NISSAN X-TRAIL 2003 Service Repair Manual

AT-5
D
E
F
G
H
I
J
K
L
MA
B
AT
SERVICE DATA AND SPECIFICATIONS (SDS) .... 530
General Specifications ......................................... 530
Shift Schedule ...................................................... 530
Stall Revolution .................................................... 531
Line Pressure ....................................................... 531
Control Valves ...................................................... 531
Accumulator ......................................................... 532
Clutch and Brakes ................................................ 533
Final Drive ............................................................ 535
Planetary Carrier and Oil Pump ........................... 536
Input Shaft ............................................................ 537
Reduction Pinion Gear ......................................... 537Band Servo ...........................................................538
Output Shaft .........................................................538
Bearing Retainer ...................................................538
Total End Play .......................................................538
Reverse Clutch End Play ......................................539
Removal and Installation ......................................539
Shift Solenoid Valves ............................................539
Solenoid Valves ....................................................539
A/T Fluid Temperature Sensor ..............................540
Revolution Sensor ................................................540
Dropping Resistor .................................................540

AT-6
TROUBLE DIAGNOSIS — INDEX

TROUBLE DIAGNOSIS — INDEXPFP:00000
Alphabetical & P No. Index for DTCECS003VK
ALPHABETICAL INDEX FOR DTC
NOTE:

Check if the vehicle is a model with Euro-OBD system or not by the “Type approval number” on
the identification plate. Refer to GI-44, "
IDENTIFICATION PLATE".

If DTC “U1000” is displayed with other DTC, first perform the trouble diagnosis for “DTC U1000
CAN COMMUNICATION LINE”. Refer to AT- 9 7 , "
DTC U1000 CAN COMMUNICATION LINE" .

*1: These numbers are prescribed by SAE J2012.Type approval number Model
Available With Euro-OBD system
Not available (blank) Without Euro-OBD system
Items
(CONSULT-II screen terms)DTC
Reference page
CONSULT-II
GST*1
A/T 1ST GR FNCTN P0731AT-125
A/T 2ND GR FNCTN P0732AT-130
A/T 3RD GR FNCTN P0733AT-135
A/T 4TH GR FNCTN P0734AT-140
ATF TEMP SEN/CIRC P0710AT-106
BATT/FLUID TEMP SEN —AT-184
CAN COMM CIRCUIT U1000AT- 9 7
CONTROL UNIT (RAM) —AT-198
CONTROL UNIT (ROM) —AT-198
CONT UNIT (EEP ROM) —AT-200
ENGINE SPEED SIG P0725AT- 11 9
INITIAL START — —
LINE PRESSURE S/V P0745AT-154
OVERRUN CLUTCH S/V P1760AT-178
PNP SW/CIRC P0705AT-100
SHIFT SOLENOID/V A P0750AT-161
SHIFT SOLENOID/V B P0755AT-167
T/C CLUTCH SOL/V P0740AT-148
THROTTLE POSI SEN P1705AT-173
VHCL SPEED SEN·A/T P0720AT- 11 2
VHCL SPEED SEN·MTR —AT-192

TROUBLE DIAGNOSIS — INDEX
AT-7
D
E
F
G
H
I
J
K
L
MA
B
AT

P NO. INDEX FOR DTC
NOTE:

Check if the vehicle is a model with Euro-OBD system or not by the “Type approval number” on
the identification plate. Refer to GI-44, "
IDENTIFICATION PLATE" .

If DTC “U1000” is displayed with other DTC, first perform the trouble diagnosis for “DTC U1000
CAN COMMUNICATION LINE”. Refer to AT- 9 7 , "
DTC U1000 CAN COMMUNICATION LINE" .

