FRONT SEAT
2. Release pawls (A) using a suitable tool and release the seatheater switch finisher (2) from the center console assembly (1).
3. Disconnect the harness connectors from the front heated seat switches.
4. Release pawls (A) using a suitable tool and remove the front heated seat switches (1) from t he seat heater switch finisher.
INSTALLATION
Installation is in the reverse order of removal.
ALJIA0973ZZ
ALJIA0974ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REAR SEATSE-33
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
REAR SEAT
Exploded ViewINFOID:0000000009462941
REAR SEAT WITHOUT REMOVABLE HEADREST
ALJIA0959ZZ
1. Rear seatback assembly (RH) 2. Rear seat bolster (RH) 3. Seat belt guide (RH)
4. Seatback board (RH) 5. Seatback trim (RH) 6. Seatback pad (RH)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SE-34
< REMOVAL AND INSTALLATION >
REAR SEAT
7. Armrest 8. Cup holder 9. Armrest hinge finisher
10. Seatback hinge assembly (RH) 11. Seat cushion assembly 12. Seat cushion wire cover
13. Seat cushion lock 14. Seat cushion pad 15. Seat cushion trim
16. Seatback hinge (LH) 17. Seatback pad (LH) 18. Seatback trim (LH)
19. Seatback board (LH) 20. Seat belt guide (LH) 21. Rear seat bolster (LH)
22. Rear seatback assembly (LH) 23. Seatback latch assembly 24. Cable guide
A. Seatback board clips B. Armrest pivot bolt
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REAR SEATSE-35
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
REAR SEAT WITH REMOVABLE HEADREST
ALJIA0958ZZ
1. Headrest (RH) 2. Rear seat bolster (RH) 3. Seat belt guide (RH)
4. Rear seatback assembly (RH) 5. Seatback board (RH) 6. Headrest holder (RH) (free)
7. Headrest holder (RH) (locked) 8. Seatback trim (RH) 9. Seatback pad (RH)
10. Armrest 11. Cup holder 12. Armrest hinge finisher
13. Seatback hinge assembly (RH) 14. Seat cushion assembly 15. Seat cushion lock
16. Seat cushion wire cover 17. Seat cushion pad 18. Seat cushion trim
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SE-36
< REMOVAL AND INSTALLATION >
REAR SEAT
Removal and Installation - Seat Cushion Assembly
INFOID:0000000009462942
1. Locate the seat cushion lock (2) at the front bottom of the seat cushion assembly (one for each side). Pull the release lever (A)
forward and lift the seat cushion upward to release the seat
cushion wire (1) from the seat cushion lock (2).
: Front
2. Then pull the seat cushion assembly forward to remove.
Removal and Installation - Seat AssemblyINFOID:0000000009462943
REMOVAL
NOTE:
Rear seatback assembly (RH) must be removed first, then rear seatback assembly (LH) can be removed.
1. Remove the rear seat cushion assembly. Refer to SE-36, "Removal and Installation - Seat Cushion
Assembly".
2. Remove the rear seat bolster (RH). Refer to SE-38, "Removal and Installation - Rear Seat Bolster"
.
3. Remove the rear seatback assembly (RH) (1).
a. Remove the seatback pivot bolt (A). CAUTION:
Do not remove hinge bolt (B ) or seatback alignment may be
necessary.
b. Release the seatback latch assembly then remove the rear seatback assembly (1) from the seatback hinge assembly (RH)
(2).
c. Remove the rear seatback assembly (RH).
4. Remove the rear seat bolster (LH). Refer to SE-38, "Removal and Installation - Rear Seat Bolster"
.
5. Remove the rear seatback assembly (LH) (1).
a. Remove retaining clip (A) from seatback pivot pin (B) using a suitable tool. (2) Seatback hinge assembly (RH)
NOTE:
Retaining clip (A) is used for factory installation only, it is not a
serviceable part and not necessary to use during installation.
19. Seatback hinge (LH) 20. Seatback pad (LH) 21. Seatback trim (LH)
22. Headrest holder (LH) (locked) 23. Headrest holder (LH) (free) 24. Seatback board (LH)
25. Rear seatback assembly (LH) 26. Seat belt guide (LH) 27. Rear seat bolster (LH)
28. Headrest (LH) 29. Seatback latch assembly 30. Cable guide
A. Seatback board clips B. Armrest pivot bolt
ALJIA0949ZZ
ALJIA0938ZZ
ALJIA0939ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REAR SEATSE-37
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
b. Remove the seatback pivot bolt (A). CAUTION:
Do not remove hinge bolt (B) or seatback alignment may be
necessary.
c. Release the seatback latch assembly then remove the rear seatback assembly (1) from the seatback hinge (LH) (2).
d. Remove the rear seatback assembly (LH).
INSTALLATION
Installation is in the reverse order of removal.
• Tighten bolts and nuts to specification. Refer to SE-33, "Exploded View"
.
