NISSAN TIIDA 2009 Service Manual PDF

(HR16DE), EC- 570 (MR Type 1)
or EC-1082 (MR
Type 2)
2. Accelerator pedal position sensor EC-412 (MR Type
1) or EC-1481
(MR Type 2)
3. Line pressure test AT-51 4. A/T fluid temperature sensor
AT-96 5. Engine speed signal
AT-106 6. Line pressure solenoid valve
AT-134 7. Control valve assembly
AT-221 8. Accumulator N-D
AT-221 OFF vehicle 9. Forward clutch
AT-306Too sharp a shock in
changing from D 1 to
D 2 . ON vehicle1. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Line pressure test AT-51 3. Accumulator servo release
AT-221 4. Control valve assembly
AT-221 5. A/T fluid temperature sensor
AT-96 OFF vehicle 6. Brake band
AT-330Items Symptom Condition Diagnostic item Reference page

AT
N
O P
Shift Shock
Too sharp a shock in
changing from D 2
to
D 3 . ON vehicle
1. Accelerator pedal position sensor EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Line pressure test AT-51 3. Control valve assembly
AT-221 OFF vehicle
4. High clutch
AT-301 5. Brake band
AT-330Too sharp a shock in
changing from D 3 to
D 4 . ON vehicle
1. Accelerator pedal position sensor EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Line pressure test AT-51 3. Control valve assembly
AT-221 OFF vehicle
4. Brake band
AT-330 5. Overrun clutch
AT-306 6. Forward one-way clutch
AT-317Gear change shock
during deceleration by
releasing accelerator
pedal. ON vehicle1. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Line pressure test AT-51 3. Overrun clutch solenoid valve
AT-149 4. Control valve assembly
AT-221Large shock in chang-
ing from 1 2 to 1 1 in
“1” position. ON vehicle 1. Control valve assembly
AT-221OFF vehicle 2. Low & reverse brake
AT-313Items Symptom Condition Diagnostic item Reference page

(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 3. Shift solenoid valve A
AT-139 4. Shift solenoid valve B
AT-144Gear change directly
from D 1 to D 3 occurs. ON vehicle
1. A/T fluid level
AT-17 2. Accumulator servo release
AT-221 OFF vehicle 3. Brake band
AT-330Too high a change
point from D 4 to D 3 ,
from D 3 to D 2 , from
D 2 to D 1 . ON vehicle
1. Accelerator pedal position sensor EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 Kickdown does not
operate when de-
pressing accelerator
pedal in D 4 within
kickdown vehicle
speed. ON vehicle1. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 3. Shift solenoid valve A
AT-139 4. Shift solenoid valve B
AT-144Kickdown operates or
engine overruns when
depressing accelera-
tor pedal in D 4 be-
yond kickdown
vehicle speed limit. ON vehicle1. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Shift solenoid valve A AT-139 4. Shift solenoid valve B
AT-144Gear change from 2
2
to 2 3 in “2” position. ON vehicle1. PNP switch adjustment
AT-224 2. Control cable adjustment
AT-216Gear change from 1
1
to 1 2 in “1” position. ON vehicle1. PNP switch adjustment
AT-224 2. Control cable adjustment
AT-216Items Symptom Condition Diagnostic item Reference page

AT
N
O P
No Down Shift Failure to change
gear from D 4 to D 3 . ON vehicle 1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Overrun clutch solenoid valve AT-149 4. Shift solenoid valve A
AT-139 5. Line pressure solenoid valve
AT-134 6. Control valve assembly
AT-221 OFF vehicle
7. Brake band
AT-330 8. Overrun clutch
AT-306Failure to change
gear from D 3 to D 2 or
from D 4 to D 2 . ON vehicle 1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Shift solenoid valve A AT-139 4. Shift solenoid valve B
AT-144 5. Control valve assembly
AT-221 OFF vehicle
6. High clutch
AT-301 7. Brake band
AT-330Failure to change
gear from D 2 to D 1 or
from D 3 to D 1 . ON vehicle 1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Shift solenoid valve A AT-139 4. Shift solenoid valve B
AT-144 5. Control valve assembly
AT-221 OFF vehicle
6. Low one-way clutch
AT-256 7. High clutch
AT-301 8. Brake band
AT-330Failure to change
from D 3 to 2 2 when
shifting selector lever
into “2” position.
AT-199 ON vehicle
1. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. Shift solenoid valve B AT-144 3. Control valve assembly
AT-221 4. Control cable adjustment
AT-216 OFF vehicle 5. Brake band
AT-330Does not change from
1 2 to 1 1 in 1st posi-
tion. ON vehicle1. PNP switch adjustment
AT-224 2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 3. Shift solenoid valve A
AT-139 4. Control valve assembly
AT-221 5. Overrun clutch solenoid valve
AT-149 OFF vehicle
6. Overrun clutch
AT-306Items Symptom Condition Diagnostic item Reference page