*1: These numbers are prescribed by SAE J2012.Type approval number Model
Available With Euro-OBD system
Not available (blank) Without Euro-OBD system
DTC
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*1
P0705 PNP SW/CIRCAT- 1 0 0
P0710 ATF TEMP SEN/CIRCAT- 1 0 6
P0720 VHCL SPEED SEN·A/TAT- 11 2
P0725 ENGINE SPEED SIGAT- 11 9
P0731 A/T 1ST GR FNCTNAT- 1 2 5
P0732 A/T 2ND GR FNCTNAT- 1 3 0
P0733 A/T 3RD GR FNCTNAT- 1 3 5
P0734 A/T 4TH GR FNCTNAT- 1 4 0
P0740 T/C CLUTCH SOL/VAT- 1 4 8
P0745 LINE PRESSURE S/VAT- 1 5 4
P0750 SHIFT SOLENOID/V AAT- 1 6 1
P0755 SHIFT SOLENOID/V BAT- 1 6 7
P1705 THROTTLE POSI SENAT- 1 7 3
P1760 OVERRUN CLUTCH S/VAT- 1 7 8
U1000 CAN COMM CIRCUITAT- 9 7
— BATT/FLUID TEMP SENAT- 1 8 4
— CONTROL UNIT (RAM)AT- 1 9 8
— CONTROL UNIT (ROM)AT- 1 9 8
— CONT UNIT (EEP ROM)AT- 2 0 0
— INITIAL START —
— VHCL SPEED SEN·MTRAT- 1 9 2

AT-8
PRECAUTIONS

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
ECS004Q0
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for On Board Diagnostic (EURO-OBD) System of A/T and Engine —
Euro-OBD —
ECS004Q1
The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:

Be sure to turn the ignition switch “OFF” and disconnect the negative battery terminal before any
repair or inspection work. The open/short circuit of related switches, sensors, solenoid valves,
etc. will cause the MIL to light up.

Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to light up due to an open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)

Be sure to route and secure the harnesses properly after work. Interference of the harness with a
bracket, etc. may cause the MIL to light up due to a short circuit.

Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to a malfunction of the EGR system or fuel injection system, etc.

Be sure to erase the unnecessary malfunction information (repairs completed) from the TCM and
ECM before returning the vehicle to the customer.
Precautions for Trouble DiagnosisECS004VN
CAN SYSTEM

Do not apply voltage of 7.0V or higher to the measurement terminals.

Use the tester with its open terminal voltage being 7.0V or less.
Precautions for Harness RepairECS004VO
CAN SYSTEM

Solder the repaired parts, and wrap with tape. [Frays of twisted
line must be within 110 mm (4.33 in)]
PKIA0306E

PRECAUTIONS
AT-9
D
E
F
G
H
I
J
K
L
MA
B
AT


Do not perform bypass wire connections for the repair
parts.(The spliced wire will become separated and the charac-
teristics of twisted line will be lost.)
PrecautionsECS004Q2

Before connecting or disconnecting the TCM harness con-
nector, turn ignition switch OFF and disconnect battery
negative cable from battery negative terminal. Failure to do
so may damage the TCM. Because battery voltage is
applied to TCM even if ignition switch is turned off.

When connecting or disconnecting pin connectors into or
from TCM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on TCM
pin terminal, when connecting pin connectors.

Before replacing TCM, perform TCM input/output signal
inspection and make sure whether TCM functions properly
or not. (See page AT- 9 4 , "
TCM Terminals and Reference
Val ue".)
PKIA0307E
SEF289H
AAT470A
MEF040DA

AT-10
PRECAUTIONS


After performing each TROUBLE DIAGNOSIS, perform
“DTC (Diagnostic Trouble Code) CONFIRMATION PROCE-
DURE”.
The DTC should not be displayed in the “DTC Confirmation
Procedure” if the repair is completed.

Before proceeding with disassembly, thoroughly clean the out-
side of the transaxle. It is important to prevent the internal parts
from becoming contaminated by dirt or other foreign matter.

Disassembly should be done in a clean work area.

Use lint-free cloth or towels for wiping parts clean. Common
shop rags can leave fibers that could interfere with the operation
of the transaxle.

Place disassembled parts in order for easier and proper assembly.

All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or
reassembly.

Gaskets, seals and O-rings should be replaced any time the transaxle is disassembled.

It is very important to perform functional tests whenever they are indicated.

The valve body contains precision parts and requires extreme care when parts are removed and serviced.
Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent
springs and small parts from becoming scattered or lost.

Properly installed valves, sleeves, plugs, etc. will slide along bores in valve body under their own weight.

Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings
and seals, or hold bearings and washers in place during assembly. Do not use grease.

Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.

After overhaul, refill the transaxle with new ATF.

When the A/T drain plug is removed, only some of the fluid is drained. Old A/T fluid will remain in torque
converter and ATF cooling system.
Always follow the procedures under “Changing A/T Fluid” in the AT section when changing A/T fluid. Refer
to “Changing A/T Fluid”, AT- 1 6 , "
A/T FLUID" .
Service Notice or PrecautionsECS004Q3
FAIL -SAF E
The TCM has an electronic Fail-Safe (limp home mode). This allows the vehicle to be driven even if a major
electrical input/output device circuit is damaged.
Under Fail-Safe, the vehicle always runs in third gear, even with a shift lever position of “1”, “2” or “D”. The cus-
tomer may complain of sluggish or poor acceleration.
When the ignition key is turned “ON” following Fail-Safe operation, O/D OFF indicator lamp blinks for about 8
seconds. Refer to AT- 2 4 6 , "
SELF-DIAGNOSTIC PROCEDURE (WITHOUT CONSULT-II)" (EXCEPT FOR
EURO-OBD) or AT- 5 2 , "
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)" (EURO-OBD).
The blinking of the O/D OFF indicator lamp for about 8 seconds will appear only once and be cleared. The
customer may resume normal driving conditions.
Always follow the “WORK FLOW”, refer to AT- 2 5 5 , "
Work Flow" (EXCEPT FOR Euro-OBD) or AT- 6 1 , "Work
Flow" (Euro-OBD).
The SELF-DIAGNOSIS results will be as follows:

The first SELF-DIAGNOSIS will indicate damage to the vehicle speed sensor or the revolution sensor.

During the next SELF-DIAGNOSIS, performed after checking the sensor, no damages will be indicated.
TORQUE CONVERTER SERVICE
The torque converter should be replaced under any of the following conditions:

External leaks in the hub weld area.

Converter hub is scored or damaged.

Converter pilot is broken, damaged or fits poorly into crankshaft.

Steel particles are found after flushing the cooler and cooler lines.

Pump is damaged or steel particles are found in the converter.

Vehicle has TCC shudder and/or no TCC apply. Replace only after all hydraulic and electrical diagnoses
have been made. (Converter clutch material may be glazed.)
SAT652J

PRECAUTIONS
AT-11
D
E
F
G
H
I
J
K
L
MA
B
AT


Converter is contaminated with engine coolant containing antifreeze.

Internal failure of stator roller clutch.

Heavy clutch debris due to overheating (blue converter).

Steel particles or clutch lining material found in fluid filter or on magnet when no internal parts in unit are
worn or damaged — indicates that lining material came from converter.
The torque converter should not be replaced if:

The fluid has an odor, is discolored, and there is no evidence of metal or clutch facing particles.

The threads in one or more of the converter bolt holes are damaged.

Transaxle failure did not display evidence of damaged or worn internal parts, steel particles or clutch plate
lining material in unit and inside the fluid filter.

Vehicle has been exposed to high mileage (only). The exception may be where the torque converter
clutch dampener plate lining has seen excess wear by vehicles operated in heavy and/or constant traffic,
such as taxi, delivery or police use.
EURO-OBD SELF-DIAGNOSIS — EURO-OBD —

A/T self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through
the blinking pattern of the O/D OFF indicator lamp or the malfunction indicator lamp (MIL). Refer to the
table on AT- 4 5 , "
SELF-DIAGNOSTIC RESULT TEST MODE" for the indicator used to display each self-
diagnostic result.

The self-diagnostic results indicated by the MIL are automatically stored in both the ECM and TCM mem-
ories.
Always perform the procedure “HOW TO ERASE DTC” on AT- 4 2 , "
HOW TO ERASE DTC" to com-
plete the repair and avoid unnecessary blinking of the MIL.

The following self-diagnostic items can be detected using ECM self-diagnostic results mode* only when
the O/D OFF indicator lamp does not indicate any malfunctions.
–PNP switch
–A/T 1st, 2nd, 3rd, or 4th gear function
*: For details of EURO-OBD, refer to EC-51, "
ON BOARD DIAGNOSTIC (OBD) SYSTEM" .

