NISSAN TEANA 2014 Service Manual

TM-286
< BASIC INSPECTION >[CVT: RE0F10E]
CVT FLUID
19. Repeat steps 8 to 18 (one time).
20. Tighten the drain plug to the specified torque. Refer to TM-387, "Exploded View"
.
21. Remove the overflow plug.
22. Install the charging pipe set (KV311039S0) into the overflow plug hole. CAUTION:
Tighten the charging pipe by hand.
23. Install the ATF changer hose to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging pipe until it stops.
24. Fill approximately 3 liter (2-5/8 lmp qt) of the CVT fluid.
25. Remove the ATF changer hose and charging pipe, then install the overflow plug. NOTE:
Perform this work quickly because CVT fluid leaks.
26. Lift down the vehicle.
27. Start the engine.
28. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “DS”, and shift it to the “P” position.
NOTE:
Hold the lever at each position for 5 seconds.
29. Check that the CONSULT “Data Monitor” in “FLUID TEMP” is 35 °C (95 °F) to 45 °C (113 °F).
30. Lift up the vehicle.
31. Remove the overflow plug and confirm that the CV T fluid is drained from the overflow plug hole.
CAUTION:
Perform this work with the vehicle idling.
NOTE:
If the CVT fluid is not drained, refer to “Adjustment” and refill with the CVT fluid.
32. When the flow of CVT fluid slows to a drip, tighten the overflow plug to the specified torque. Refer to TM-
387, "Exploded View".
CAUTION:
Never reuse O-ring.
33. Lift down the vehicle.
34. Select “Data Monitor” in “T RANSMISSION” using CONSULT.
35. Select “CONFORM CVTF DETERIORTN”.
36. Select “Erase”.
37. Stop the engine.
AdjustmentINFOID:0000000009464232
CAUTION:
• During adjustment of the CVT fluid level, check CO NSULT so that the oil temperature may be main-
tained from 35 to 45 °C (95 to 113 °F).
• During adjustment of the CVT fluid level, check that the engine speed is maintaining 500 rpm.
• Use caution when looking into the drain hole as th ere is a risk of dripping fluid entering the eye.
1. Check that the selector lever is in the “P ” position, then completely engage the parking brake.
2. Start the engine.
3. Adjust the CVT fluid temperature to be approximately 40 °C (104 °F).
NOTE:
The CVT fluid is largely affected by temperature. Therefore be sure to use CONSULT and check the
“FLUID TEMP” under “TRANSMISSION” in “Data Monitor” while adjusting.
4. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “DS”, and shift it to the “P” position.
NOTE: CVT fluid : Refer to
TM-413, "General Specification"
.
Fluid capacity : Refer to TM-413, "General Specification"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

CVT FLUIDTM-287
< BASIC INSPECTION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Hold the lever at each position for 5 seconds.
5. Lift up the vehicle.
6. Check that there is no CVT fluid leakage.
7. Remove the overflow plug from converter housing.
8. Install the charging pipe set (KV311039S0) (A) into the overflow plug hole.
CAUTION:
Tighten the charging pipe by hand.
9. Install the ATF changer hose (B) to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
10. Fill approximately 0.5 liter (1 /2 lmp qt) of the CVT fluid.
11. Remove the ATF changer hose from the charging pipe, and check that the CVT fluid drains out from the charging pipe. If it
does not drain out, perform charging again.
CAUTION:
Perform this work with the vehicle idling.
12. When the flow of CVT fluid slows to a drip, re move the charging pipe from the converter housing.
13. Tighten the overflow plug to the specified torque. Refer to TM-387, "Exploded View"
.
CAUTION:
Never reuse O-ring.
14. Lift down the vehicle.
15. Stop the engine.
JSDIA3714ZZ
JSDIA3713ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-288
< BASIC INSPECTION >[CVT: RE0F10E]
STALL TEST
STALL TEST
Work ProcedureINFOID:0000000009464233
INSPECTION
1. Check the engine oil level. Replenish if necessary. Refer to
LU-25, "Inspection".
2. Check for leak of the CVT fluid. Refer to TM-377, "Inspection"
.
3. Drive for about 10 minutes to warm up the vehicle so that the CVT fluid temperature is 50 to 80°C (122 to
176 °F).
4. Be sure to apply the parking brake and block the tires.
5. Start the engine, depress the brake pedal and sh ift the selector lever to “D” position.
6. While depressing the brake pedal, depress the accelerator pedal gradually.
7. Read the stall speed quickly and release your foot from the accelerator pedal quickly. CAUTION:
Do not depress the accelerator pedal for 5 seconds or more during the test.
8. Shift the selector lever to “N” position.
9. Cool the CVT fluid. CAUTION:
Run the engine with the idle speed for at least 1 minute.
10. Put the selector lever to the R position and perform Step 6 to Step 9 again.
NARROWING-DOWN MALFUNCTIONING PARTS
O: Within the stall speed standard value.
H: Stall speed is higher than the standard value.
L: Stall speed is lower than the standard value.
Stall speed : Refer to TM-413, "Stall Speed".
Selector lever position
Possible cause
DR
Stal l s pe ed HO•Forward clutch
O H • Reverse brake
LL •Engine
• Torque converter one way clutch
HH • Line pressure is low.
• Primary pulley
• Secondary pulley
• Chain belt
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

