Page 1539 of 5883
EC-190
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0300, P0301, P0302, P0303, P0304 MISFIRE
P0300, P0301, P0302, P0303, P0304 MISFIRE
DTC LogicINFOID:0000000001670954
DTC DETECTION LOGIC
When a misfire occurs, engine speed will fluctuate. If the engine speed fluctuates enough to cause the crank-
shaft position (CKP) sensor (POS) signal to vary, ECM can determine that a misfire is occurring.
The misfire detection logic consists of the following two conditions.
1. One Trip Detection Logic (Three Way Catalyst Damage)
On the 1st trip that a misfire condition occurs that can damage the three way catalyst (TWC) due to over-
heating, the MI will blink.
When a misfire condition occurs, the ECM monitors the CKP sensor signal every 200 engine revolutions
for a change.
When the misfire condition decreases to a level that will not damage the TWC, the MI will turn off.
If another misfire condition occurs that can damage the TWC on a second trip, the MI will blink.
When the misfire condition decreases to a level that will not damage the TWC, the MI will remain on.
If another misfire condition occurs that can damage the TWC, the MI will begin to blink again.
2. Two Trip Detection Logic (Exhaust quality deterioration)
For misfire conditions that will not damage the TWC (but will affect vehicle emissions), the MI will only light
when the misfire is detected on a second trip. During this condition, the ECM monitors the CKP sensor
signal every 1,000 engine revolutions.
A misfire malfunction can be detected on any one cylinder or on multiple cylinders.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Restart engine and let it idle for about 15 minutes.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-191, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
1. Turn ignition switch OFF and wait at least 10 seconds.
Sensor Input signal to ECM ECM function
Crankshaft position sensor (POS) Engine speed On board diagnosis of misfire
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0300 Multiple cylinder misfire detected Multiple cylinder misfire. Improper spark plug
Insufficient compression
Incorrect fuel pressure
The fuel injector circuit is open or shorted
Fuel injector
Intake air leak
The ignition signal circuit is open or shorted
Lack of fuel
Signal plate
Heated oxygen sensor 1
Incorrect PCV hose connection P0301 No.1 cylinder misfire detected No. 1 cylinder misfires.
P0302 No. 2 cylinder misfire detected No. 2 cylinder misfires.
P0303 No. 3 cylinder misfire detected No. 3 cylinder misfires.
P0304 No. 4 cylinder misfire detected No. 4 cylinder misfires.
Page 2204 of 5883
P0300, P0301, P0302, P0303, P0304 MISFIRE
EC-855
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0300, P0301, P0302, P0303, P0304 MISFIRE
DTC LogicINFOID:0000000001161823
DTC DETECTION LOGIC
When a misfire occurs, engine speed will fluctuate. If the engine speed fluctuates enough to cause the crank-
shaft position (CKP) sensor (POS) signal to vary, ECM can determine that a misfire is occurring.
The misfire detection logic consists of the following two conditions.
1. One Trip Detection Logic (Three Way Catalyst Damage)
On the 1st trip that a misfire condition occurs that can damage the three way catalyst (TWC) due to over-
heating, the MI will blink.
When a misfire condition occurs, the ECM monitors the CKP sensor signal every 200 engine revolutions
for a change.
When the misfire condition decreases to a level that will not damage the TWC, the MI will turn off.
If another misfire condition occurs that can damage the TWC on a second trip, the MI will blink.
When the misfire condition decreases to a level that will not damage the TWC, the MI will remain on.
If another misfire condition occurs that can damage the TWC, the MI will begin to blink again.
2. Two Trip Detection Logic (Exhaust quality deterioration)
For misfire conditions that will not damage the TWC (but will affect vehicle emissions), the MI will only light
when the misfire is detected on a second trip. During this condition, the ECM monitors the CKP sensor
signal every 1,000 engine revolutions.
