TM-296
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464248
CAN (Controller Area Network) is a serial communication
line for real- NISSAN TEANA 2014 Service Manual
TM-296
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464248
CAN (Controller Area Network) is a serial communication
line for real-](/img/5/57390/w960_57390-4510.png)
TM-296
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464248
CAN (Controller Area Network) is a serial communication
line for real-time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent malfunction detection ability.
Many electronic control units are equipped onto a vehi cle, and each control unit shares information and links
with other control units during operation (not independently ). In CAN communication, control units are con-
nected with 2 communication lines (CAN-H line, CAN-L li ne) allowing a high rate of information transmission
with less wiring. Each control unit transmits/recei ves data but selectively reads required data only.
DTC LogicINFOID:0000000009464249
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROCEDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine and wait for at least 5 seconds.
2. Check the DTC.
Is
“U1000” detected?
YES >> Go to TM-296, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464250
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U1000 CAN COMM CIRCUIT
(CAN Communication Line) When the ignition switch is ON, TCM cannot
send the CAN communication signal continu-
ously for 2 seconds or more. Harness or connector
(CAN communication line is open or
shorted)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4512 of 4801
![NISSAN TEANA 2014 Service Manual
U1117 LOST COMMUNICATION (ABS)TM-297
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U1117 LOST COMMUNICATION (ABS)
DTC LogicINFOID:0000000009464251
DTC DETECTION LOGIC
DTC NISSAN TEANA 2014 Service Manual
U1117 LOST COMMUNICATION (ABS)TM-297
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U1117 LOST COMMUNICATION (ABS)
DTC LogicINFOID:0000000009464251
DTC DETECTION LOGIC
DTC](/img/5/57390/w960_57390-4511.png)
U1117 LOST COMMUNICATION (ABS)TM-297
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U1117 LOST COMMUNICATION (ABS)
DTC LogicINFOID:0000000009464251
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Start the engine and wait for 5 seconds or more.
2. Check the DTC.
Is
“U 111 7” detected?
YES >> Go to TM-297, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464252
For the diagnosis procedure, refer to LAN-18, "Trouble Diagnosis Flow Chart".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
U 111 7 LOST COMM (ABS)
(Lost Communication With
ABS) When the ignition switch is ON, TCM is unable
to receive the CAN communications signal
from ABS actuator and electric unit (control
unit) continuously for 2 seconds or more. • ABS actuator and electric unit (control
unit)
• Harness or connector (CAN communication line is open or
shorted)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4513 of 4801
![NISSAN TEANA 2014 Service Manual
TM-298
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P062F EEPROM
P062F EEPROM
DescriptionINFOID:0000000009464253
TCM compares the calculated value stored in the flash
ROM with the value stored in TCM. If NISSAN TEANA 2014 Service Manual
TM-298
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P062F EEPROM
P062F EEPROM
DescriptionINFOID:0000000009464253
TCM compares the calculated value stored in the flash
ROM with the value stored in TCM. If](/img/5/57390/w960_57390-4512.png)
TM-298
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P062F EEPROM
P062F EEPROM
DescriptionINFOID:0000000009464253
TCM compares the calculated value stored in the flash
ROM with the value stored in TCM. If the calculated
value does not agree with the stored value, TCM judges this as a malfunction.
DTC LogicINFOID:0000000009464254
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Check the DTC.
Is
“P062F” detected?
YES >> Go to TM-298, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464255
1.CHECK INTERMITTENT INCIDNT
Refer to GI-43, "Intermittent Incident"
.
Is the inspection result normal?
YES >> Replace the TCM. Refer to TM-384, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P062F EEPROM
(Internal Control Module EE-
PROM Error) Flash ROM error is detected when turning ON
the ignition switch. • TCM (Flash ROM)
• Harness or connector
[TCM power supply (b ack-up) circuit is
open or shorted]
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4514 of 4801
![NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-299
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0705 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464256
DTC DETECTION LOGI NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-299
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0705 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464256
DTC DETECTION LOGI](/img/5/57390/w960_57390-4513.png)
P0705 TRANSMISSION RANGE SENSOR ATM-299
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0705 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464256
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Turn ignition switch ON.
2. Shift the selector lever through entire positions from “P” to “DS”. (Hold the selector lever at each position
for 5 seconds or more.)
3. Check the first trip DTC.
Is
“P0705” detected?