Removal and Installation - Seatback HingeINFOID:0000000009462944
REMOVAL
1. Remove the seat cushion assembly, rear seatback assembly (RH), and the rear seatback assembly (LH).
Refer to SE-36, "Removal and Installation - Seat Assembly"
.
2. Remove the bolt and nut from the seatback hinge assembly (RH), then remove.
3. Remove the bolt from the s eatback hinge (LH), then remove.
INSTALLATION
1. Install seatback hinge assembly (RH) and seatback hinge (LH) loosely.
2. Install the rear seatback assembly (LH) and engage into seatback latch assembly.
3. Install the rear seatback assembly (RH) and engage into seatback latch assembly.
4. Tighten seatback hinge nut and bolts to specification. Refer to SE-33, "Exploded View"
.
CAUTION:
Ensure rear seatback assemblies (LH/RH) fold and latch properly. Adjust if necessary.
5. Install remaining components in reverse order of removal.
Removal and Installation - Seatback Latch AssemblyINFOID:0000000009462945
REMOVAL
1. Remove the rear seat bolster (LH/RH). Refer to SE-38, "Removal and Installation - Rear Seat Bolster".
2. Place the rear seatback assemblies (LH/RH) in the folded down position.
3. Remove the rear parcel shelf finisher. Refer to INT-26, "Exploded View"
.
4. From trunk area release pawls (A) to open cable guide (1).
5. Unclip latch cable (2) at location (B). : Front
NOTE:
LH side shown; RH side similar.
6. Remove two seatback latch assembly bolts and the seatback latch assembly.
INSTALLATION
Installation is in the reverse order of removal.
• Tighten two seatback latch assembly bolts to specification. Refer to SE-33, "Exploded View"
.
ALJIA0940ZZ
ALJIA0948ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SE-38
< REMOVAL AND INSTALLATION >
REAR SEAT
Removal and Installation - Armrest Assembly
INFOID:0000000009462946
REMOVAL
1. Place the rear seatback assembly LH in the folded down position.
2. Remove the armrest hinge fini sher using a suitable tool.
3. Remove the armrest pi vot bolt and the armrest.
INSTALLATION
Installation is in the reverse order of removal.
• Tighten the armrest pivot bolt to specification. Refer to SE-33, "Exploded View"
.
Removal and Installation - Rear Seat BolsterINFOID:0000000009462947
REMOVAL
1. Remove the seat cushion assembly. Refer to SE-36, "Removal and Installation - Seat Cushion Assembly".
2. Remove the seat belt from the seat belt guide.
3. Remove the bolt at bottom of rear seat bolster.
4. Lift the rear seat bolster to remove.
INSTALLATION
Installation is in the reverse order of removal.
• Tighten rear seat bolster bolt to specification. Refer to SE-33, "Exploded View"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

FRONT SEATSE-39
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
UNIT DISASSEMBLY AND ASSEMBLY
FRONT SEAT
DRIVER SIDE
DRIVER SIDE : Exploded ViewINFOID:0000000009462948
DRIVER SEAT - POWER
ALJIA0955ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SE-40
< UNIT DISASSEMBLY AND ASSEMBLY >
FRONT SEAT
1. Seat cushion trim 2. Seat cushion pad 3. Seat cushion heater (if equipped)
4. Seat cushion outer finisher (RH) 5. Seat cushion inner finisher (RH front)6. Seat cushion inner finisher (RH rear)
7. Rear slide cover (RH) 8. Seat belt buckle 9. Slide cover (RH)
10. Front slide cover (RH) 11. Front slide cover (LH) 12. Seat harness
13. Seat cushion outer finisher (LH) 14. Seat slide knob 15. Seat recline knob
16. Lumbar support switch (if equipped) 17. Power seat switch 18. Slide cover (LH)
19. Seat frame assembly 20. Rear slide cover (LH) 21. Seat cushion inner finisher (LH rear)
22. Seat cushion inner finisher (LH front) 23. Rear hinge cover 24. Side air bag module
25. Headrest holder (locked) 26. Headrest holder (free) 27. Seatback assembly
28. Lumbar support assembly (if equipped) 29. Headrest 30. Seatback board
A. Rear hinge cover clips B. Seatback board clips C. Side air bag module nuts
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

FRONT SEATSE-41
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
DRIVER SEAT - MANUAL
ALJIA0956ZZ
1. Seat cushion trim 2. Seat cushion pad 3. Seat cushion heater (if equipped)
4. Seat cushion outer finisher (RH) 5. Seat cushion inner finisher (RH front)6. Seat cushion inner finisher (RH rear)
7. Rear slide cover (RH) 8. Seat belt buckle 9. Slide cover (RH)
10. Front slide cover (RH) 11. Front slide cover (LH) 12. Seat harness
13. Seat frame assembly 14. Slide cover (LH) 15. Seat cushion outer finisher (LH)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