2. Shift solenoid valve A
AT-139 3. Control valve assembly
AT-221 4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 5. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
OFF vehicle 6. Brake band AT-330Failure to change
gear from D 2 to D 3 . ON vehicle 1. Control cable adjustment
AT-216 2. Shift solenoid valve B
AT-144 3. Control valve assembly
AT-221 4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 5. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
OFF vehicle 6. High clutch
AT-301 7. Brake band
AT-330Failure to change
gear from D 3 to D 4 . ON vehicle 1. PNP switch adjustment
AT-224 2. Overdrive control switch
AT-172 3. Control cable adjustment
AT-216 4. Shift solenoid valve A
AT-139 5. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 6. A/T fluid temperature sensor
AT-96 OFF vehicle 7. Brake band
AT-330A/T does not shift to
D 4 when driving with
OD ON. (OD OFF in-
dicator lamp is off.) ON vehicle1. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
2. PNP switch adjustment AT-224 3. Overdrive control switch
AT-172 4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 5. Shift solenoid valve A
AT-139 6. Overrun clutch solenoid valve
AT-149 7. Control valve assembly
AT-221 8. A/T fluid temperature sensor
AT-96 9. Line pressure solenoid valve
AT-134 OFF vehicle
10. Brake band
AT-330 11. Overrun clutch
AT-306Items Symptom Condition Diagnostic item Reference page

AT
N
O P
Slips/Will Not Engage
Vehicle will not run in
“R” position (but runs
in “D”, “2” and “1” po-
sitions). Clutch slips.
Very poor accelera-
tion. ON vehicle
1. Control cable adjustment
AT-216 2. Stall test
AT-51 3. Line pressure test
AT-51 4. Line pressure solenoid valve
AT-134 5. Control valve assembly
AT-221 OFF vehicle
6. Reverse clutch
AT-296 7. High clutch
AT-301 8. Forward clutch
AT-306 9. Overrun clutch
AT-306 10. Low & reverse brake
AT-313Vehicle will not run in
“D” and “2” positions
(but runs in “1” and
“R” positions). ON vehicle 1. Control cable adjustment
AT-216OFF vehicle 2. Low one-way clutch
AT-256Vehicle will not run in
“D”, “1”, “2” positions
(but runs in R posi-
tion). Clutch slips.
Very poor accelera-
tion. ON vehicle
1. A/T fluid level
AT-17 2. Stall test
AT-51 3. Line pressure test
AT-51 4. Line pressure solenoid valve
AT-134 5. Control valve assembly
AT-221 6. Accumulator N-D
AT-221 OFF vehicle
7. Reverse clutch
AT-296 8. High clutch
AT-301 9. Forward clutch
AT-306 10. Forward one-way clutch
AT-317 11. Low one-way clutch
AT-256Clutches or brakes
slip somewhat in start-
ing. ON vehicle1. A/T fluid level
AT-17 2. Control cable adjustment
AT-216 3. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
4. Line pressure test AT-51 5. Line pressure solenoid valve
AT-134 6. Control valve assembly
AT-221 7. Accumulator N-D
AT-221 OFF vehicle
8. Forward clutch
AT-306 9. Reverse clutch
AT-296 10. Low & reverse brake
AT-313 11. Oil pump
AT-277 12. Torque converter
AT-256Items Symptom Condition Diagnostic item Reference page

,
AT-187 ON vehicle
1. A/T fluid level
AT-17 2. Line pressure test
AT-51 3. Control valve assembly
AT-221 OFF vehicle
4. Forward clutch
AT-306 5. Oil pump
AT-277 6. Torque converter
AT-256Almost no shock or
clutches slipping in
change from D 1 to D 2
. ON vehicle1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Line pressure test AT-51 4. Accumulator servo release
AT-221 5. Control valve assembly
AT-221 OFF vehicle 6. Brake band
AT-330Almost no shock or
slipping in changing
from D 2 to D 3 . ON vehicle 1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Line pressure test AT-51 4. Control valve assembly
AT-221 OFF vehicle
5. High clutch
AT-301 6. Forward clutch
AT-306Almost no shock or
slipping in changing
from D 3 to D 4 . ON vehicle 1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Line pressure test AT-51 4. Control valve assembly
AT-221 OFF vehicle 5. Brake band
AT-330Races extremely fast
or slips in changing
from D 4 to D 3 when
depressing accelera-
tor pedal. ON vehicle1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Line pressure test AT-51 4. Line pressure solenoid valve
AT-134 5. Shift solenoid valve A
AT-139 6. Control valve assembly
AT-221 OFF vehicle
7. Brake band
AT-330 8. Forward clutch
AT-306Races extremel y
ON hi l 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
Items Symptom Condition Diagnostic item Reference page