YES >> Go to TM-299, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464257
1.CHECK TCM INPUT SIGNALS
With CONSULT
1. Turn ignition switch ON.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “D POSITION SW”, “N POSITION SW”, “R POSITION SW”, “P POSITION SW” and “DS RANGE
SW”.
4. Shift the selector lever through entire positions from “P” to “DS” and check ON/OFF of each monitor item.
Without CONSULT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0705 T/M RANGE SENSOR A
[Transmission Range Sensor
A Circuit (PRNDL Input)] When all of the following conditions are satis-
fied and this state is maintained for 2 seconds:
• Two or more range signals simultaneously stay ON continuously
• TCM power supply voltage: More than 11 V • Harness or connector
(Short circuit between transmission
range switch and TCM)
• Transmission range switch
Monitor item Test condition Condition
D POSITION SW Selector lever: “D” position On
Other than the above Off
N POSITION SW Selector lever: “N” position On
Other than the above Off
R POSITION SW Selector lever: “R” position On
Other than the above Off
P POSITION SW Selector lever: “P” position On
Other than the above Off
DS RANGE SW Selector lever: “DS” position On
Other than the above Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4515 of 4801
![NISSAN TEANA 2014 Service Manual
TM-300
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
3. Turn ignition switch ON.
4. Shift the selector lever from “P” to “DS” and check voltage between TCM harn NISSAN TEANA 2014 Service Manual
TM-300
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
3. Turn ignition switch ON.
4. Shift the selector lever from “P” to “DS” and check voltage between TCM harn](/img/5/57390/w960_57390-4514.png)
TM-300
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
3. Turn ignition switch ON.
4. Shift the selector lever from “P” to “DS” and check voltage between TCM harness connector terminals and
ground.
Is the inspection result normal?
YES >> Check intermitt ent incident. Refer to GI-43, "Intermittent Incident".
NO-1 [“D POSITION SW” is “ON” when selector is not in “D” position. (Or connector terminal 4 is at power
voltage.)]>>GO TO 2.
NO-2 [“N POSITION SW” is “ON” when selector is not in “N” position. (Or connector terminal 5 is at power
voltage.)]>>GO TO 4.
NO-3 [“R POSITION SW” is “ON” when selector is not in “R” position. (Or connector terminal 6 is at power
voltage.)]>>GO TO 6.
NO-4 [“P POSITION SW” is “ON” when selector is not in “P” position. (Or connector terminal 7 is at power
voltage.)]>>GO TO 8.
NO-5 [“DS POSITION SW” is “ON” w hen selector is not in “DS” position. (Or connector terminal 2 is at power
voltage.)]>>GO TO 10.
2.CHECK D POSITION SW CIRCUIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK D POSITION SW CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON.
3. Check voltage between TCM harness connector terminal and ground.
+
−Test condition Voltage
TCM
Connector Terminal
F16 2
Ground Selector lever: “ DS” position 10 – 16 V
Other than the above Approx. 0 V
4 Selector lever: “D” position 10 – 16 V
Other than the above Approx. 0 V
5 Selector lever: “N” position 10 – 16 V
Other than the above Approx. 0 V
6 Selector lever: “R” position 10 – 16 V
Other than the above Approx. 0 V
7 Selector lever: “P” position 10 – 16 V
Other than the above Approx. 0 V
TCM Continuity
Connector Terminal
F16 4 2
Not existed
5
6
7
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4516 of 4801
![NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-301
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctio NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-301
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctio](/img/5/57390/w960_57390-4515.png)
P0705 TRANSMISSION RANGE SENSOR ATM-301
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctioning parts.
4.CHECK N POSITION SW CIRCUIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts.
5.CHECK N POSITION SW CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON.
3. Check voltage between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctioning parts.
6.CHECK P POSITION SW CIRCUIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace malfunctioning parts.
+
−Vo l ta g e
TCM
Connector Terminal F16 4 Ground Approx. 0 V
TCM Continuity
Connector Terminal
F16 5 2
Not existed
4
6
7
+ −Vo l ta g e
TCM
Connector Terminal F16 5 Ground Approx. 0 V
TCM Continuity
Connector Terminal
F16 7 2
Not existed
4
5
6
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4517 of 4801
![NISSAN TEANA 2014 Service Manual
TM-302
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
7.CHECK P POSITION SW CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON NISSAN TEANA 2014 Service Manual
TM-302
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
7.CHECK P POSITION SW CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON](/img/5/57390/w960_57390-4516.png)
TM-302
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
7.CHECK P POSITION SW CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON.
