After wiper blade replacement, return
the wiper arm to its original position.
Otherwise it may be damaged when the
engine hood is opened.
Make sure the wiper blade contacts the
glass. Otherwise, the arm may be dam-
aged from wind pressure.
If you wax the surface of the hood, be
careful not to let wax get into the washer
nozzle. This may cause clogging or im-
proper windshield washer operation. If wax
gets into the nozzle, remove it with a needle
or small pin.Pull the parking brake lever up. If the number
of clicks is out of the range as listed above, see
your NISSAN dealer.
SDI0425
DI1010-C
PARKING BRAKE
7-18
Z01.2.1/R50-DX

With the engine running, check distance A
between the upper surface of the pedal and
the dash lower panel.
Distance A
M/T models
2-1/2 in (65 mm) or more
A/T models
2-3/4 in (70 mm) or more
If it is out of the range shown above, see your
NISSAN dealer.
See your NISSAN dealer and have it
checked if the brake pedal height does
not return to normal.
Brake pad wear indicators
The disc brake pads on your vehicle have
audible wear indicators. When a brake pad
requires replacement, it will make a high
pitched scraping or screeching sound when
the vehicle is in motion whether or not the
brake pedal is depressed. Have the brakes
checked as soon as possible if the wear indi-
cator sound is heard.
Under some driving or climate conditions, oc-
casional brake squeak, squeal or other noise
may be heard. Occasional brake noise during
light to moderate stops is normal and does not
affect the function or performance of the brake
system.
The rear drum brakes (if so equipped) do not
have audible wear indicators. Should you ever
hear an unusually loud noise from the rear
drum brakes, have them inspected as soon as
possible by your NISSAN dealer.
Proper brake inspection intervals shouldbe followed.For more information regarding
brake inspections, see the appropriate main-
tenance schedule information in the ªMainte-
nance Scheduleº section of this manual.
DI0453
BRAKE PEDAL
7-19
Z01.2.1/R50-DX

Check the brake booster function with the
following steps:
1. With the engine off, press and release the
brake pedal several times. When brake
pedal movement (distance of travel) re-
mains the same from one pedal application
to the next, continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a
little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without
depressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradu-
ally with each depression as the vacuum is
released from the booster.
If the brakes do not operate properly, have the
brake checked by your NISSAN dealer.Press the pedal by hand and be sure the free
travel is within the above limit. If free travel is
out of the range shown above, see your NIS-
SAN dealer.
Engine compartment (Headlight
fuses)
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are ªOFFº.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
DI0070-BSDI0395
BRAKE BOOSTER CLUTCH PEDAL FUSES
7-20
Z01.2.1/R50-DX

Never use a fuse of higher amperage rating
than that specified on the fuse box cover.
6. If a new fuse opens again, have the elec-
trical system checked and repaired by your
NISSAN dealer.
Passenger compartment
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are ªOFFº.
2. Pull to open the fuse box cover/coin tray.
3. Pull the fuse box cover/coin tray horizon-
tally to remove it.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.Never use a fuse of higher amperage rating
than that specified on the fuse box cover.
6. If a new fuse opens again, have the elec-
trical system checked and repaired by your
NISSAN dealer.
SDI0447
7-21
Z01.2.1/R50-DX

HEADLIGHTS
Semi-sealed beam type
The headlight is a semi-sealed beam type
which uses a replaceable headlight (halogen)
bulb. A bulb can be replaced inside the engine
compartment without removing the headlight
assembly.
High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratchedor the bulb is dropped.
Hold the plastic base when handling the
bulb. Never touch the glass envelope.
Removing the headlight bulb
1. Disconnect the battery negative cable.
2. Disconnect the electrical connector from
the rear end of the bulb.
3. Turn the bulb retaining ring counterclock-
wise until it is free from the headlight reflec-
tor, then remove it.
4. Remove the headlight bulb. Do not shake
or rotate the bulb when removing it.
Replacing the headlight bulb
1. Insert the bulb into the headlight reflector
with the flat side of the plastic base facing
upward.
2. Install the bulb retaining ring and turn it
clockwise until it stops.
3. Push the electrical connector into the bulb
plastic base until it snaps and stops.
4. Connect the battery negative cable.
DO NOT TOUCH THE BULB.
IUse the same number and wattage as
originally installed:
Wattage 65/45
Bulb no. 9004
IAiming is not necessary after replac-
ing the bulb. When aiming adjust-
ment is necessary, contact your NIS-
SAN dealer.
IDo not leave the bulb out of the head-
light reflector for a long period of time
as dust, moisture, and smoke may
enter the headlight body and affect
the performance of the headlight.
DI0156
LIGHT BULBS
7-22
Z01.2.1/R50-DX