A misfire malfunction can be detected on any one cylinder or on multiple cylinders.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Restart engine and let it idle for about 15 minutes.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-856, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
1. Turn ignition switch OFF and wait at least 10 seconds.
Sensor Input signal to ECM ECM function
Crankshaft position sensor (POS) Engine speed On board diagnosis of misfire
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0300 Multiple cylinder misfire detected Multiple cylinder misfire. Improper spark plug
Insufficient compression
Incorrect fuel pressure
The fuel injector circuit is open or shorted
Fuel injector
Intake air leak
The ignition signal circuit is open or shorted
Lack of fuel
Signal plate
Heated oxygen sensor 1
Incorrect PCV hose connection P0301 No.1 cylinder misfire detected No. 1 cylinder misfires.
P0302 No. 2 cylinder misfire detected No. 2 cylinder misfires.
P0303 No. 3 cylinder misfire detected No. 3 cylinder misfires.
P0304 No. 4 cylinder misfire detected No. 4 cylinder misfires.
Page 2413 of 5883
EC-1064
< FUNCTION DIAGNOSIS >[K9K]
FUEL INJECTION CONTROL
energy returned by the piezo actuator is reused, which keeps down the amount of energy that has to be sup-
plied for the next injection process.
Engine Synchronisation
One of the determining factors for fuel injection control is knowing the position of each of the pistons in their
respective cylinders at all times.
The angular position is measured by means of a magneto-inductive sensor which is excited by the teeth
machined onto the flywheel; this is known as the crankshaft position sensor. The flywheel has 60 teeth, each 6
degrees apart; 2 of these teeth are missing to form a notch.
A second sensor (Hall-effect sensor), stimulated by a tooth machined onto the camshaft, which turns at half
the engine speed, provides a signal relating to the progress of the injection cycle. Indeed, when the piston of
cylinder 1 is at top dead centre (TDC), either at the end of the compression stroke or at the end of the exhaust
stroke, the camshaft position sensor enables a distinction to be made between these two states.
By comparing the signals from these two sensors, the computer is able to provide all its systems with synchro-
nisation parameters, namely: the angular position of the flywheel, engine speed, the number of the active fuel
injector and the progress of the injection cycle.
This module also supplies the system with the rotation speed signal.
The camshaft position sensor is only used when starting the engine. As soon as the engine is running by itself
(not being cranked by the starter), the signal provided by the crankshaft position sensor is sufficient. If the
camshaft position sensor should fail while the engine is running, this will not affect the operation of the engine.
Quantity of Fuel Injected and Control of Start of Injection
The parameters for controlling injection are, for each cylinder, the quantity to be injected and the start of
injection. These are calculated by the ECM from the following information:
- Engine speed.
- Accelerator pedal position.
- Turbocharge air pressure.
- Engine coolant temperature.
- Intake air temperature.
- Fuel pump temperature.
- Mass air flow.
- Pressure of fuel in the rail.
Station to Station Flow Regulation
The aim of this regulation process is to facilitate smooth engine operation by compensating for the system
variations (fuel injectors, compression rate, etc.) which affect the torque generated by each cylinder during
combustion.
The regulation process is only active at idle speed, with a warm engine and on condition that the engine speed
is sufficiently stable. An injection timing correction coefficient is assigned to each cylinder; this is "learning" all
the time the regulation process is active and remains fixed at the last value that was learned when the regula-
tion is inactive.
At each new cycle, the coefficients are initialised to 1.
Cylinder Balancing Control
This controller allows smooth behavior of running engine, reduction of noise and oscillations in the drivetrain
by compensating for system dispersions (fuel injectors, compression ratio, manufacturing tolerances of cylin-
ders or valves...) having an influence on the torque generated by each cylinder during combustion.
The controller is only activated if engine is in idle, warm and not too rough. Corrective coefficient on the injec-
tion time is associated with each cylinder that is learnt as soon as the regulation is active. Otherwise it remains
with its last memorized value.
At each new driving cycle, coefficients are initialized to 1.
Page 2648 of 5883
EM-1
ENGINE
C
D
E
F
G
H
I
J
K
L
M
SECTION EM
A
EM
N
O
P
CONTENTS
ENGINE MECHANICAL
HR16DE
SYMPTOM DIAGNOSIS ...............................