3. Check voltage between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctioning parts.
8.CHECK R POSITION SW CIRCUIT (PART1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace malfunctioning parts.
9.CHECK R POSITION SW CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON.
3. Check voltage between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctioning parts.
10.CHECK DS POSITION SWITCH CIRCUIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM harness connector terminals.
+
−Vo l ta g e
TCM
Connector Terminal F16 7 Ground Approx. 0 V
TCM Continuity
Connector Terminal
F16 6 2
Not existed
4
5
7
+ −Vo l ta g e
TCM
Connector Terminal F16 6 Ground Approx. 0 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4518 of 4801
![NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-303
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace malfunctio NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-303
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace malfunctio](/img/5/57390/w960_57390-4517.png)
P0705 TRANSMISSION RANGE SENSOR ATM-303
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace malfunctioning parts.
11 .CHECK DS POSITION SWITCH CIRCUIT (PART 2)
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON.
3. Check voltage between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace malfunctioning parts.
12.CHECK TRANSMISSI ON RANGE SWITCH
Check transmission range switch. Refer to TM-303, "Component Inspection"
.
Is the check result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component InspectionINFOID:0000000009464258
1.CHECK TRANSMISSION RANGE SWITCH
Check continuity between transmissi on range switch connector terminals.
Is the inspection result normal?
TCM Continuity
Connector Terminal
F16 2 4
Not existed
5
6
7
+ −Vo l ta g e
TCM
Connector Terminal F16 2 Ground Approx. 0 V
Transmission range switch Condition Continuity
Te r m i n a l
1 – 2 Manual lever: “P” and “N” positions Existed
Other than the above Not existed
3 – 4 Manual lever: “P” position Existed
Other than the above Not existed
3 – 5 Manual lever: “R” position Existed
Other than the above Not existed
3 – 6 Manual lever: “N position Existed
Other than the above Not existed
3 – 7 Manual lever: “D” position Existed
Other than the above Not existed
3 – 8 Manual lever: “DS” position Existed
Other than the above Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4519 of 4801
![NISSAN TEANA 2014 Service Manual
TM-304
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
YES >> INSPECTION END
NO >> There is a malfunction of transmission range switch. Replace transaxle assembly. Refer t NISSAN TEANA 2014 Service Manual
TM-304
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
YES >> INSPECTION END
NO >> There is a malfunction of transmission range switch. Replace transaxle assembly. Refer t](/img/5/57390/w960_57390-4518.png)
TM-304
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0705 TRANSMISSION
RANGE SENSOR A
YES >> INSPECTION END
NO >> There is a malfunction of transmission range switch. Replace transaxle assembly. Refer to TM-
407, "Removal and Installation".
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4520 of 4801
![NISSAN TEANA 2014 Service Manual
P0706 TRANSMISSION RANGE SENSOR ATM-305
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0706 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464259
DTC DETECTION LOGI NISSAN TEANA 2014 Service Manual
P0706 TRANSMISSION RANGE SENSOR ATM-305
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0706 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464259
DTC DETECTION LOGI](/img/5/57390/w960_57390-4519.png)
P0706 TRANSMISSION RANGE SENSOR ATM-305
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0706 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464259
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Shift the selector lever through entire positions from “P” to “DS”. (Hold the selector lever at each position
for 40 seconds or more.)
3. Check the first trip DTC.
Is
“P0706” detected?
YES >> Go to TM-305, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464260
1.ADJUSTMENT OF CONTROL CABLE
Adjust control cable. Refer to TM-289, "Adjustment"
.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” in “TRANSMISSION”.
3. Touch “Erase”.
4. Perform “DTC CONFIRMATION PROCEDURE". Refer to TM-305, "DTC Logic"
.
Is
“P0706” detected?
YES >> GO TO 3.
NO >> INSPECTION END
3.CHECK POWER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect transmission range switch connector.
3. Turn ignition switch ON.
4. Check voltage between transmission range switch harness connector terminal and ground.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0706 T/M RANGE SENSOR A
(Transmission Range Sensor
A Circuit Range/Performance) When all of the following conditions are satis-
fied and this state is maintained for 30 sec-
onds:
• All range signals stay OFF
• TCM power supply voltage: More than 11 V • Harness or connector
(Open circuit between ignition switch
and transmission range switch/open
circuit between transmission range
switch and TCM)
• Transmission range switch
• Control cable
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
