NISSAN TEANA 2014 Service Manual

ECM
EC-111
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
HO2S 02H
Heated oxygen sensor 2
(Bank 1) P0138 07H 0CH
Minimum sensor output voltage for test
cycle
P0137 08H 0CH Maximum sensor output voltage for
test cycle
P0138 80H 0CH Sensor output voltage
P0139 81H 0CH Difference in sensor output voltage
P0139 82H 11H Rear O2 sensor delay response diag-
nosis
03H Heated oxygen sensor 3
(Bank 1) P0143 07H 0CH
Minimum sensor output voltage for test
cycle
P0144 08H 0CH Maximum sensor output voltage for
test cycle
P0146 80H 0CH Sensor output voltage
P0145 81H 0CH Difference in sensor output voltage
05H Air fuel ratio (A/F) sensor 1
(Bank 2) P0151 83H 0BH
Minimum sensor output voltage for test
cycle
P0151 84H 0BH Maximum sensor output voltage for
test cycle
P0150 85H 0BH Minimum sensor output voltage for test
cycle
P0150 86H 0BH Maximum sensor output voltage for
test cycle
P0153 87H 04H Response rate: Response ratio (lean
to rich)
P0153 88H 04H Response rate: Response ratio (rich to
lean)
P2A03 or P2098 89H 84H The amount of shift in air fuel ratio (too
lean)
P2A03 or P2099 8AH 84H The amount of shift in air fuel ratio (too
rich)
P0150 8BH 0BH Difference in sensor output voltage
P0153 8CH 83H Response gain at the limited frequency
P014E 8DH 04H O2 sensor slow response - Rich to
lean bank 2 sensor 1
P014E 8EH 04H O2 sensor slow response - Rich to
lean bank 2 sensor 1
P014F 8FH 84H O2 sensor slow response - Lean to rich
bank 2 sensor 1
P014F 90H 84H O2 sensor slow response - Lean to rich
bank 2 sensor 1
P015C 91H 01H O2 sensor delayed response - Rich to
lean bank 2 sensor 1
P015C 92H 01H O2 sensor delayed response - Rich to
lean bank 2 sensor 1
P015D 93H 01H O2 sensor delayed response - Lean to
rich bank 2 sensor 1
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-112
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
HO2S05H
Air fuel ratio (A/F) sensor 1
(Bank 2) P015D 94H 01H
O2 sensor delayed response - Lean to
rich bank 2 sensor 1
P0153 95H 04H Response rate: Response ratio (lean
to rich)
P0153 96H 84H Response rate: Respon
se ratio (rich to
lean)
06H Heated oxygen sensor 2
(Bank 2) P0158 07H 0CH
Minimum sensor output voltage for test
cycle
P0157 08H 0CH Maximum sensor output voltage for
test cycle
P0158 80H 0CH Sensor output voltage
P0159 81H 0CH Difference in sensor output voltage
P0159 82H 11H Rear O2 sensor delay response diag-
nosis
07H Heated oxygen sensor 3
(Bank2) P0163 07H 0CH
Minimum sensor output voltage for test
cycle
P0164 08H 0CH Maximum sensor output voltage for
test cycle
P0166 80H 0CH Sensor output voltage
P0165 81H 0CH Difference in sensor output voltage
CATA-
LYST 21H
Three way catalyst function
(Bank1) P0420 80H 01H O2 storage index
P0420 82H 01H Switching time lag engine exhaust in-
dex value
P2423 83H 0CH Difference in 3rd O2 sensor output
voltage
P2423 84H 84H O2 storage index in HC trap catalyst
22H Three way catalyst function
(Bank2) P0430 80H 01H O2 storage index
P0430 82H 01H Switching time lag engine exhaust in-
dex value
P2424 83H 0CH Difference in 3rd O2 sensor output
voltage
P2424 84H 84H O2 storage index in HC trap catalyst
EGR
SYSTEM 31H EGR function P0400 80H 96H
Low flow faults: EGR temp change rate
(short term)
P0400 81H 96H Low flow faults: EGR temp change rate
(long term)
P0400 82H 96H Low flow faults: Difference between
max EGR temp and EGR temp under
idling condition
P0400 83H 96H Low flow faults: Max EGR temp
P1402 84H 96H High Flow Faults: EGR temp increase
rate
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-113
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
VVT
SYSTEM 35H VVT Monitor (Bank1)
P0011 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0014 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0011 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0014 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100A 84H 10H VEL slow response diagnosis P1090 85H 10H VEL servo system diagnosis
P0011 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052A Retarded: P052B 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
36H VVT Monitor (Bank2) P0021 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0024 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0021 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0024 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100B 84H 10H VEL slow response diagnosis P1093 85H 10H VEL servo system diagnosis
P0021 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052C Retarded: P052D 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
EVAP
SYSTEM 39H
EVAP control system leak
(Cap Off) P0455 80H 0CHDifference in pressure sensor output
voltage before and after pull down
3BH EVAP control system leak
(Small leak) P0442 80H 05H
Leak area index (for more than 0.04
inch)
3CH EVAP control system leak
(Very small leak) P0456 80H 05H
Leak area index (for more than 0.02
inch)
P0456 81H FDH Maximum internal pressure of EVAP
system during monitoring
P0456 82H FDH Internal pressure of EVAP system at
the end of monitoring
3DH Purge flow system P0441 83H 0CH Difference in pressure sensor output
voltage before and after vent control
valve close
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-114
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
O2 SEN-
SOR
