NISSAN PATHFINDER 1999 R50 / 2.G Manual PDF

To defog the glass hatch and the outside door
mirrors, start the engine and push the switch
on. (The indicator light will come on.) Push the
switch again to turn the defogger off.
It will automatically turn off in approximately 15
minutes. If the window clears before this time,
push the switch off manually.When cleaning the inner side of the
glass hatch, be careful not to scratch ordamage the glass hatch defogger.
HEADLIGHT SWITCH
LightingTurn the switch to the
position:
The side combination, tail, license plate and
SIC0593
SIC1068
GLASS HATCH AND OUTSIDE
MIRROR (if so equipped)
DEFOGGER SWITCHHEADLIGHT AND TURN SIGNAL
SWITCH2-18
Instruments and controls
Z
01.1.22/R50-D/V5
X

instrument lights will come on.
Turn the switch to the
position:
Headlights will come on and all the other lights
remain on.
Battery saver systemIWhen the headlight switch is in the
or
position while the ignition switch is in
the ON position, the lights (including the
front fog light) will automatically turn off 45
seconds after the ignition switch has been
turned to the OFF position.
IWhen you open either the driver's or front
passenger's door, the lights turn off within
the 45 seconds.
IWhen the headlight switch remains in theor
position after the lights auto-
matically turn off, the lights will turn on
when the ignition switch is turned to the ON
position from the OFF position.
IWhen you turn on the headlight
switch again after the lights automati-
cally turn off, the lights will not turn
off automatically. Be sure to turn the
light switch to the OFF position whenyou leave the vehicle for extended
periods of time, otherwise the battery
will go dead.
INever leave the light switch on when
the engine is not running for ex-
tended periods of time.
Headlight beam selectTo select the high beam, push the lever for-
ward. Pull it back to select the low beam.
SIC1069
Instruments and controls
2-19
Z
01.1.22/R50-D/V5
X

Passing signalPulling the lever toward you will turn on the
passing signal even when the headlight switch
is off.Passing signal can operate only when
the light switch is in the
or
position. It does not operate after
the light has turned off automatically.
Instrument brightness controlThe instrument brightness control operates
when the light switch is in the
or
position.
Turn the control to adjust the brightness of
instrument panel lights and power window
switch lights.
When the control is turned to the right until a
click sound is heard, the light intensity will be
at maximum. When the control is turned to the
left until a click sound is heard, the light will be
turned off.
DAYTIME RUNNING LIGHT
SYSTEM (Canada only)The headlights automatically illuminate at a
reduced intensity when the engine is started
with the parking brake released. The daytime
running lights operate with the headlight switch
in the off position or in the
position. Turn
the headlight switch to theposition for
full illumination when driving at night.
If the parking brake is applied before the
engine is started, the daytime running lights do
not illuminate. The daytime running lights illu-
minate once the parking brake is released.
The daytime running lights will remain on until
the ignition switch is turned off.
SIC0052
2-20
Instruments and controls
Z
01.1.22/R50-D/V5
X

When the daytime running light system
is active, tail lights on your vehicle are
not on. It is necessary at dusk to turn on
your headlights. Failure to do so could
cause an accident injuring yourself and
others.
TURN SIGNAL SWITCH
Turn signalMove the lever up or down to signal to the
turning direction. When the turn is completed,
the turn signals cancel automatically.
Lane change signalTo indicate a lane change, move the lever up
or down to the point where lights begin flash-
ing.
SIC1070
Instruments and controls
2-21
Z
01.1.22/R50-D/V5
X

To turn the fog lights on, turn the headlight
switch to the
position, then turn the
switch to theposition. To turn them off,
turn the switch to the OFF position.
The headlights must be on for the fog lights to
operate.Push the switch on to warn other drivers when
you must stop or park under emergency con-
ditions. All turn signal lights will flash.
Some state laws may prohibit the use of the
hazard warning flasher switch while driv-
ing.
IWhen stalled or stopped on the road-
way under emergency conditions,
move the vehicle well off the road.
IDo not use the switch while movingon the highway unless unusual cir-
cumstances force you to drive so
slowly that your vehicle might be-
come a hazard to other traffic.
ITurn signals do not work when the
switch is operating.
The flasher can be actuated with the ignition
switch either off or on.
IC1292
SIC0594
FRONT FOG LIGHT SWITCH (if so
equipped)HAZARD WARNING FLASHER
SWITCH2-22
Instruments and controls
Z
01.1.22/R50-D/V5
X