OTHER LIGHTS
Item Wattage (W) Bulb No.
Front turn signal light 27 1156
Front fog light (H3 type) 55
Side combination light 5 168
Rear combination light
Turn signal 27 1156
Stop/Tail 27/8 1157
Back-up 27 1156
High mounted stop light 5 168
License plate light5or10
7.5168*1
89*2
Interior light 10 Ð
Vanity mirror light 1.4 Ð
Spot light 8 Ð
*1: For 5W light
*2: Option
Replacing procedures
All other lights are either type A, B, C or D.
When replacing a bulb, first remove the lens
and/or cover.
MDI0006
7-23
Z01.2.1/R50-DX

SDI0427
7-24
Z01.2.1/R50-DX

SDI0428
SDI0333
7-25
Z01.2.1/R50-DX

If you have a flat tire, see ªIn case of
emergencyº section.
Maximum inflation pressure
Do not exceed the maximum inflation pres-
sures shown on the side wall of the tire.
Tire inflation pressure
Periodically check the tire pressure (including
spare). Incorrect tire pressure may adversely
affect tire life and vehicle handling. Tire pres-
sure should be checked when tires are COLD.
Tires are considered COLD after the vehicle
has been parked for three or more hours, or
driven less than 1 mile (1.6 km). COLD tirepressures are shown on the tire placard affixed
to the center console lid.
The vehicle capacity weight is indicated
on the tire placard. Do not load your
vehicle beyond this capacity. Overload-
ing your vehicle may result in reduced
tire life, unsafe operating conditions due
to premature tire failure, or unfavorable
handling characteristics and could also
lead to a serious accident. Loading be-
yond the specified capacity may also
result in failure of other vehicle compo-
nents.
Before taking a long trip, or whenever
you have loaded your vehicle heavily,
use a tire pressure gauge to ensure that
the tire pressure is at the specified level.
Do not drive your vehicle over 85 MPH
(140 km/h) unless it is equipped with
high speed capability tires. Driving
faster than 85 MPH (140 km/h) may re-
sult in tire failure, loss of control and
possible injury.
Types of tires
When changing or replacing tires, be
sure all four tires are of the same type
(i.e., Summer, All Season or Snow) and
construction. Your NISSAN dealer may
be able to help you with information
about tire type, size, speed rating and
availability. Replacement tires may have
a lower speed rating than the factory
equipped tires, and may not match the
potential maximum vehicle speed. Never
exceed the maximum speed rating of the
tire.
All season tires
NISSAN specifies All Season tires on some
models to provide good performance for use
all year around, including snowy and icy road
conditions. All Season Tires are identified by
ªALL SEASONº and/or ªM&Sº on the tire side-
wall. Snow tires have better snow traction than
All Season tires and may be more appropriate
in some areas.
DI0047
WHEELS AND TIRES
7-26
Z01.2.1/R50-DX

Summer tires
NISSAN specifies summer tires on some mod-
els to provide superior performance on dry
roads. Summer tire performance in snow and
ice will be substantially reduced. Summer tires
do not have the tire traction rating ªM&Sº on
the tire sidewall.
If you plan to operate your vehicle in snowy or
icy conditions, NISSAN recommends the use
of ªSNOWº or ªALL SEASONº tires on all four
wheels.
Snow tires
If snow tires are needed, it is necessary to
select tires equivalent in size and load rating to
the original equipment tires. If you do not, it
can adversely affect the safety and handling of
your vehicle.
Generally, snow tires will have lower speed
ratings than factory equipped tires and may
not match the potential maximum vehicle
speed. Never exceed the maximum speed
rating of the tire.
For additional traction on icy roads, studded
tires may be used. However, some provinces
and states prohibit their use. Check local, state
and provincial laws before installing studded
tires. Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may bepoorer than that of non-studded snow tires.
4-wheel drive model
If you install snow tires, they must also be the
same size, brand, construction and tread pat-
tern on all four wheels.
ONLY use spare tires specified for each
4-wheel drive model.
Tire chains
Use of tire chains is prohibited according to
location. Check the local laws before installing
tire chains. When installing tire chains, make
sure they are of proper size for the tires on
your vehicle and are installed according to the
chain manufacturer's suggestions.Use only
SEA class ªSº chains.Other types may
damage your vehicle. Use chain tensioners
when recommended by the tire chain manu-
facturer to ensure a tight fit. Loose end links of
the tire chain must be secured or removed to
prevent the possibility of whipping action dam-
age to the fenders or underbody. If possible,
avoid fully loading your vehicle when using tire
chains. In addition, drive at a reduced speed.
Otherwise, your vehicle may be damagedand/or vehicle handling and performance may
be adversely affected.
Do not use tire chains on dry roads.
Tire chains must be installed only on the
rear wheels and not on the front wheels.
Do not drive with tire chains on paved roads
which are clear of snow. Driving with chains in
such conditions can cause damage to the
various mechanisms of the vehicle due to
some overstress. When driving on clear paved
roads, be sure to change to 2WD.
7-27
Z01.2.1/R50-DX