HEATER 41H A/F sensor 1 heater (Bank 1)
Low Input: P0031
High Input: P0032 81H 0BHConverted value of heater electric cur-
rent to voltage
42H Heated oxygen sensor 2 heat-
er (Bank 1) Low Input: P0037
High Input: P0038 80H 0CH
Converted value of heater electric cur-
rent to voltage
43H Heated oxygen sensor 3 heat-
er (Bank 1) P0043 80H 0CHConverted value of heater electric cur-
rent to voltage
45H A/F sensor 1 heater (Bank 2) Low Input: P0051
High Input: P0052 81H 0BHConverted value of heater electric cur-
rent to voltage
46H Heated oxygen sensor 2 heat-
er (Bank 2) Low Input: P0057
High Input: P0058 80H 0CH
Converted value of heater electric cur-
rent to voltage
47H Heated oxygen sensor 3 heat-
er (Bank 2) P0063 80H 0CHConverted value of heater electric cur-
rent to voltage
SEC-
OND-
ARY AIR 71H Secondary air system P0411 80H 01H
Secondary air injection system incor-
rect flow detected
Bank1: P0491
Bank2: P0492 81H 01H
Secondary air injection system insuffi-
cient flow
P2445 82H 01H Secondary air injection system pump
stuck off
P2448 83H 01H Secondary air injection system high
airflow
Bank1: P2440
Bank2: P2442 84H 01H
Secondary air injection system switch-
ing valve stuck open
P2440 85H 01H Secondary air injection system switch-
ing valve stuck open
P2444 86H 01H Secondary air injection system pump
stuck on
FUEL
SYSTEM 81H
Fuel injection system function
(Bank 1) P0171 or P0172 80H 2FH Long term fuel trim
P0171 or P0172 81H 24H The number of lambda control
clamped
P117A 82H 03H Cylinder A/F imbalance monitoring
82H Fuel injection system function
(Bank 2) P0174 or P0175 80H 2FH Long term fuel trim
P0174 or P0175 81H 24H The number of lambda control
clamped
P117B 82H 03H Cylinder A/F imbalance monitoring
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-115
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
MISFIRE A1H Multiple cylinder misfires P0301 80H 24H
Misfiring counter at 1000 revolution of
the first cylinder
P0302 81H 24H Misfiring counter at 1000 revolution of
the second cylinder
P0303 82H 24H Misfiring counter at 1000 revolution of
the third cylinder
P0304 83H 24H Misfiring counter at 1000 revolution of
the fourth cylinder
P0305 84H 24H Misfiring counter at 1000 revolution of
the fifth cylinder
P0306 85H 24H Misfiring counter at 1000 revolution of
the sixth cylinder
P0307 86H 24H Misfiring counter at 1000 revolution of
the seventh cylinder
P0308 87H 24H Misfiring counter at 1000 revolution of
the eighth cylinder
P0300 88H 24H Misfiring counter at 1000 revolution of
the multiple cylinders
P0301 89H 24H Misfiring counter at 200 revolution of
the first cylinder
P0302 8AH 24H Misfiring counter at 200 revolution of
the second cylinder
P0303 8BH 24H Misfiring counter at 200 revolution of
the third cylinder
P0304 8CH 24H Misfiring counter at 200 revolution of
the fourth cylinder
P0305 8DH 24H Misfiring counter at 200 revolution of
the fifth cylinder
P0306 8EH 24H Misfiring counter at 200 revolution of
the sixth cylinder
P0307 8FH 24H Misfiring counter at 200 revolution of
the seventh cylinder
P0308 90H 24H Misfiring counter at 200 revolution of
the eighth cylinder
P0300 91H 24H Misfiring counter at 1000 revolution of
the single cylinder
P0300 92H 24H Misfiring counter at 200 revolution of
the single cylinder
P0300 93H 24H Misfiring counter at 200 revolution of
the multiple cylinders
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-116
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
MISFIREA2H No. 1 cylinder misfire
P0301 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0301 0CH 24H Misfire counts for last/current driving
cycles
A3H No. 2 cylinder misfire P0302 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0302 0CH 24H Misfire counts for last/current driving
cycles
A4H No. 3 cylinder misfire P0303 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0303 0CH 24H Misfire counts for last/current driving
cycles
A5H No. 4 cylinder misfire P0304 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0304 0CH 24H Misfire counts for last/current driving
cycles
A6H No. 5 cylinder misfire P0305 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0305 0CH 24H Misfire counts for last/current driving
cycles
A7H No. 6 cylinder misfire P0306 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0306 0CH 24H Misfire counts for last/current driving
cycles
A8H No. 7 cylinder misfire P0307 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0307 0CH 24H Misfire counts for last/current driving
cycles
A9H No. 8 cylinder misfire P0308 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0308 0CH 24H Misfire counts for last/current driving
cycles
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ENGINE CONTROL SYSTEMEC-117
< WIRING DIAGRAM > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
WIRING DIAGRAM
ENGINE CONTROL SYSTEM
Wiring DiagramINFOID:0000000009462126
FOR CALIFORNIA
ABBWA1118GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-118
< WIRING DIAGRAM >[QR25DE]
ENGINE CONTROL SYSTEM
ABBWA0994GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ENGINE CONTROL SYSTEMEC-119
< WIRING DIAGRAM > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ABBWA0879GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-120
< WIRING DIAGRAM >[QR25DE]
ENGINE CONTROL SYSTEM
ABBWA0880GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