5
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING .............................
5
NVH Troubleshooting - Engine Noise .......................5
Use the Chart Below to Help You Find the Cause
of the Symptom .........................................................
6
PRECAUTION ...............................................7
PRECAUTIONS ...................................................7
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
7
Precaution for Procedure without Cowl Top Cover ......7
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .....................................
7
Precaution for Drain Coolant .....................................8
Precaution for Disconnecting Fuel Piping .................8
Precaution for Removal and Disassembly ................8
Precaution for Inspection, Repair and Replace-
ment ..........................................................................
8
Precaution for Assembly and Installation ..................8
Parts Requiring Angular Tightening ..........................8
Precaution for Liquid Gasket .....................................9
PREPARATION ...........................................11
PREPARATION ..................................................11
Special Service Tools ..............................................11
Commercial Service Tools ......................................12
ON-VEHICLE MAINTENANCE ....................15
DRIVE BELTS ....................................................15
Checking .................................................................15
Tension Adjustment ................................................15
Removal and Installation .........................................16
AIR CLEANER FILTER ......................................18
Removal and Installation .........................................18
SPARK PLUG ...................................................19
Exploded View .........................................................19
Removal and Installation .........................................19
CAMSHAFT VALVE CLEARANCE ..................21
Inspection and Adjustment ......................................21
COMPRESSION PRESSURE ...........................24
Inspection ................................................................24
ON-VEHICLE REPAIR .................................25
DRIVE BELT IDLER PULLEY ..........................25
Exploded View .........................................................25
Removal and Installation .........................................25
AIR CLEANER AND AIR DUCT .......................27
Exploded View .........................................................27
Removal and Installation .........................................27
Inspection ................................................................28
INTAKE MANIFOLD .........................................29
Exploded View .........................................................29
Removal and Installation .........................................29
EXHAUST MANIFOLD ......................................32
Exploded View .........................................................32
Removal and Installation .........................................32
FUEL INJECTOR AND FUEL TUBE ................35
Exploded View .........................................................35
Removal and Installation .........................................35
Inspection ................................................................39
OIL PAN (LOWER) ...........................................40
Exploded View .........................................................40
Removal and Installation .........................................40
Inspection ................................................................41
OIL PAN (UPPER) AND OIL STRAINER .........42
Component ..............................................................42
Page 2650 of 5883
EM-3
C
D
E
F
G
H
I
J
K
L
M
EMA
N
O
P Component ............................................................
145
Removal and Installation .......................................145
CAMSHAFT VALVE CLEARANCE .................148
Valve Clearance ....................................................148
COMPRESSION PRESSURE ..........................151
Checking Compression Pressure ..........................151
ON-VEHICLE REPAIR ...............................153
DRIVE BELT AUTO TENSIONER ...................153
Component ............................................................153
Removal and Installation of Drive Belt Auto Ten-
sioner ....................................................................
153
AIR CLEANER AND AIR DUCT ......................154
Component ............................................................154
Removal and Installation .......................................154
INTAKE MANIFOLD .........................................156
Component ............................................................156
Removal and Installation .......................................156
EXHAUST MANIFOLD .....................................159
Component ............................................................159
Removal and Installation .......................................159
FUEL INJECTOR AND FUEL TUBE ...............162
Component ............................................................162
Removal and Installation .......................................162
OIL PAN ...........................................................166
Component ............................................................166
Removal and Installation .......................................166
IGNITION COIL ................................................172
Component ............................................................172
Removal and Installation .......................................172
ROCKER COVER .............................................173
Component ............................................................173
Removal and Installation .......................................173
TIMING CHAIN .................................................176
Component ............................................................176
Removal and Installation .......................................177
CAMSHAFT ......................................................186
Component ............................................................186
Removal and Installation .......................................186
OIL SEAL .........................................................195
Removal and Installation of Valve Oil Seal ...........195
Removal and Installation of Front Oil Seal ............195
Removal and Installation of Rear Oil Seal ............196
CYLINDER HEAD ............................................198
Component ............................................................198
Removal and Installation .......................................198
Component ............................................................200
Disassembly and Assembly ..................................200
Inspection After Disassembly ................................202
REMOVAL AND INSTALLATION .............207
ENGINE ASSEMBLY ......................................207
Component ............................................................207
Removal and Installation .......................................207
DISASSEMBLY AND ASSEMBLY ............211
ENGINE UNIT ..................................................211
Component ............................................................211
Disassembly and Assembly ...................................212
Inspection After Disassembly ................................219
HOW TO SELECT PISTON AND BEARING ..230
How to Select Piston and Bearing .........................230
SERVICE DATA AND SPECIFICATIONS
(SDS) ..........................................................
