OthersMaximum speed
not attained.
Acceleration
poor.ON vehicle1. A/T fluid levelAT- 1 4
2. PNP switchAT- 1 6 1
3. 3rd position switchAT- 1 6 1
4. Accelerator pedal position sensor
EC-272*1, EC-652*2
5. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 8 0, AT- 8 6
6. Shift solenoid valve AAT- 9 0
7. Shift solenoid valve BAT- 9 5
8. Control valve assemblyAT- 2 2 5
OFF vehicle9. Reverse clutchAT- 2 9 6
10. High clutchAT- 3 0 1
11. Brake bandAT- 3 2 9
12. Low & reverse brakeAT- 3 1 5
13. Oil pumpAT- 2 7 5
14. Torque converterAT- 2 5 5
Transaxle noise
in “D”, “3”, “2”, “1”
and “R” positions.ON vehicle 1. A/T fluid levelAT- 1 4
OFF vehicle 2. Torque converterAT- 2 5 5
Engine brake
does not operate
in “1” position.ON vehicle1. PNP switchAT- 1 6 1
2. A/T positionAT- 2 1 5
3. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 8 0, AT- 8 6
4. Control valve assemblyAT- 2 2 5
5. Overrun clutch solenoid valveAT- 1 0 0
OFF vehicle6. Overrun clutchAT- 3 0 77. Low & reverse brakeAT- 3 1 5
Transaxle over-
heats.ON vehicle1. A/T fluid levelAT- 1 4
2. Engine idle speed
EC-45*1, EC-387*2
3. Accelerator pedal position sensor
EC-272*1, EC-652*2
4. Line pressure testAT- 4 6
5. Line pressure solenoid valveAT- 1 2 6
6. Control valve assemblyAT- 2 2 5
OFF vehicle7. Oil pumpAT- 2 7 5
8. Reverse clutchAT- 2 9 6
9. High clutchAT- 3 0 1
10. Brake bandAT- 3 2 9
11. Forward clutchAT- 3 0 7
12. Overrun clutchAT- 3 0 7
13. Low & reverse brakeAT- 3 1 5
14. Torque converterAT- 2 5 5
