After the child restraint is removed and the
seat belt is allowed to wind back into the
retractor, the automatic locking mode (child
restraint mode) is canceled; the seat belt only
locks during a sudden stop or impact.1-44
Seats, restraints and supplemental air bag systems
Z
01.1.22/R50-D/V5
X
Page 52 of 274

MEMO
Seats, restraints and supplemental air bag systems
1-45
Z
01.1.22/R50-D/V5
X
Page 53 of 274

2 Instruments and controlsInstrument panel ....................................................... 2-2
Meters and gauges ................................................... 2-3
Speedometer and odometer ..................................... 2-3
Tachometer ............................................................... 2-4
Engine coolant temperature gauge ........................... 2-4
Fuel gauge ................................................................ 2-5
Compass and outside temperature display (if so
equipped) .................................................................. 2-6
Outside temperature display ..................................... 2-6
Compass display ....................................................... 2-7
Warning/indicator lights and chimes ......................... 2-9
Checking bulbs.......................................................... 2-9
Warning lights ........................................................... 2-9
Indicator lights ......................................................... 2-12
Chimes .................................................................... 2-14
Security system ....................................................... 2-14
Theft warning (if so equipped) ................................ 2-14
Nissan vehicle immobiliser system ......................... 2-16
Windshield wiper and washer switch ...................... 2-16
Rear window wiper and washer switch................... 2-17
Glass hatch and outside mirror (if so equipped)
defogger switch ...................................................... 2-18
Headlight and turn signal switch ............................. 2-18
Headlight switch ...................................................... 2-18Daytime running light system (Canada only) .......... 2-20
Turn signal switch ................................................... 2-21
Front fog light switch (if so equipped)..................... 2-22
Hazard warning flasher switch ................................ 2-22
Horn......................................................................... 2-23
Heated seats (if so equipped) ................................. 2-23
Power socket........................................................... 2-24
Cigarette lighter and ashtray ................................... 2-25
Storage .................................................................... 2-25
Glasses case........................................................... 2-26
Cup holders ............................................................. 2-26
Glove box ................................................................ 2-27
Console box ............................................................ 2-28
Luggage hooks........................................................ 2-30
Cargo net (if so equipped) ...................................... 2-31
Tonneau cover (if so equipped) .............................. 2-31
Luggage rack (if so equipped) ................................ 2-32
Windows .................................................................. 2-33
Power windows (if so equipped) ............................. 2-33
Sunroof (if so equipped) ......................................... 2-34
Automatic sunroof ................................................... 2-34
Interior lights............................................................ 2-35
Personal lights......................................................... 2-36
Vanity mirror light (if so equipped) .......................... 2-37
Z
01.1.22/R50-D/V5
X
Page 54 of 274

Integrated HomeLink
Universal Transceiver (if so
equipped) ................................................................ 2-37
Programming HomeLink........................................ 2-38
Canadian programming ........................................... 2-39
Operating the integrated HomeLink
Universal
Transceiver.............................................................. 2-39
Programming problem-diagnosis ............................ 2-39
Clearing the programmed information .................... 2-39
Rolling code programming ...................................... 2-40
Reprogramming a single HomeLinkbutton .......... 2-40
If your vehicle is stolen ........................................... 2-40
Nissan communicator (if so equipped) ................... 2-41
Nissan communicator purpose................................ 2-42Nissan communicator outline .................................. 2-42
Safe operating recommendations ........................... 2-42
Quick summary ....................................................... 2-42
Functions ................................................................. 2-43
Function and description ......................................... 2-44
Nissan communicator indicator description ............ 2-47
Payment for Nissan communicator use .................. 2-48
System limitations ................................................... 2-48
False activations and password selections............. 2-50
Steering switch for cellular phone (Models with
communicator)......................................................... 2-50
Switch operations .................................................... 2-51
Z
01.1.22/R50-D/V5
X
Page 55 of 274

Driver's supplemental air bag (P.1-10)Cruise control
set switch
(P.5-17)
Outside mirror remote control
(P.3-15) Headlight/dimmer/turn signal switch (P.2-18)
Front fog light switch (P.2-22)Meter/gauge (P.2-3)
Windshield
and rear
window wiper/
washer
switch
(P.2-16)Hazard warning flasher switch (P.2-22)
Center ventilator (P.4-2)
Heater/air conditioner control (P.4-3)Compass/outside air temperature display (P.2-6)
Passenger supplemental air bag (P.1-10)
Side ventilator (P.4-2)
Glove box (P.2-27)
Cigarette lighter (P.2-25)
Radio/CD player (P.4-19)/clock (P.4-15)
Glass hatch/outside mirror defogger switch (P.2-18)
Ignition switch/steering lock (P.5-6) Steering switch for cellular phone
(Models with Nissan Communicator)Heated seat switch (P.2-23)
Tilting steering wheel adjust lever (P.3-14)Hood release handle (P.3-9) Fuse box cover (P.8-22)/Tray (P.2-25)Security indicator light (P.2-14) Cruise control main switch (P.5-17)
Instrument brightness control (P.2-20)
SIC1180
See the page indicated in parentheses for operating details.
INSTRUMENT PANEL2-2
Instruments and controls
Z
01.1.22/R50-D/V5
X
Page 56 of 274