238
SERVICE DATA AND SPECIFICATIONS
(SDS) ...............................................................
238
Standard and Limit ................................................238
K9K
SYMPTOM DIAGNOSIS ............................
249
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING .........................
249
NVH Troubleshooting - Engine Noise ....................249
Use the Chart Below to Help You Find the Cause
of the Symptom .....................................................
250
PRECAUTION ............................................251
PRECAUTIONS ...............................................251
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...............................................................
251
Precaution for Procedure without Cowl Top Cover ..251
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .................................
251
Precaution for Drain Coolant .................................252
Precaution for Disconnecting Fuel Piping ..............252
Precaution for Removal and Disassembly .............252
Precaution for Inspection, Repair and Replace-
ment .......................................................................
252
Precaution for Assembly and Installation ..............252
Parts Requiring Angular Tightening .......................252
Precaution for Liquid Gasket .................................253
Precaution for Diesel Equipment ...........................253
Installation of Thread Inserts .................................257
PREPARATION .........................................258
PREPARATION ...............................................258
Special Service Tools ............................................258
Commercial Service Tools .....................................260
ON-VEHICLE MAINTENANCE ..................263
Page 2769 of 5883
EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000001381439
GENERAL SPECIFICATIONS
Drive BeltsINFOID:0000000001381440
BELT DEFLECTION:
*: When engine is cold.
BELT TENSION AND FREQUENCY:
Engine typeHR16DE
Cylinder arrangementIn-line 4
Displacement cm
3 (cu in)1,598 (97.51)
Bore and stroke mm (in)78.0 x 83.6 (3.071 x 3.291)
Valve arrangementDOHC
Firing order1-3-4-2
Number of piston ringsCompression 2
Oil 1
Number of main bearings5
Compression ratio10.7
Compression pressure
kPa (bar, kg/cm
2, psi)/200 rpmStandard 1,510 (15.1, 15.4, 219)
Minimum 1,265 (12.65, 12.9, 183)
Differential limit between cylinders 6.2 (0.06, 0.06, 0.9)
Valve timing
(Intake valve timing control - “ON”)
Unit: degree
abcde f
208 228 -11 (24) 59 (24) 4 24
JPBIA0552ZZ
LocationDeflection adjustment * Unit: mm (in)
Used belt
New belt
Limit After adjusted
Drive beltWith A/C models 7.9 (0.31) 4.8 - 5.3 (0.19 - 0.21) 4.2 - 4.5 (0.17 - 0.18)
Without A/C models 7.1 (0.28) 4.3 - 4.7 (0.17 - 0.19) 3.6 - 3.9 (0.14 - 0.15)
Applied pushing force 98 N (10 kg, 22 lb)
Page 2885 of 5883
EM-238
< SERVICE DATA AND SPECIFICATIONS (SDS) [MR18DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000001337815
GENERAL SPECIFICATIONS
DRIVE BELT
WATER CONTROL VALVE
