock
DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ×××
Air conditioner AIR CONDITIONER ×
Intelligent Key system INTELLIGENT KEY ××××
Combination switch COMB SW ×
BCM BCM× × ×××
Immobilizer IMMU ××××
Interior room lamp battery saver BATTERY SAVER ×××
Vehicle security system THEFT ALM ××
RAP system RETAINED PWR ×
Signal buffer system SIGNAL BUFFER ×
TPMS AIR PRESSURE MONITOR ××××
Panic alarm system PANIC ALARM ×
Revision: August 2015 2016 Versa Note

cardiagn.com