SPEEDOMETER AND ODOMETER
SpeedometerThe speedometer indicates vehicle speed.Odometer/twin trip odometerThe odometer/twin trip odometer are displayed
when the ignition key is in the ON position.
The odometer records the total distance the
vehicle has been driven.
The twin trip odometer records the distance of
individual trips.
SIC0857
SIC0858
METERS AND GAUGES
Instruments and controls
2-3
Z
01.1.22/R50-D/V5
X
Page 57 of 274

Changing the display:
Push the reset knob to change the display as
follows:
ODO,TRIP A,TRIP B,ODO
Resetting the trip odometer:
Push the reset knob for more than 1 second to
reset the trip odometer to zero.
TACHOMETERThe tachometer indicates engine speed in
revolutions per minute (r/min).When engine speed approaches the red
zone, shift to a higher gear. Operating
the engine in the red zone may cause
serious engine damage.
ENGINE COOLANT
TEMPERATURE GAUGEThe gauge indicates the engine coolant tem-
perature.
The engine coolant temperature will vary with
the outside air temperature and driving condi-
tions.If the gauge indicates engine coolant
temperature over the normal range, stop
the vehicle as soon as safely possible. If
SIC0754A
SIC0859
SIC0545
2-4
Instruments and controls
Z
01.1.22/R50-D/V5
X
Page 58 of 274

the engine is overheated, continued op-
eration of the vehicle may seriously
damage the engine. See ªIf your vehicle
overheatsº in the ª6. In case of emer-
gencyº section for immediate action
required.
FUEL GAUGEThe gauge indicates the APPROXIMATE fuel
level in the tank.
The gauge may move slightly during braking,
turning, acceleration, or going up or down hill.
The gauge needle is designed to remain in
approximately the same position, even when
the ignition key is turned OFF.
Refill the fuel tank before the gauge regis-
ters Empty.
The indicator light comes on when the fuel
tank is getting low. Refuel as soon as it isconvenient, preferably before the gauge
reaches E. There will be a small reserve of
fuel in the tank when the fuel gauge needle
reaches E.
If the vehicle is driven with the fuel level
very low, the malfunction indicator light
may come on. Refuel as soon as pos-
sible. After re-fueling, the light should
go off. If the light remains on, have the
vehicle inspected by an authorized
NISSAN dealer.
For additional information, see the ªMal-
function indicator light (MIL)º later in
this section.
SIC0960
Instruments and controls
2-5
Z
01.1.22/R50-D/V5
X
Page 59 of 274

This unit is a display unit with the following
functions:
IFunction to measure terrestrial magnetism
and indicate heading direction of vehicle
IFunction to indicate outside air temperature
IFunction to indicate caution for frozen road
surfaces
OUTSIDE TEMPERATURE
DISPLAYPush the switch when the ignition key is in the
ACC or ON position. The outside temperature
will be displayed in ÉF.
ISelecting the indication range
Push the switch to change from ÉF to ÉC.
IIf the outside temperature drops below the
freezing point, the display indicates ICE.IWhen the outside temperature is be-
tween 130ÉF (55ÉC) and 158ÉF (70ÉC), the
display shows 130ÉF (55ÉC).
IWhen the outside temperature is lower
than þ20ÉF (þ30ÉC) or higher than 158ÉF
(70ÉC), the display shows only
---
though it is operating. This is not a
problem.
IThe outside temperature sensor is
installed in the front of the radiator.
The display may not indicate the pre-
cise temperature due to the heat of
the road and engine depending on
the direction of the wind and driving
conditions, etc.
IUse the ICE indication for reference
only. Confirm the traffic information
and road conditions to drive safely.
SIC0590
SIC0610
COMPASS AND OUTSIDE
TEMPERATURE DISPLAY
(if so equipped)2-6
Instruments and controls
Z
01.1.22/R50-D/V5
X
Page 60 of 274

COMPASS DISPLAYPush the switch when the ignition key is in the
ACC or ON position. The direction will be
displayed.Zone variation change procedureThe difference between magnetic north and
geographical north is known as variance. In
some areas, this difference can sometimes be
great enough to cause false compass read-
ings. Follow these instructions to set the vari-
ance for your particular location if this hap-
pens:
1. Establish your location on the zone map.
Record your zone number.
2. Push the ON/OFF switch in for five seconds
until the current zone entry number is dis-
played.
3. Press the ON/OFF switch repeatedly until
the new zone entry number is displayed.
Once the desired zone number is displayed,
stop pressing the ON/OFF switch and the
display will show compass direction within a
few seconds.
SIC0611
Instruments and controls
2-7
Z
01.1.22/R50-D/V5