EXHAUST MANIFOLD
Unit: mm (in)
THERMOSTAT
SPARK PLUG
Unit: mm (in)
CYLINDER HEAD
Engine typeMR18DE
Cylinder arrangementIn-line 4
Displacement
cm
3 (cu in)1,798 (109.71)
Bore and stroke mm (in) 84.0 x 81.1 (3.307 x 3.192)
Valve arrangementDOHC
Firing order1-3-4-2
Number of piston ringsCompression 2
Oil 1
Compression ratio9.9
Compression pressure
kPa (bar, kg/cm
2 , psi) / 250 rpmStandard 1,500 (15.0, 15.3, 217.6)
Minimum 1,200 (12.0, 12.2, 174)
Differential limit between cylinders 100 (1.0, 1.0, 15)
Tension of drive belt Auto adjustment by auto-tensioner
Valve opening temperature 93.5 - 96.5°C (200 - 206°F)
Maximum valve lift 8 mm/ 108°C (0.315 in/ 226°F)
Valve closing temperature More than 90°C (194°F)
Items Limit
Surface distortionEach exhaust port 0.3 (0.012)
Entire part 0.7 (0.028)
Valve opening temperature 80.5 - 83.5°C (177 - 182°F)
Maximum valve lift 8 mm/ 95°C (0.315 in/ 203°F)
Valve closing temperature More than 77°C (171°F)
Plug typePlatinum-tipped TYPE
MakeNGK
Standard typePLZKAR6A-11
Spark plug gapNominal: 1.1 (0.043)
Page 2907 of 5883
EM-260
< PREPARATION >[K9K]
PREPARATION
Commercial Service Tools
INFOID:0000000001381460
KV113B0220
(Mot. 1586)
Front oil seal drift setTool for installing crankshaft seals, timing end
KV113B0230
(Mot. 1632)
Camshaft seal insertTool for installing inlet camshaft seals
KV113B0240
(Rou. 15-01)
Shaft protectorInternal shaft protector
16 mm (0.63 in) dia.
KV113B0400
(Mot. 1592)
Compression gauge attachmentConnecting compression gauge and glow
plug holex
—
(Mot. 1606-A)
Camshaft pulley holderTool for locking sprockets for toothed timing
belt
—
(Mot. 1638)
Belt tension gaugeSetting drive belt tension NISSAN tool number
(RENAULT tool No.)
Tool nameDescription
MBIB0712E
E1BIA0053ZZ
MBIB0382E
NISSAN tool number
(RENAULT tool No.)
Tool nameDescription
KV113B0030
(Mot. 11)
Crankshaft bearing removerCrankshaft bearing extractor
KV113B0040
(Mot. 251-01)
Dial gauge stand setGauge stand used with KV113B0050 (Mot.
252-01)
MBIB0359E
MBIB0360E
Page 2980 of 5883
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-333
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000001381516
GENERAL SPECIFICATIONS
Drive BeltINFOID:0000000001381517
DRIVE BELT
CamshaftINFOID:0000000001381518
CAMSHAFT
Unit: mm (in)
Cylinder arrangement In-line 4
Displacement cm
3 (cu in)1.461 (89.15)
Bore and stroke mm (in)76 x 80.5 (2.99 x 3.17)
Valve arrangementSOHC
Firing order1-3-4-2
Number of piston ringsCompression 2
Oil 1
Number of main bearings5
Compression ratio15.3
Compression pressure kPa (bar, kg/cm
2, psi)Maximum pressure must be at least 1,800
(18, 18.36, 261)
Valve timing
abcde f
200°191°-9°20°-7°27°
PBIC0187E
Tension of drive belt Auto adjustment by auto-tensioner
Items Standard
Camshaft bracket inner diameterNo. 1, 2, 3, 4, 5 25.04 - 25.06 (0.9858 - 0.9866)
No. 6 28.04 - 28.06 (1.1039 - 1.1047)
Camshaft journal diameterNo. 1, 2, 3, 4, 5 24.979 - 25.000 (0.9834 - 0.9843)
No. 6 27.979 - 28.000 (1.1015 - 1.1024)
Camshaft end play 0.080 - 0.178 (0.0031 - 0.0070)
Camshaft runoutLess than 0.05 (0.0020)