Certain systems and components, especially those related to EURO-OBD, may use a new style
slide-locking type harness connector.
For description and how to disconnect, refer to PG-70, "
HARNESS CONNECTOR" .
Wiring Diagrams and Trouble DiagnosisECS004Q4
When you read wiring diagrams, refer to the following:

GI-14, "How to Read Wiring Diagrams"

PG-2, "POWER SUPPLY ROUTING"
When you perform trouble diagnosis, refer to the following:

GI-10, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES"

GI-23, "How to Perform Efficient Diagnosis for an Electrical Incident"

AT-12
PREPARATION

PREPARATIONPFP:00100
Special Service ToolsECS004Q5
Tool number
Tool nameDescription
KV381054S0
Puller

Removing differential side oil seals

Removing differential side bearing outer race

Removing idler gear bearing outer race
a: 250 mm (9.84 in)
b: 160 mm (6.30 in)
ST33400001
Drift

Installing LH differential side oil seal

Installing oil seal on oil pump housing
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.
KV40100621
DriftInstalling RH differential side oil seal
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.
ST2505S001
Oil pressure gauge set
1. ST25051001 Oil pressure
gauge
2. ST25052000 Hose
3. ST25053000 Joint pipe
4. ST25054000 Adapter
5. ST25055000 Adapter

Measuring line pressure
ST27180001
Puller

Removing idler gear
a: 100 mm (3.94 in)
b: 110 mm (4.33 in)
c: M8 x 1.25P
ST23540000
Pin punch

Removing and installing parking rod plate and
manual plate pins
a: 2.3 mm (0.091 in) dia.
b: 4 mm (0.16 in) dia.
NT414
NT086
NT086
NT097
NT424
NT442

PREPARATION
AT-13
D
E
F
G
H
I
J
K
L
MA
B
AT

ST25710000
Pin punch
Aligning groove of manual shaft and hole of
transmission case
a: 2 mm (0.08 in) dia.
KV32101000
Pin punch

Removing and installing manual shaft retaining pin

Removing and installing pinion mate shaft lock pin
a: 4 mm (0.16 in) dia.
KV31102400
Clutch spring compressor

Removing and installing clutch return springs

Installing low and reverse brake piston
a: 320 mm (12.60 in)
b: 174 mm (6.85 in)
KV40100630
Drift

Installing reduction gear bearing inner race

Installing idler gear bearing inner race
a: 67.5 mm (2.657 in) dia.
b: 44 mm (1.73 in) dia.
c: 38.5 mm (1.516 in) dia.
ST30720000
Bearing installer

Installing idler gear bearing outer race
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.
ST35321000
Drift

Installing output shaft bearing
a: 49 mm (1.93 in) dia.
b: 41 mm (1.61 in) dia.
ST33230000
Drift

Installing differential side bearing inner race
a: 51 mm (2.01 in) dia.
b: 28.5 mm (1.122 in) dia. Tool number
Tool nameDescription
NT410
NT410
NT423
NT107
NT115
NT073
NT084

AT-14
PREPARATION

ST33220000
Drift
Selecting differential side bearing adjusting shim
a: 37 mm (1.46 in) dia.
b: 31 mm (1.22 in) dia.
c: 22 mm (0.87 in) dia.
ST3306S001
Differential side bearing
puller set
1. ST33051001 Puller
2. ST33061000 Adapter

Removing differential side bearing inner race
a: 38 mm (1.50 in) dia.
b: 28.5 mm (1.122 in) dia.
c: 130 mm (5.12 in)
d: 135 mm (5.31 in)
e: 100 mm (3.94 in)
ST3127S000
Preload gauge
1. GG9103000 Torque
wrench
2. HT62900000 Socket
adapter

Checking differential side bearing preload
ST35271000
Drift

Installing idler gear

Installing differential side bearing inner race
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.
KV38107700
Preload adapter

Selecting differential side bearing adjusting shim

Checking differential side bearing preload
KV38105210
Preload adapter

Selecting differential side bearing adjusting shim

Checking differential side bearing preload Tool number
Tool nameDescription
NT085
AMT153
NT124
NT115
NT087
NT075