CVT POSITIONTM-289
< BASIC INSPECTION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
CVT POSITION
InspectionINFOID:0000000009464234
1. Turn ON the ignition switch with the shift selector at the “P” position.
2. Press the shift selector button with the brake pedal depressed, and confirm that the shift selector can be
moved to positions other than “P”. Also confirm that movement is not allowed from the “P” position to other
position without depressing the brake pedal.
3. Move the shift selector and check for “excessive effort”, “sticking”, “noise” or “rattle”.
4. Confirm that shift selector stops at each position with the feel of engagement when it is moved through all
the positions. Check whether or not the actual position the shift selector is in matches the position shown
by the transaxle body.
5. Make sure that the shift selector is moved to all the shift posi- tions in the manner shown.
• (A): Press shift selector button to operate shift selector, while depressing the brake pedal.
• (B): Press shift selector button to operate shift selector.
• (C): Shift selector can be operated without pressing the shift selector button.
6. When the shift selector button is pressed without applying for- ward/backward force to the shift selector at “P”, “R”, “N”, “D” or
“Ds” positions, there should be no “sticking” on the shift selector
button operation.
7. Check that the back-up lamps do not illuminate when the shift selector is in the “P” position.
8. Check that the engine can be started with the sh ift selector in the “P” and “N” positions only.
9. Check that the transaxle is locked completely when the shift selector is in the “P” position.
AdjustmentINFOID:0000000009464235
1. Shift the shift selector to the “P” position.
CAUTION:
Turn wheels at least a quarter turn and be certain the park position mechanism is fully engaged.
2. Loosen the control cable nut. CAUTION:
Do not apply force to the manual lever.
3. Position the manual lever in the “P” position.
4. Tighten the control cable nut to specified torque. Refer to TM-
380, "Exploded View".
CAUTION:
Hold manual lever when tightening.
AWDIA1019ZZ
JSDIA1875ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-290
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
U0073 COMMUNICATION BUS A OFF
DTC/CIRCUIT DIAGNOSIS
U0073 COMMUNICATION BUS A OFF
DTC LogicINFOID:0000000009464236
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROCEDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for at least 5 seconds.
2. Check the DTC.
Is
“U0073” detected?
YES >> Go to TM-290, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464237
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U0073 COMM BUS A OFF
(Control Module Communica-
tion Bus A Off) TCM communication blockage lasts for 2 sec-
onds or more when turning ON the ignition
switch. (Communication not established.) Harness or connector
(CAN communication line is error)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

U0100 LOST COMMUNICATION (ECM A)TM-291
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U0100 LOST COMMUNICATION (ECM A)
DTC LogicINFOID:0000000009464238
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROC EDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for at least 5 seconds.
2. Check the DTC.
Is
“U0100” detected?
YES >> Go to TM-291, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464239
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U0100 LOST COMM (ECM A)
(Lost Communication With
ECM/PCM A ) When the ignition switch is ON, TCM is un-
able to receive the CAN communications
signal from ECM continuously for 2 sec-
onds or more. •ECM
• Harness or connector (CAN communication line is open or
shorted)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-292
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
U0140 LOST COMMUNICATION (BCM)
U0140 LOST COMMUNICATION (BCM)
DTC LogicINFOID:0000000009464240
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROCEDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Start the engine and wait for at least 5 seconds.
2. Check the DTC.
Is
“U0140” detected?
YES >> Go to TM-292, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464241
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U0140 LOST COMM (BCM)
(Lost Communication With
Body Control Module) When the ignition switch is ON, TCM is unable
to receive the CAN communications signal
from BCM continuously for 2 seconds or more. •BCM
• Harness or connector (CAN communication line is open or
shorted)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

U0141 LOST COMMUNICATION (BCM A)TM-293
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U0141 LOST COMMUNICATION (BCM A)
DTC LogicINFOID:0000000009464242
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROC EDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Start the engine and wait for at least 5 seconds.
2. Check the DTC.
Is
“U0141” detected?
YES >> Go to TM-293, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464243
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U0141 LOST COMM (BCM A)
(Lost Communication With
Body Control Module A) When the ignition switch is turned ON, TCM
continues no reception of the CAN communi-
cation signal from IPDM E/R for 2 seconds or
more. • IPDM E/R
• Harness or connector (CAN communication line is open or
shorted)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-294
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
U0155 LOST COMMUNICATION (IPC)
U0155 LOST COMMUNI
CATION (IPC)
DTC LogicINFOID:0000000009464244
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROCEDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for at least 5 seconds.
2. Check the DTC.
Is
“U0155” detected?
YES >> Go to TM-294, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464245
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
[Trouble diagnosis content] DTC detection condition Possible causes
U0155 LOST COMM (IPC)
[Lost Communication With In-
strument Panel Cluster (IPC)
Control Module] When the ignition switch is ON, TCM is unable
to receive the CAN communications signal
from the combination meter continuously for 2
seconds or more. • Combination meter
• Harness or connector (CAN communication line is open or
shorted)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

U0300 CAN COMMUNICATION DATATM-295
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U0300 CAN COMMUNICATION DATA
DTC LogicINFOID:0000000009464246
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROC EDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine and wait for 5 seconds or more.
2. Check the DTC.
Is
“U0300” detected?
YES >> Go to TM-295, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464247
1.CONTROL UNIT CHECK
Check the number of control units replaced before “U0300” is detected.
Is one control unit replaced?
YES >> The specification of the control unit replac ed may be incorrect. Check the part number and the
specification.
NO >> GO TO 2.
2.CONTROL UNIT CHECK
With CONSULT
1. Remove one of the control unit replaced.
2. Assemble the old control unit before replacement.
3. Turn ignition switch ON, and wait for 2 seconds or more.
4. Select “Self Diagnostic Results” in “TRANSMISSION”.
Is
“U0300”detected?
YES >> Turn OFF the ignition switch and check other control units in the same manner.
NO >> The specification of the control unit remov ed may be incorrect. Check the part number and the
specification.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U0300 CAN COMM DATA
(Internal Control Module Soft-
ware Incompatibility) When the ignition switch is ON, the data length
transmitted from each control unit is shorter
than the specified length and the status contin-
ues for 2 seconds or more. Control unit other than TCM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
