NISSAN TEANA 2014 Service Manual

PWC-134
< SYMPTOM DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
ANTI-PINCH SYSTEM DOES
NOT OPERATE NORMALLY (PASSENGER SIDE)
ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (PASSENGER
SIDE)
Diagnosis ProcedureINFOID:0000000009460974
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2. CHECK DOOR WINDOW SLIDING PART
• A foreign material adheres to window glass or glass run rubber.
• Glass run rubber wear or deformation.
• Sash is tilted too much or not enough.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3. CHECK ENCODER CIRCUIT
Check encoder circuit.
Refer to PWC-115, "PASSENGER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATES NORMAL-
LY (DRIVER SIDE)
PWC-135
< SYMPTOM DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATES
NORMALLY (DRIVER SIDE)
Diagnosis ProcedureINFOID:0000000009460975
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2. CHECK ENCODER
Check encoder.
Refer to PWC-113, "DRIVER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-136
< SYMPTOM DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
AUTO OPERATION DOES NOT OPERAT
E BUT MANUAL OPERATES NORMAL-
LY (PASSENGER SIDE)
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATES
NORMALLY (PASSENGER SIDE)
Diagnosis ProcedureINFOID:0000000009460976
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2. CHECK ENCODER
Check encoder.
Refer to PWC-115, "PASSENGER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER WINDOW RETAINED POWER OPERATION DOES NOT OPERATE
PROPERLY
PWC-137
< SYMPTOM DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW RETAINED POWE R OPERATION DOES NOT OPER-
ATE PROPERLY
Diagnosis ProcedureINFOID:0000000009460977
1. CHECK FRONT DOOR SWITCH
Check front door switch.
Refer to DLK-100, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-138
< SYMPTOM DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER WINDOW LOCK SWIT
CH DOES NOT FUNCTION
POWER WINDOW LOCK SWITCH DOES NOT FUNCTION
Diagnosis ProcedureINFOID:0000000009460978
1. REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
Replace main power window and door lock/unlock switch.
Refer to PWC-142, "Removal and Installation"
. After that, PWC-99, "POWER WINDOW MAIN SWITCH : Spe-
cial Repair Requirement".
>> INSPECTION END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DOOR KEY CYLINDER SWITCH DOES NOT OPERATE POWER WINDOWS
PWC-139
< SYMPTOM DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
DOOR KEY CYLINDER SWITCH DOES NOT OPERATE POWER WIN-
DOWS
Diagnosis ProcedureINFOID:0000000009460979
1.PERFORM INITIALIZATION PROCEDURE
Initialization procedure is performed and operation is confirmed.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK FRONT DOOR LOCK ASSEMBL Y LH (DOOR KEY CYLINDER SWITCH)
Check front door lock assembly LH (door key cylinder switch).
Refer to PWC-120, "Component Function Check"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 1.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-140
< SYMPTOM DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000009460980
1. CHECK INTELLIGENT KEY FUNCTION
Check Intelligent Key function.
Refer to DLK-146, "Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PRE-INSPECTION FOR DIAGNOSTICPWC-141
< PERIODIC MAINTENANCE > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
PERIODIC MAINTENANCE
PRE-INSPECTION FOR DIAGNOSTIC
Basic InspectionINFOID:0000000009460981
BASIC INSPECTION
1.INSPECTION START
1. Check the service history.
2. Check the following parts.
• Fuse/circuit breaker blown.
• Poor connection, open or short circuit of harness connector.
• Battery voltage.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PWC-142
< REMOVAL AND INSTALLATION >[LH & RH FRONT ANTI-PINCH]
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
REMOVAL AND INSTALLATION
MAIN POWER WINDOW AND
DOOR LOCK/UNLOCK SWITCH
Removal and InstallationINFOID:0000000009460982
REMOVAL
1. Remove the front door pull handle outer finisher using a suitable tool.
2. Release the pawls using a suitable tool and lift the main power window and door lock/unlock switch and
finisher as an assembly by starting at the rear, then pull upward and remove.
3. Disconnect the harness connector from the main power window and door lock/unlock switch.
4. Release the four pawls (two on each side) using a suitable tool, then separate the main power window and door lock/unlock
switch (1) from the main power window and door lock switch fin-
isher (2).
: Pawl
CAUTION:
Do not bend back the pawls on the switch finisher too far or
breakage may occur.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
When the main power window and door lock/unlock swit ch is disconnected from the harness connector it is
necessary to perform the initialization procedure. Refer to PWC-27, "ADDITIONAL SERVICE WHEN REMOV-
ING BATTERY NEGATIVE TERMINAL : Special Repair Requirement".
ALKIA2630ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RHPWC-143
< REMOVAL AND INSTALLATION > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Removal and InstallationINFOID:0000000009460983
REMOVAL
1. Remove the front door pull handle outer finisher using a suitable tool.
2. Release the pawls using a suitable tool and lift the power window and door lock/unlock switch RH and fin- isher as an assembly by starting at the rear, then pull upward and remove.
3. Disconnect the harness connector from the pow er window and door lock/unlock switch RH.
4. Release the four pawls (two on each side) using a suitable tool, then separate the power window and door lock/unlock switch
RH (1) from the power window and door lock switch RH finisher
(2).
: Pawl
CAUTION:
Do not bend back the pawls on th e switch finisher too far or
breakage may occur.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2630ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
