NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual REAR AXLE &
REAR SUSPENSION
SECTION
RA
CONTENTS
PRECAUTIONS AND PREPARATION............................1
Precautions ..................................................................1
Special Service

Page 2 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual Precautions
+When installing rubber parts, ®nal tightening must be car-
ried out under unladen condition* with tires on ground.
*: Fuel, radiator coolant and engine oil full. Spare tire, jack,
hand t

Page 3 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual Commercial Service Tools
Tool name Description
Equivalent to GG94310000
j
1Flare nut crowfoot
j
2Torque wrench
NT360
Removing and installing each brake piping
a: 10 mm (0.39 in)
Rear axle oil seal dri

Page 4 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual NVH Troubleshooting Chart
Use the chart below to help you ®nd the cause of the symptom. If necessary, repair or replace these parts.
Reference pageRA-4
RA-14
Ð
Ð
Ð
RA-12
RA-15
RA-5
NVH in PD secti

Page 5 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual SRA813A
REAR AXLE AND REAR SUSPENSION
RA-4

Page 6 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual Rear Axle and Rear Suspension Parts
Check rear axle and rear suspension parts for excessive play, wear
or damage.
+Shake each rear wheel to check for excessive play.
+Retighten all nuts and bolts to t

Page 7 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual Components
SRA816A
REAR AXLE
RA-6

Page 8 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual Removal
CAUTION:
+Before removing the rear axle, disconnect the ABS wheel
sensor from the assembly. Then move it away from the
axle. Failure to do so may result in damage to the sensor
wires and the s

Page 9 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual 7. Unbend lock washer with a screwdriver.
Do not reuse lock washer once removed. Always install new
one.
8. Remove bearing lock nut with Tool.
9. Remove wheel bearing together with bearing cage and ba

Page 10 of 26

NISSAN PATROL 1998 Y61 / 5.G Rear Suspension Workshop Manual Inspection
AXLE SHAFT
Check axle shaft for straightness, cracks, damage, wear or distor-
tion. Replace if necessary.
BEARING CAGE
Check bearing cage for deformation or cracks. Replace if neces-
sary.