To sound the horn, push the center pad area of
the steering wheel.The front seat(s) are warmed by built-in heat-
ers. The switches located on the instrument
panel can be operated independently of each
other.
1. Start the engine.
The battery could run down if the heater is
operated while the engine is not running.
2. Push the
(Low) or
(High) po-
sition of the switch, as desired, depending
on the temperature. The indicator light in
the switch will illuminate.
The heater is controlled by a thermostat,
automatically turning the heater on and off.The indicator light will remain on as long as
the switch is on.
3. When the vehicle's interior is warmed or
before you leave the vehicle, be sure to turn
the switch off.
IDo not use the seat heater for ex-
tended periods or when no one is
using the seat.
IDo not put anything on the seat which
insulates heat, such as a blanket,
cushion, seat cover, etc. Otherwise,
the seat may become overheated.
IDo not place anything hard or heavy
on the seat or pierce it with a pin or
similar object. This may result in
damage to the heater.
IAny liquid spilled on the heating seat
should be removed immediately with
a dry cloth.
IWhen cleaning the seat, never use
benzine, thinner, or any similar mate-
rials.
IIf any abnormalities are found or the
SIC0861
SIC0684
HORN HEATED SEATS (if so equipped)
Instruments and controls
2-23
Z
01.1.22/R50-D/V5
X

heating seat does not operate, turn
the switch OFF and have the system
checked by your NISSAN dealer.
ITake care as the socket and plug may
be hot during or immediately after
use.
IThis power point is not designed for
use with a cigarette lighter unit.
IDo not use with accessories that ex-
ceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.
IUse this power point with the enginerunning. (If the engine is stopped,
this could result in a discharged bat-
tery.)
IAvoid using when the air conditioner,
headlights or rear window defogger
is on.
IBefore inserting or disconnecting a
plug, be sure to turn off the power
switch of electrical accessory being
used or the ACC power of the vehicle.
IPush the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tempera-
ture fuse may blow.
IWhen not in use, be sure to close the
cap. Do not allow water to contact the
socket.
SIC0686
POWER SOCKET
2-24
Instruments and controls
Z
01.1.22/R50-D/V5
X

The cigarette lighter operates when the igni-
tion switch is in ACC or ON.
Push the lighter in all the way. When the lighter
is heated, it will spring out.
Replace the lighter in its original position after
use.The cigarette lighter should not be used
while driving in order that full attention
may be given to the driving operation.The cigarette lighter socket is a power
source for the cigarette lighter element
only. The use of the cigarette lighter
socket as a power source for any other
accessory is not recommended.
TRAYThe coin tray should not be used while
driving in order that full attention may be
given to the driving operation.Do not place valuable items in the tray.
SIC0685
SIC0596
CIGARETTE LIGHTER AND
ASHTRAYSTORAGE
Instruments and controls
2-25
Z
01.1.22/R50-D/V5
X

GLASSES CASEThe glasses case can be opened by pushing
the button.The glasses case should not be used
while driving in order that full attention
may be given to the driving operation.
IDo not use for anything other than
glasses.
IDo not leave glasses in the glasses
case while parking in direct sunlight.
The heat may damage the glasses.
CUP HOLDERSThe cup holders should not be used
while driving in order that full attention
may be given to the driving operation.IAvoid abrupt starting and braking
when the cup holder is being used to
prevent spilling the drink. If the liquid
SIC0557
SIC0553A
2-26
Instruments and controls
Z
01.1.22/R50-D/V5
X

is hot, it can scald you or your pas-
senger.
IUse only soft cups in the cup holder.
Hard objects can injure you in an
accident.
To open, push the cup holder.
To close, fully push the cup holder.
GLOVE BOXWhen locking or unlocking the glove box, use
the master key.
The glove box may be opened by the handle.Keep glove box lid closed while driving
to help prevent injury in an accident or
during a sudden stop.
SIC0698
SPA0388
Instruments and controls
2-27
Z
01.1.22/R50-D/V5
X