AT
N
O P
Slips/Will Not Engage
Races extremely fast
or slips in changing
from D 3 to D 2 when
depressing accelera-
tor pedal. ON vehicle1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Line pressure test AT-51 4. Line pressure solenoid valve
AT-134 5. Shift solenoid valve B
AT-144 6. Control valve assembly
AT-221 OFF vehicle
7. Brake band
AT-330 8. High clutch
AT-301Races extremely fast
or slips in changing
from D 4 or D 3 to D 1
when depressing ac-
celerator pedal. ON vehicle1. A/T fluid level
AT-17 2. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
3. Line pressure test AT-51 4. Line pressure solenoid valve
AT-134 5. Shift solenoid valve A
AT-139 6. Shift solenoid valve B
AT-144 7. Control valve assembly
AT-221 OFF vehicle
8. Forward clutch
AT-306 9. Forward one-way clutch
AT-317 10. Low one-way clutch
AT-256Vehicle will not run in
any position. ON vehicle
1. A/T fluid level
AT-17 2. Control cable adjustment
AT-216 3. Line pressure test
AT-51 4. Line pressure solenoid valve
AT-134 OFF vehicle
5. Oil pump
AT-277 6. High clutch
AT-301 7. Brake band
AT-330 8. Low & reverse brake
AT-313 9. Torque converter
AT-256 10. Parking components
AT-236Items Symptom Condition Diagnostic item Reference page

ON vehicle
1. Ignition switch and starter
PG-3 ,
SC-9 2. Control cable adjustment
AT-216 3. PNP switch adjustment
AT-224Engine starts in posi-
tions other than “P”
and “N”. ON vehicle
1. Control cable adjustment
AT-216 2. PNP switch adjustment
AT-224Transaxle noise in“ P”
and “N” positions. ON vehicle1. A/T fluid level
AT-17 2. Line pressure test
AT-51 3. Accelerator pedal position sensor
EC-412
(HR16DE), EC- 959 (MR Type 1)
or EC-1481 (MR
Type 2)
4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTR AT-101 ,
AT-154 OFF vehicle
5. Oil pump
AT-277 6. Torque converter
AT-256Items Symptom Condition Diagnostic item Reference page

AT
N
O P
Others Vehicle moves when
changing into “P” po-
sition or parking gear
does not disengage
when shifted out of “P”
position. ON vehicle 1. Control cable adjustment
AT-216OFF vehicle 2. Parking components
AT-236Vehicle runs in “N” po-
sition.
AT-184 ON vehicle 1. Control cable adjustment
AT-216OFF vehicle
2. Forward clutch
AT-306 3. Reverse clutch
AT-296 4. Overrun clutch
AT-306Vehicle braked when
shifting into “R” posi-
tion. ON vehicle
1. A/T fluid level
AT-17 2. Control cable adjustment
AT-216 3. Line pressure test
AT-51 4. Line pressure solenoid valve
AT-134 5. Control valve assembly
AT-221 OFF vehicle
6. High clutch
AT-301 7. Brake band
AT-330 8. Forward clutch
AT-306 9. Overrun clutch
AT-306Excessive creep. ON vehicle 1. Engine idling speed
EC-30
(HR16DE), EC- 570 (MR Type 1)
or EC-1082 (MR
Type 2)
Engine stops when
shifting lever into “R”,
“D”, “2” and “1” posi-
tions. ON vehicle
1. Engine idling speed
EC-30
(HR16DE), EC- 570 (MR Type 1)
or EC-1082 (MR
Type 2)
2. A/T fluid level AT-17 3. Torque converter clutch solenoid valve
AT-124 4. Control valve assembly
AT-221 OFF vehicle 5. Torque converter
AT-256Vehicle braked by
gear change from D 1
to D 2 . ON vehicle 1. A/T fluid level
AT-17OFF vehicle
2. Reverse clutch
AT-296 3. Low & reverse brake
AT-313 4. High clutch
AT-301 5. Low one-way clutch
AT-256Vehicle braked by
gear change from D 2
to D 3 . ON vehicle 1. A/T fluid level
AT-17OFF vehicle 2. Brake band
AT-330Vehicle braked by
gear change from D 3
to D 4 . ON vehicle 1. A/T fluid level
AT-17OFF vehicle
2. Overrun clutch
AT-306 3. Forward one-way clutch
AT-317 4. Reverse clutch
AT-296Items Symptom Condition Diagnostic item Reference page
